GPM ROB2DRAVO User manual

GLOBAL PROCUREMENT AND MARKETING LIMITED
2 Door Wardrobe
Assembly Instructions - Please keep for future reference
No. people Assembly Time SKU #
ROB2DRAVO
Dimensions
Width: 79.5cm
Depth: 49.5cm
Height: 180cm
75 mins
(approx.)
1
For purchasing this
GPM Limited
product
ROB2DRAVO
180cm
79.5cm
49.5cm
If you need help or have damaged or missing parts, please email [email protected]
PLEASE READ THESE INSTRUCTIONS FULLY BEFORE STARTING ASSEMBLY
PLEASE DO NOT THROW THE PACKAGING AWAY UNTIL YOU ARE SATISFIED WITH PURCHASE,
GOODS NEED TO BE RETURNED IN ORIGINAL PACKAGING.
Important

Check you have all the
components and tools listed
on pages 4 and 5.
Remove all fittings from the
plastic bags and separate
them into their groups.
Keep children and animals
away from the work area,
small parts could choke if
swallowed.
Make sure you have enough
space to lay out the parts
before starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close to
its final position (in the same
room) as possible.
Assemble on a soft, level
surface to avoid damaging the
unit or your floor.
We do not recommend the
use of power
drill/drivers for
inserting screws,
as this could
damage the unit.
Only use hand screwdrivers.
Dispose of all packaging
carefully and responsibly.
Safety and Care Advice
Warnings
·Place heaviest items in the lowest drawers.
·Useless specifically designed to accommodate, do not set TVs
or other heavy objects on top of this product.
·Never allow children to climb or hang on drawers, doors or
shelves.
·Never open more than one drawer at a time.
·Do not defeat or remove the drawer interlock system.
·Use of tip-over restraints may only reduce, but not eliminate,
the risk of tip-over.
CHILD SAFETY
ANCHOR AND PROTECT A CHILD
Use of anti-tip kit is required
CLIMBING MAY RESULT IN SERIOUS INJURY
If you are unhappy with the product and wish to return it,
please follow the retailer's returns procedure.
2
Care and Maintenance
Only clean using a damp cloth and
mild detergent, do not use bleach or
abrasive cleaners.
From time to time check that there
are no loose screws on this unit.
This product should not be discarded
with household waste. Take to your
local authority waste disposal centre.
If kept outside please ensure in the winter months that the product is correctly covered or put away into a dry
environment to prevent corrosion, weathering or damage.
If your product is not designed to be outside, we recommend that it is always kept indoors in a dry environment.
Important
PLEASE READ THESE INSTRUCTIONS FULLY BEFORE STARTING ASSEMBLY
PLEASE DO NOT THROW THE PACKAGING AWAY UNTIL YOU ARE SATISFIED WITH PURCHASE,
GOODS NEED TO BE RETURNED IN ORIGINAL PACKAGING.

Exploded View If you have damaged or missing components,
email: [email protected]
3
1
2
3
5
4
6
8
7
9
10
10

Components - Fixings
(A)
Tools Required
Ruler - Use this to measure your screws (mm)
Important - Please read these instructions fully before starting assembly
(B) (C) (D)
(E) (F) (G) (H)
(J) (K) (L)
(M) (N) (O) (P)
(Q)
(I)
Please check that you have all the components listed below before constructing your item.
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
0
If you have damaged or missing components,
email: [email protected]
4
18pcs 18pcs 14pcs
2pcs
1pc
2pcs
2pcs 1pc 2pcs
6pcs 2pcs 2pcs
5pcs
5pcs
40pcs 2pcs
20pcs
