Graco ProConnect 19Y298 Operating instructions

334599K
EN
Repair
ProConnect Endurance
Displacement Pump
For professional use only.
Models: 17C487, 17C488, 17C489, 17C721, 17M992, 24Z731, 19Y298, 19B732
Important Safety Instructions
Read all warnings and instructions in this manual and related manuals.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
Use only genuine Graco replacement parts.
The use of non-Graco replacement parts may void warranty.

Contents
2334599K
Contents
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Pressure Relief . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Trigger Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Pressure Relief Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Pump Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Disassemble Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Assemble Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Pump Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Warnings
334599K 3
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this
equipment. The exclamation point symbol alerts you to a general warning and the hazard
symbols refer to procedure-specific risks. When these symbols appear in the body of this
manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols
and warnings not covered in this section may appear throughout the body of this manual
where applicable.
WARNING
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help
prevent fire and explosion:
•Do not spray flammable or combustible materials near an open flame or sources of ignition
such as cigarettes, motors, and electrical equipment.
•Paint or solvent flowing through the equipment is able to result in static electricity. Static
electricity creates a risk of fire or explosion in the presence of paint or solvent fumes. All
parts of the spray system, including the pump, hose assembly, spray gun, and objects in
and around the spray area shall be properly grounded to protect against static discharge
and sparks. Use Graco conductive or grounded high-pressure airless paint sprayer hoses.
•Verify that all containers and collection systems are grounded to prevent static discharge.
Do not use pail liners unless they are anti static or conductive.
•Connect to a grounded outlet and use grounded extensions cords. Do not use a 3-to-2
adapter.
•Do not use a paint or a solvent containing halogenated hydrocarbons.
•Do not spray flammable or combustible liquids in a confined area.
•Keep spray area well-ventilated. Keep a good supply of fresh air moving through the area.
•Sprayer generates sparks. Keep pump assembly in a well ventilated area at least 20 feet
(6.1 m) from the spray area when spraying, flushing, cleaning, or servicing. Do not spray
pump assembly.
•Do not smoke in the spray area or spray where sparks or flame is present.
•Do not operate light switches, engines, or similar spark producing products in the spray
area.
•Keep area clean and free of paint or solvent containers, rags, and other flammable
materials.
•Know the contents of the paints and solvents being sprayed. Read all Safety Data Sheets
(SDS) and container labels provided with the paints and solvents. Follow the paint and
solvents manufacturer’s safety instructions.
•Fire extinguisher equipment shall be present and working.

Warnings
4334599K
WARNING
SKIN INJECTION HAZARD
High-pressure spray is able to inject toxins into the body and cause serious bodily injury. In the
event that injection occurs, get immediate surgical treatment.
•Do not aim the gun at, or spray any person or animal.
•Keep hands and other body parts away from the discharge. For example, do not try to stop
leaks with any part of the body.
•Always use the nozzle tip guard. Do not spray without nozzle tip guard in place.
•Use Graco nozzle tips.
•Use caution when cleaning and changing nozzle tips. In the case where the nozzle tip clogs
while spraying, follow the Pressure Relief Procedure for turning off the unit and relieving
the pressure before removing the nozzle tip to clean.
•Equipment maintains pressure after power is shut off. Do not leave the equipment
energized or under pressure while unattended. Follow the Pressure Relief Procedure
when the equipment is unattended or not in use, and before servicing, cleaning, or
removing parts.
•Check hoses and parts for signs of damage. Replace any damaged hoses or parts.
•This system is capable of producing 3300 psi. Use Graco replacement parts or accessories
that are rated a minimum of 3300 psi.
•Always engage the trigger lock when not spraying. Verify the trigger lock is functioning
properly.
•Verify that all connections are secure before operating the unit.
•Know how to stop the unit and bleed pressure quickly. Be thoroughly familiar with the
controls.
PRESSURIZED ALUMINUM PARTS HAZARD
Use of fluids that are incompatible with aluminum in pressurized equipment can
cause serious chemical reaction and equipment rupture. Failure to follow this
warning can result in death, serious injury, or property damage.
•Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon
solvents or fluids containing such solvents.
•Do not use chlorine bleach.
•Many other fluids may contain chemicals that can react with aluminum. Contact your
material supplier for compatibility.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on
skin, inhaled, or swallowed.
•Read SDSs to know the specific hazards of the fluids you are using.
•Store hazardous fluid in approved containers, and dispose of it according to applicable
guidelines.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent
serious injury, including eye injury, hearing loss, inhalation of toxic fumes, and burns.
This protective equipment includes but is not limited to:
•Protective eye wear, and hearing protection.
•Respirators, protective clothing, and gloves as recommended by the fluid and solvent
manufacturer.
CALIFORNIA PROPOSITION 65
This product contains a chemical known to the State of California to cause cancer,
birth defects or other reproductive harm. Wash hands after handling.

