Graco Check-Mate 2100 A Series Operation manual

Instructions – Parts List
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
Copyright 2002, Graco Inc. is registered to I.S. EN ISO 9001
CARBON STEEL
Check–Matet2100 Pumps
With Priming Piston, and Severe–Duty Rod and Cylinder
Part No. 222828 Pump, Series A
Part No. 246935 Pump, Series A
12:1 Ratio, with BulldogrAir Motor
8.3 MPa, 83 bar (1200 psi) Maximum Fluid Working Pressure
0.7 MPa, 7 bar (100 psi) Maximum Air Input Pressure
Part No. 222829 Pump, Series A
12:1 Ratio, with Quiet BulldogrAir Motor
8.3 MPa, 83 bar (1200 psi) Maximum Fluid Working Pressure
0.7 MPa, 7 bar (100 psi) Maximum Air Input Pressure
Part No. 222835 Pump, Series A
Part No. 246936 Pump, Series A
24:1 Ratio, with KingtAir Motor
16.6 MPa, 166 bar (2400 psi) Maximum Fluid Working Pressure
0.7 MPa, 7 bar (100 psi) Maximum Air Input Pressure
Part No. 222901 Pump, Series B
24:1 Ratio, with Quiet KingtAir Motor
16.6 MPa, 166 bar (2400 psi) Maximum Fluid Working Pressure
0.7 MPa, 7 bar (100 psi) Maximum Air Input Pressure
Part No. 222940 Pump, Series A
39:1 Ratio, with PremiertAir Motor
26.9 MPa, 269 bar (3900 psi) Maximum Fluid Working Pressure
0.7 MPa, 7 bar (100 psi) Maximum Air Input Pressure
Part No. 222902 Pump, Series B
Part No. 246937 Pump, Series A
with ViscountrHydraulic Motor
15.9 MPa, 159 bar (2300 psi) Maximum Fluid Working Pressure
10 MPa, 103 bar (1500 psi) Maximum Hydraulic Input Pressure
308149P
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
See page 2 for Table of Contents.
Part No.
222835
Shown
Parts

2 308149
Table of Contents
Warnings 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation (Air-Powered Pumps) 8. . . . . . . . . . . . . . . . .
Installation (Hydraulic-Powered Pumps) 10. . . . . . . . . .
Operation/Maintenance
All Models 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air-Powered Models 12. . . . . . . . . . . . . . . . . . . . . . . .
Hydraulic-Powered Models 14. . . . . . . . . . . . . . . . . .
Service
Troubleshooting Chart 15. . . . . . . . . . . . . . . . . . . . . . .
Required Tools 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disconnecting the Displacement Pump 16. . . . . . . .
Reconnecting the Displacement Pump 18. . . . . . . .
Displacement Pump Service 19. . . . . . . . . . . . . . . . .
Parts Drawings and Lists
Pump Assemblies 25. . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement Pump 28. . . . . . . . . . . . . . . . . . . . . . . .
Technical Data and Performance Charts 30. . . . . . . . . .
Dimensions 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounting Hole Layout 37. . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Standard Warranty 38. . . . . . . . . . . . . . . . . . . . . .
Graco Information 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

308149 3
Symbols
Warning Symbol
WARNING
This symbol alerts you to the possibility of serious
injury or death if you do not follow the instructions.
Caution Symbol
CAUTION
This symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow the
instructions.
WARNING
INSTRUCTIONS
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equipment to rupture or malfunction and result in serious injury.
This equipment is for professional use only.
Read all instruction manuals, tags, and labels before operating the equipment.
Use the equipment only for its intended purpose. If you are uncertain about usage, call your Graco
distributor.
Do not alter or modify this equipment. Use only genuine Graco parts and accessories.
Check equipment daily. Repair or replace worn or damaged parts immediately.
Do not exceed the maximum working pressure of the lowest rated system component. Refer to the
Technical Data on pages 30–35 for the maximum working pressure of this equipment.
Use fluids and solvents which are compatible with the equipment wetted parts. Refer to the Tech-
nical Data section of all equipment manuals. Read the fluid and solvent manufacturer’s warnings.
Do not kink or overbend hoses or use hoses to pull equipment.
Route hoses away from traffic areas, sharp edges, moving parts, and hot surfaces. Do not expose
Graco hoses to temperatures above 82C (180F) or below –40C (–40F).
Wear hearing protection when operating this equipment.
Do not lift pressurized equipment.
Comply with all applicable local, state, and national fire, electrical, and safety regulations.

4 308149
WARNING
SKIN INJECTION HAZARD
Spray from the gun/valve, hose leaks, or ruptured components can inject fluid into your body and
cause extremely serious injury, including the need for amputation. Fluid splashed in the eyes or on the
skin can also cause serious injury.
Fluid injected into the skin might look like just a cut, but it is a serious injury. Get immediate surgi-
cal treatment.
Do not point the gun/valve at anyone or at any part of the body.
Do not put your hand or fingers over the spray tip/nozzle.
Do not stop or deflect leaks with your hand, body, glove or rag.
Do not “blow back” fluid; this is not an air spray system.
Always have the tip guard and the trigger guard on the gun/valve when spraying.
Be sure the gun/valve trigger safety operates before spraying.
Lock the gun/valve trigger safety when you stop spraying.
Follow the Pressure Relief Procedure on page 12 whenever you: are instructed to relieve pres-
sure; stop spraying; clean, check, or service the equipment; and install or clean the spray tip/
nozzle.
Tighten all fluid connections before operating the equipment.
Check the hoses, tubes, and couplings daily. Replace worn, damaged, or loose parts immediately.
Permanently coupled hoses cannot be repaired; replace the entire hose.
Use only Graco approved hoses. Do not remove any spring guard that is used to help protect the
hose from rupture caused by kinks or bends near the couplings.
MOVING PARTS HAZARD
Moving parts, such as the air motor piston, can pinch or amputate your fingers.
Keep clear of all moving parts when starting or operating the pump.
Before servicing the equipment, follow the Pressure Relief Procedure on page 12 to prevent the
equipment from starting unexpectedly.

