Graco DynaMite 25D100 Parts list manual

3A5311D
EN
Instructions - Parts
Tandem Heavy Duty
DynaMite™Supply
System
Used for precision dispense of single component viscous materials for 1 gallon (3.79 liter)
containers. For professional use only.
Not approved for use in European explosive atmosphere locations.
Part No. 25D100, 25R495
1200 psi (8.3 MPa, 83 bar) Maximum Fluid Working Pressure
100 psi (0.7 MPa, 7 bar) Maximum Air Inlet Pressure
Important Safety Instructions
Read all warnings and instructions in this manual
and in all related manuals. Save all instructions.

23A5311D
Contents
Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Part Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Component Identification . . . . . . . . . . . . . . . . . . . . 7
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
System Location and Setup . . . . . . . . . . . . . . . . 8
Connect and Disconnect Tubes . . . . . . . . . . . . . 9
Flush the System . . . . . . . . . . . . . . . . . . . . . . . . 9
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Dispense Material . . . . . . . . . . . . . . . . . . . . . . . 10
Adjust the Low Level Switch . . . . . . . . . . . . . . . 11
Light Tower Operation . . . . . . . . . . . . . . . . . . . 11
Replacing a Material Pail . . . . . . . . . . . . . . . . . 11
Shutdown and Care of the System . . . . . . . . . . 12
Pressure Relief Procedure . . . . . . . . . . . . . . . . 12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Tandem Heavy Duty DynaMite Supply System,
25D100, 25R495 . . . . . . . . . . . . . . . . . . . . 15
Tandem Heavy Duty Supply Unit, 25D098 . . . . 16
Tandem Hose Kit, 25D099, 25R496 . . . . . . . . . 19
System Logic Diagram . . . . . . . . . . . . . . . . . . . . . 20
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Technical Specifications . . . . . . . . . . . . . . . . . . . . 23
California Proposition 65 . . . . . . . . . . . . . . . . . . . 23
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 24
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . 24

Related Manuals
3A5311D 3
Related Manuals
Part Numbers
Overview
The Tandem Heavy Duty DynaMite Supply System is
designed to provide continuous dispensing of material
by having two DynaMite 190 Extruders supplying mate
rial to the same dispensing equipment. This method
avoids having to interrupt production when replacing a
pail of material.
Only one supply pump is active at a time. The system
automatically starts the non-active supply pump when
the active supply pump is done dispensing material.
This enables the operator to replace the pail of material
for the pump that just completed dispensing while the
other pump continues to dispense material.
This process is controlled by a switch on each supply
pump that is triggered when the pump reaches its low
limit. When the system stops that pump from dispensing
and actuates the other pump, the light tower signals the
operator that it is time to replace the pail of material.
Manuals
Part Description
308302 DynaMite™190 Extruder Instructions - Parts
3A3442 NXT Air Motor Repair and Parts Manual
Part No. Maximum Fluid
Working Pressure Description
25D100 1200 psi (8.3 MPa, 83 bar)
Tandem Heavy Duty DynaMite Supply System with hoses, 5/8 x
120-outlet - Approved
25R495 1200 psi (8.3 MPa, 83 bar)
Tandem Heavy Duty DynaMite Supply System with hoses, 3/4 x
120-outlet - Approved

Warnings
43A5311D
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama
tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When
these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific
hazard symbols and warnings not covered in this section may appear throughout the body of this manual where
applicable.
SKIN INJECTION HAZARD
High-pressure fluid from spray gun, dispensing device, hose leaks, or ruptured components will pierce
skin. This may look like just a cut, but it is a serious injury that can result in amputation. Get immediate
surgical treatment.
• Do not point the dispensing device at anyone or at any part of the body.
• Do not put your hand over the fluid outlet.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Follow the Pressure Relief Procedure when you stop dispensing and before cleaning, checking, or
servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses and couplings daily. Replace worn or damaged parts immediately.
MOVING PARTS HAZARD
Moving parts can pinch, cut or amputate fingers and other body parts.
• Keep clear of moving parts.
• Do not operate equipment with protective guards or covers removed.
• Pressurized equipment can start without warning. Before checking, moving, or servicing equipment,
follow the Pressure Relief Procedure and disconnect all power sources.

