GPX D190B User manual

For the most up-to-date version of this User’s Guide, go to www.gpx.com
D190B
DVD Player
USER’S GUIDE
V:1327-0504-10

GPX | D190B2
12. Use only with a cart, stand, tripod, bracket, or table specied by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has
been dropped.
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
• WARNING: To reduce the risk of re or electric shock, do not expose this
apparatus to rain or moisture.
• AveRtIssemeNt: Pour réduire le risque d’incendie ou de choc électrique,
ne pas exposer cet appareil sous la pluie et l’humidité.
• CAUtION: Use of controls or adjustments or performance of procedures other
than those specied may result in hazardous radiation exposure.
• WARNING: Changes or modications to this unit not expressly approved by
the party responsible for compliance could void the user’s authority to operate
the equipment.
• WARNING: Do not place the unit on top of any soft, porous, or sensitive
surfaces to avoid damaging the surface. Use a protective barrier between the
unit and surface to protect the surface.
• WARNING: Use of this unit near uorescent lighting may cause interference
regarding use of the remote. If the unit is displaying erratic behavior move away
from any uorescent lighting, as it may be the cause.
• CAUtION: Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type.
• PRÉCAUTION: Danger d’explosion si les piles sont remplacées de façon
incorrect. Remplacer les piles seulement par le même type de pile ou
l’équivalent.
• WARNING: There is a danger of explosion if you attempt to charge standard
Alkaline batteries in the unit. Only use rechargeable NiMH batteries.
• WARNING: The remote control’s button cell battery contains mercury. Do not
put in the trash, instead recycle or dispose of as hazardous waste
• WARNING: Lithium batteries, like all rechargeable batteries are recyclable and
should be recycled or disposed of in normal household waste. Contact your local
government for disposal or recycling practices in your area. They should never
be incinerated since they might explode.
Main plug is used as disconnect device and it should remain readily operable
during intended use.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh,
etc) batteries.
No mezcle baterías viejas y nuevas.
No mezcle baterías alcalinas, estándar (carbono-zinc) o recargables (ni-cad,
ni-mh, etc.).
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding
- type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. When the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
This product utilizes a Class 1 laser to read
Compact Discs. This laser Compact Disc Player is
equipped with safety switches to avoid exposure
when the CD door is open and the safety interlocks
are defeated. Invisible laser radiation is present
when the CD Player’s lid is open and the system’s
interlock has failed or been defeated. It is very
important that you avoid direct exposure to the
laser beam at all times. Please do not attempt to
defeat or bypass the safety switches.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
The lightning ash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of
sufcient magnitude to constitute a risk of electric
shock to persons.
WARNING: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
Warnings and Precautions
imPortant safety instructions
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

CUstOmeR HeLPLINe | 1-314-621-2881 GPX | D190B 3
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equip-
ment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or televi-
sion reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
• The apparatus shall not be exposed to dripping or splashing and
that no objects lled with liquids, such as vases, shall be placed
on apparatus.
L’appareil ne doit pas être exposé aux écoulements ou aux
éclaboussures et aucun objet ne contenant de liquide, tel qu’un
vase, ne doit être placé sur l’objet.
• Main plug is used as disconnect device and it should remain
readily operable during intended use. In order to disconnect the
apparatus from the mains completely, the mains plug should be
disconnected form the mains socket outlet completely.
La prise du secteur ne doit pas être obstruée ou doit être
facilement accessible pendant son utilisation. Pour être
complètement déconnecté de l’alimentation d’entrée, la prise doit
être débranchée du secteur.
• Battery shall not be exposed to excessive heat such as sunshine,
re or the like.
Les piles ne doivent pas être exposées à de forte chaleur, tel qu’à
la lumière du soleil, au feu ou autres choses de semblable.
• Caution marking is located at the rear of the apparatus.
Les marquages sont inscrits de derrière de l’appareil.
• The marking information is located at the rear of apparatus.
Les précautions d’emploi sont inscrites de derrière de l’appareil.
• This symbol indicates that this product incorporates double
insulation between hazardous mains voltage and user accessible
parts.
fcc Warnings
additional Warnings