308149 5
WARNING
FIRE AND EXPLOSION HAZARD
Improper grounding, poor ventilation, open flames or sparks can cause a hazardous condition and
result in a fire or explosion and serious injury.
Ground the equipment and the object being sprayed. Refer to Grounding on page 7.
If there is any static sparking or you feel an electric shock while using this equipment, stop spray-
ing immediately. Do not use the equipment until you identify and correct the problem.
Provide fresh air ventilation to avoid the buildup of flammable fumes from solvents or the fluid
being sprayed.
Keep the spray area free of debris, including solvent, rags, and gasoline.
Electrically disconnect all equipment in the spray area.
Extinguish all open flames or pilot lights in the spray area.
Do not smoke in the spray area.
Do not turn on or off any light switch in the spray area while operating or if fumes are present.
Do not operate a gasoline engine in the spray area.
Keep a fire extinguisher in the work area.
TOXIC FLUID HAZARD
Hazardous fluid or toxic fumes can cause serious injury or death if splashed in the eyes or on the skin,
inhaled, or swallowed.
Know the specific hazards of the fluid you are using.
Store hazardous fluid in an approved container. Dispose of hazardous fluid according to all local,
state and national guidelines.
Always wear protective eyewear, gloves, clothing and respirator as recommended by the fluid and
solvent manufacturer.

6 308149
Notes

308149 7
Installation
Grounding
WARNING
FIRE AND EXPLOSION HAZARD
Before operating the pump, ground the
system as explained below. Also read
the section FIRE AND EXPLOSION
HAZARD on page 5.
1. King Pumps: use a ground wire and clamp. See
Fig. 1. Remove the ground screw (Z) and insert
through eye of ring terminal at the end of ground
wire (Y). Fasten ground screw back onto pump
and tighten securely. Connect the other end of the
wire to a true earth ground. Order Part No. 222011
Ground Wire and Clamp.
All Other Pumps: use a ground wire and clamp.
See Fig. 2. Loosen the grounding lug locknut (W)
and washer (X). Insert one end of a 1.5 mm(12
ga) minimum ground wire (Y) into the slot in lug (Z)
and tighten the locknut securely. Connect the other
end of the wire to a true earth ground. Order Part
No. 237569 Ground Wire and Clamp.
2. Air and hydraulic hoses: use only electrically
conductive hoses.
3. Fluid hoses: use only electrically conductive fluid
hoses.
4. Air compressor or hydraulic power supply: follow
manufacturer’s recommendations.
5. Spray gun/dispensing valve: grounding is obtained
through connection to a properly grounded fluid
hose and pump.
6. Fluid supply container: according to your local
code.
7. Object being sprayed: according to your local
code.
8. All solvent pails used when flushing, according to
your local code. Use only metal pails, which are
conductive, placed on a grounded surface. Do not
place the pail on a nonconductive surface, such as
paper or cardboard, which interrupts the grounding
continuity.
9. To maintain grounding continuity when flushing or
relieving pressure, always hold a metal part of the
spray gun/dispensing valve firmly to the side of a
grounded metal pail, then trigger the gun/valve.
Fig. 1 TI1052
Y
Z
Fig. 2
W
X
Y
Z
0864

8 308149
Installation
(AIR-POWERED PUMPS)
NOTE: Reference numbers and letters in parentheses
in the text refer to the callouts in the figures and the
parts drawings.
Accessories are available from your Graco distributor.
If you supply your own accessories, be sure they are
adequately sized and pressure-rated to meet the
system’s requirements.
The Typical Installation shown in Fig. 3 is only a guide
for selecting and installing system components and
accessories. Contact your Graco distributor for assis-
tance in designing a system to suit your particular
needs.
01177A
Fig. 3
KEY
APump
B200 Liter (55 Gallon) Air-Powered Ram
CPump Runaway Valve
DAir Line Lubricator
EBleed-Type Master Air Valve
(required, for pump)
FPump Air Regulator
GAir Manifold
HElectrically Conductive Air Supply Hose
JAir Line Filter
KBleed-Type Master Air Valve (for accessories)
LFluid Regulator
MFluid Drain Valve (required)
NElectrically Conductive Fluid Supply Hose
PFluid Shutoff Valve
RGun/Valve Swivel
SAirless Spray Gun or Dispensing Valve
TRam Air Regulator
YGround Wire (required, see page 7 for
installation instructions)
A
B
D
E
F
G
H
JK
M
Y
MAIN AIR LINE
R
S
T
L
M
N
P
R
S
FLUID HEADER PIPE
(3 in. Diameter)
LP
M
N
C

