Graco 224342 A Series User manual

308116V
EN
Instructions
Stainless Steel Pumps
Severe-Duty, UHMWPE/PTFE or PTFE Packed
For transferring or dispensing low viscosity sealants and adhesives. For professional use
only.
Important Safety Instructions
Read all warnings and instructions in this
manual before using the equipment.
Save these instructions.
0195
Model 224342 Shown

2 308116V
Contents
Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Typical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Air and Fluid Hoses . . . . . . . . . . . . . . . . . . . . . . . 8
Air Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Fluid Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Flush Before Using Equipment . . . . . . . . . . . . . . 8
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Pressure Relief Procedure . . . . . . . . . . . . . . . . . . 9
Flush the Equipment . . . . . . . . . . . . . . . . . . . . . . 9
Packing Nut . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Start and Adjust the Pump . . . . . . . . . . . . . . . . 10
Shutdown and Care for the Pump . . . . . . . . . . . 11
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Disconnect the Displacement Pump . . . . . . . . . 13
Connect the Displacement Pump . . . . . . . . . . . 13
Disassemble the Displacement Pump . . . . . . . . 15
Assemble the Displacement Pump . . . . . . . . . . 15
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Model 224342 . . . . . . . . . . . . . . . . . . . . . . . . . . 18
10:1 Ratio President Pump . . . . . . . . . . . . . . . . 18
Models 261630, 224343 (shown) . . . . . . . . . . . . 19
5:1 Ratio Monark Pump . . . . . . . . . . . . . . . . . . . 19
Models 247147, 902147 (shown) . . . . . . . . . . . . 20
5:1 Ratio Monark Pump . . . . . . . . . . . . . . . . . . . 20
Model 254999, 224341 (shown) . . . . . . . . . . . . . 21
Severe-Duty, UHMWPE/PTFE Packed Stainless
Steel Displacement Pump . . . . . . . . . . . . . . 21
Model 15G976 . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Severe-Duty, PTFE Packed Stainless Steel
Displacement Pump. . . . . . . . . . . . . . . . . . . 23
Performance Charts . . . . . . . . . . . . . . . . . . . . . . . . 25
10:1 President . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5:1 Monark . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Mounting Hole Layout . . . . . . . . . . . . . . . . . . . . . . 26
Technical Specifications . . . . . . . . . . . . . . . . . . . . 27
California Proposition 65 . . . . . . . . . . . . . . . . . . . . 27
Graco Standard Warranty. . . . . . . . . . . . . . . . . . . . 28
Related Manuals
Manual in
English Description
306982 President Air Motors
307043 Monark Air Motors

Models
308116V 3
Models
UHMWPE/PTFE Packed Pumps
Model 224342, Series A
10:1 Ratio President® Pump
1800 psi (13 MPa, 125 bar) Maximum Fluid Working Pressure
180 psi (1.3 MPa, 12.5 bar) Maximum Air Input Pressure
Model 224343, Series A
5:1 Ratio Monark® Pump
1800 psi (13 MPa, 125 bar) Maximum Fluid Working Pressure
180 psi (1.3 MPa, 12.5 bar) Maximum Air Input Pressure
UHMWPE/PTFE Packed Pumps
Model 261630, Series A
PTFE PACKED PUMPS
Model 247147, Series A
Model 902147, Series A
5:1 Ratio Monark Pump
600 psi (4.2 MPa, 42 bar) Maximum Fluid Working Pressure
120 psi (0.8 MPa, 8.4 bar) Maximum Air Input Pressure
Severe-Duty Displacement Pumps have an abrasion-resistant displacement rod and cylinder. Refer to Technical
Specifications, page 27, for Wetted Parts information.
Ex II 2 G Ex h IIC T3 Gb
Ex II 2 G Ex h IIC T3 Gb

