Graco High-Flo JS17A8 User manual

Instructions - Parts List
High-Flo®4-Ball and High-Flo®
Plus 4-Ball Pumps with XL Air
Motor 3A6938D
EN
Air-powered pumps for low pressure, high volume circulation of finishing materials. Do
not use for flushing or purging lines with caustics, acids, abrasive line strippers, and other
similar fluids. For professional use only.
See Models, page 3, for model information.
Important Safety Instructions
Read all warnings and instructions in this
manual before using the equipment.
Save these instructions.
II 2 G
Ex h IIB T3 Gb
0°C Ta 60°C
Pumps are shown on optional floor stands.

Related Manuals
23A6938D
Contents
Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Typical Installation . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Plumbing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Flush Before Using Equipment . . . . . . . . . . . . . . 8
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Pressure Relief Procedure . . . . . . . . . . . . . . . . . 9
Prime the Pump . . . . . . . . . . . . . . . . . . . . . . . . . 9
Stop Pump at Bottom of Stroke . . . . . . . . . . . . 10
Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Preventive Maintenance Schedule . . . . . . . . . . 11
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Reassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
High-Flo Pumps 1500cc or 2000cc with Sealed
4-Ball Lowers . . . . . . . . . . . . . . . . . . . . . . . 16
High-Flo Plus Pumps 2500cc, 3000cc, or
4000cc with Sealed 4-Ball Lowers . . . . . . . 16
High-Flo Pumps with 1500cc or 2000cc Open
Wet Cup 4-Ball Lowers . . . . . . . . . . . . . . . . 18
High-Flo Pumps with 750cc Sealed 4-Ball
Lowers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Motor Mounting Hole Diagrams . . . . . . . . . . . . . . 23
Performance Charts . . . . . . . . . . . . . . . . . . . . . . . . 24
Technical Specifications . . . . . . . . . . . . . . . . . . . . 27
California Proposition 65 . . . . . . . . . . . . . . . . . . . 27
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 28
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . 28
Related Manuals
Manual in
English Description
3A5423 XL™ 6500 and 3400 Air Motors
3A5348 Repair/Parts Manual, Sealed 4-Ball Plus Lowers
333022 Sealed 4-Ball Lowers
3A3452 4-Ball Lowers with Open Wet Cup
311619 Pump Mounting Kits

Models
3A6938D 3
Models
Your model number is marked on the pump identification plate located toward the rear of the air motor.
To determine the model number of your pump from the following matrix, select the six digits which describe your
pump. The first digit is always J for circulation pumps. The remaining five digits define the construction.
For example, a circulation pump with stainless steel construction, a 1.7:1 ratio, low noise exhaust, no DataTrak
option, a sealed lower with tri-clamp fittings, and an Ultralife rod and cylinder is model number JS17A8.
To order replacement parts, see page 16.
*Not all lower combinations are available. Consult the product brochure for available models.
JS 17 A 8
First Digit Second
Digit Third and Fourth Digit Fifth Digit Sixth Digit
Pump Fluid
Component
Material Ratio Code ‡ Motor Size Lower Size Exhaust DataTrak™LowerStyleand Fittings* Rod Cylinder
J
(all
circulation
pumps)
C
(carbon
steel) 17 3400 4000 ALow
Noise No 5Sealed, tri-clamp, NPT Chrome Chrome
S
(stainless
steel) 23 3400 3000 BLow
Noise Yes 6Sealed,
tri-clamp, NPT Ultralife Ultralife
28 3400 2500 CRemote No 8Sealed, tri-clamp Ultralife Ultralife
33 6500 4000 DRemote Yes 9Open Wet Cup,
NPT Ultralife Ultralife
35 3400 2000 0Open Wet Cup,
tri-clamp Ultralife Ultralife
44 6500 3000
45 3400 1500
53 6500 2500
90 3400 750
‡ Ratio Code
XX = X.X:1 ratio