308149 9
Installation
(AIR-POWERED PUMPS)
SYSTEM ACCESSORIES
WARNING
A bleed-type master air valve (E) and a fluid drain
valve (M) are required in your system. These
accessories help reduce the risk of serious injury,
including fluid injection and splashing of fluid in the
eyes or on the skin, and injury from moving parts if
you are adjusting or repairing the pump.
The bleed-type master air valve relieves air trapped
between this valve and the pump after the air is
shut off. Trapped air can cause the pump to cycle
unexpectedly. Locate the valve close to the pump.
The fluid drain valve assists in relieving fluid pres-
sure in the displacement pump, hose, and gun.
Triggering the gun to relieve pressure may not be
sufficient.
Air and Fluid Hoses
Be sure all air hoses (H) and fluid hoses (N) are prop-
erly sized and pressure-rated for your system. Use
only electrically conductive hoses. Fluid hoses must
have spring guards on both ends.
Mounting Accessories
WARNING
For Model 222940 Premier Pump, do not lift the
pump by the lift ring when the total weight exceeds
550 lb (250 kg).
Mount the pump (A) to suit the type of installation
planned. Fig. 3 on page 8 illustrates a ram-mounted
pump in a multi-gun header system. Pump dimensions
and the mounting hole layout are shown on pages 36
and 37.
If you are mounting the pump on a ram, refer to the
separate ram manual for installation and operation
instructions.
Air Line Accessories
Install the following accessories in the order shown in
Fig. 3, using adapters as necessary:
An air line lubricator (D) provides automatic air
motor lubrication.
A bleed-type master air valve (E) is required in
your system to relieve air trapped between it and
the air motor when the valve is closed (see the
WARNING above). Be sure the bleed valve is
easily accessible from the pump, and is located
downstream from the air regulator.
An air regulator (F) controls pump speed and
outlet pressure by adjusting the air pressure to the
pump. Locate the regulator close to the pump, but
upstream from the bleed-type master air valve.
Apump runaway valve (C) senses when the
pump is running too fast and automatically shuts off
the air to the motor. A pump which runs too fast can
be seriously damaged.
An air manifold (G) has a swivel air inlet. It
mounts to a ram, and has ports for connecting lines
to air accessories, such as the ram air regulator
(T).
An air line filter (J) removes harmful dirt and
moisture from the compressed air supply.
A second bleed-type air valve (K) isolates the air
line accessories for servicing. Locate upstream
from all other air line accessories.
Fluid Line Accessories
Install the following accessories in the positions shown
in Fig. 3, using adapters as necessary:
Install a fluid shutoff valve (P) at each gun drop,
to isolate the gun and fluid accessories for servic-
ing.
Install a fluid drain valve (M) near the pump fluid
outlet, and at each gun station. The drain valves
are required in your system to relieve fluid pressure
in the displacement pump, hose and gun (see the
WARNING at left). Drain valves at the gun stations
may be mounted in the base of a fluid regulator
(L), using an adapter.
A fluid regulator (L) controls fluid pressure to the
gun/valve, and dampens pressure surges.
A gun or valve (S) dispenses the fluid. The gun
shown in Fig. 3 is a high pressure dispensing gun
for highly viscous fluids.
A gun swivel (R) allows freer gun movement.

10 308149
Installation
(HYDRAULIC-POWERED PUMPS)
NOTE: Reference numbers and letters in parentheses
in the text refer to the callouts in the figures and the
parts drawing.
Accessories are available from your Graco . If you
supply your own accessories, be sure they are ade-
quately sized and pressure-rated to meet the system’s
requirements.
The Typical Installation shown in Fig. 4 is only a guide
for selecting and installing system components and
accessories. Contact your Graco distributor for assis-
tance in designing a system to suit your particular
needs.
CAUTION
It is very important to keep the hydraulic supply
system clean at all times. Be sure that all hydraulic
fluid lines are absolutely clean. Blow out the lines
with air and flush thoroughly with solvent before
connecting to the hydraulic motor, to avoid introduc-
ing harmful contaminants into the motor. Plug the
hydraulic lines immediately when they are discon-
nected.
Do not exceed 37.8 liter/min (10 gpm) hydraulic oil
volume to the motor, to avoid pump stalling.
For optimum pump performance, keep the tempera-
ture of the hydraulic oil below 54C (130F)
01178
KEY
APump
B200 Liter (55 Gallon) Air-Powered Ram
CHydraulic Supply Line
DHydraulic Return Line
EDrain Line (from pressure reducing valve)
FPressure Gauge
GFlow Control Valve
HPressure Reducing Valve
JAccumulator
KDrain Line (from motor drip pan)
LFluid Regulator
MFluid Drain Valve (required)
NElectrically Conductive Fluid
Supply Hose
PFluid Shutoff Valve
RGun/Valve Swivel
SAirless Spray Gun
or Dispensing Valve
TRam Air Regulator
UHydraulic Supply Line Shutoff Valve
VHydraulic Return Line Shutoff Valve
YGround Wire (required, see page 7 for
installation instructions)
AA Hydraulic Return Line Filter
B
D
E
F
G
H
J
K
M
N
P
YL
R
S
T
U
C
V
HYDRAULIC
POWER SUPPLY
DRAINAGE
CONTAINER
AA
A
L
MM
P
S
N
AIR FILTER FOR RAM AIR SHUTOFF VALVE FOR RAM
MAIN AIR LINE FLUID HEADER PIPE
(3 in. Diameter)
R
Fig. 4