GPX | D190B4
• Supports: DVD+/-R/RW, CD-R/RW, JPEG CD
• Progressive scan
• Component video output
• Coaxial digital audio output
• Composite video output
• Stereo audio output
• Remote control
• Multi-language on-screen display
• Aspect ratio: 16:9, 4:3
• NTSC
• AC power: attached AC power cable
dVd Player
features
• D190B
• Remote control, requires 2 AAA batteries (not included)
• RCA audio/video cable
• Warranty card
• User’s guide
included

CUstOmeR HeLPLINe | 1-314-621-2881 GPX | D190B 5
6
introduction
8
setuP
10
Playing a disc
12
comPany information
9
adVanced setuP
11
dVd setuP menu
taBle of contents

GPX | D190B6
introduction
120V ~ 60Hz
Pb/CbY Pr/Cr
AUDIO OUT DIGITAL
VIDEO
RL COAXIAL
VIDEO OUT
DVD / CD PLAYER
POWER
disc draWer
comPonent Video
outPut
stereo audio
outPuts
comPosite Video
outPut
coaXial digital audio
outPut
oPen/close
Press to open or close
the DISC DRAWER.
Play/Pause
Press to play or pause a
loaded disc.
stoP
Press to stop a loaded
disc during play.
PoWer indicator
PoWer
Press to power the DVD
player o or on.

CUstOmeR HeLPLINe | 1-314-621-2881 GPX | D190B 7
mute
Press to mute the volume.
oPen/close
Press to open or close the
DISC DRAWER.
numBer KeyPad
title
Press to access the title
menu on a loaded DVD.
menu
Press to access the main
menu on a loaded DVD.
direction/enter
Press to navigate and make
selections on on-screen
menus.
searcH
Press to search forwards
or backwards through a
loaded disc.
Volume
Press to adjust the volume.
Wide
Press to adjust the aspect
ratio.
osd
Press to view the on-screen
display.
stoP
Press to stop a disc during
play.
n/P
Press to switch between
NTSC and PAL.
l/r
Press to adjust the audio
mode of a supported DVD.
Prog
Press to program a loaded
disc to play chapters or
tracks in a specied order.
Video
Press to switch between
the COMPONENT and
COMPOSITE VIDEO
OUTPUTS.
PoWer
Press to power the DVD
player o or on.
goto
Press and use the on-screen
display to go to a specied
track, chapter, or time on a
loaded disc.
suBtitle
Press to switch between
available subtitle modes.
angle
Press to adjust the viewing
angle on supported DVDs.
audio
Press to switch between
available audio modes.
setuP
Press to access the setup
menu.
sKiP
Press to skip forwards
or backwards through a
loaded disc.
Play/Pause
Press to play or pause a
loaded disc.
Zoom
Press to zoom in or out on a
playing DVD.
sloW
Press to view the loaded
DVD in slow motion.
rePeat
Press to repeat the current
chapter or track or an entire
disc.
steP
Press repeatedly to view
the loaded DVD one frame
at a time.
a-B
Use to create a repeating
loop on a loaded DVD.
CUstOmeR HeLPLINe | 1-314-621-2881 GPX | D190B 7

GPX | D190B8
Plug the attached AC cord into
a standard AC power outlet to
power the home theater system.
Requires 2 AAA size batteries
(not included)
setuP
PoWer
remote
comPosite Video
120V ~ 60Hz
Pb/Cb
Y
Pr/Cr
AUDIO OUT DIGITAL
VIDEO
R
L
COAXIAL
VIDEO OUT
120V ~ 60Hz
Pb/CbY Pr/Cr
AUDIO OUT DIGITAL
VIDEO
RL COAXIAL
VIDEO OUT
teleVision
1PlugtheincludedRCAaudio/
videocableintotheCOMPOSITE
VIDEO OUTPUT (yellow)onthe
DVDplayerandthecomposite
videoinput(yellow)ona
television.
2Plugtheremainingplugsonthe
includedRCAaudio/videocable
intotheRCA STEREO AUDIO
OUTPUTS (redandwhite)onthe
DVDplayerandtheRCAstereo
audioinputs(redandwhite)ona
television.
3Adjustthetelevision’sinputsetting
tocorrespondtotheinputsused
whenconnectingtheDVDplayer.
STEREO
AUDIO
INPUTS
COMPOSITE
VIDEO
INPUT