Warnings
43A6938D
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-
tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When
these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific
hazard symbols and warnings not covered in this section may appear throughout the body of this manual where
applicable.
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. Paint or sol-
vent flowing through the equipment can cause static sparking. To help prevent fire and explosion:
• Use equipment only in well ventilated area.
• Eliminateallignitionsources; suchas pilotlights,cigarettes,portableelectric lamps,andplasticdrop
cloths (potential static sparking).
• Ground all equipment in the work area. See Grounding instructions.
• Never spray or flush solvent at high pressure.
• Keep work area free of debris, including solvent, rags and gasoline.
• Do not plug or unplug power cords, or turn power or light switches on or off when flammable fumes
are present.
• Use only grounded hoses.
• Hold gun firmly to side of grounded pail when triggering into pail. Do not use pail liners unless they
are anti-static or conductive.
•Stop operation immediately if static sparking occurs or you feel a shock.Do not use equipment
until you identify and correct the problem.If there is static sparking or you feel a shock, stop oper-
ation immediately. Do not use equipment until you identify and correct the problem.
Static charge may build up on plastic parts during cleaning and could discharge and ignite flammable
vapors. To help prevent fire and explosion:
• Clean plastic parts only in a well ventilated area.
• Do not clean with a dry cloth.
• Keep a working fire extinguisher in the work area.
PRESSURIZED EQUIPMENT HAZARD
Fluid from the equipment, leaks, or ruptured components can splash in the eyes or on skin and cause
serious injury.
• Follow the Pressure Relief Procedure when you stop spraying/dispensing and before cleaning,
checking, or servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses, tubes, and couplings daily. Replace worn or damaged parts immediately.

Warnings
3A6938D 5
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Donotexceedthemaximumworkingpressureor temperatureratingofthelowestratedsystemcom-
ponent. See Technical Specifications in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Specifi-
cations in all equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete
information about your material, request Safety Data Sheet (SDS) from distributor or retailer.
• Turn off all equipment and follow the Pressure Relief Procedure when equipment is not in use.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine manu-
facturer’s replacement parts only.
• Donotalterormodifyequipment.Alterationsormodificationsmayvoidagencyapprovalsand create
safety hazards.
• Make sure all equipment is rated and approved for the environment in which you are using it.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
MOVING PARTS HAZARD
Moving parts can pinch, cut or amputate fingers and other body parts.
• Keep clear of moving parts.
• Do not operate equipment with protective guards or covers removed.
• Pressurizedequipmentcan start withoutwarning. Before checking, moving, or servicing equipment,
follow the Pressure Relief Procedure and disconnect all power sources.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or
swallowed.
• Read Safety Data Sheet (SDS) to know the specific hazards of the fluids you are using.
• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury, including
eye injury, hearing loss, inhalation of toxic fumes, and burns. Protective equipment includes but is not
limited to:
• Protective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and solvent manufacturer.

Typical Installation
63A6938D
Typical Installation
Key:
AMixTank
B Pump Stand
C Fluid Supply Line; 1-1/2 in. (38 mm) minimum diameter
D Fluid Shutoff Valve
E Fluid Line
FPump
G Surge Tank
H Air Shutoff Valve (bleed-type)
J Air Supply Line
K Air Line Filter
L Air Regulator and Gauge
M Master Air Valve (bleed-type)
N Fluid Drain Valve
P Air Line Drain Valve
Y Pump Ground Wire (required, see page 7 for installation)
FIG. 1. Typical Installation

Installation
3A6938D 7
Installation
Grounding
Pump: use a ground wire and clamp (not included). See
FIG. 2. Remove the green ground screw (Z) from the
bottom of the air motor. Insert the screw through the
loop on the end of the ground wire (Y) and reattach the
screw to the air motor. Connect the ground clamp to a
true earth ground. Order Part No. 244524, Ground Wire
and Clamp.
Air and fluid hoses: use only electrically conductive
hoses with a maximum of 500 ft. (150 m) combined
hose length to ensure grounding continuity. Check the
electrical resistance of hoses. If the total resistance to
ground exceeds 25 megohms, replace hose immedi-
ately.
Air compressor: follow manufacturer’s recommenda-
tions.
Surge tank: use a ground wire and clamp.
Dispense valve: ground through a connection to a
properly grounded fluid hose and pump.
Fluid supply container: follow local code.
Object being sprayed: follow local code.
Solvent pails used when flushing: follow local code.
Use only conductive metal pails, placed on a grounded
surface. Do not place the pail on a non-conductive sur-
face, such as paper or cardboard, which interrupts
grounding continuity.
To maintain grounding continuity when flushing or
relieving pressure: hold metal part of the spray gun or
valve firmly to the side of a grounded metal pail, and
then trigger the gun or open the valve.
Mounting
The pump can be mounted using one of the following
options:
• Stand mount: Kit 253692
• Wall mount: Kit 255143
• Floor mount:
• Kit 19Y313—Complete kit
• Kit 19Y286—Plate for mounting to an existing
floor mount
Pump Mounting Kits manual 311619 describes the
mount parts and how to install each.
The equipment must be grounded to reduce the risk
of static sparking. Static sparking can cause fumes to
ignite or explode. Grounding provides an escape wire
for the electric current.
FIG. 2. Ground Wire
TI8250a
Z Y