308149 11
Installation
(HYDRAULIC-POWERED PUMPS)
SYSTEM ACCESSORIES
WARNING
A fluid drain valve (M) is required in your system to
help reduce the risk of serious injury, including fluid
injection and splashing of fluid in the eyes or on the
skin if you are adjusting or repairing the pump.
The fluid drain valve assists in relieving fluid pres-
sure in the displacement pump, hose, and gun.
Triggering the gun to relieve pressure may not be
sufficient.
Mounting Accessories
Mount the pump (A) to suit the type of installation
planned. Fig. 4 on page 10 illustrates a ram-mounted
pump in a multi-gun header system. Pump dimensions
and the mounting hole layout are shown on pages 36
and 37.
If you are mounting the pump on a air-powered ram,
refer to the separate ram manual for installation and
operation instructions, and recommended air accesso-
ries.
Filters
Be sure your hydraulic power supply is equipped with a
suction filter to the hydraulic pump and a system return
line filter (AA) of 10 micron size.
Carefully follow the manufacturer’s recommendations
on reservoir and filter cleaning, and periodic changes
of hydraulic fluid. Use only Graco-approved hydraulic
oil. Order Part No. 169236, 5 gal. (19 liter) or 207428,
1 gal. (3.8 liter). Do not substitute a lower grade oil or
one with a lower flash point.
Hydraulic Lines
The motor has a 3/4 npt(f) hydraulic oil supply fitting,
and a 1” npt(f) hydraulic oil return fitting. Use a mini-
mum 13 mm (1/2 in.) ID hydraulic supply line, and a
minimum 16 mm (5/8 in.) ID return line.
On the hydraulic supply line (C), install the following
accessories in the order shown in Fig. 4, using adapt-
ers as necessary:
Ashutoff valve (U) to isolate the pump for servic-
ing.
A fluid pressure gauge (F) to monitor hydraulic oil
pressure to the motor and to avoid overpressurizing
the motor or displacement pump, and a pressure-
and temperature-compensated flow control
valve (G) to prevent the motor from running too
fast and possibly damaging itself.
A pressure reducing valve (H), with a drain line
(E) running into the hydraulic return line (D).
An accumulator (J) to reduce the hammering
effect caused by the motor reversing direction.
On the hydraulic return line (D), install the following
accessories in the order shown in Fig. 4, using adapt-
ers as necessary:
Ashutoff valve (V) to isolate the pump for servic-
ing.
Afilter (AA) of 10 micron size.
Hydraulic Motor Drip Pan
The hydraulic motor has a drip pan to collect any
leakage that may occur. Connect a 6 mm (1/4 in.) ID
drain line (K) to the barbed hose fitting on the drip pan,
and place the free end in a suitable container to re-
ceive the drainage.
Fluid Supply Hoses
Be sure the fluid supply hose (N) is properly sized and
pressure-rated for your system. Use only electrically
conductive hoses. Fluid hoses must have spring
guards on both ends.
Fluid Line Accessories
Install the following accessories in the positions shown
in Fig. 4, using adapters as necessary:
Install a fluid shutoff valve (P) at each gun drop,
to isolate the gun and fluid accessories for servic-
ing.
Install a fluid drain valve (M) near the pump fluid
outlet, and at each gun station. The drain valves
are required in your system to relieve fluid pressure
in the displacement pump, hose and gun (see the
WARNING at left). Drain valves at the gun stations
may be mounted in the base of a fluid regulator
(L), using an adapter.
A fluid regulator (L) controls fluid pressure to the
gun/valve, and dampens pressure surges.
A gun or valve (S) dispenses the fluid. The gun
shown in Fig. 4 is a high pressure dispensing gun
for highly viscous fluids.
A gun swivel (R) allows freer gun movement.

