Graco 25A931 User manual

3A3998C
EN
Installation
Compressor Kit for ToughTek™
F340e Fireproofing Pump
For the installation of a compressor to ToughTek F340e fireproofing systems.
For professional use only.
Kit 25A930 - 120 VAC Compressor Kit
Kit 25A931 - 240 VAC Compressor Kit
Important Safety Instructions
Read all warnings and instructions in the F340e
Operation manual. Save these instructions.
WLD
EE
DD



WLD
E
E
DD 


WLD
Tighten all fasteners one full turn past hand tight.
1
Installation:
1. Remove and discard the toolbox and toolbox mounting bracket.
2. Install two screws (31) into holes (b).
3. Install two nuts (30) onto studs (a).

Models
Models
Compressor and Motor Repair
For 120 V sprayer, use Compressor and Motor Replacement Kit 287315.
For 230 V sprayer, use Compressor and Motor Replacement Kit 287344.
Kits include motor/compressor and mounting hardware.
Disassembly
1. Remove two screws and access the cover on the left
side of the motor.
2. Remove the ground nut and disconnect the green
ground wire.
3. Disconnect the black and white wires to the motor.
4. Disconnect the air line from the compressor to the
cooler and remove the air line.
Models
25A930 100-120 VAC 25A931 230-240 VAC
Max Pressure: 55 psi (3.7 bar, 0.37 MPa) Max Pressure: 55 psi (3.7 bar, 0.37 MPa)
Max Flow: 5 cfm Max Flow: 5 cfm
Current Draw: 15 Amps Current Draw: 8.5 Amps
ti4457a
ti4458a
ti4405a

Models
5. Remove two fasteners and washers.
6. Remove fasteners and washers on the other side of
the motor.
7. Lift out the motor and remove it from the assembly.
8. Thoroughly clean inside housing to remove dust
and debris.
Reassembly
1. Install the motor into the assembly.
2. Install the washers and fasteners on both sides of
the motor.
3. Install the air line and connect the air line from the
compressor to the cooler.
4. Connect the black and white wires to the motor.
5. Install the green ground wire and tighten the ground
nut.
6. Install the cover on the left side of the motor and
tighten two screws.
ti4463a

Compressor Rebuild Kit
Compressor Rebuild Kit
To replace the piston, seals and sleeve.
For 120 V sprayer, use Compressor Rebuild Kit 287330.
For 230 V sprayer, use Compressor Rebuild Kit 287331.
Disassembly
1. Remove the three screws in the side of the motor
cover. Remove the cover.
2. Remove the fan bolt from the center of the fan and
remove the fan from the housing.
3. Remove the 3/8 in. bolt holding the piston to the
motor shaft.
4. Loosen the four bolts on top of the motor housing.
5. Remove the bolts and housing from the motor.
6. Remove the piston rod from the motor.
ti4460a
ti4478a
ti4706a
ti4707a
ti4708a
ti4709a
ti4710a

Compressor Rebuild Kit
Reassembly
1. Insert the new piston rod in the motor housing.
2. Replace and tighten the piston bolt.
3. Replace the top motor housing and four bolts.
Tighten the four bolts.
4. Replace the motor fan and center the fan bolt.
Tighten the fan bolt.
5. Replace the motor cover and screws.
ti4700a
ti4701a
ti4703a
ti4704a
ti4485a

Parts
Parts
Parts List
WLD






 





















 



9$
1
Tighten fittings one full turn past hand-tight.
Ref. Part Description Qty.
1 - - - - - TRAY, weldment, compressor 1
2 24K895 FAN, cooling, 120 V, E10 (Kit 25A930) 2
24K896 FAN, cooling, 240 V (Kit 25A931) 2
3 25E572 COOLER, assembled, F340e 1
4 125871 TIE, cable, 7.50 in. 7
5 17F718 SWITCH, rocker, 2-position 1
6 115836 GUARD, finger 2
7 116171 BUSHING, strain relief 1
8 119381 COVER, terminal 1
9 - - - - - COVER, weldment, compressor 1
10 25E570 COMPRESSOR, air (6 cfm) 120 V (Kit 25A930) 1
25E571 COMPRESSOR, air (8 cfm) 240 V (Kit 25A931) 1
11 17K734 TUBE, compressor 1
12 17K733 TUBE, air, cooler 1
13 117723 SCREW, mach, x rec, panhd 8
14 127278 NUT, keps, hex 8
15 151395 WASHER, flat 8
16 - - - - - SCREW, flge, serrated, 10-24 x 0.5 8
17 115942 NUT, hex, flange head 2
18 110996 NUT, hex, flange head 3
19 17G371 HARNESS, F340E, compressor 1
20 17G372 CORD, 120V, compressor (Kit 25A930) 1
17G373 CORD, 240V, compressor (Kit 25A931) 1
21 17L426 MANIFOLD, F340e, 120V (Kit 25A930) 1
17L427 MANIFOLD, F340e, 230V (Kit 25A931) 1
22 15J075 LABEL, safety, hotsurf & energized 1
24 195551 RETAINER, plug, adapter (Kit 25A931) 1
25 242001 CORD SET, adapter, Europe (Kit 25A931) 1
26 242001 CORD SET, adapter, Europe (Kit 25A931) 1
30 110996 NUT 4
31 111801 SCREW 2
32 113500 ADHESIVE 1
Use compressor rebuild kit 287330 (120 V), or 287331 (230 V)
to replace the piston, seals, and sleeve.
Ref. Part Description Qty.
All written and visual data contained in this document reflects the latest product information available at the time of publication.
Graco reserves the right to make changes at any time without notice.
Original instructions. This manual contains English. MM 3A3998
Graco Headquarters: Minneapolis
International Offices: Belgium, China, Japan, Korea
GRACO INC. AND SUBSIDIARIES • P.O. BOX 1441 • MINNEAPOLIS MN 55440-1441 • USA
Copyright 2016, Graco Inc. All Graco manufacturing locations are registered to ISO 9001.
www.graco.com
Revision C, November 2018
