Graco TRITON 3D350HP Operation manual

311689G
ENG
Instructions/Parts List
TRITON®3D350HP
Diaphragm Pump
Used to pump waterborne and solvent-based paints and catalysts.
Part No. 253707, Series D
3:1 Ratio Air-Operated Double Diaphragm Pump, with BSPP Fittings
Part No. 253708, Series D
3:1 Ratio Air-Operated Double Diaphragm Pump, with npt Fittings
0.6 MPa, 6 bar (88 psi) Maximum Air Input Pressure
1.8 MPa, 18 bar (260 psi) Maximum Fluid Working Pressure
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
TI1962A
II2G

2
Contents
Warning...................................3
Installation ................................5
General Information ......................5
Tighten Threaded Connections ..............5
Mounting the Pump .......................6
AirLine ................................7
FluidSuctionLine ........................7
FluidOutletLine .........................7
Grounding ..............................9
Operation ................................10
Pressure Relief Procedure ................10
Flush the Pump Before First Use ...........10
Starting and Adjusting the Pump ...........10
Pump Shutdown ........................10
Maintenance ..............................11
Lubrication ............................11
Flushing and Storage ....................11
Tighten Threaded Connections .............11
Preventive Maintenance Schedule ..........11
Troubleshooting ..........................12
Repair ...................................14
Prepare the Pump for Repair ...............14
General Repair Notes ....................14
FaultIndications ........................14
Tools Required .........................14
Replace the Diaphragms ..................15
Repair the Air Valve ......................17
Replace the Ball Check Valves .............19
Replace the Cylinder and Piston Seals .......21
Parts ....................................23
TechnicalData ............................25
Performance Charts ........................26
Dimensions ...............................27
Wall Mount Hole Pattern ....................27
Torque Sequence ..........................27
Graco Standard Warranty ...................28
GracoInformation .........................28

3
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-
tion point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific risk. Refer back
to these warnings. Additional, product-specific warnings may be found throughout the body of this manual where
applicable.
Warning
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equipment to rupture or malfunction and result in serious injury.
• This equipment is for professional use only.
• Read all instruction manuals, tags, and labels before operating the equipment.
• Use the equipment only for its intended purpose. If you are not sure, call your Graco distributor.
• Do not alter or modify this equipment. Use only genuine Graco parts and accessories.
• Check equipment daily. Repair or replace worn or damaged parts immediately.
• Do not exceed the maximum working pressure of the lowest rated system component. Refer to the
Technical Data on page 25 for the maximum working pressure of this equipment.
• Use fluids and solvents which are compatible with the equipment wetted parts. Refer to the Techni-
cal Data section of all equipment manuals. Read the fluid and solvent manufacturer's warnings.
• Do not use hoses to pull equipment.
• Route hoses away from traffic areas, sharp edges, moving parts, and hot surfaces. Do not expose
Graco hoses to temperatures above 82°C (180°F) or below -40°C (-40°F).
• Wear hearing protection when operating this equipment.
• Comply with all applicable local, state, and national fire, electrical, and safety regulations.
PRESSURIZED EQUIPMENT HAZARD
Spray from the gun, hose leaks, or ruptured components can splash fluid in the eyes or on the skin and
cause serious injury.
• Do not point the gun at anyone or at any parts of the body.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Follow the Pressure Relief Procedure on page 10 whenever you are instructed to relieve pressure;
stop spraying; clean, check, or repair the equipment; and install or clean the spray nozzle.
• Tighten all fluid connections before operating the equipment.
• Check the hoses, tubes, and couplings daily. Replace worn, damaged, or loose parts immediately.
Permanently coupled hoses cannot be repaired; replace the entire hose.
FIRE AND EXPLOSION HAZARD
Improper grounding, poor ventilation, open flames or sparks can cause a hazardous condition and result
in a fire or explosion and serious injury.
• Ground the equipment and the object being sprayed. Refer to Grounding on page 9.
• If there is any static sparking or you feel an electric shock while using this equipment, stop the
equipment immediately. Do not use the equipment until you identify and correct the problem.
• Provide fresh air ventilation to avoid the buildup of flammable fumes from solvents or the fluid being
sprayed.
• Keep the work area free of debris, including solvent, rags, and gasoline.
• Eliminate all ignition sources such as pilot lights, cigarettes, and static arcs from plastic drop cloths.
Do not plug in or unplug power cords or turn lights on or off in the spray area.

