Graco Check-Mate L500CM Operation manual

Instructions - Parts
Ink Pump Packages
For use with medium to high viscosity inks. For professional use only.
Not for use in explosive atmospheres.
With priming piston and MaxLife®rod and cylinder.
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
ti14639a
Package with NXT Air Motor
and
L500CM Displacement Pump
See page 3 for model information, including
maximum working pressures. Package with Viscount II
Hydraulic Motor and L500CM
Displacement Pump
ti14637a
Package with NXT Air Motor,
DataTrak™, and L200CM
Displacement Pump
ti14636a
3A0096B
ENG

Related Manuals
23A0096B
Contents
Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Ink Pump Packages . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Grounding (All Pumps) . . . . . . . . . . . . . . . . . . . . 7
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Air-Powered Pumps . . . . . . . . . . . . . . . . . . . . . . 8
Hydraulic-Powered Pumps . . . . . . . . . . . . . . . . 10
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Tighten Clamps . . . . . . . . . . . . . . . . . . . . . . . . . 12
Wet Cup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Wet Cup Drain Fitting . . . . . . . . . . . . . . . . . . . . 12
Torque Wet Cup . . . . . . . . . . . . . . . . . . . . . . . . 12
Pressure Relief Procedure . . . . . . . . . . . . . . . . . . 13
Prime/Flush . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Start Up and Adjust Pump . . . . . . . . . . . . . . . . . . 14
Air-Powered Pumps . . . . . . . . . . . . . . . . . . . . . 14
Hydraulic-Powered Pumps . . . . . . . . . . . . . . . . 14
All Pumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Air-Powered Ink Packages . . . . . . . . . . . . . . . . 16
258753 Hydraulic-Powered Ink Package . . . . . 17
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 20
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . 20
Related Manuals
Component Manuals in English
:
Manual Description
312375 Check-Mate®Displacement Pump
Instructions-Parts
312376 Check-Mate®Pump Packages
Instructions-Parts
312468 200 cc Check-Mate Displacement
Pump Repair Parts Manual
312470 500 cc Check-Mate Displacement
Pump Repair Parts Manual
311238 NXT Air Motor Instructions-Parts
307158 Viscount®II Hydraulic Motor
Instructions-Parts
3A0133
24C743 and 24C744 King™Air
Motor Conversion Kits;
24D625 Viscount®II Hydraulic
Motor Conversion Kit

Ink Pump Packages
3A0096B 3
Ink Pump Packages
Check your pump package’s identification plate for the 6-digit part number of your pump package.
To order replacement parts, see Parts section starting on page 16.
Ink Pump
Package
Part No. Series Ratio
Data Monitoring
Power
Source
Pump
Size
Maximum Air
or Hydraulic
Input Pressure
psi (MPa, bar)
Maximum Fluid
Working
Pressure
psi (MPa, bar)None DataTrak
Remote
DataTrak
258744 A 14:1 ✔Air 500 cc 100 (0.7, 7.0) 1400 (9.7, 97)
258745 A 14:1 ✔Air 500 cc 100 (0.7, 7.0) 1400 (9.7, 97)
258746 A 14:1 ✔Air 500 cc 100 (0.7, 7.0) 1400 (9.7, 97)
258747 A 23:1 ✔Air 200 cc 100 (0.7, 7.0) 2300 (15.9, 159)
258748 A 23:1 ✔Air 200 cc 100 (0.7, 7.0) 2300 (15.9, 159)
258749 A 23:1 ✔Air 200 cc 100 (0.7, 7.0) 2300 (15.9, 159)
258750 A 26:1 ✔Air 500 cc 100 (0.7, 7.0) 2600 (17.9, 179)
258751 A 26:1 ✔Air 500 cc 100 (0.7, 7.0) 2600 (17.9, 179)
258752 A 26:1 ✔Air 500 cc 100 (0.7, 7.0) 2600 (17.9, 179)
258753 A 1.6:1 ✔Hydraulic
Oil
500 cc 1500 (10, 103) 2300 (15.9, 159)
Package Identification Plate
ti14691a ti14690a
ti14689a
Location on Air-Powered
Packages
Location on
Hydraulic-Powered
Packages