12 308149
Operation
(ALL MODELS)
Pressure Relief Procedure
WARNING
SKIN INJECTION HAZARD
Fluid under high pressure can be in-
jected through the skin and cause
serious injury. To reduce the risk of an
injury from injection, splashing fluid, or moving
parts, follow the Pressure Relief Procedure
whenever you:
are instructed to relieve the pressure,
stop spraying/dispensing,
check or service any of the system equipment,
or install or clean the spray tip/nozzle.
1. Engage the gun/valve trigger safety.
2. Shut off the air or hydraulic supply to the pump.
3. In air-powered systems, close the bleed-type
master air valve (required in your system). In
hydraulic-powered systems, close the hydraulic
supply line valve first, then the return line valve.
4. Unlock the gun/valve safety latch.
5. Hold a metal part of the gun/valve firmly to the side
of a grounded metal pail, and trigger the gun/valve
to relieve pressure.
6. Lock the gun/valve safety latch.
7. Open the drain valve (required in your system)
and/or the pump bleeder valve, having a container
ready to catch the drainage.
8. Leave the drain valve open until you are ready to
spray/dispense again.
If you suspect that the spray tip/nozzle or hose is
completely clogged, or that pressure has not been fully
relieved after following the steps above, very slowly
loosen the tip guard retaining nut, nozzle, or hose end
coupling and relieve pressure gradually, then loosen
completely. Now clear the tip/nozzle or hose.
Packing Nut/Wet-Cup
Fill the packing nut/wet-cup (2) 1/3 full with Graco
Throat Seal Liquid (TSL) or compatible solvent. See
Fig. 5. Using the supplied wrench (104), adjust the
packing nut weekly so it is just snug; do not overtigh-
ten. Follow the Pressure Relief Procedure above
before adjusting the packing nut.
Flushing the Pump
The pump is tested with lightweight oil, which is left in
to protect the pump parts. If the fluid you are using
may be contaminated by the oil, flush it out with a
compatible solvent before using the pump.
WARNING
Before operating the pump, ground the system as
explained under FIRE AND EXPLOSION HAZARD
and Grounding on page 5.
(AIR-POWERED MODELS)
Starting and Adjusting the Pump
Supply fluid to the pump, per the requirements of your
system.
Refer to Fig. 3 on page 8. Be sure the air regulator
(F) is closed. Then open the pump’s bleed-type master
air valve (E). Hold a metal part of the spray gun/dis-
pensing valve (S) firmly to the side of a grounded
metal pail and hold the trigger open. Now slowly open
the air regulator until the pump starts.
Cycle the pump slowly until all the air is pushed out
and the pump and hoses are fully primed. Release the
spray gun/dispensing valve trigger and engage the
safety latch. The pump should stall against pressure
when the trigger is released.
If the pump fails to prime properly, open the bleeder
valve plug (35) slightly. Use the bleed hole, on the
underside of the valve body (34), as a priming valve
until the fluid appears at the hole. See Fig. 5. Close the
plug (35).
NOTE: When changing fluid containers with the hose
and gun already primed, open the bleeder valve plug
(35), to assist in priming the pump and venting air
before it enters the hose. Close the bleeder valve
when all air has been eliminated.
WARNING
To reduce the risk of fluid injection, do not use your
hand or fingers to cover the bleed hole when
priming the pump.

308149 13
Operation
(AIR-POWERED MODELS)
With the pump and lines primed, and with adequate air
pressure and volume supplied, the pump will start and
stop as the gun/valve is opened and closed. In a
circulating system, the pump will speed up or slow
down on demand, until the air supply is shut off.
Use the air regulator (F) to control the pump speed
and the fluid pressure. Always use the lowest air
pressure necessary to get the desired results. Higher
pressures cause premature tip/nozzle and pump wear.
WARNING
To reduce the risk of overpressurizing your system,
which could result in component rupture and cause
serious injury, never exceed the specified maxi-
mum incoming air pressure to the pump (see the
Technical Data on pages 30–35)
Never allow the pump to run dry of the fluid being
pumped. A dry pump will quickly accelerate to a high
speed, possibly damaging itself. A pump runaway
valve (C), which shuts off the air supply to the pump if
the pump accelerates beyond the pre-set speed, is
available. See Fig. 3 on page 8. If your pump acceler-
ates quickly, or is running too fast, stop it immediately
and check the fluid supply. If the supply container is
empty and air has been pumped into the lines, refill the
container and prime the pump and the lines with fluid,
or flush and leave it filled with a compatible solvent. Be
sure to eliminate all air from the fluid system.
Shutdown and Care of the Pump
WARNING
To reduce the risk of serious injury whenever you
are instructed to relieve pressure, always follow the
Pressure Relief Procedure on page 12.
For overnight shutdown, relieve the pressure. Stop
the pump at the bottom of the stroke to prevent fluid
from drying on the exposed displacement rod and
damaging the throat packings.
Always flush the pump before the fluid dries on the
displacement rod. Never leave water or water-based
fluid in the pump overnight. First, flush with water or a
compatible solvent, then with mineral spirits. Relieve
the pressure, but leave the mineral spirits in the pump
to protect the parts from corrosion.
Fig. 5
1Bleed hole must
face down.
104
0913A
Model 222835 Shown
2
134, 35