CUstOmeR HeLPLINe | 1-314-621-2881 GPX | D190B 9
adVanced setuP
comPonent Video
digital audio
120V ~ 60Hz
Pb/CbY Pr/Cr
AUDIO OUT DIGITAL
VIDEO
RL COAXIAL
VIDEO OUT
120V ~ 60Hz
Pb/CbY Pr/Cr
AUDIO OUT DIGITAL
VIDEO
RL COAXIAL
VIDEO OUT
stereo system
teleVision Requiresacomponentvideocable
(notincluded).
1Plugacomponentvideocable
intotheCOMPONENT VIDEO
OUTPUTS (green,blue,red)
ontheDVDplayerandthe
componentvideoinput(green,
blue,red)onatelevision.
2PlugtheincludedRCAaudio/
videocableintotheRCA STEREO
AUDIO OUTPUTS (redandwhite)
ontheDVDplayerandtheRCA
stereoaudioinputs(redand
white)onatelevision.
3Adjustthetelevision’sinputsetting
tocorrespondtotheinputsused
whenconnectingtheDVDplayer.
Requiresacoaxialdigitalaudio
cable(notincluded).
1Plugacoaxialdigitalaudiocable
intotheCOAXIALDIGITAL
AUDIO OUTPUT ontheDVD
playerandthecoaxialdigitalaudio
inputonatelevisionorstereo
system.
2Adjustthetelevisionorstereo
system’sinputsettingto
correspondtotheinputused
whenconnectingtheDVDplayer.
DIGITAL AUDIO INPUT
COMPONENT VIDEO INPUT

GPX | D190B10
Playing a disc
Playing tHe dVd or cd Playing a JPeg disc
Programming a dVd or cd
1ConnecttheDVDplayertoa
televisionandpressthePOWER
buttontoturntheDVDplayeron.
2PresstheOPEN/CLOSEbuttonto
opentheDISC DRAWER.
3LoadadiscintotheDISC
DRAWER,labelsidefacingup,
andpresstheOPEN/CLOSE
buttontoclosetheDISC
DRAWER.
4Theloadeddiscwillbeginplaying
automatically.Ifitdoesnot,press
thePLAY/PAUSEbutton.
1LoadaJPEGdiscintotheDISC
DRAWER.
2AslideshowofJPEGphotos
fromtheCDwillbeginplaying
automatically.
3PresstheSTOPbuttontoaccess
afileviewoftheloadedJPEG
disc.
4UsetheDIRECTION/ENTER
buttonsontheremotetoselect
andviewphotos.
1Followtheinstructionsfor“Playing
aDVDorCD”.
2PressthePROGbuttononthe
remote.
3PresstheDIRECTION buttonsto
highlighttheblanksundertitle,
chapter,ortrack.
4UsetheNUMBER KEYPADon
theremotetoenterinthetitle,
chapter,ortracknumberyouwish
toprogram.
5Highlightandpresstheon-screen
PLAYbuttonusingtheENTER
button.
6Tocanceltheprogram,highlight
theon-screenCLEARPROGRAM
buttonandpresstheENTER
buttonontheremote.

CUstOmeR HeLPLINe | 1-314-621-2881 GPX | D190B 11
dVd setuP menu
accessing tHe setuP menu
setuP menu
1PresstheSETUP buttononthe
remotetoaccesstheDVDsetup
menu.
LANGUAGE
OSDlanguage
Subtitle
Audio
DVDmenu
VIDEO
AspectRatio
TVSystem
VideoOut
SmartPicture
AUDIO
DigitalOutput
NightMode
DownSampling
MISCELLANEOUS
UseDefaultSettings
ScreenSaver

© 2009 Digital Products International (DPI, Inc.) | All other trademarks appearing herein are the property of their respective owners.
Specications are subject to change without notice
To download this User’s Guide in English,
Spanish, or French, visit the support section at
www.gpx.com.
Para transferir esta guía de usuario en inglés,
español, o francés, visite la sección de la ayuda en
www.gpx.com.
Pour télécharger ce guide de l’utilisateur en
anglais, espagnol, ou français, visitez la section de
soutien chez www.gpx.com.
Address: 2116 Carr Street, St. Louis MO, 63106
Phone: [phone]
Fax: [phone]
Email: [email protected]
Parts Email: [email protected]
Website: www.gpx.com
comPany information
international suPPort
contact information