Warnings
4 308116V
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The
exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks.
When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings.
Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this
manual where applicable.
WARNING
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system
component. See Technical Specifications in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical
Specifications in all equipment manuals. Read fluid and solvent manufacturer’s warnings. For
complete information about your material, request Safety Data Sheets (SDSs) from distributor or
retailer.
• Do not leave the work area while equipment is energized or under pressure.
• Turn off all equipment and follow the Pressure Relief Procedure when equipment is not in use.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine
manufacturer’s replacement parts only.
• Do not alter or modify equipment. Alterations or modifications may void agency approvals and create
safety hazards.
• Make sure all equipment is rated and approved for the environment in which you are using it.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
SKIN INJECTION HAZARD
High-pressure fluid from gun, hose leaks, or ruptured components will pierce skin. This may look like
just a cut, but it is a serious injury that can result in amputation. Get immediate surgical treatment.
• Do not spray without tip guard and trigger guard installed.
• Engage trigger lock when not spraying.
• Do not point gun at anyone or at any part of the body.
• Do not put your hand over the spray tip.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Follow the Pressure Relief Procedure when you stop spraying and before cleaning, checking, or
servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses and couplings daily. Replace worn or damaged parts immediately.

Warnings
308116V 5
MOVING PARTS HAZARD
Moving parts can pinch, cut or amputate fingers and other body parts.
• Keep clear of moving parts.
• Do not operate equipment with protective guards or covers removed.
• Equipment can start without warning. Before checking, moving, or servicing equipment, follow the
Pressure Relief Procedure and disconnect all power sources.
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. Paint or solvent
flowing through the equipment can cause static sparking. To help prevent fire and explosion:
• Use equipment only in well-ventilated area.
• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop
cloths (potential static sparking).
• Ground all equipment in the work area. See Grounding instructions.
• Never spray or flush solvent at high pressure.
• Keep work area free of debris, including solvent, rags and gasoline.
• Do not plug or unplug power cords, or turn power or light switches on or off when flammable fumes
are present.
• Use only grounded hoses.
• Hold gun firmly to side of grounded pail when triggering into pail. Do not use pail liners unless they
are anti-static or conductive.
•Stop operation immediately if static sparking occurs or you feel a shock. Do not use equipment until
you identify and correct the problem.
• Keep a working fire extinguisher in the work area.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or
swallowed.
• Read Safety Data Sheets (SDSs) to know the specific hazards of the fluids you are using.
• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury, including
eye injury, hearing loss, inhalation of toxic fumes, and burns. Protective equipment includes but is not
limited to:
• Protective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and solvent manufacturer.
WARNING

Typical Installation
6 308116V
Typical Installation
Key:
A Pump
B Pump Runaway Valve
C Air Line Lubricator
D Bleed--Type Master Air Valve (required, for pump)
E Pump Air Regulator
F Air Line Filter
G Bleed--Type Master Air Valve (for accessories)
H Electrically Conductive Air Supply Line
J Fluid Drain Valve (required)
K Fluid Filter
L Fluid Supply Hose
M Spray Gun
N Fluid Suction Hose
P Wall Bracket
Y Ground Wire (required; see page 6 for installation
instructions)
FIG. 1: Typical Installation
0774A
YH
A
P
N
J
K
CD
BEFG
M
L

Installation
308116V 7
Installation
NOTE: Reference numbers and letters in parentheses
in the text refer to the callouts in the figures and the
parts drawing.
If you supply your own accessories, be sure they are
adequately sized and pressure--rated to meet the
system’s requirements.
The Accessories shown on page 8 is only a guide for
selecting and installing system components and
accessories. Contact your Graco distributor for
assistance in designing a system to suit your particular
needs.
Grounding
Pump: use ground wire and clamp (supplied). Loosen
grounding lug locknut (W) and washer. Insert ground
wire end (Y) into lug (Z) slot and tighten locknut
securely. Connect ground clamp to a true earth ground.
Air and fluid hoses: use only electrically conductive
hoses. Check electrical resistance of hoses. If total
resistance to ground exceeds 29 megohms, replace
hose immediately.
Air compressor: follow manufacturer’s
recommendations.
Spray gun: ground through connection to a properly
grounded fluid hose and pump.
Fluid supply container: follow local code.
Object being sprayed: follow local code.
Solvent pails used when flushing: follow local code.
Use only conductive metal pails, placed on a grounded
surface. Do not place the pail on a nonconductive
surface, such as paper or cardboard, which interrupts
grounding continuity.
To maintain grounding continuity when flushing or
relieving pressure: hold metal part of the spray
gun/dispense valve firmly to the side of a grounded
metal pail, then trigger the gun/valve.
Mounting
Mount the pump to suit the type of installation planned.
The pump Dimensions and Mounting Hole Layout are
shown on page 26.
If the pump is immersed, be sure the pump intake is 1/2
in. (13 mm) off the bottom of the fluid container.
If the pump is mounted on the wall or on a stand,
connect a suction line to the pump’s 3/4 in. npt(f) fluid
inlet and place the other end of the line in the fluid
container.
The equipment must be grounded to reduce the risk
of static sparking. Static sparking can cause fumes
to ignite or explode. Grounding provides an escape
wire for the electric current.
Y
Z
X
W