Installation
83A6938D
Plumbing
Install a fluid shutoff valve (D) between the mix tank (A)
and the pump (F).
When using a stainless steel pump, use stainless steel
plumbing to maintain a corrosion-resistant system.
Flush Before Using Equipment
The equipment was tested with lightweight oil, which is
left in the fluid passages to protect parts. To avoid con-
taminating your fluid with oil, flush the equipment with a
compatible solvent before using the equipment. See
Flushing the Fluid Supply Lines, page 11.
Accessories
Install the following accessories in the order shown in
FIG. 1, page 6, using adapters as necessary.
Fluid Line
See FIG. 1, page 6.
•Fluid shutoff valve (D): shuts off fluid flow.
•Fluid filter: with a 60 mesh (250 micron) stainless
steel element to filter particles from the fluid as it
leaves the pump.
•Fluid drain valve (N): required in your system, to
relieve fluid pressure in the hose and gun.
Air Line
See FIG. 1, page 6.
•Second bleed-type air valve (H): isolates air line
accessories for servicing. Locate upstream from all
other air line accessories.
•Air line filter (K): removes harmful dirt and mois-
ture from compressed air supply.
•Pump air regulator (L): to control pump speed and
outlet pressure. Locate close to the pump.
•Bleed-type master air valve (M): required in your
system to relieve air trapped between it and the air
motor when the valve is closed.
NOTICE
To prevent a bellows failure in a sealed 4-ball pump:
• Do not exceed fluid inlet pressure of 15 psi (0.1
MPa, 1.0 bar).
• Do not use a ball check pump on the inlet side of
this pump.
• Do not use a suction tube with a check valve on
the inlet side of this pump.
Trapped air can cause the pump to cycle unexpect-
edly, which could result in serious injury from splash-
ing or moving parts. Be sure the valve is easily
accessible from the pump and located downstream
from the air regulator. Be sure the air bleed hole
points away from the operator.
To help prevent fluid over pressurization, do not
exceed the maximum air inlet pressure rating to the
air motor (see page 27). If you can apply more than
the maximum air input pressure to the system, install
a safety relief valve between the bleed-type master
air valve and the air motor. The safety relief valve
must be set to open if the air inlet pressure to the
motor exceeds the motor rating.

Operation
3A6938D 9
Operation
Pressure Relief Procedure
Follow the Pressure Relief Procedure
whenever you see this symbol.
1. Close the bleed-type master air valve (M).
2. Open the dispensing valve, if used.
3. Open all fluid drain valves (N) in the system, having
a waste container ready to catch drainage.
4. Leave drain valve(s) open until you are ready to
pump again.
Prime the Pump
1. Fill the wet cup with Throat Seal Liquid (TSL).
NOTE: Sealed 4-ball lowers with bellows do not
require TSL.
NOTE: During operation the TSL level in the wet cup will
fluctuate slightly at pump changeover.
2. Close pump air regulator (L) by turning the knob
counterclockwise, reducing pressure to zero. Close
the bleed-type air valve (H). Also verify that all drain
valves (N) are closed.
3. Connect air line (J) to bleed type air valve (H).
4. Check that all fittings throughout system are tight-
ened securely.
5. Connect the fluid supply line (C) from the mix tank
shutoff valve (D) to the pump.
6. Connect the fluid line (E) to the pump outlet or surge
suppressor outlet (G), if used.
NOTE: If your pump has DataTrak, see your separate
XL air motor manual for DataTrak instructions.
7. DataTrak equipped units with runaway protection
only: enable the prime/flush function by pushing the
prime/flush button on the DataTrak.
8. Open bleed-type air valve (H). Slowly turn pump air
regulator (L) clockwise, increasing pressure until
pump starts.
9. Cycle pump slowly until all air is pushed out and
pump and hoses are fully primed.
10. DataTrak equipped units with runaway protection
only: disable the prime/flush function by pushing the
prime/flush button on the DataTrak.
11. Close the fluid shutoff valve (D) downstream of the
pump. The pump should stall against pressure.
NOTE: In a circulation system, the pump operates con-
tinuously until the power supply is shut off. In a
direct-supply system, the pump starts when the dis-
pense valve is opened, and stops when the dispense
valve is closed.
This equipment stays pressurized until pressure is
manually relieved. To help prevent serious injury from
splashing fluid and moving parts, follow the Pressure
Relief Procedure when you stop spraying and before
cleaning, checking, or servicing the equipment.
NOTICE
Do not allow the pump to run quickly for a long period
of time as this may damage the packings.