4
TOXIC FLUID HAZARD
Hazardous fluid or toxic fumes can cause serious injury or death if splashed in the eyes or on the skin,
inhaled, or swallowed.
• Know the specific hazards of the fluid you are using.
• Store hazardous fluid in an approved container. Dispose of hazardous fluid according to all local,
state and national guidelines.
• Always wear protective eyewear, gloves, clothing and respirator as recommended by the fluid and
solvent manufacturer.
• If a diaphragm fails, fluid is exhausted along with the air. When pumping hazardous fluids, place the
pump in an appropriate container to catch the fluid if a diaphragm ruptures.
MOVING PARTS HAZARD
Moving parts, such as the diaphragm shaft, can pinch or amputate your fingers.
• Before servicing the equipment, follow the Pressure Relief Procedure on page 10 to prevent the
equipment from starting unexpectedly.
PERSONAL PROTECTIVE EQUIPMENT
You must wear appropriate protective equipment when operating, servicing, or when in the operating
area of the equipment to help protect you from serious injury, including eye injury, inhalation of toxic
fumes, burns, and hearing loss. This equipment includes but is not limited to:
• Protective eyewear
• Clothing and respirator as recommended by the fluid and solvent manufacturer
• Gloves
• Hearing protection
Warning

Installation
5
Installation
General Information
•FIG. 3 on page 8 is only a guide for installing system
components and accessories. It is not an actual sys-
tem design. Contact your Graco distributor for assis-
tance in designing a system to suit your particular
needs.
• Always use Genuine Graco Parts and Accessories,
available from your Graco distributor. If you supply
your own accessories, be sure they are adequately
sized and pressure-rated for your system.
• Reference numbers and letters in parentheses refer
to the reference numbers in the figures and the
parts list on page 23.
Tighten Threaded Connections
1. Before each use, check all hoses for wear or dam-
age and replace as necessary.
2. Check to be sure all threaded connections are tight
and leak-free.
3. Check and re-torque all screws and fasteners at
least every two months. Re-torque the fluid cover
screws first, followed by the manifold screws. Note:
Before using pump, loosen fluid cover screws (31)
1-2 turns and then re-torque to 20 N•m (15 ft-lb).

Installation
6
Mounting the Pump
For ease of operation and service, mount the pump so
the air inlet, fluid inlet, and fluid outlet ports are easily
accessible. The inlet port must point down and the outlet
port must point up.
Use 5/8 in. lag screws or bolts for mounting.
Wall Mount Installation
1. Wall Mount Kit 245875 is available. See FIG.1.
2. Be sure the wall can support the weight of the
pump, bracket, hoses and accessories, as well as
the stress caused during operation.
3. Using the wall bracket (B) as a template, drill 5/8 in.
mounting holes in the wall. See page 27 for a wall
mounting diagram. Mount the bracket 1.2-1.5 m (4-5
ft) above the floor.
4. Attach the bracket (B) to the pump (A) with the
screws (C) and washers (D) provided in the kit.
5. Attach the bracket to the wall. Use screws (E) that
are long enough to keep the pump from vibrating
during operation. Be sure the pump is level.
Floor Stand Installation
Floor Stand Kit 245874 is available. See FIG.2to
assemble.
To ensure proper operation, mount the pump in a
horizontal position.
FIG. 1: Wall Mount Kit
TI2079B
C
D
B
A
E
FIG. 2: Floor Stand Installation
TI20798

Installation
7
Air Line
1. Install the air line accessories as shown in FIG.3.
Mount these accessories on the wall or on a
bracket. Be sure the air line supplying the accesso-
ries is grounded.
a. Install an air regulator (C) and gauge to control
the fluid pressure. The fluid outlet pressure will
be three times the setting of the air regulator.
b. A bleed-type master air valve (B) is required in
your system to relieve air trapped between it
and the pump when the valve is closed. Trapped
air can cause the pump to cycle unexpectedly
which could result in serious injury including
splashing in the eyes or on the skin, or injury
from moving parts. Be sure the bleed valve is
easily accessible from the pump, and is located
downstream from the air regulator.
c. The air line filter (D) removes harmful dirt and
moisture from the compressed air supply.
d. A second bleed-type air valve (T) isolates the air
line accessories for servicing. Locate upstream
from all other air line accessories.
2. Install a grounded, flexible air hose (A) between the
accessories and the pump air inlet. See Technical
Data on page 25 to determine the air inlet size of
your pump. Use a minimum 13 mm (1/2 in.) ID air
hose.
3. Screw an air line quick disconnect coupler (N) onto
the end of the air hose (A), and screw the mating fit-
ting into the pump air inlet snugly. Do not connect
the coupler to the fitting until you are ready to oper-
ate the pump.
Fluid Suction Line
• Use conductive hoses (E). See FIG.3.
• See Technical Data on page 25 to determine the
fluid inlet size of your pump.
• For maximum suction lift (wet and dry) information,
see Technical Data on page 25.
Fluid Outlet Line
1. Use conductive fluid hoses (J). See FIG.3.See
Technical Data on page 25 to determine the fluid
outlet size of your pump.
2. Install a fluid drain valve (G) near the fluid outlet.
The fluid drain valve is required to relieve pressure
in the hose and gun. The drain valve reduces the
risk of serious injury, including splashing in the eyes
or on the skin, or injury from toxic fluids.
3. Install a shutoff valve (H) in the fluid outlet line.