14 308149
Operation
(HYDRAULIC-POWERED MODELS)
Starting and Adjusting the Pump
Supply fluid to the pump, per the requirements of your
system.
Refer to Fig. 4 on page 10. Check the hydraulic fluid
level before each use, and add fluid as necessary.
Make certain that the supply line shutoff valve (U) and
the return line shutoff valve (V) are closed, then start
the hydraulic power supply.
Hold a metal part of the gun/valve (S) firmly to the side
of a grounded metal pail and hold the trigger open.
Open the return line shutoff valve (V) first, then slowly
open the supply line shutoff valve (U).
Cycle the pump slowly until all the air is pushed out
and the pump and hoses are fully primed. Release the
spray gun/dispensing valve trigger and engage the
trigger safety. The pump should stall against pressure
when the trigger is released.
If the pump fails to prime properly, open the bleeder
valve (35) slightly. Use the bleed hole on the underside
of the valve body (34) as a priming valve until the fluid
appears at the hole. See Fig. 10. Close the plug (35).
NOTE: When changing fluid containers with the hose
and gun already primed, open the bleeder valve plug
(35), to assist in priming the pump and venting air
before it enters the hose. Close the bleeder valve
when all air has been eliminated.
WARNING
To reduce the risk of fluid injection, do not use your
hand or fingers to cover the bleed hole when
priming the pump.
With the pump and lines primed, and with adequate
hydraulic volume supplied, the pump will start and stop
as the gun/valve is opened and closed. In a circulating
system, the pump will speed up or slow down on
demand, until the hydraulic power supply is shut off.
Use the fluid pressure gauge (F) and flow control valve
(G) to control the pump speed and the fluid outlet
pressure. Always use the lowest hydraulic flow and
pressure necessary to get the desired results. Higher
pressures cause premature tip/nozzle and pump wear.
WARNING
To reduce the risk of overpressurizing your system,
which could result in component rupture and cause
serious injury, never exceed 10 MPa, 103 bar
(1500 psi) Maximum Hydraulic Input Pressure to
the pump or 15.9 MPa, 159 bar (2300 psi) Maxi-
mum Fluid Working Pressure (see the Technical
Data on page 35).
To prevent overpressurizing the hydraulic motor or
its seals, always shut off the supply line valve (U)
first, then shut off the return line valve (V).
CAUTION
Do not allow the hydraulic oil temperature to exceed
54C (130F). The pump seals will wear faster and
leakage may occur if the pump is operated at higher
oil temperatures.
Never allow the pump to run dry of the fluid being
pumped. A dry pump will quickly accelerate to a high
speed, possibly damaging itself. If your pump acceler-
ates quickly, or is running too fast, stop it immediately
and check the fluid supply. If the supply container is
empty and air has been pumped into the lines, refill the
container and prime the pump and the lines with fluid,
or flush and leave it filled with a compatible solvent. Be
sure to eliminate all air from the fluid system.
Shutdown and Care of the Pump
WARNING
To reduce the risk of serious injury whenever you
are instructed to relieve pressure, always follow the
Pressure Relief Procedure on page 12.
For overnight shutdown, relieve the pressure. Stop
the pump at the bottom of the stroke to prevent fluid
from drying on the exposed displacement rod and
damaging the throat packings.
Always flush the pump before the fluid dries on the
displacement rod. Never leave water or water-based
fluid in the pump overnight. First, flush with water or a
compatible solvent, then with mineral spirits. Relieve
the pressure, but leave the mineral spirits in the pump
to protect the parts from corrosion.

308149 15
Troubleshooting
WARNING
To reduce the risk of serious injury whenever you
are instructed to relieve pressure, always follow the
Pressure Relief Procedure on page 12.
1. Relieve the pressure.
2. Check all possible causes and problems before
disassembling the pump.
PROBLEM CAUSE SOLUTION
Pump fails to operate Restricted line or inadequate air/hydraulic
supply; closed or clogged valves
Clear; increase air/hydraulic supply.
Check that valves are open.
Obstructed fluid hose or gun/valve;
fluid hose ID is too small
Open, clear*; use hose with larger ID.
Fluid dried on the displacement rod Clean; always stop pump at bottom of stroke;
keep wet-cup 1/3 filled with compatible solvent.
Dirty, worn, or damaged motor parts Clean or repair; see separate motor manual.
Pump operates, but out-
put low on both strokes
Restricted line or inadequate air/hydraulic
supply; closed or clogged valves
Clear; increase air/hydraulic supply.
Check that valves are open.
Obstructed fluid hose or gun/valve;
fluid hose ID is too small
Open, clear*; use hose with larger ID.
Bleeder valve open Close.
Air leaking into supply container Check ram plate seal.
Fluid too heavy for pump priming Use bleeder valve (see pages 12 and 14); use ram.
Worn packings in displacement pump Replace packings.
Pump operates, but out-
put low on downstroke
Fluid too heavy for pump priming Use bleeder valve (see pages 12 and 14); use ram.
Held open or worn intake valve or seals Clear valve; replace seals.
Pump operates, but out-
put low on upstroke
Held open or worn piston valve or seals Clear valve; replace seals.
Erratic or accelerated
pump speed
Exhausted fluid supply Refill and prime.
Fluid too heavy for pump priming Use bleeder valve (see pages 12 and 14); use ram.
Held open or worn piston valve or seals Clear valve; replace seals.
Held open or worn priming piston Clear; service.
Worn packings in displacement pump Replace packings.
* To determine if the fluid hose or gun is obstructed, relieve the pressure. Disconnect the fluid hose and place a container at
the pump fluid outlet to catch any fluid. Turn on the air/hydraulic power just enough to start the pump. If the pump starts when
the air/hydraulic power is turned on, the obstruction is in the fluid hose or gun.
NOTE:If you experience air motor icing, contact your Graco distributor.