Warnings
43A0096B
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-
tion point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific risk. Refer back
to these warnings. Additional, product-specific warnings may be found throughout the body of this manual where
applicable.
WARNING
SKIN INJECTION HAZARD
High-pressure fluid from gun, hose leaks, or ruptured components will pierce skin. This may look like just
a cut, but it is a serious injury that can result in amputation. Get immediate surgical treatment.
• Do not point gun at anyone or at any part of the body.
• Do not put your hand over the spray tip.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Do not spray without tip guard and trigger guard installed.
• Engage trigger lock when not spraying.
• Follow Pressure Relief Procedure in this manual, when you stop spraying and before cleaning,
checking, or servicing equipment.
MOVING PARTS HAZARD
Moving parts can pinch or amputate fingers and other body parts.
• Keep clear of moving parts.
• Do not operate equipment with protective guards or covers removed.
• Pressurized equipment can start without warning. Before checking, moving, or servicing equipment,
follow the Pressure Relief Procedure in this manual. Disconnect power or air supply.
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help prevent
fire and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop
cloths (potential static arc).
• Keep work area free of debris, including solvent, rags and gasoline.
• Do not plug or unplug power cords, or turn power or light switches on or off when flammable fumes
are present.
• Ground all equipment in the work area. See Grounding instructions.
• Use only grounded hoses.
• Hold gun firmly to side of grounded pail when triggering into pail.
• If there is static sparking or you feel a shock, stop operation immediately. Do not use equipment
until you identify and correct the problem.
• Keep a working fire extinguisher in the work area.

Warnings
3A0096B 5
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system
component. See Technical Data in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Data in all
equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete information
about your material, request MSDS forms from distributor or retailer.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine manu-
facturer’s replacement parts only.
• Do not alter or modify equipment.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or
swallowed.
• Read MSDS’s to know the specific hazards of the fluids you are using.
• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.
• Always wear impervious gloves when spraying or cleaning equipment.
PERSONAL PROTECTIVE EQUIPMENT
You must wear appropriate protective equipment when operating, servicing, or when in the operating
area of the equipment to help protect you from serious injury, including eye injury, inhalation of toxic
fumes, burns, and hearing loss. This equipment includes but is not limited to:
• Protective eyewear
• Clothing and respirator as recommended by the fluid and solvent manufacturer
•Gloves
• Hearing protection
WARNING

Warnings
63A0096B

Installation
3A0096B 7
Installation
Grounding (All Pumps)
The equipment must be grounded. Grounding reduces
the risk of static and electric shock by providing an
escape wire for the electrical current due to static build
up or in the event of a short circuit.
Pump: use the ground wire and clamp supplied.
Remove the ground screw (air-powered packages) or
loosen the grounding lug locknut and washer (hydrau-
lic-powered packages). Install the 1.5 mm2(12 ga) mini-
mum ground wire and tighten the screw or locknut
securely. Connect the clamp to a true earth ground.
Air and fluid hoses: use only electrically conductive
hoses.
Air compressor: follow manufacturer's recommenda-
tions.
Dispense valve: ground through connection to a prop-
erly grounded fluid hose and pump.
Fluid supply container: follow your local code.
Object being sprayed: follow your local code.
Solvent pails used when flushing: follow local code.
Use only conductive metal pails, placed on a grounded
surface. Do not place the pail on a nonconductive sur-
face, such as paper or cardboard, which interrupts
grounding continuity.
To maintain grounding continuity when flushing or
relieving pressure: hold metal part of the dispense
valve firmly to the side of a grounded metal pail, then
trigger the valve.
Location
When selecting the location for the pump, keep the fol-
lowing in mind:
• There must be sufficient space on all sides of the
pump for installation, operator access, repair, and
air circulation. See Dimensions, page 18.
• Ensure that the floor stand (2) is level in all direc-
tions. If necessary, level the stand using metal
shims. Secure the stand to the floor using 1/2 in. (13
mm) anchors that are long enough to prevent the
pump from tipping. See Dimensions, page 18, for
mounting hole layout.
FIG. 1. Ground Wire
ti8250a