Installation
8
Key:
A Air Supply Line
B Bleed-Type Master Air Valve
C Air Regulator
D Air Line Filter
E Fluid Suction Line
F Fluid Supply
G Fluid Drain Valve
H Fluid Shutoff Valve
J Fluid Line
K Mounting Bracket
L Internal Air Relief Valve
M Muffler
N Air Line Quick Disconnect Coupler
P Pump Air Piston
R Pump Diaphragms
S Pump Ball Checks
T Air Shutoff Valve
Y Pump Ground Wire
FIG. 3. Typical Installation
A
BC
D
E
F
G
H
J
K
L
M
N
Y
T
P
R
RS
S
S
S
TI1961B

Installation
9
Grounding
Ground all of this equipment:
•Pump: use a ground wire and clamp. See FIG.4.
Loosen the grounding screw (X). Insert one end of a
1.5 mm2(12 ga) minimum ground wire (Y) into the
pump’s grounding clamp (8) and tighten the screw
(X) securely. Connect the other end of the wire to a
true earth ground. For a ground wire and clamp,
order Part No. 238909.
•Air and fluid hoses: Use only electrically conductive
hoses.
•Air compressor: Follow manufacturer’s recommen-
dations.
•Fluid supply drum: Follow your local code.
•All solvent pails used when flushing: Follow your
local code. Use only metal pails, which are conduc-
tive, placed on a grounded surface. Do not place the
pail on a nonconductive surface, such as paper or
cardboard, which interrupts the grounding continu-
ity.
FIG. 4. Grounding the Pump
Before operating the pump, ground the system as
explained below. Read the warnings on page 3.
Y
X
TI2085A

Operation
10
Operation
Pressure Relief Procedure
1. Shut off the air to the pump.
2. Open the dispensing valve, if used.
3. Open the fluid drain valve to relieve all fluid pres-
sure, having a container ready to catch the drain-
age.
Flush the Pump Before First Use
The pump was tested in oil. If the oil could contaminate
the fluid you are pumping, flush the pump thoroughly
with a compatible solvent. Follow the steps under Start-
ing and Adjusting the Pump.
Starting and Adjusting the Pump
1. Be sure the pump is properly grounded. Refer to
Grounding on page 9.
2. Check all fittings to be sure they are tight. Be sure to
use a compatible liquid thread sealant on all male
threads.
3. Re-torque all screws and fasteners before startup.
Re-torque the fluid cover screws first, followed by
the manifold screws.
4. Place the suction tube (E) in the fluid to be pumped.
5. Place the end of the fluid hose (J), see FIG.3,into
an appropriate container.
6. Close the fluid drain valve (G). Open the fluid shutoff
valve (H).
7. With the pump air regulator (C) closed, open the
bleed-type master air valve (B).
8. If the fluid hose has a dispensing device, hold it
open while continuing with the following step.
9. Slowly open the air regulator (C) until the pump
starts to cycle. Allow the pump to cycle slowly until
all air is pushed out of the lines and the pump is
primed.
If you are flushing, run the pump long enough to thor-
oughly clean the pump and hoses. Close the air regula-
tor. Remove the suction tube (E) from solvent and place
it in the fluid to be pumped.
Pump Shutdown
Short Term Shutdown
For a short term shutdown, relieve the pressure (see at
left).
Long Term Shutdown
For a long term shutdown, such as several hours or
overnight:
1. Flush the pump thoroughly.
2. Leave compatible solvent in the pump.
3. Relieve the pressure (see at left).
Read the warnings on page 3, and follow the Pres-
sure Relief procedure below whenever you:
• are instructed to relieve pressure
• stop spraying
• check or service any of the equipment
• install or clean the fluid nozzle.
Operating the pump beyond the maximum air
input pressure will decrease diaphragm life.
Do not operate the pump dry for long periods of
time to avoid reducing diaphragm life.