Operation
10 3A6938D
Stop Pump at Bottom of Stroke
Relieve the pressure when you stop the pump for any
reason. Stop the pump on the down stroke, before the
air motor changes over.
Shutdown
Follow the Pressure Relief Procedure, page 9.
Always flush the pump before the fluid dries on the dis-
placement rod. See Flushing the Fluid Supply Lines
on page 11.
NOTICE
Failure to stop the pump at the bottom of its stroke
allows fluid to dry on the piston rod (R), which can
damage the throat seal.

Maintenance
3A6938D 11
Maintenance
Preventive Maintenance
Schedule
The operating conditions of your particular system
determine how often maintenance is required. Establish
a preventive maintenance schedule by recording when
and what kind of maintenance is needed, and then
determine a regular schedule for checking your system.
Your schedule shouldinclude the maintenance activities
described in the following sections.
Flushing the Fluid Supply Lines
• Flush before changing colors, before fluid can dry in
the equipment, at the end of the day, before storing,
and before repairing equipment.
• Flush at the lowest pressure possible. Check con-
nectors for leaks and tighten as necessary.
• Flush with a fluid that is compatible with the fluid
being dispensed and the equipment wetted parts.
Cleaning the Air Line Filter
Drain and clean as necessary.
Checking the Mix Tank Volume
Performing a Stall Test
Perform a stall test periodically to ensure the piston seal
is in good working condition and to prevent system
over-pressurization:
Close the fluid shutoff valve (D) closest to the pump on
the down stroke and be sure that the pump stalls. Open
the fluid shutoff valve to restart the pump. Close thefluid
shutoff valve (D) closest to the pump on the upstroke
and be sure that the pump stalls.
Stop the pump on the down stroke, before the air motor
changes over.
Changing the TSL On Wet Cup Models
On Wet Cup Models check the condition of the TSL and
the level in the wet cup every week, minimum. TSL
should be changed at least every month.
To avoid fire andexplosion, alwaysground equipment
and waste container. To avoid static sparking and
injury from splashing, always flush at the lowest pos-
sible pressure.
NOTICE
Do not let the mix tank run dry. When the tank is
empty, the pump demands more power as it tries to
suck in some fluid. This causes the pump to run too
fast, which can seriously damage the pump.
NOTICE
Do not allow the pump to run quickly for a long period
of time as this may damage the seal.
NOTICE
Failure to stop the pump at the bottom of its stroke
allows fluid to dry on the piston rod (R), which can
damage the throat seal when the pump is restarted.

Troubleshooting
12 3A6938D
Troubleshooting
1. Follow the Pressure Relief Procedure, page 9,
before checking or servicing pump.
Problem Cause Solution
Pump output low on both strokes. Restricted air supply lines. Clear any obstructions; be sure all shutoff
valves are open; increase pressure, but
do not exceed maximum working pres-
sure.
Exhausted fluid supply. Refill and reprime pump.
Clogged fluid outlet line, valves, etc. Clear.
Worn piston packing. Replace. See lower manual.
Pump output low on only one stroke. Held open or worn ball check valves. Check and repair.
Worn piston packings. Replace. See lower manual.
No output. Improperly installed ball check valves. Check and repair.
Pump operates erratically. Exhausted fluid supply. Refill and reprime pump.
Held open or worn ball check valves. Check and repair.
Worn piston packing. Replace. See lower manual.
Pump will not operate. Restricted air supply lines. Clear any obstructions; be sure all shut
off valves are open; increase pressure,
but do not exceed maximum working
pressure.
Exhausted fluid supply. Refill and reprime pump.
Clogged fluid outlet line, valves, etc. Clear.
Damaged air motor. See air motor manual.
Fluid dried on piston rod. Disassemble and clean pump. See lower
manual. In future, stop pump at bottom of
stroke.