Installation
83A0096B
Air-Powered Pumps
• Reference numbers and letters in parentheses in
the text refer to numbers and letters in the illustra-
tions.
•F
IG. 2, page 9, shows a typical installation of an
air-powered pump. It is only a guide. Contact your
Graco distributor for actual system designs.
• Be sure all accessories, including air lines and fluid
lines, are adequately sized and pressure-rated to
meet system requirements.
• Use only electrically conductive hoses. Fluid hoses
must have spring guards on both ends.
Air Line Accessories
Install the following accessories as shown in FIG. 2,
using adapters as necessary.
•Bleed type master air valve (J) is required in your
system to shut off the air supply to the pump. When
closed, the valve will bleed off all air in the pump. Be
sure the valve is easily accessible from the pump.
•Air regulator (H) controls pump speed and outlet
pressure by adjusting the air pressure to the pump.
Locate the regulator close to the pump, but
upstream from the bleed-type master air valve.
•Air line filter (L) removes harmful dirt and moisture
from the compressed air supply. Also, install a drain
valve at the bottom of each air line drop, to drain off
moisture.
•Air shutoff relief valve (M) isolates the air line
accessories for servicing. Locate upstream from all
other air line accessories.
•DataTrak: see the NXT air motor manual 311238 for
DataTrak information.
Fluid Line Accessories
Install the following accessories as shown in FIG. 2,
using adapters as necessary.
• Install a fluid shutoff valve at each valve drop, to
isolate the valve and fluid accessories for servicing.
• Install a fluid drain valve near the pump fluid outlet,
and at each valve station. The drain valves are
required in your system to relieve fluid pressure in
the displacement pump, hose and valve. Drain
valves at the valve stations may be mounted in the
base of a fluid regulator, using an adapter.
•Fluid regulator controls fluid pressure to the valve,
and dampens pressure surges.
•Dispense valve dispenses the fluid.
•Valve swivel allows freer valve movement.
A bleed type master air valve (J) is required to help
reduce the risk of serious injury, including fluid injection
and splashing of fluid in the eyes or on the skin, and
injury from moving parts if you are adjusting or repair-
ing the pump.
The bleed valve shuts off the air to the pump and
relieves air trapped between this valve and the pump
after the air is shut off. Trapped air can cause the pump
to cycle unexpectedly. Locate the valve close to the
pump.

Installation
3A0096B 9
Key:
A Air Motor
B Displacement Pump
C Floor Stand
D Air Inlet
F 76 mm (3 in.) Fluid Inlet
G Fluid Outlet
H Air Regulator
J Bleed Type Master Air Valve (required)
K Air Line Drain Valve (not supplied)
L Air Filter (not supplied)
M Air Shutoff Relief Valve (for accessories, not supplied)
N Pump Bleed Valve
PWetCup
R Wet Cup Drain Fitting (if used)
T DataTrak Module (standard module shown; see Ink Pump
Packages chart on page 3 for data monitoring options)
Y Ground Wire (required, see page 7)
FIG. 2. Typical Installation, Air-Powered Pumps
A
B
C
N
G
F
ti14665a
M
L
D
P
H
J
K
R
T
Y

Installation
10 3A0096B
Hydraulic-Powered Pumps
• Reference numbers and letters in parentheses in
the text refer to numbers and letters in the illustra-
tions.
•F
IG. 3, page 11, shows a typical installation of an
hydraulic-powered pump. It is only a guide. Contact
your Graco distributor for actual system designs.
• Be sure all accessories, including hydraulic lines
and fluid lines, are adequately sized and pres-
sure-rated to meet system requirements.
• Use only electrically conductive hoses. Fluid hoses
must have spring guards on both ends.
Always plug the hydraulic inlets, outlets and lines when
disconnecting them for any reason to avoid introducing
dirt and other contaminants into the system.
Be sure that your hydraulic power supply is equipped
with a suction filter to the hydraulic pump and a system
return line filter of 10 micron size. Carefully follow the
manufacturer's recommendations on reservoir and filter
cleaning and periodic changes of hydraulic fluid.
NOTE: Hydraulic fluid is exhausted from differential
hydraulic motors only on the upstroke of the operating
cycle. The oil return line must have at least twice the
flow capacity as the oil supply line. Otherwise, back
pressure on the hydraulic motor piston will slow down
the motor and the fluid displacement pump, resulting in
a loss of pump performance.
On the hydraulic oil supply line (D), install a shutoff valve
(E) to isolate the system for servicing; a fluid pressure
gauge (J) to monitor hydraulic oil pressure to the motor
and avoid overpressurizing the motor or displacement
pump; a pressure- and temperature-compensated flow
control valve (H) to prevent the motor from running too
fast; a pressure reducing valve (K) with a drain line (M)
running directly into the hydraulic return line (T); and an
accumulator (L) to reduce the hammering effect caused
by the motor reversing direction.
On the hydraulic return line (T), install a shutoff valve (S)
for isolating the motor for servicing.
NOTICE
The Hydraulic Power Supply must be kept clean at all
times to avoid damage to the motor and hydraulic
power supply.
Blow out hydraulic lines with air and flush thoroughly
before connection to the motor.
Plug hydraulic inlets, outlets, and line ends when dis-
connecting them for any reason.