Warnings
3A5311D 5
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. Paint or sol
vent flowing through the equipment can cause static sparking. To help prevent fire and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop
cloths (potential static sparking).
• Ground all equipment in the work area. See Grounding instructions.
• Never spray or flush solvent at high pressure.
• Keep work area free of debris, including solvent, rags and gasoline.
• Do not plug or unplug power cords, or turn power or light switches on or off when flammable fumes
are present.
• Use only grounded hoses.
• Hold dispensing device/gun firmly to side of grounded pail when triggering into pail. Do not use pail
liners unless they are anti-static or conductive.
•Stop operation immediately if static sparking occurs or you feel a shock.Do not use equipment until
you identify and correct the problem.
• Keep a working fire extinguisher in the work area.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or
swallowed.
• Read Safety Data Sheet (SDS) to know the specific hazards of the fluids you are using.
• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.
SPLATTER HAZARD
Hot or toxic fluid can cause serious injury if splashed in the eyes or on skin. During blow off of platen,
splatter may occur
• Use minimum air pressure when removing platen from drum.

Warnings
63A5311D
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system com
ponent. See Technical Specifications in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Specifica
tions in all equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete infor
mation about your material, request Safety Data Sheet (SDS) from distributor or retailer.
• Do not leave the work area while equipment is energized or under pressure.
• Turn off all equipment and follow the Pressure Relief Procedure when equipment is not in use.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine manu
facturer’s replacement parts only.
• Do not alter or modify equipment. Alterations or modifications may void agency approvals and create
safety hazards.
• Make sure all equipment is rated and approved for the environment in which you are using it.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury, including
eye injury, hearing loss, inhalation of toxic fumes, and burns. Protective equipment includes but is not
limited to:
• Protective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and solvent manufacturer.

Component Identification
3A5311D 7
Component Identification
Key:
A DynaMite 190 Extruders (Supply Pumps)
BTable
C Light Tower
D Low Level Switches
E Material Supply Line
F Air Valve
G Bypass Valves
H Bypass Valve Controls
J Material Check Valves
K Air Shut Off Valve
L Air Inlet Manifold
M Shuttle Valve
N Light Tower Activation Pressure Switch
P Light Tower Power Cord
R Mounting Holes
S Pail Support
FIG. 1: System Components
A
E
G
H
B
F
C
A
G
H
D
N
K
J
L
Rear View
P
Under Tabletop View
MR
S

Installation
83A5311D
Installation
NOTE: See DynaMite 190 Extruder Instructions - Parts
manual 308302 for specific DynaMite pump installation
information, including wiper plate setup and pump com
ponents and accessories
Grounding
Pump: for both pumps, unscrew the green grounding
screw (W) and washer (X) located on the ram base (Z).
Install a 1.5 mm2(12 awg) minimum ground wire (Y)
and secure with the screw and washer. Connect the
other end of the ground wire to a true earth ground.
Air and fluid hoses: use only electrically conductive
hoses with a maximum of 500 ft. (150 m) combined
hose length to ensure grounding continuity. Check elec
trical resistance of hoses. If total resistance to ground
exceeds 29 megohms, replace hose immediately.
Air compressor: follow manufacturer’s recommenda
tions.
Spray gun / Dispense valve: ground through connec
tion to a properly grounded fluid hose and pump.
Fluid supply container: follow local code.
To maintain grounding continuity when flushing or
relieving pressure: hold metal part of the spray
gun/dispense valve firmly to the side of a grounded
metal pail, then trigger the gun/valve.
System Location and Setup
NOTE: The letters in parentheses used in this descrip
tion refer to the callouts in Figure 1 on page 7.
1. Move the machine using a fork lift or pallet jack.
Insert the forks under the table’s lower shelf.
2. Place the unit on a hard, level surface. Check that
the unit is level in all directions. Refer to Dimen
sions on page 21 to ensure that there is sufficient
overhead clearance. Leave room on both sides so
the air regulators on the supply pumps will be easily
accessible.
3. Mount the table (B) to the floor using four 1/2 in. (12
mm) bolts through the table’s mounting holes (R).
4. Plug the light tower power cord (P) into a wall outlet.
5. Connect an air supply hose to the 1/4 npt air shut off
valve (K) on the main air inlet manifold (L).
The equipment must be grounded to reduce the risk
of static sparking. Static sparking can cause fumes to
ignite or explode. Grounding provides an escape wire
for the electric current.
FIG. 2: Grounding Connection on Pump
Z
Y
W
X
FIG. 3: Air Supply Hose Connection
Air Inlet
Shut Off
Valve

