Graco Swivi Seat User manual

Swivi Seat™ 3-in-1 Booster
©2015 Graco NWL00505508A 9/30
使用說明書 User Manual

2
孩童用餐椅
Toddler Booster
本產品可以下列模式使用：
This product can be used in the following modes:
新生兒模式
Infant Recline
嬰幼兒餐椅
Feeding Booster
固定於椅座
attached to chair

3
若不遵守這些警告和安裝說明可能導致嚴重傷害或死亡。
‧請妥善收存使用手冊以供
日後使用。
‧為了您孩子的安全，請於
使用產品前詳細閱讀警告
標示和使用手冊。
‧每次使用前請檢查本產品
是否出現硬體損壞、接頭
鬆動、缺少零件或邊緣鋒
利之情況。
‧若零部件缺少或損壞時，
請勿使用本產品。
‧請勿自行替換零件。
‧摔倒危險：切勿於孩童乘
坐時移動或拉高座椅。
‧需由成人組裝。
‧切勿讓孩童離開視線，使
用本產品時，請勿讓孩子
離開視線。
‧為防止因滑出、掉落或翻
倒所造成之嚴重傷害或死
亡，請務必使用安全帶，
隨時於傾斜或垂直時以產
品所附之固定系統保護您
的孩子，餐盤並非用來將
孩子固定於本產品中，建
議於孩童無需協助即可自
己坐好時方使用本產品的坐
‧切勿讓孩子自行從桌旁推開。
‧切勿將餐盤強壓向孩童，
請使用兩個調整位置，請
確認兩個調整齒輪皆固定
於於扶手槽內。
‧窒息的危險：請勿將產品
置於具繩索，如窗簾繩、
窗簾、電話線等之任何區
域附近。
‧請依照裝設說明謹慎操作
，若遇到任何困難，請致
電客服中心請參閱封底。
‧若產品出現任何損壞或斷
裂，請停止使用本產品。
‧請勿於機動車上使用本產
品，以防止造成嚴重傷害
或死亡。
‧請勿於孩童乘坐時調整產
品靠背傾斜度。
‧將本產品固定於椅座上時
，請務必使用固定帶並確
保固定帶緊緊拉住。
‧若本產品無法安全且牢牢
固定於該成人座椅，請勿
於該椅子使用本產品。
‧本產品適用於歲以下及體
重公斤（磅）以下
之孩童。
‧本產品僅可使用
™之附件。
警 告
立模式。

4
若不遵守這些警告和安裝說明可能導致嚴重傷害或死亡。
‧在孩童能自行乘坐餐椅前（約
2歲半左右），在任何時候皆
應以約束系統將孩童固定於餐
椅上，餐盤並非使用於將孩子
固定於餐椅上。
‧請勿將本產品使用於凳子、旋
轉椅、折疊椅或任何其他本產
品無法牢固使用之椅子，建議
使用具有四腳、高靠背及具堅
固座位之椅子。
‧建議於新生兒頸部安定前（約
4個月左右）將座椅角度調整
至躺臥模式進行使用。
警 告

5
Failure to follow these warnings and the
assembly instructions could result in serious injury or death.
•PLEASE SAVE THIS BOOK FOR
FUTURE USE.
•FOR YOUR CHILD’S SAFETY,
read the labels and the owner’s
manual before using product.
•BEFORE EACH USE. Inspect the
toddler booster for damaged
hardware, loose joints, missing parts,
or sharp edges.
•DO NOT USE toddler booster if any
parts are missing or broken.
•DO NOT substitute parts.
•FALL HAZARD Never move or lift
booster seat with child in it.
•ADULT ASSEMBLY REQUIRED.
•NEVER LEAVE CHILD UNAT-
TENDED. Always keep your child in
view in product.
•PREVENT SERIOUS INJURY OR
DEATH FROM SLIDING OUT,
FALLS, OR TIPPING OVER.
Always use seat belt. Secure your
child at all times with the restraint
system provided, either in the reclining
or upright position. The tray is not
designed to hold your child in the
product. It is recommended that the
product be used in the upright position
only by children capable of sitting
upright unassisted.
•NEVER allow a child to push away
from table.
•DO NOT FORCE TRAY against
child. Use only the two adjustment
positions. Be sure both adjustment
fingers are engaged in armrest slots.
•STRANGULATION HAZARD: Do
not place product in any location
where there are cords, such as window
blind cords, drapes, phone cords, etc.
•FOLLOW ASSEMBLY INSTRUC-
TIONS CAREFULLY. If you
experience any difficulties, please
contact the Customer Service Depart-
ment.
•DISCONTINUE USING YOUR
TODDLER BOOSTER should it
become damaged or broken.
•PREVENT SERIOUS INJURY OR
DEATH. Do not use in motor vehicles.
•DO NOT ADJUST the recline of
product with your child in it.
•ALWAYS USE booster straps to
attach feeding booster seat to any
chair. Always ensure straps are pulled
tightly.
•IF FEEDING BOOSTER SEAT
CANNOT be securely and safely
attached to the adult chair, do not use
feeding booster seat with that chair.
•THIS FEEDING BOOSTER SEAT
is designed to be used by a child up to
5 years of age and up to 50 lbs
(22.7kg).
•USE ONLY Swivi Seat™ toddler
booster accessories with this product.