Pressure Relief
334599K 5
Pressure Relief
Trigger Lock
Always engage the trigger lock when sprayer
is stopped to prevent the gun from being
triggered accidentally by hand or if dropped
or bumped.
Pressure Relief Procedure
1. Engage the trigger lock.
ti24612a
LineLazer ES 1000
This equipment stays pressurized until
pressure is manually relieved. To help
prevent serious injury from pressurized
fluid, such as skin injection, splashed fluid
and moving parts, follow the Pressure
Relief Procedure whenever sprayer is
stopped and before sprayer is cleaned or
checked, and before equipment is
serviced.
ti24851a
LineLazer ES 1000

Pressure Relief
6334599K
2. Turn the ON/OFF switch to OFF posi-
tion. Wait 7 seconds for power to dissi-
pate.
3. Unplug power cord or shut engine off.
For LineLazer ES 1000, unplug power
cord and disconnect battery.
4. Engage the trigger lock.
5. Remove tip guard.
6. Turn pressure control to the lowest set-
ting. Disengage trigger lock.
ti24852a
ti24853a
ti24854a
LineLazer ES 1000

Pressure Relief
334599K 7
7. Hold a metal part of the gun firmly to a
grounded metal pail. Trigger the gun to
relieve pressure.
8. Engage the trigger lock.
9. Open any fluid drain valves in system.
Leave drain valves open until ready to
spray again.
ti24585a
ti24855a
LineLazer ES 1000
ti24608a

Pump Removal
8334599K
Pump Removal
Pump removal includes disconnecting the
fluid inlet and outlet and removing the pump.
1. Use a hammer to loosen pump retaining
nut.
2. Turn pump retaining nut to free pump
rod cover.
3. Swing pump rod cover open.
4. Disconnect outlet hose and suction
hose from pump.
5. Slide pump out of the drive housing.
ti27248a
ti27249a
ti27250a
ti27252a

Repair
334599K 9
Repair
Disassemble Pump
1. Remove packing nut and throat
adjustment spacer. Retaining nuts are
not removable and not sold separately.
2. Unscrew cylinder from intake valve.
3. Dissemble intake valve. Clean and
inspect. O-ring may require a pick for
removal.
4. Tap piston rod out of cylinder with a
hammer or flip over and tap piston rod
out against a bench.
ti24863a
Retaining
Nuts
ti24870a
NOTICE
If using a pick to remove the O-ring use care
to avoid damage to the machined surfaces.
ti24874a
ti24875a

Repair
10 334599K
5. For Model 19Y298 Only:
Remove piston rod from sleeve, or
remove sleeve from cylinder if only rod
was removed in previous step. Ensure
o-ring inside cylinder is removed.
6. Unscrew piston valve from piston rod.
7. Clean and inspect parts. The piston has
a special thread locking/sealing patch.
Apply thread sealant to the threads, if
needed.
Do not clean or wipe the piston valve
threads. Cleaning the piston valve
threads could destroy the special sealing
patch and cause the piston valve to come
loose during operation, causing a pump
burst and possible serious bodily injury.
ti24876a
ti24877a

Repair
334599K 11
8. Remove and discard throat packing
and glands from the cylinder. Assemble Pump
1. Soak leather packings in SAE 30W oil for
one hour before assembly.
ti24880a
Leather
Packings
ti24890a
Leather
Packings
ti24893a

Repair
12 334599K
2. Install ball in piston rod. If thread seal-
ant is applied to piston valve threads,
ensure that none gets on the ball.
3. Torque to 27 ± 3 ft-lb (37 ± 4 N•m).
4. Assemble leather throat packings
soaked earlier.
5. Loosely install packing nut with o-ring
onto cylinder.
ti24891a
ti24892a
Leather
Packings
ti24893a
ti24894

Repair
334599K 13
6. Apply liberal amounts of grease or oil to
piston packings.
7. Grease top inch or two of piston rod
that will go through the cylinder throat
packings. Gently guide displacement
rod up through throat packings. Tap
bottom of piston valve as necessary
with a leather or plastic hammer.
8. For Model 19Y298 Only: Slide piston
assembly (with force) into bottom of
sleeve.
9. For Model 19Y298 Only: Grease top
inch or two of piston rod that will go
through the cylinder throat packings.
ti24895a
ti24896a