Installation
3A5311D 9
Connect and Disconnect Tubes
Follow these steps when connecting and disconnecting
any air tubes on the tandem DynaMite supply system.
Connection
1. Grasp the tube, then slowly push it straight into the
fitting until it stops.
2. Be sure that the tube is securely connected, and will
not pull out when air pressure is applied. To check,
pull gently on the tube.
Disconnection
1. Follow the Pressure Relief Procedure on page 12.
2. Push evenly on the fitting’s red release button.
3. While holding the release button in, pull the tube out
of the fitting.
4. To reuse the tubing, cut off the previous connection
portion at 90°, being careful not to damage the outer
diameter of the tube.
NOTE: Use of a tube cutter is recommended. The fitting
will leak if the tubing is not cut at 90°.
Flush the System
NOTE: The pumps in the tandem supply system are
tested with lightweight oil, which is left in to protect the
pump parts. If the fluid you are using might be contami
nated by the oil, flush it out with a compatible solvent
before using the pump.
Flush with a fluid that is compatible with the fluid you are
pumping and with the wetted parts in your system.
Check with your fluid manufacturer or supplier for rec
ommended fluids and flushing frequency. Always flush
the pump before fluid dries on the displacement rod.
Refer to DynaMite 190 Extruder Instructions - Parts
manual 308302 for instructions on how to flush the
DynaMite 190 Extruder pumps.
To avoid fire and explosion, always ground equipment
and waste container. To avoid static sparking and
injury from splashing, always flush at the lowest pos
sible pressure.
NOTICE
Never leave water or water-based fluid in a carbon
steel pump overnight. If you are pumping
water-based fluid, flush with water first, then with a
rust inhibitor, such as mineral spirits. Relieve pres
sure, but leave rust inhibitor in the pump to protect
parts from corrosion.

Operation
10 3A5311D
Operation
NOTE: Refer to the DynaMite 190 Extruder Instructions
- Parts, manual 308302, for specific operation informa
tion about the DynaMite 190 Extruder.
NOTE: The letters in parentheses used in this section
refer to the callouts in Figure 1 on page 7.
Startup
1. Install a pail of material in the active supply pump.
as described in the Start and Adjust the Ram sec
tion of DynaMite 190 Extruder Instructions - Parts,
manual 308302.
2. Perform the steps described in Start and Adjust the
Pump and Prime the Pump and Pump Fluid sec
tions of DynaMite 190 Extruder Instructions - Parts,
manual 308302.
3. Turn the bypass valve control (H) on the non-active
supply pump to the ON position.
4. Install a pail of material in the non-active supply
pump as described in the Start and Adjust the Ram
section of DynaMite 190 Extruder Instructions -
Parts, manual 308302.
5. Perform the steps described in Start and Adjust the
Pump and Prime the Pump and Pump fluid sections
of DynaMite 190 Extruder Instructions - Parts, man
ual 308302.
6. Turn the bypass valve control (H) on the non-active
supply pump to the OFF position.
Dispense Material
1. Connect the material supply line (E) to the dispens
ing equipment. Refer to the instructions included
with the dispensing equipment for making connec
tions.
2. Make sure the pumps and lines are primed and with
adequate air pressure and volume supplied.
3. Use the air motor regulator on the pump to control
the pump speed and fluid pressure.
To reduce the risk of serious injury and damage to
equipment, do not shut off the air supply to the ram or
the pumps when the ram is raised. Doing so will
cause the pump to fall uncontrolled to the bottom.
Also, as the ram is raised and lowered, the wiper
plate, ram tubes, and pump mounting bracket move.
To reduce the risk of pinching or amputation or fin
gers, keep your hands away from the wiper plate, lip
of the material can, pump bracket, ram tubes, and air
motor coupling cavity while the pump is operating.
FIG. 4: Bypass Valve Control On
On Position
FIG. 5: Bypass Valve Control Off
NOTICE
Always use the lowest air pressure necessary to get
the desired results. Higher pressures cause prema
ture tip/nozzle and pump wear.
Off Position