Accessories
8 308116V
Accessories
Install the following accessories in the order shown in
Operation, page 9, using adapters as necessary.
Air and Fluid Hoses
Be sure all air and fluid hoses are properly sized and
pressure--rated for your system. Use only conductive
air and fluid hoses. Fluid hoses must have spring
guards on both ends.
Connect a conductive fluid hose (L) to the pump’s fluid
outlet. See FIG. 1: Typical Installation on page 6.
Connect a fluid suction hose (N) to the pump’s 3/4
npt(f) fluid intake.
Use a conductive 1/2 in. I.D. (minimum) air hose (H) to
supply air to the pump.
Air Line
•Bleed-type master air valve (D): required in your
system to relieve air trapped between it and the air
motor when the valve is closed.
NOTE: Be sure the valve is easily accessible from
the pump and located downstream from the air
regulator.
•Pump runaway valve (B): senses when the pump
is running too fast and automatically shuts off the
air to the motor. A pump which runs too fast can be
seriously damaged.
•Air line lubricator (C): provides automatic air
motor lubrication.
•Pump air regulator (E): to control pump speed and
outlet pressure. Locate it close to the pump.
•Air line filter (F): removes harmful dirt and moisture
from compressed air supply.
•Second bleed-type air valve (G): isolates air line
accessories for servicing. Locate upstream from all
other air line accessories.
Fluid Line
•Fluid filter (K): filters particles from the fluid as it
leaves the pump.
•Fluid drain valve (J): required in your system, to
relieve fluid pressure in the hose and gun
•Gun (M): to dispense fluid.
Flush Before Using Equipment
The equipment was tested with lightweight oil, which is
left in the fluid passages to protect parts. To avoid
contaminating your fluid with oil, flush the equipment
with a compatible solvent before using the equipment.
See Flush the Equipment.
If the pump is being used to supply a circulating
system, allow the solvent to circulate until the pump is
thoroughly flushed.
Trapped air can cause the pump to cycle
unexpectedly which could result in serious injury
from moving parts or splashing. A bleed--type
master air valve (D) is required in your system to
relieve trapped air between the valve and the pump
after the air is shut off.
Unrelieved fluid pressure in the system can result in a
skin injection injury. Triggering the gun to relieve
pressure may not be sufficient. A fluid drain valve (J)
is required in your system to help reduce the risk of
serious bodily injury including skin injection operating
or repairing the pump.