6
•ALWAYS SECURE CHILD IN
THE RESTRAINT UNTIL CHILD
IS ABLE to get in and out of the
feeding booster without help (about 2
1/2 years old), the child should be
secured in the feeding booster seat at
all times by the restraining system.
The tray is not designed to hold the
child in the chair.
•DO NOT USE the booster on a stool,
swivel chair, folding chair or any other
type of chair to which this booster
cannot be firmly attached. The
recommended type of chair shall be
with four legs, a high backrest, and a
firm seat.
•Use the fully recline position
until infant can hold up head without
help (about 4 months old).
Failure to follow these warnings and the
assembly instructions could result in serious injury or death.

各部位名稱
Parts list
7
不同型號可能不包括下圖所示之配件，安裝前請檢查所有零
件，若有缺少、弄錯或者破損時，請與經銷商或者總公司連
絡。（請參閱封底「產品保證書」）
This model may not include some features shown below.
Check that you have all the parts for this model BEFORE
assembling your product. If any parts are missing, call
Customer Service.
所有型號
ALL MODELS
限定型號
CERTAIN MODELS

1
輔助靠背
Backrest
8
將輔助靠背安裝於餐椅上
Insert seat back guides into seat base.

9
將輔助靠背向後翻壓至固定卡槽內
Rotate seat back until it attaches to base.
2
喀擦!
SNAP!

3
4
2
1
座椅保護套
Seat Pad
10
將安全腰帶由座椅保護套導孔中
穿出
Pull waist straps through open-
ings in seat pad.
將座椅保護套由座椅上方套入
Wrap seat pad over the top of the
infant seat.
如圖所示，將座椅保護套固定於
座椅前側
Secure seat pad to front of infant
seat as shown.
將安全肩帶及安全股帶由座椅保
護套導孔中穿出
Pull shoulder straps and crotch
strap through openings in seat
pad.

新生兒守護墊
Body Support
11
1
3
2
如圖所示，將新生兒保護墊固定
於座椅上
Place body support on top of the
seat pad.
將安全肩帶及安全股帶由新生兒
保護墊導孔中穿出
Pull shoulder straps and crotch
strap through openings in body
support.
將安全腰帶由新生兒保護墊導孔
中穿出
Pull waist straps through open-
ings in body support.

2
餐盤的使用方式
To Use Tray
12
1
喀擦!
SNAP!
按壓餐盤兩側之固定扣，將餐
盤卡進座椅側邊之餐盤卡榫內
Squeeze release levers on
each side of tray, slide tray
on seat, and snap into side
tray locks.
不使用時，請按下餐盤前方之
按鈕
To release push button on
front of tray.
不使用時，請按壓餐盤兩側之
固定扣並將餐盤滑出
To release squeeze release
levers on each side of tray
and slide off.
或or

2
上層餐盤
Tray Cover
13
1
喀擦!
SNAP!
將上層餐盤向下推至餐盤處來
安裝固定
Attach tray cover by pushing
it down on the tray.
可使用洗碗機 Dishwasher safe.
不使用時，請由餐盤後方拉起
To remove pull up on the
back of the tray.

1
2
調整座椅角度
To Recline Seat
14
警告：
WARNING
按壓座位前側之按鈕並向下推
或拉來調整座椅角度
Press button on front of seat
and push down or pull up to
adjust.
孩童乘坐時請勿調整座椅角度。
當座椅處於躺臥模式時，請務必移除餐盤。
DO NOT adjust the seat recline with the
child in it. Tray must be removed when the
seat is in the fully reclined position.
可4階段調整座椅角度
There are 4 recline positions.
座椅處於躺臥模式時，請務必
移除餐盤
Tray must be removed when
the seat is in the reclined
position.

1
將座椅兩側的把手向欲旋轉座
椅的方向拉
Locate one of the handles on
the side of the booster and
pull towards the direction you
want to rotate the seat.
2
旋轉座椅
To Recline Seat
15
警告：
WARNING
孩童乘坐時請勿旋轉座椅。
DO NOT adjust the seat with the child in it.
可旋轉3方向
There are 3 positions.

1 4
5
2
3
安全固定裝置
To Secure Child
5點式安全帶5 Point Harness
16
警告：
WARNING
跌落危險：請務必使用安全帶。
Falling Hazard：Always use the seat belt.
移動安全帶環扣來調整安
全帶鬆緊
Use slide adjuster at
shoulder and waist for
tighter adjustment.

6
7
10
8
9
17
3點式安全帶 3 Point Buckle
移動安全腰帶環扣來調整
安全帶鬆緊
Use slide adjuster at
waist for further adjust-
ment.
轉換為3點式安全帶
To convert to 3-pt harness

11 需改變安全帶導孔位置時
，請確認座椅保護套和椅
背的肩部安全帶導孔位置
相同
安全帶必須穿進導孔中，
甚至與肩同高或略高於肩
膀，請避免安全帶扭曲變
形
When changing harness
strap slots, MAKE SURE
harness straps are going
through same slots in
seat pad and seat back.
The harness straps must
go into slot that is even
with or slightly above the
shoulders. Avoid twisting
straps.
18

1
2
孩童用餐椅的使用方式
Using as Toddler Booster
19
解開椅座及椅背之卡榫。
Disconnect seat back from
base.
自椅座上移除椅背及座椅保
護套。
Remove seat back and
pad from seat base.

1
將本產品固定於椅子上
Attaching booster seat to chair
20
將本產品下方翻轉至正面
操作。
Turn infant/toddler
feeding booster seat
over.
解開固定扣。
Unfasten clips.