Operation
3A5311D 11
Adjust the Low Level Switch
The low level switches (D) are set at the factory. How
ever, you may need to make adjustments to them based
on your specific application and the material you are
using. Follow these steps and refer to Figure 6 to make
adjustments.
1. Let the supply pump dispense material to the
desired low level of material remaining in the pail.
NOTE: The low level should be as close as possible to
the point before the pump would start to run away.
2. Loosen the two low level switch screws enough to
be able to slide the low level switch up and down.
3. Adjust the low level switch and bracket so that the
switch activates when it comes into contact with the
supply pump’s air cylinder mounting plate.
4. Tighten the two screws to secure the switch and
bracket at that position.
5. Repeat steps 1 through 4 for the other supply pump.
Light Tower Operation
This process of switching from one supply pump to
another is controlled by the low level switch (D) on each
supply pump. This switch is triggered when the material
in the pump reaches its low level. See Adjust the Low
Level Switch.
When the system activates the low level switch and
actuates the other pump, the light tower (C) signals the
operator that it is time to replace the pail of material.
Replacing a Material Pail
When the light tower signal is red, it is time to replace
one of the pails.
1. Turn the bypass valve control (H) to the ON position
on the non-active supply pump with the empty pail.
2. Replace the pail. Refer to DynaMite 190 Extruder
Instructions - Parts, manual 308302.
3. Turn the bypass valve control (H) to its OFF posi
tion.
The light tower signal returns to green and the
non-active supply pump is now ready when the active
supply pump reaches a low level.
FIG. 6: Low Level Switch Adjustment
Low Level
Low Level
Air Cylinder
Mounting Plate
Switch
Bracket
Switch Screws
Bracket View
Switch View
Light Tower Signal
Green Both Supply pumps have material and are
ready or are actively pumping.
Red
One or both of the supply pumps has
reached the low level limit. Replace the pail
as soon as possible.
NOTICE
The tandem supply system does not automati
cally stop pumping if both pails reach low level; it
continues to pump until the active supply pump
is empty. When the red light is on, make sure you
replace the empty pail before the material reaches its
low limit in the active pail. If the non-active supply
pump pail is not replaced, the active pump continues
to accelerate, damaging the pump and possibly
inducing air into the material lines.

Operation
12 3A5311D
Shutdown and Care of the
System
1. Stop the pumps at the bottom of the stroke to pre
vent fluid from drying on the exposed displacement
rod and damaging the throat packings.
2. Set the ram director valve on the supply pump to the
down position. See Figure 7.
3. Follow the Pressure Relief Procedure on page 12.
4. Always flush the pumps before the fluid dries on the
displacement rods.
Pressure Relief Procedure
Follow the Pressure Relief Procedure whenever
you see this symbol.
1. Lock the dispensing device of the equipment that is
being used with this supply system.
2. Turn off the main air supply and disconnect the
main air line from the air shut off valve (K) on the
machine.
3. Set the ram director valve to the down position. The
ram slowly drops.
4. Quickly move the ram director valve up and down to
bleed air from the ram cylinder.
5. Unlock the dispensing device.
6. Hold a metal part of the dispensing device firmly to
the side of a grounded container and trigger the
device to relieve pressure.
7. Lock the dispensing device.
NOTICE
Never leave water or water-based fluid in a carbon
steel pump overnight. If you are pumping
water-based fluid, flush with water first, then with a
rust inhibitor, such as mineral spirits. Relieve pres
sure, but leave rust inhibitor in the pump to protect
parts from corrosion.
This equipment stays pressurized until pressure is
manually relieved. To help prevent serious injury from
pressurized fluid, such as skin injection, splashing
fluid, and moving parts, follow the Pressure Relief
Procedure when you stop dispensing and before
cleaning, checking, or servicing the equipment.
FIG. 7: Pressure Relief Components
Ram Director Valve
Main Air Line
Pressure Gauge

Operation
3A5311D 13
8. Open the pump bleeder valve.
9. Leave the pump bleeder valve open until you are
ready to dispense again.
If you suspect that the spray tip/nozzle or hose is com
pletely clogged, or that pressure has not been fully
relieved, proceed as follows:
10. Have a container ready to catch the drainage.
11. Very slowly loosen the hose end coupling to relieve
pressure gradually; then loosen it completely.
12. Clear the tip/nozzle or hose.
FIG. 8: Open Valves
Pump Bleeder Valve