Operation
308116V 9
Operation
Pressure Relief Procedure
Follow the Pressure Relief Procedure whenever
you see this symbol.
1. Engage the spray gun (M) trigger lock.
2. Close the bleed-type master air valve (D) to shut off
air supply to pump (A).
3. Disengage the spray gun trigger lock.
4. Hold a metal part of the spray gun (M) firmly to a
grounded metal pail. Trigger the gun to relieve
pressure.
5. Engage the spray gun trigger lock.
6. Open all fluid drain valves in the system, having a
waste container ready to catch drainage. Leave
drain valve(s) open until you are ready to spray
again.
7. If you suspect the spray tip or hose is clogged or
that pressure has not been fully relieved:
a. VERY SLOWLY loosen the tip guard retaining
nut or the hose end coupling to relieve pressure
gradually.
b. Loosen the nut or the coupling completely.
c. Clear the obstruction in the hose or tip.
Flush the Equipment
• Flush before changing colors, before fluid can dry
in the equipment, at the end of the day, before
storing, and before repairing equipment.
• Flush at the lowest pressure possible. Check
connectors for leaks and tighten as necessary.
• Flush with a fluid that is compatible with the fluid
being dispensed and the equipment wetted parts.
1. Perform Pressure Relief Procedure.
2. Remove spray tip and soak in solvent.
3. Hold a metal part of the spray gun (M) firmly to a
grounded metal pail.
4. Set pump (A) to lowest possible fluid pressure, and
start pump.
5. Trigger the spray gun until clean solvent dispenses.
6. Perform Pressure Relief Procedure.
This equipment stays pressurized until pressure is
manually relieved. To help prevent serious injury from
pressurized fluid, such as skin injection, splashing
fluid and moving parts, follow the Pressure Relief
Procedure when you stop spraying and before
cleaning, checking, or servicing the equipment.
To avoid fire and explosion, always ground
equipment and waste container. To avoid static
sparking and injury from splashing, always flush at
the lowest possible pressure.

Operation
10 308116V
Packing Nut
Keep the packing nut/wet-cup (2) filled with Graco
Throat Seal Liquid (TSL™) or compatible solvent, to
help prolong the packing life. Adjust the packing nut
weekly so it is just tight enough to prevent leakage; do
not overtighten. Always follow the Pressure Relief
Procedure, page 9, before adjusting the packing nut.
Start and Adjust the Pump
1. See the Typical Installation on page 6. Be sure the
air regulator (E) and bleed--type master air valve (D)
are closed.
2. Connect a suction hose (N) to the pump fluid inlet.
3. Hold a metal part of the spray gun (M) firmly to the
side of a grounded metal pail and hold the trigger
open.
4. Open the pump bleed-type master air valve (D).
5. Slowly open the air regulator until the pump starts,
at about 40 psi (0.9 MPa, 2.8 bar).
6. Cycle the pump slowly until all the air is pushed out
and the pump and hoses are fully primed.
7. Release the spray gun trigger and engage the
trigger lock. The pump should stall against pressure
when the trigger is released.
8. Perform the Pressure Relief Procedure, page 9.
9. Install the spray tip in the gun.
10. With the pump and lines primed, and with adequate
air pressure and volume supplied, the pump will
start and stop as you open and close the gun. In a
circulating system, the pump will speed up or slow
down on demand, until the air supply is shut off.
NOTE: If the container is empty and air has been
pumped into the lines, refill the container and prime
the pump and the lines, or flush and leave it filled
with a compatible solvent. Eliminate all air from the
fluid system.
11. Use an adequately sized air regulator (E) to control
the pump speed and the fluid pressure.
Moving parts can pinch or amputate your fingers or
other body parts. When air is supplied to the motor,
the air motor piston (located behind the air motor
plates) moves. Never operate the pump with the air
motor plates removes.
0195
2
Air
Motor
Plate
NOTICE
Do not allow the pump to run dry. It will quickly
accelerate to a high speed, causing damage. If your
pump is running too fast, stop it immediately and
check the fluid supply.
NOTICE
Always use the lowest air pressure necessary to get
the desired results. Higher pressures cause
premature tip and pump wear.

Operation
308116V 11
Shutdown and Care for the
Pump
1. Perform the Pressure Relief Procedure, page 9.
2. Stop the pump at the bottom of its stroke.
NOTICE
If the pump stops at the top of its stroke, then fluid
may dry on the exposed displacement rod and
damage the throat packings.
NOTICE
Always flush the pump before fluid dries on the
displacement rod and causes damage.