Repair
3A6938D 13
Repair
Disassembly
1. Relieve the pressure. Follow the Pressure Relief
Procedure, page 9.
2. Disconnect the hoses from the lower and plug the
ends to prevent fluid contamination.
3. Remove the 2-piece shield (22) by inserting a
screwdriver straight into the slot, and using it as a
lever to release the tab. Repeat for all tabs. Do not
use the screwdriver to pry the shields apart. See
FIG. 3.
4. Loosen the coupling nut (3) and remove the collars
(4). Remove the coupling nut from the piston rod
(R). Unscrew the lock nuts (7) from the tie rods (6).
Separate the motor (1) and lower (2). See Parts, on
page 16.
5. To repair the air motor or lower, see the separate
manuals listed under Related Manuals, on page 2.
Reassembly
1. If the coupling adapter (5) and tie rods (6) have not
been disassembled from the motor, skip to step 2.
If the coupling adapter (5) and tie rods (6) have
been disassembled from the motor, follow these
steps:
a. Screw the tie rods (6) into the motor (1) and
torque to 50-60 ft-lb (68-81 N•m). See Parts,
page 16.
b. Apply red Loctite®to the coupling adapter (5).
c. Screw the coupling adapter (5) into the motor
shaft and torque to 90-100 ft-lb. (122-136 N•m).
d. Continue to step 2.
2. Assemble the coupling nut (3) over the piston rod
(R).
3. Orient the lower (2) to the motor (1). Position the
lower on the tie rods (6).
4. If you are reusing lock nuts (7) and the nylon of the
lock nut is worn or cut, add blue Loctite to the tie rod
threads.
5. Screw the lock nuts (7) onto the tie rods. Leave the
lock nuts (7) loose enough to allow the lower to
move so that it can be aligned correctly.
6. Insert the collars (4) into the coupling nut (3).
Tighten the coupling nut onto the coupling adapter
(5) and torque to 90-100 ft-lb. (122-136 N•m) to
align the motor shaft with the piston rod (R).
7. Tighten the lock nuts (7) and torque to 50-60 ft-lb
(68-81 N•m).
This equipment stays pressurized until pressure is
manually relieved. To help prevent serious injury from
splashing fluid and moving parts, follow the Pressure
Relief Procedure before servicing the equipment.
FIG. 3. Shield Disassembly
ti15759a ti15770a
Step 1
Step 2

Repair
14 3A6938D
8. Install the shields (22) by engaging the bottom lips
with the groove in the top plate. Snap the two
shields together.
9. Flush and test the pump before reinstalling it in the
system. Connect hoses and flush the pump. While it
is pressurized, check for smooth operation and
leaks. Adjust or repair as necessary before reinstall-
ing in the system.
10. Reconnect the pump ground wire before operating.
FIG. 4. Shield Reassembly
22
22
22
22

Repair
3A6938D 15

Parts
16 3A6938D
Parts
High-Flo Pumps 1500cc or 2000cc with Sealed 4-Ball Lowers
High-Flo Plus Pumps 2500cc, 3000cc, or 4000cc with
Sealed 4-Ball Lowers
1
5
4
2
6
7
3
4
2
3
1
1
2
Torque to 50-60 ft-lb (68-81 N•m).
Apply lubricant.
Torque to 90-100 ft-lb. (122-136 N•m).
Apply red Loctite®and torque to 140-150 ft-lb.
(190-203 N•m).
1
2
3
4
57
56
22
R
2500cc, 3000cc, 4000cc 1500cc, 2000cc

Parts
3A6938D 17
Common Parts
†Used only on Jx33xx, Jx44xx, and
Jx53xx assemblies.
Replacement safety labels, tags, and cards are
available at no cost.
Ref. Part Description Qty.
1See pages
20-21 MOTOR, XL 1
2 LOWER, 4-Ball 1
3 17F000 NUT, coupling, M22 x 1.5 1
4 184128 COLLAR, coupling 2
5 15H369 ADAPTER, coupling, M22 x 1.5 1
6 16X771 TIE ROD, 14.37 in (365 mm) - 12.09 in. (307.09 mm) between
shoulders 3
7 108683 NUT, lock, hex; 9/16-12 unc 3
10 See pages
20-21 KIT, DataTrak with solenoid (not shown) 1
13†111337 FITTING, tee (not shown) 1
14†100615 BUSHING, hex (not shown) 1
15†116643 VALVE, safety (not shown) 1
16†157785 FITTING, swivel (not shown) 1
22 25P848 SHIELD, kit; includes 2 shields 1
5616K116 LABEL, notice 1
5715F674 LABEL, safety 1
58172479 TAG, safety (1500cc, 2000cc only;
not shown) 1

