GPM BEDPALWHT User manual

GLOBAL PROCUREMENT AND MARKETING LIMITED
1
PALERMO UNDER TRUNDLE BED
Assembly Instructions –Please keep for future reference
BEDPALWHT
Dimensions
No. people
Assembly Time
OW #
Width: 90 cm
30 mins (approx.)
BEDPALWHT
Length: 185 cm
Height: 38 cm

2
Important –Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please email [e-mail]
Safety and Care Advice
Important –Please read these instructions fully before starting assembly
•Check you have all the
components, parts, hardware
and tools listed on pages 3 &
4.
•Remove all fittings from the
plastic bags and separate
them into their groups.
•Keep children and animals
away from the work area,
small parts could choke if
swallowed.
•Make sure you have enough
space to lay out the parts
before starting.
•Do not stand or put weight on
the product, this could cause
damage.
•Assemble the item as close to
its final position (in the same
room) as possible.
•Assemble on a soft, level
surface to avoid damaging the
unit or your floor.
•We do not recommend the
use of power
drill/drivers for
inserting screws,
as this could
damage the unit.
Only use hand screwdrivers.
•Dispose of all packaging
carefully and responsibly.
Care and Maintenance
•Only clean using a damp cloth and
mild detergent, do not use bleach or
abrasive cleaners.
•From time to time check that there
are no loose screws on this unit.
•This product should not be
discarded with household waste.
Take to your local authority waste
disposal centre.
If you are unhappy with the product and wish to return it,
please follow the retailer’s returns procedure.

3
Components –Part List
please check that you have all the components listed below before constructing your item.
Description
Qty
A
SIDE RAIL
2
B
CENTRE SUPPORT RAIL
1
C
CENTRE CROSS RAIL
2
D
FOLDING LEG
2
E
END RAIL
2
F
SPRUNG WOOD SLAT
12
G
WHEEL
4
If you have damaged or missing components,
email: [e-mail]

4
Please check that you have all the hardware & tools listed below before constructing your item.
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
1
Bolt M6 x 12mm
X4
2
Bolt M8 x 35mm
X10
3
Bolt M6 x 10mm
X2
4
M8 X 50mm
X4
5
Nut M6
X2
6
Nut M8
X 4
7
Plastic Slat Cap
X24
Tools Required
Allen Key M4 Allen Key M5 Spanner M4 Spanner M5
Scale Ruler –Use this to measure your screws (mm) ( Actual Ruler Not Provided )

5
Assembly Instructions
Important –Please read these instructions fully before starting assembly
If you have damaged or missing components,
email: [e-mail]

6