Troubleshooting
14 3A5311D
Troubleshooting
Before servicing this equipment always make sure to
follow the Pressure Relief Procedure on page 12.
NOTE: See DynaMite 190 Extruder Instructions - Parts,
manual 308302 for specific DynaMite 190 troubleshoot
ing information.
Problem Cause Solution
Neither supply pump operates. No inlet air to the tandem supply
system.
Connect an air supply to the supply
system’s air inlet.
Make sure there are no kinks in the
airlines.
Non-active pump does not pump for
priming.
Bypass valve is turned off. Turn on the bypass valve. See
Startup on page 10.
Non-active pump does not raise or
lower the ram.
Bypass valve is turned off. Turn on the bypass valve. See
Startup on page 10.
Light tower does not turn on. No power to the light tower. Plug light tower power supply into a
wall outlet.
Light tower does not change to red
color when low level switch is acti
vated.
No air to the pressure switch. Check all air lines.
Maker sure there are no kinks in the
airlines.
Make sure the pressure switch is
working properly.
Make sure the shuttle valve is work
ing properly.
Low level switch is not activating the
light tower.
No air to the pressure switch. Check all air lines.
Maker sure there are no kinks in the
airlines.
Make sure the pressure switch is
working properly.
Make sure the shuttle valve is work
ing properly.
Make sure the low level switch is
properly adjusted. See Adjust the
Low Level Switch on page 11.
No material flowing to the dispense
valve.
No inlet air to the supply system. Connect an air supply to the supply
system’s air inlet.
Make sure there are no kinks in the
airlines
Active supply pump is not primed Prime the pump. See Startup on
page 10.

Parts
3A5311D 15
Parts
Tandem Heavy Duty DynaMite Supply System, 25D100, 25R495
FIG. 9: Tandem Heavy Duty DynaMite Supply System
21
Tighten included bolts to secure clamp to table.
3
3
10
Ref Part Description Quantity
25D100 25R495
1 25D098 SUPPLY UNIT, tandem, extruder, 190, uhd 1 1
2 25D099 KIT, HOSE, tandem, 5/8 x 120 - outlet 1 ---
25R496 KIT, HOSE, tandem, 3/4 x 120 - outlet --- 1
10 17T615 INSERT, pail, extruder 2 2

Parts
16 3A5311D
Tandem Heavy Duty Supply Unit, 25D098
FIG. 10: Tandem Supply Unit - View 1, Left Supply Pump without Air Tubing
101(x2)
104(x2)
104(x2)
105(x2)
153(x2)
107(x4)
102(x2)
106(x2)
107(x4)
117(x2)
112(x4)
111(x2)
115(x2)
113(x2)
108(x4)
108(x4)
109(x4)
114(x2)
116(x2)
122(x2)
118(x2)
119(x2)
113
113
121
119(x2)
120
112
150A
151A
151A

Parts
3A5311D 17
FIG. 11: Tandem Supply Unit - View 2, Rear and Under Tabletop without Air Tubing
128(x4)
125(x8)
131
123
126(x8)
133
132
134
127
130(x4)
129(x4)
138
136
135 113(x2)
141(x2) 143(x2)
142(x2)
115(x3)
141(x2)
140 (x2)
137
139
Under Tabletop View
136
133
145(x2)
144
1. Apply pipe sealant to all no swivel pipe threads.
Do not over tighten.
6
6
152