Troubleshooting
12 308116V
Troubleshooting
1. Perform Pressure Relief Procedure, page 9,
before checking or repairing the pump.
2. Check all possible problems and causes before
disassembling pump.
* To determine if the fluid hose or gun is obstructed, perform the Pressure Relief Procedure, page 9. Disconnect
the fluid hose and place a container at the pump fluid outlet to catch any fluid. Turn on the air just enough to start
the pump (about 20-40 psi [0.1-0.3 MPa, 1.4-2.8 bar]). If the pump starts when the air is turned on, the obstruction
is in the fluid hose or gun.
Problem Cause Solution
Pump fails to operate. Restricted line or inadequate air supply. Clear; increase air supply.
Insufficient air pressure; closed or
clogged air valves, etc.
Open; clean.
Exhausted fluid supply. Refill; purge all air from pump and fluid
lines.
Damaged air valving mechanism;
stalling.
Service air motor (see Related
Manuals, page 2).
Dried fluid seizure of displacement rod
(13).
Clean, check, or replace throat packings
(5, 24); always stop pump at bottom of
stroke and keep wet cup filled with
compatible solvent.
Pump operates but output is low on
both strokes.
Restricted line or inadequate air supply. Clear; increase air supply.
Insufficient air pressure; closed or
clogged air valves, etc.
Open; clean.
Exhausted fluid supply. Refill; purge all air from pump and fluid
lines.
Clogged fluid line, valves, etc. Clear.*
Packing nut (2) too tight. Loosen (see page 10).
Loose packing nut (2) or worn throat
packings (5, 24).
Tighten packing nut (see page 10);
replace throat packings.
Pump operates but output is low on
downstroke.
Held open or worn intake valve. Clear; service.
Pump operates but output is low on
upstroke.
Held open or worn fluid piston valve or
packings (20, 23).
Clear; service.
Erratic or accelerated operation. Exhausted fluid supply. Refill; purge all air from pump and fluid
lines.
Held open or worn intake valve. Clear; service.
Held open or worn fluid piston valve or
packings (20, 23).
Clear; service.

Repair
308116V 13
Repair
Disconnect the Displacement
Pump
1. Perform Flush the Equipment procedure, page 9.
Stop the pump at the bottom of its stroke.
2. Perform the Pressure Relief Procedure, page 9.
3. Disconnect the air and fluid hoses. Remove the
pump from its mounting.
NOTE: Note the relative position of the pump fluid
outlet (R) to the air motor air inlet (S).
4. Unscrew the tie rod locknuts (102) from the tie rods
(103). Remove the cotter pin (111).
5. Unscrew the displacement rod (13) from the air
motor (108). Carefully pull the displacement pump
(101) off the air motor (108).
6. Inspect the o-ring (110). See FIG. 2, page 14.
NOTE: To service the displacement pump, refer to
Disassemble the Displacement Pump, page 15,
and Assemble the Displacement Pump, 15. To
service the air motor, refer to the separate motor
manual, supplied.-
Connect the Displacement
Pump
1. Lubricate the o-ring (110) and check that it is in
place on the displacement rod (13).
2. Align the pump fluid outlet (R) with the air motor air
inlet (S) as was noted in step 2 under Disconnecting
the Displacement Pump. Position the displacement
pump (101) on the tie rods (103). See FIG. 2, page
14.
3. Screw the locknuts (102) onto the tie rods (103)
loosely.
4. Screw the displacement rod (13) into the shaft of
the air motor (108) until the pin holes in the rod and
shaft align. Install the cotter pin (111).
5. Apply thread sealant to the pump fluid outlet (R)
and the threads of the fluid hose.
6. Mount the pump and reconnect all hoses.
Reconnect the ground wire if it was disconnected
during repair.
7. Tighten the packing nut/wet-cup (2) so it is snug.
Fill the wet-cup with TSL or compatible solvent.
8. Tighten the tie rod locknuts (102):
-Model 224342: Torque to 20-30 ft-lb (27-41
N•m)
-Models 224343, 902147, 247147, 261630:
Torque to 10-15 ft-lb (14-20 N•m).
9. Start the pump and run it at about 40 psi (0.3 MPa,
2.8 bar) air pressure, to ensure proper pump
operation.
10. Check for fluid leakage at the packing nut/wet-cup
(2). Perform the Pressure Relief Procedure,
page 9, before tightening the packing nut/wet-cup.

