Graco Tot Wheels Entertainer 4033 User manual

234
© 2000 Graco 308-2-00 308999 5 6
Congratulations on your purchase
of a Graco®Tot Wheels Entertainer®
activity center!
Graco is the recognized leader in the
design and manufacture of quality baby
products. e believe your new Graco®
Tot heels Entertainer®activity center is a
wise choice, promising many hours of
enjoyment for your baby.
Before using your activity center, please
take a few minutes to read this Owners
Manual. The short time you spend reading
these instructions will help you use your
activity center properly.
Customer atisfaction
Our goal is to make every product the best it
can be! e are also committed to supporting our
products after purchase. If you would like to speak
with us about your product, please contact our
Customer Service Department at 1-800-345-4109
or visit our Internet website, www.gracobaby.com.
Our knowledgeable staff will be ready to answer
any questions you may have concerning parts, use
or maintenance. hen you call, please have the
model and serial numbers ready so your call
may be processed quickly and efficiently.
PART LI T
CHECK that you have all the parts listed below
BEFORE assembling your activity center.
If any parts are missing,
call Customer Service at 1-800-345-4109
or visit our Internet website, www.gracobaby.com.
THIS PRODUCT REQUIRES ADULT ASSEMBLY.
Tools required: rench or pliers, screwdriver
Tray
Lets play safe.
Graco®activity centers have been designed with your childs enjoyment in mind. It is your responsibility to ensure your babys safety
by following these guidelines and using simple common sense. Lets work together to keep your baby safe and happy.
Graco is concerned about the safety of every child who uses one of our products. e know that parents and other caregivers
are equally concerned about the safety of their children. There are certain safety precautions which you must always take to
help minimize the risk that a baby using one of our mobile activity centers will be harmed. Specifically, the parent or caregiver in
charge of the baby should always follow these rules.
1. Never leave your baby unattended.
Most accidents happen to children while they are unsupervised. At a minimum, the caregiver should be in the same room with
the baby at all times keeping the baby under a watchful eye. Because a baby can propel a mobile activity center at surprising
speed and is eager to explore all sorts of potential hazards, direct and diligent supervision by the caregiver is required at all
times. If you believe proper supervision of your baby cannot be guaranteed, or that your home presents particular dangers from
which the baby cannot be adequately protected while using our mobile activity center, we suggest that you not use this product
and that you consider instead an activity center without wheels, swing, playard, or other fine Graco®product for your baby.
2. Properly prepare your babys play space  neutralize potential hazards.
Potential hazards in the room must be removed or guarded against before placing a baby in a mobile activity center. Keep in
mind that the mobile activity center gives the baby the ability to move around the play area much more quickly than would
otherwise be possible. That means its important to prepare play space by installing and using gates, removing objects from
reach, and closing doors to keep the baby away from potential hazards, such as:
When to use your Tot Wheels Entertainer activity center
Your baby should be able to sit unaided and be able to
support most of his/her body weight with his/her legs
(about 6 months old).
Both feet should be able to touch the floor.
When NOT to use your Tot Wheels Entertainer activity center
Do not use until your child can sit up alone.
hen your child can walk unaided.
hen your child reaches 30 lbs. in weight.
hen your child has grown over 32 inches in height.
If your activity center has become broken or damaged.
If you havent prepared a safe play space for your baby.
Other things to avoid
Dont lift or carry your baby in the activity center.
Dont adjust the activity center with your baby in it.
Dont use the activity center if it is broken or damaged.
hen you are able to watch your baby at all times while
playing in the activity center.
hen you have prepared your babys play space
according to these guidelines.
If the tray of your activity center is lower than your babys waist
level when your child stands in the activity center.
If you havent blocked access to stairs and steps.
If you havent assembled the activity center according
to these instructions.
Dont use the activity center with your child in it on a
table or countertop.
Keep dangling electrical cords out of babys reach, such as
an iron on an ironing board, lamp cords, etc.
Stairs
Steps
Raised thresholds
Driveways and sidewalks
Ramps or inclines
Decks
Ranges, heaters, fireplaces, hot
liquids and other heat sources
Blind or drape cords
Objects on tables
Dangling electrical cords or small appliances
Pots and pans on stoves
Books on shelves
Bathtubs or open toilets
Swimming pools or other containers filled with liquid
Any other dangers unique to your environment
Only your commitment to safety can give your child the safe, happy playtime you desire.
TAIR HAZARD:
Avoid serious injury or death.
Block stairs/steps securely before
using walker.
Avoid falls and other hazards. Never allow walker
to be pushed while child is in it.
Never leave child unattended. Always keep child
in view while in walker.
Use only on flat surfaces free of objects that could
cause the walker to tip over.
To avoid burns, keep your child away from hot
liquids, ranges, radiators, space heaters,
fireplaces, etc.
To reduce the chance of your child slipping out of
the seat, check that both of your childs feet touch
the floor.
Never carry the product with the child in it.
Discontinue using the walker should it become
damaged or broken.
Read all instructions before assembly and use of
this product.
Keep instructions for future use.
Seat
Pin (2)
Seat back
Parking
stands (3)
Base
OWNER MANUAL
Tot Wheels Entertainer
Activity Center
®
Model 4033
Model No.
erial No.
Dear Customer,
Please fill in the
model and serial
numbers above
from the label
on the underside
of the tray.
To Assemble the Tray
tep 1.
Insert front of seat back into
two slots on top of tray as
shown.
tep 2.
Lower seat back so that
fingers at rear of back snap
into the two slots at rear
of tray.
CHECK that seat back is
firmly attached by pulling
upward on back. It should
not come loose.
To Attach the eat
tep 1.
Place seat onto tray assembly
as shown. Put pocket of seat
over seat back, and place leg
holes into center area of tray.
tep 2.
Tuck edges of seat into
channel in tray.
tep 3.
From underside of tray, pull
grommets through holes at
bottom of tray and hook them
onto pegs as shown. Be sure
all eight grommets are hooked
onto pegs.
Do not hook grommets on
the flat tabs opposite the
pegs.
To Attach the Base
tep 1.
Place base on floor with
wheels down.
tep 2.
Open tubes of tray assembly
until they latch as shown.
tep 3.
Front tube has plastic T
ends. Tilt tray assembly as
shown. Insert one plastic T
into slot on the inside front
of the base. Repeat on
opposite side, flexing tube
inward if needed to engage
the slot.
tep 4.
Lower rear tube so holes in
ends of tube line up with
two holes in back of activity
center base.
Be sure that plastic T
pieces remain in their slots.
tep 5.
Insert pin into hole on tab
side of base hole, through
tray tube, and out through
base hole on the other side
as shown. Press firmly until
tab snaps over head of pin.
Repeat on other side.
Be sure all parts of tray
and base are securely
fastened, with T pieces
in their slots and tabs
holding pins firmly.
Push
Head
of pin Tab holds
pin