Repair
14 334599K
10. For Model 19Y298 Only: Grease
o-rings (231 and 219) and place on
sleeve (232). Slide sleeve/piston rod
assembly into bottom of cylinder.
Replace o-ring (230) if desired.
11. Grease o-ring and place on outside
diameter ring groove.
12. Clean seat thoroughly. Reassemble
intake valve with a seat, ball, and new
o-ring. Seat may be flipped over and
used on other side.
13. Torque to 135 ± 7 ft-lb (183 ± 9 N•m)
ti24897a
ti24898a
ti24899a

Repair
334599K 15
14. Install o-ring onto packing nut. Torque
to 75 ± 5 in-lb (8.5 ± 0.5 N•m) or addi-
tional 1/2 turn from hand tight.
15. Storage
ti24900a
ti24901a

Repair
16 334599K
Throat Packing Adjustment
When pump packings begin to leak after
much use, perform Pressure Relief
Procedure, page 5 and tighten packing nut
down until leakage stops or lessens. This
allows approximately 100 gallons of
additional operation before a repacking is
required. Packing nut can be tightened
without o-ring removal.
This equipment stays pressurized until
pressure is manually relieved. To help
prevent serious injury from pressurized
fluid, such as skin injection, splashed fluid
and moving parts, follow the Pressure
Relief Procedure whenever sprayer is
stopped and before sprayer is cleaned or
checked, and before equipment is
serviced.
ti24988a

Pump Installation
334599K 17
Pump Installation
Pump installation includes securing the pump
and connecting to the fluid inlet and outlet.
1. Connect outlet hose to pump.
2. Move pump displacement rod up or
down until it slides into the connecting
rod when the pump is slid into the drive
housing.
3. Slide pump all the way into drive hous-
ing.
4. Close pump rod cover. Make certain
that it is flush against drive housing.
5. Use both hands to tighten pump retain-
ing nut.
6. Use a hammer to turn pump retaining
nut an additional 1/8 to 1/6th turn or 45°
to 60°.
7. Install suction hose.
ti24086a
ti24085b
ti25139a
ti24087a
ti24088a
ti24089a
1/8 - 1/6
ti24090a

Parts
18 334599K
Parts
Models 17C487, 17C488, 17C489, 17C721, 17M992, 24Z731
202
203
220
204
221
205
201
225
206
219
208
224
209
211
207
212
213
218
215
217
216
223
222
229
ti24903a

Parts
334599K 19
Parts List
Models 17C487, 17C488, 17C489, 17C721, 17M992, 24Z731
Ref. Part Description Qty.
201 24W617 ROD, displacement,
includes 212
1
202* 180656 BUTTON, plug 1
203 193047 NUT, packing 1
204* 176757 GLAND, female, throat 1
205* 176754 GLAND, male throat 1
206 24W619 CYLINDER, pump
includes 219, 229
1
207* 105444 BALL, sst, 0.3125 in. 1
208* 195129 GLAND, male piston 1
209* 180073 GLAND, female, piston 1
211* 15G234 GUIDE, piston 1
212 239937 VALVE, piston
(included with 201)
1
21315C011 GUIDE, ball 1
215246429 KIT, seat, carbide
includes 213, 217 and
218
1
216 15B611 VALVE, intake housing 1
217*15B112 PACKING, o-ring
(0.941 in. OD)
1
218*105445 BALL, sst, 0.5000 in. 1
219* 17V093 PACKING, o-ring 1
220* 160516 O-RING 1
221* 176755 V-PACKING, leather,
throat
2
222* 192710 V-PACKING, throat,
V-MaxTM
UHMWPE, blue
3
223* 176749 V-PACKING, leather,
piston
2
224* 192712 V-PACKING, piston,
V-MaxTM
UHMWPE, blue
3
225
Models 17C487, 17C488, 17C489, 17C721
17C231 FITTING, pump, QD,
1/4 npt
1
Model 17M992
162453 FITTING, 1/4 npt 1
229 NUTS, retaining, not sold separately
* - Also included in Kit 18B260 (formerly part
number 244194)
- Also included in Kit 246429
Ref. Part Description Qty.

Parts
20 334599K
Parts
Model 19Y298, 19B732