Repair
14 308116V
FIG. 2
0194
S
108
110
13
111
2
R
101
102
103
1
2
3
Lubricate.
Model 224342: Torque to 20--30 ft-lb (27--41 Nm).
Models 224343, 902147, 247147, 261630: Torque to 10--15 ft-lb (14--20 Nm).
Apply sealant, as required.
2
2
3
1

Repair
308116V 15
Disassemble the Displacement
Pump
NOTE: When disassembling the pump, lay out removed
parts in sequence to ease reassembly. Clean all parts
with a compatible solvent and inspect them for wear or
damage. Refer to Fig 5.
NOTE: Standard Repair Kit 224401 (UHMWPE/PTFE
packings) is available. For the best results, use all the
new parts in the kit. Parts included in the kit are
denoted with one asterisk, for example (3*).
NOTE: Conversion Kit 224889 is available to convert
the pump to all PTFE packings. See page 19 for details.
NOTE: Clean all the parts thoroughly when
disassembling. Check them carefully for damage or
wear, replacing parts as needed.
1. Perform the Disconnect the Displacement Pump
procedure, page 13.
2. Unscrew the locking ring (7) from the cylinder (8).
See Fig FIG. 3. Remove the intake valve housing
(15).
3. Remove the o-ring (12), ball stop pin (6), ball guide
(9) and ball (4) from the intake valve housing (15).
4. Loosen the packing nut (2). Push the displacement
rod (13) down as far as possible, then pull it out the
bottom of the cylinder (8).
5. Secure the flats of the displacement rod (13) in a
vise. Use a wrench on the flats of the piston
mounting stud (28) to screw the piston off the rod.
6. Remove one cotter pin (3) and the ball stop pin (21),
taking note which set of holes it is in. Remove the
ball (4).
7. Place the flats of the piston mounting stud (28) in a
vise, and unscrew the piston stud (26). Remove the
piston packings (20, 23), glands (25, 27), washer
(19), and shims (31).
8. Remove the packing nut (2), throat packings (5, 24),
and glands (11, 14) from the outlet housing (1).
9. Inspect all parts for damage. Clean all parts and
threads with a compatible solvent before
reassembling.
10. Inspect the polished surfaces of the displacement
rod (13) and cylinder (8) for scratches, scoring or
other damage, which can cause premature packing
wear and leaking. To check, run a finger over the
surface or hold the part up to the light at an angle.
Be sure the ball seats of the piston (26) and intake
valve housing (15) are not chipped or nicked.
Replace any worn or damaged parts.
Assemble the Displacement
Pump
NOTE: On UHMWPE/PTFE packed pumps, the packing
order is one UHMWPE packing, two PTFE packings,
and one UHMWPE packing. On PTFE packed pumps,
all four packings are PTFE.
1. Lubricate the throat packings and place them in the
outlet housing (1) in the following order, with the
lips of the v-packings facing down (see FIG. 3 on
page 17):
- male gland (11*),
- v-packings (24* or 5*)
- female gland (14*).
2. Apply thread lubricant and install the packing nut
(2) loosely.
3. If you removed the cylinder (8), apply thread
lubricant and reinstall it in the outlet housing (1),
making sure to replace the o-ring (10).
4. Install shims (31*) onto the piston stud (26) as
required to eliminate end play.
5. Lubricate the piston packings and place them on
the piston stud (26) in the following order, with the
lips of the v-packings facing down:
- female gland (25*)
- v-packings (23* or 20*)
- male gland (27*)
- washer (19*).
6. Apply thread sealant and screw the piston stud (26)
onto the piston mounting stud (28). Torque to 50-70
ft-lb (68-95 N•m).
7. Install the piston ball (4*) on the piston seat. Slide
the ball stop pin (21*) into the desired set of holes,
and secure with the cotter pin (3*).