16 308149
Service
WARNING
To reduce the risk of serious injury whenever you
are instructed to relieve pressure, always follow the
Pressure Relief Procedure on page 12.
Required Tools
Torque wrench
Bench vise, with soft jaws
Rubber mallet
Hammer
O-ring pick
13 mm (1/2 in.) dia. brass rod
Set of socket wrenches
Set of adjustable wrenches
24 in. adjustable wrench
Thread lubricant
Thread sealant
Loctite2760or equivalent
NOTE: Service Tool 109508 is available as an acces-
sory. The tool fits over the top of the displacement rod,
making it easier to apply a 24 inch adjustable wrench
or 3/4 in. drive socket when connecting or disconnect-
ing the rod from the piston assembly.
Disconnecting the Displacement Pump
WARNING
Keep hands and fingers away from the priming
piston during operation and whenever the pump is
charged with air/hydraulic fluid to reduce the risk of
injury! On the pump downstroke the priming piston
extends beyond the intake housing to pull the
material into the pump. The priming piston works
under extreme force. During operation and when-
ever the pump is charged with air/hydraulic fluid,
the priming piston can severely injury or amputate
a hand or finger, or break a tool, caught between it
and the intake housing. Always relieve the pres-
sure before checking, clearing, cleaning, flushing,
or servicing any part of the pump.
On King and Bulldog air-powered pumps, the air
motor piston (located behind the air motor shield)
moves when air is supplied to the motor. Never
operate the pump with the air motor shield re-
moved.
On Premier air-powered pumps, the rocker arms
(located beneath the rocker arm covers) move
when air is supplied to the motor. Never operate
the pump with the rocker arm covers removed.
Before servicing the pump, relieve the pressure to
prevent the pump from starting accidentally.
1. Flush the pump, if possible. Stop the pump at the
bottom of its stroke. Relieve the pressure.
2. Disconnect the air or hydraulic hose. Plug all
hydraulic hoses immediately, to prevent contami-
nation of the hydraulic system. Hold the fluid outlet
fitting (20) with a wrench to keep it from being
loosened while you disconnect the fluid hose.
3. Disconnect the displacement pump (105) from the
motor (101) as follows. Be sure to note the relative
position of the pump’s fluid outlet to the air or
hydraulic inlet of the motor. If the motor does not
require servicing, leave it attached to its mounting.
CAUTION
Be sure to use at least two people when lifting,
moving, or disconnecting the pump. This pump is too
heavy for one person. If you are disconnecting the
displacement pump from a motor which is still
mounted (for example, on a ram), be sure to support
the displacement pump while it is being discon-
nected, to prevent it from falling and causing injury or
property damage. Do this by securely bracing the
pump, or by having at least two people hold it while
another disconnects it.
4. Using an adjustable wrench, unscrew the coupling
nut (103). Remove the coupling collars (108). Take
care not to lose or drop them. See Fig. 6.
5. Hold the tie rod flats with a wrench to keep the
rods from turning. Unscrew the nuts (106) from the
tie rods (107). Carefully remove the displacement
pump (105) from the motor (101).
6. Refer to page 19 for displacement pump service.
To service the air or hydraulic motor, refer to the
separate motor manual, supplied.

308149 17
Service
Fig. 6
King, Bulldog, and
Viscount Pumps
(Model 222835
Shown)
Premier Pumps
(Model 222940
Shown)
01403B
1
3
4
2
0914A
Torque to 129–142 N.m (95–105 ft–lb).
Torque to 196–210 N.m (145–155 ft–lb).
Torque to 135–169 N.m (100–125 ft–lb).
Square hole is for use with torque wrench.
5
6
Torque to 129–142 N.m (95–105 ft–lb).
Torque to 312–340 N.m (230–250 ft–lb).
101
107 102
108
103
1
2
105
20106
104
104
106 20
105
2
1
103
108
102
107
101
109
1
1
2
3
4
5
26
6
3
5
4
6
7Apply Loctite2760(or equivalent) to threads.
7
7

18 308149
Service
Reconnecting the Displacement Pump
CAUTION
Be sure to use at least two people when lifting,
moving, or disconnecting the pump. This pump is too
heavy for one person. If you are disconnecting the
displacement pump from a motor which is still
mounted (for example, on a ram), be sure to support
the displacement pump while it is being discon-
nected, to prevent it from falling and causing injury or
property damage. Do this by securely bracing the
pump, or by having at least two people hold it while
another disconnects it.
NOTE: On Premier models, ensure that the rod adapt-
er (102) has not loosened during maintenance. Proper
torque is necessary to prevent the rod adapter from
loosening during the pump operation.
If the rod adapter (102) has loosened during mainte-
nance, remove the adapter and apply Loctite2760
(or equivalent) to the rod adapter and air motor piston
threads, and then torque as specified in Fig. 6.
1. Use at least two people to hold the displacement
pump while another reconnects it to the motor (see
the CAUTION above). Orient the pump’s fluid
outlet to the air or hydraulic inlet as was noted in
step 3 under Disconnecting the Displacement
Pump. Position the displacement pump (105) on
the tie rods (107). See Fig. 6.
2. Screw the nuts (106) onto the tie rods (107) and
torque as noted in Fig. 6.
3. Place the coupling nut (103) on the displacement
rod (1), then place the coupling collars (108) into
the nut. Loosely screw the coupling nut onto the
connecting rod adapter (102) or connecting rod
(109, Model 222940 only). Hold the adapter or
connecting rod flats with a wrench to keep it from
turning. Use an adjustable wrench to tighten the
coupling nut. Torque as noted in Fig. 6.
4. Torque the packing nut (2) to 135–169 N.m
(100–125 ft–lb).
5. Reconnect all hoses. Reconnect the ground wire if
it was disconnected. Fill the wet-cup (2) 1/3 full of
Graco Throat Seal Liquid or compatible solvent.
6. Turn on the air or hydraulic power supply. On
hydraulic pumps, open the hydraulic return line
valve first, then the supply line valve. Run the
pump slowly to ensure that it is operating properly.

