Gossen MetraWatt SMARTCONTROL ECS User manual

Installation Instructions
SMARTCONTROL | ECS
Energy Management System
Installation of I/O24 Expansion Module
3-349-595-03
3/5.19

2GMC-I Messtechnik GmbH
1. Prerequisites
The I/O24 expansion set can only be installed if a basic PCB from
revision level 2.3x onwards is available, see encircled marking in
the picture below.

GMC-I Messtechnik GmbH 3
2. Installation
The installation accessories which come with the standard
equipment consist of four 20 mm hexagonal distance sleeves and
a 10 cm flat ribbon cable.
Disconnect the SMARTCONTROL from the mains system.
Ground persons and tools before starting the installation
work.
Remove the bottom four M3 screws and replace them by the
four distance sleeves.

4GMC-I Messtechnik GmbH
Place the I/O24 interface onto the distance sleeves and
establish a screw connection with the four M3 screws.
Connect the expansion slots with the flat ribbon cable.
The connection of the input/output terminals and further
configuration with the Software SMARTCONTROL Manager is
described in the operating instructions (3-349-552-03), which
you can find on our Homepage.

GMC-I Messtechnik GmbH 5
3 Repair and Replacement Parts Service,
Calibration Center and
Rental Instrument Service
If required please contact:
GMC-I Service GmbH
Service-Center
Beuthener Str. 41
90471 Nuremberg, Germany
Phone: [phone]
Fax: [phone]
e-mail: [email protected]
www.gmci-service.com
This address is only valid in Germany. Please contact our
representatives or subsidiaries for service in other countries.
4 Product Support Industry
If required please contact:
GMC-I Messtechnik GmbH
Product Support Hotline Industry
Phone: [phone]
Fax: [phone]
e-mail [email protected]

6GMC-I Messtechnik GmbH