Parts
18 3A6938D
High-Flo Pumps with 1500cc or 2000cc Open Wet Cup 4-Ball
Lowers
High-Flo Pumps with 750cc Sealed 4-Ball Lowers
1
5
4
7
3
22
57
2
R
Torque to 50-60 ft-lb (68-81 N•m).
Apply lubricant.
Torque to 90-100 ft-lb. (122-136 N•m).
Apply red Loctite®and torque to 140-150 ft-lb.
(190-203 N•m).
1
2
3
4
621
1
2
4
3
Tri-clamp (inlet)
NPT (outlet)
Open wet cup
2
56

Parts
3A6938D 19
Common Parts
Replacement safety labels, tags, and cards are available at
no cost.
Ref. Part Description Qty.
1Seepages
20-21 MOTOR, XL 1
2 LOWER, 4-Ball 1
3 17F000 NUT, coupling, M22 x 1.5 1
4 184128 COLLAR, coupling 2
5 15H369 ADAPTER, coupling, M22 x 1.5 1
6 15G924 TIE ROD, 14.37 in (365 mm) - 12.09 in. (307.09 mm) between
shoulders 3
7 108683 NUT, lock, hex; 9/16-12 unc 3
10 Seepages
20-21 KIT, DataTrak with solenoid (not shown) 1
22 25P848 SHIELD, kit; includes 2 shields 1
5616K116 LABEL, notice 1
5715F674 LABEL, safety 1
58172479 TAG, safety (not shown) 1

Parts
20 3A6938D
1.7:1 Ratio, 4000cc Pump
2.3:1 Ratio, 3000cc Pump
2.8:1 Ratio, 2500cc Pump
3.3:1 Ratio, 4000cc Pump
3.5:1 Ratio, 2000cc Pump
4.4:1 Ratio, 3000cc Pump
Ref. 1 Ref. 2 Ref. 10
Pump
(See page 3) Pump Series
XL Air
Motor
(See
3A5423)
4-Ball
Lower
(See
3A5348) DataTrak
JS17A8 AXL34L0 17Z389 N/A
JS17B8 A 24X550
JS17C8 AXL34R0 N/A
JS17D8 A 24X550
Ref. 1 Ref. 2 Ref. 10
Pump
(See page 3) Pump Series
XL Air
Motor
(See
3A5423)
4-Ball
Lower
(See
3A5348) DataTrak
JS23A8 AXL34L0 17Z388 N/A
JS23B8 A 24X550
JS23C8 AXL34R0 N/A
JS23D8 A 24X550
Ref. 1 Ref. 2 Ref. 10
Pump
(See page 3) Pump Series
XL Air
Motor
(See
3A5423)
4-Ball
Lower
(See
3A5348) DataTrak
JS28A8 AXL34L0 17Z387 N/A
JS28B8 A 24X550
JS28C8 AXL34R0 N/A
JS28D8 A 24X550
Ref. 1 Ref. 2 Ref. 10
Pump
(See page 3) Pump Series
XL Air
Motor
(See
3A5423)
4-Ball
Lower
(See
3A5348) DataTrak
JS33A8 AXL65L0 17Z389 N/A
JS33B8 A 24X550
JS33C8 AXL65R0 N/A
JS33D8 A 24X550
Ref. 1 Ref. 2 Ref. 10
Pump
(See
page 3) Pump Series XL Air Motor (See 3A5423)
4-Ball Lower
(See 333022 for
sealed lowers
and 3A3452 for
open lowers.) DataTrak
JS35A0 AXL34L0 17K667 (Open) N/A
JS35B0 A 24X550
JS35C0 AXL34R0 N/A
JS35D0 A 24X550
JS35A8 AXL34L0 17K659 (Sealed) N/A
JS35B8 A 24X550
JS35C8 AXL34R0 N/A
JS35D8 A 24X550
JS35A9 AXL34L0 17K671 (Open) N/A
JS35B9 A 24X550
JS35C9 AXL34R0 N/A
JS35D9 A 24X550
JC35A9 AXL34L0 17K663 (Open) N/A
JC35B9 A 24X550
Ref. 1 Ref. 2 Ref. 10
Pump
(See page 3) Pump Series
XL Air
Motor
(See
3A5423)
4-Ball
Lower
(See
3A5348) DataTrak
JS44A8 AXL65L0 17Z388 N/A
JS44B8 A 24X550
JS44C8 AXL65R0 N/A
JS44D8 A 24X550