Parts
18 3A5311D
25D098 Parts List
* Not shown.
Warning Labels for 25D097
Replacement Danger and Warning labels, tags, and
cards are available at no cost.
Ref Part Description Qty
101 25D097 SUPPLY UNIT, extruder, ss,
190, uhd 2
102 25C843 PLATE, wiper, 1 gal, heavy duty 2
104 C20362 FITTING, tee, air, qd, 1/4 tube 4
105 17T079 BRACKET, tandem, valve,
switch 2
106 C06182 VALVE, limit, air 2
107 297863 SCREW, cap, socket head 8
108 188773 WASHER, flat 8
109 C19208 WASHER, lock 4
111 100139 PLUG, pipe 2
112 C06061 MUFFLER, sintered, dia 1/8 5
113 597151 FITTING, elbow 9
114 17S873 VALVE, air, 3 way, spring, 1/4
npt 2
115 C19407 FITTING, connector, male 5
116 125733 FITTING, tee, 1/4 tube x 1/4 npt 2
117 100840 FITTING, elbow, street 2
118 15B565 VALVE, ball 2
119 114109 FITTING, elbow, male, swivel 4
120 17T081 BRACKET, tandem, valve 1
121 113338 VALVE, air, remote, 4 way 1
122 104705 SCREW, cap, sch 2
123 17T090 TABLE, custom, 38 x 20 x 32,
steel 1
125 100214 WASHER, lock 8
126 17S889 NUT, custom, m5, cs 8
127 17S888 FLANGE, mounting, pipe, light
tower 1
128 C19810 SCREW, cap, socket hd 4
129 110755 WASHER, plain 4
130 100015 NUT, hex mscr 4
131 17S747 PIPE, aluminum, sch 40, 1/2 npt,
36l 1
Ref Part Description Qty.
132 127087 LIGHT, tower, 30 mm, red/grn 1
133 17S867 HARNESS, m12, light tower 1
134 82/0143/
11 VALVE, shuttle, 1/8 npt, f 1
135 103656 FITTING, pipe, hex 1
136 17S842 SWITCH, pressure, air, 20 psi,
1/8 npt 1
137 17S995 MANIFOLD, 3 port, 1/4 npt,
alum, 1000 psi 1
138 101754 PLUG, pipe, 3/8 nptf 1
139 118758 FITTING, adapter 1
140 111821 SCREW, cap, sch 2
141 107016 WASHER, plain 4
142 100079 WASHER, lock, spring 2
143 100284 NUT, hex mscr 2
144 17S872 CABLE, power,100-240 v, 24 dc,
36 w 1
145 84/0805/
89
CABLE, tie mount, 1 x 1 sq w/
adhesive 2
146 054130* TUBE, plyeth .250 od 28 ft.
147 114958* STRAP, tie 10
149 054106* TUBE, plyeth .375 od 20 ft.
152 129775 VALVE, sleeve, shutoff, 1/4, mxf 1
153 17U289 PLATE, mounting, valve 2
Ref Part Description Quantity per
Supply Unit
150A 186505LABEL, warning 1
151A 186502LABEL, warning 3

Parts
3A5311D 19
Tandem Hose Kit, 25D099, 25R496
FIG. 12: Tandem Hose Kit
206(x2)
210
205
214
214
201
204(x2)
203(x2)
202(x2)
208(x2)
211(x4)
209
212(x2)
1. Apply pipe sealant to all male pipe threads.
Ref Part Description Quantity
25D099 25R496
201 166466 FITTING, tee, pipe, female 1 1
202 121116 FITTING, elbow, 3/4 npt m-m rt angle 2 2
203 16T480 VALVE, check 2 2
204 124286 FITTING, adapter, 3/4 npt m x 8 jic m 2 2
205 16V311 HOSE, assy, ss brd, 5/8 x 120, ss 1 ---
16D286 HOSE, assy, ss brd, 3/4 x 120, ss --- 2
206 6313-93-SS HOSE, assy, ss brd, 5/8 x 32, ss 2 2
208 116703 ADAPTER, 3/4-16 jic x 1/4 npt 2 2
209 17T280 PLATE, mounting, check valve 1 1
210 17T281 PLATE, clamping, check valve 1 1
211 110580 SCREW, cap, socket hd 4 4
212 130279 BOLT, u, 5/16-18, 1.75 id, steel 2 2
214 15Y934 FITTING, 5/8 jic x 3/4 npt 2 ---
C20708 FITTING, 3/4 jic x 3/4 npt --- 2

System Logic Diagram
20 3A5311D
System Logic Diagram
FIG. 13: Tandem Heavy Duty DynaMite Supply System Logic Diagram
INLET
MANIFOLD
17S995
PLANT AIR
100 PSI MAX
203
RIGHT PUMP
25D097
LEFT PUMP
25D097
INEX AB
SOL-1
113338
EB P EA
B A 000
100
100
EB P EA
B A
SW-1
C06182
SW-2
C06182
A
EAP
BYPASS-1
17S873
103
BV-1
102
101
101
105
105
104
A
EAP
BYPASS-2
17S873
203
202
201
204
BV-2
000
200
204
205
205
200201
106 206
106 106
206
206
AIR IN
PRESSURE
SWITCH
17S842
COM
NC NO
1
M12 5 PIN
FEMALE
2 3 4 5
HARNESS
17S867
-V+V
100-240V
50-60HZ
3
3
24V
41
3
24V
1 2 3 4 5
LIGHT
TOWER
127087
POWER
SUPPLY
17S872
PB PA
SHUTTLE
VALVE
82/0143/11
103