Repair
16 308116V
8. Place the flats of the displacement rod (13) in a
vise. Apply sealant and screw the piston assembly
onto the displacement rod. Torque to 50-70 ft-lb
(68-95 Nm).
9. Insert the displacement rod (13) into the bottom of
the cylinder (8), being careful not to scratch the
cylinder. Push the rod straight up until it protrudes
from the packing nut (2).
10. Install the ball (4*), guide (9), o-ring (12), and ball
stop pin (6*) in the intake valve housing (15).
11. Place the intake valve assembly in the locking ring
(7). Apply thread sealant to the locking ring and
cylinder (8), and screw the ring onto the cylinder.
12. Follow Connect the Displacement Pump, page
13.

Repair
308116V 17
FIG. 3
0191C
2
14*
24* or 5*
5*
11*
1
13
See Detail A
2
3*
21*
6*
15
4*
12*
7
9
26
4
28
8
10*
1
28
19*
27*
20* or 23*
20*
20* or 23*
25*
26
31*
24* or 5*
See Detail B
Detail A: Throat Packings
Detail B: Piston Packings
NOTE: Lips of
u-packings must
face up.
1
2
3
3
NOTE: Lips of v-packings
must face down.

Parts
18 308116V
Parts
Model 224342
10:1 Ratio President Pump
‡ Keep spare parts on hand to reduce down time.
▲ Replacement safety labels, tags, and cards are
available at no cost.
0194c
108
110‡
111‡
101
102
103
PlateNo. 177843, Rev G
138
137
Ref. Part Description Qty.
101 224341 DISPLACEMENT PUMP ASSY.
See pages 18--19 for parts
1
102 102021 NUT, lock; 3/8--16; stainless steel 3
103 166237 ROD, tie; stainless steel; 3.5 in.
(89 mm) shoulder to shoulder
3
108 207352 AIR MOTOR
See 306982 for parts
1
110‡156082 SEAL, o-ring; nitrile rubber 1
111‡101946 PIN, cotter; stainless steel;
0.12 in. (3.2 mm) x 1.5 in.
(3.8 mm)
1
137▲180233 LABEL, warning 1
138▲177843 LABEL, warning 1

Parts
308116V 19
Models 261630, 224343 (shown)
5:1 Ratio Monark Pump
‡ Keep spare parts on hand to reduce down time.
▲ Replacement safety labels, tags, and cards are
available at no cost.
0196c
108
110
‡
103
111
‡
102
101
142
143
Ref. Part Description Qty.
101 224341 DISPLACEMENT PUMP ASSY.
for Model 224343 only;
See pages 18--19 for parts
1
254999 DISPLACEMENT PUMP ASSY.
for Model 261630 only;
See pages 18--19 for parts
1
102 102021 NUT, lock; 3/8--16; stainless steel 3
103 24B189 KIT, tie rod 3
108 205997 AIR MOTOR
See 307043 for parts
1
110‡156082 SEAL, o-ring; nitrile rubber 1
111‡101946 PIN, cotter; stainless steel;
0.12 in. (3.2 mm) x 1.5 in.
(3.8 mm)
1
142▲180233 LABEL, warning 1
143▲177843 LABEL, warning 1

Parts
20 308116V
Models 247147, 902147 (shown)
5:1 Ratio Monark Pump
108
116
115
114
113
112
101
102
111‡
103
110‡
1
1
1
1
1
142
143
1
Items 112--116 used on Model 902147 only.
‡ Keep spare parts on hand to reduce down time.
▲ Replacement safety labels, tags, and cards are
Ref. Part Description Qty.
101 15G976 DISPLACEMENT PUMP
ASSY.
See pages 20--21 for parts
1
102 102021 NUT, lock; 3/8--16; sst 3
103 24B189 KIT, tie rod 3
108 205997 AIR MOTOR
See 307043 for parts
1
110‡156082 SEAL, o-ring; nitrile rubber 1
111‡101946 PIN, cotter; stainless steel;
0.12 in. (3.2 mm) x 1.5 in.
(3.8 mm)
1
112 166027 ELBOW, street; 90; sst 1
113 166719 TUBE, rise; sst 1
114 166029 NUT, flareless tube; sst 1
115 102186 FERRULE, for 3/4 in. OD
tube; sst
1
116 166030 ADAPTER, tube 1
142▲180233 LABEL, warning 1
143▲177843 LABEL, warning 1