308149 19
Service
Displacement Pump Disassembly
When disassembling the pump, lay out all the removed
parts in sequence, to ease reassembly. Clean all parts
with a compatible solvent and inspect them for wear or
damage. Refer to Fig. 10.
NOTE: Repair Kit 222860 is available to replace the
packings and seals. Parts included are denoted with
an asterisk, for example (7*). Repair Kit 222974 is
available to repair the intake valve. Parts included are
denoted with a symbol, for example (10). For the best
results, use all the new parts in the kits. Conversion Kit
222861 is available to convert the pump to all PTFE
v-packings, and Conversion Kit 222862 is available to
convert to leather v-packings. See page 29.
1. Remove the displacement pump from the air motor
as explained on page 16.
2. Hold the flats of the priming piston rod (12) with an
adjustable wrench, and use a second wrench to
unscrew the priming piston nut (14) from the rod.
Slide the priming piston (15) and guide (13) off the
rod. Inspect the outer surface of the guide (13) and
the inner and outer surfaces of the piston (15) for
scoring, wear, or other damage.
3. Stand the pump upright in a vise. Loosen the
packing nut (2) using the packing nut wrench (104)
supplied, or a hammer and brass rod. Using a
socket wrench, remove the six capscrews (32).
4. Tap the underside of the outlet housing (19) with a
rubber mallet to loosen the housing from the
cylinder (4). Lift the outlet housing off the pump
and set it aside. Be careful not to scratch the
displacement rod (1) while removing the housing.
Remove the seal (39) from the top of the cylinder.
5. Lift the cylinder (4) up off the intake housing (17).
The displacement rod (1), piston assembly, intake
valve assembly, and priming piston rod (12) will
come with the cylinder.
6. Place the cylinder (4) sideways in a vise with soft
jaws. Using a rubber mallet on the end of the
priming piston rod (12), drive the displacement rod
(1) and piston assembly out the top of the cylinder.
Continue to pull the rod out of the cylinder until the
priming piston rod (12) comes free.
7. Remove the seal (39) from the bottom of the
cylinder (4). Hold the cylinder up to the light at an
angle to examine the inside surface for scoring or
damage.
8. Place the flats of the displacement rod (1) in a
vise. Using a 13 mm (1/2 in.) diameter brass rod,
pry the intake check valve assembly away from
the rod guide (18) far enough to apply wrenches to
the valve assembly. See Fig. 7.
Fig. 7
1
01171
12
INTAKE CHECK VALVE
18
6
13 mm (1/2 in.) Diameter Brass Rod.
10 9
1
9. Hold the valve body (10) steady with a wrench on
the flats. Using an adjustable wrench, loosen the
intake packing nut (9) to decrease tension on the
priming piston rod (12). Now slide the intake valve
assembly off the rod and set it aside. See Fig. 8.
Fig. 8
1
3
2
01172
12
When reassembling
items 9 and 10,
torque to 97–106 N.m
(71–78 ft–lb).
See page 22.
Hold valve body (10)
steady.
Loosen intake
packing nut (9).
1 3
2 3

20 308149
Service
10. Pull the seal (39) and seat (11) out the top of the
intake housing (17). See Fig. 10. If the seat is
difficult to remove, turn the housing upside down
and drive the seat out using a hammer and brass
rod.
11. Examine the mating surfaces of the seat (11) and
the intake valve body (10) for damage.
12. Slide the rod guide (18) off the priming piston rod
(12). Unscrew the priming piston rod from the
piston (6). Run a finger over the surface of the rod
to check for scratches or scoring.
NOTE: Service Tool 109508 is available as an acces-
sory. The tool fits over the top of the displacement rod
(1), making it easier to apply a 24 inch adjustable
wrench or 3/4 in. drive socket when disconnecting the
rod from the piston (6).
13. Place the flats of the piston (6) in a vise. Unscrew
the displacement rod (1) from the piston (6). Lift
the piston seat and guide assembly off the piston.
Inspect the mating surfaces of the piston (6) and
piston seat (8) for damage. See the Detail in Fig.
10.
14. Remove the displacement rod (1) from the vise
and inspect it for scratches and scoring by running
a finger over the surface.
15. Place the piston seat and guide assembly in the
vise and close the jaws on the flats of the seat (8)
just tight enough to hold the part. Slide a brass rod
through the openings in the piston guide (5) and
unscrew it from the seat as shown in Fig. 9. Re-
move the piston seal (7).
Fig. 9
1
2
01173
5
8
13 mm (1/2 in.) Diameter Brass Rod.
When reassembling items 5 and 8, ap-
ply thread sealant and torque to approx.
125–137 N.m (92–101 ft–lb).
16. Take the intake valve assembly removed in step 9
and unscrew the packing nut (9) from the valve
body (10). Using an o-ring pick, remove the glands
(16, 41) and v-packings (40 and 42) from the valve
body. Remove the seal (43) from the packing nut.
See the Detail in Fig. 10.
NOTE: The seal (43) is press-fit in the packing nut and
may require cutting to ease removal.
17. Unscrew the bleeder valve plug (35) completely
from the valve housing (34). Clean the valve
threads and the bleed hole in the valve housing. It
is not necessary to remove the valve housing from
the outlet housing (19).
18. Remove the packing nut (2) from the outlet hous-
ing (19). Remove the throat packings (22, 24) and
glands (21, 23) from the outlet housing (19). Do
not remove the fluid outlet nipple (20) and o-ring
(25) from the outlet housing unless they need
replacement.
19. Inspect all parts for damage. Clean all parts and
threads with a compatible solvent. Reassemble as
explained on page 22.
