Graco Viscount 17K963 Operation manual

3A3381E
EN
Instructions - Parts List
Viscount®4-Ball Pumps
Hydraulic-powered pumps for low pressure, high volume circulation of finishing materials.
Do not use for flushing or purging lines with caustics, acids, abrasive line strippers, and
other similar fluids. For professional use only.
See page 3 for model information, including maximum working pressure.
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
Viscount II Pump with
2000cc 4-Ball Lower,
Sealed
Viscount II Pump with
2000cc 4-Ball Lower,
Open Wet Cup
Viscount I Pump with
1000cc 4-Ball Lower,
Open Wet Cup
Viscount I Pump with
2000cc 4-Ball Lower,
Sealed
II 2 G Ex h IIB T3 Gb

Contents
23A3381E
Contents
Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Plumbing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Flush Before Using Equipment . . . . . . . . . . . . . . 7
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Pressure Relief Procedure . . . . . . . . . . . . . . . . 11
Prime the Pump . . . . . . . . . . . . . . . . . . . . . . . . 11
Stop Pump at Bottom of Stroke . . . . . . . . . . . . 11
Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Preventive Maintenance Schedule . . . . . . . . . . 12
Flushing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Mix Tank Volume . . . . . . . . . . . . . . . . . . . . . . . 12
Hydraulic Power Supply Check . . . . . . . . . . . . . 12
Stall Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Changing the TSL On Wet Cup Models . . . . . . 12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Reassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Viscount I Pumps:
Models 17K963, 17E231, 17E235, and
17E239 750cc, 1000cc, 1500cc, or
2000cc with Sealed 4-Ball Lower . . . . . . . . 17
Viscount I Pumps:
Models 17K964, 17K965, 17E230, 17E232,
17E233, 17E234, 17E236, 17E237, 17E238,
17E240, and 17E241
750cc, 1000cc 1500cc or 2000cc with 4-Ball
Lower, Open Wet Cup . . . . . . . . . . . . . . . . 18
Viscount 2 Pump:
Model 17E243; 2000cc with Sealed 4-Ball
Lower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Viscount 2 Pumps:
Models 17E242, 17E244, and 17E245
2000cc with 4-Ball Lower, Open Wet Cup . 20
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Mounting Stand Hole Layouts . . . . . . . . . . . . . . . 22
255143 Wall Mount Bracket . . . . . . . . . . . . . . . . . . 23
Performance Charts . . . . . . . . . . . . . . . . . . . . . . . . 24
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 30
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . 30
Related Manuals
Part No. Description
308330 Viscount I Plus Hydraulic Motor manual
308048 Viscount II Hydraulic Motor manual
333022 Repair/Parts Manual, Sealed 4-Ball Lowers
3A3452 Repair/Parts Manual, 4-Ball Lowers with
Open Wet Cup

Models
3A3381E 3
Models
Model
No. Motor Lower Size Lower type
Maximum Pump
WorkingPressure
psi (MPa, bar)
Connection
Fittings
Style Lower Material Rod Coating Cylinder Coating
17K963 VISCOUNT 1 750cc Sealed 460 (3.2, 32.0) tri-clamp SST Ultralife™Ultralife™
17K964 VISCOUNT 1 750cc Open 460 (3.2, 32.0) npt SST Ultralife™Ultralife™
17K965 VISCOUNT 1 750cc Open 460 (3.2, 32.0) tri-clamp SST Ultralife™Ultralife™
17E238 VISCOUNT 1 1000cc Open 300 (2.1, 21.0) npt CS Chrome Chrome
17E239 VISCOUNT 1 1000cc Sealed 300 (2.1, 21.0) tri-clamp SST Ultralife™Ultralife™
17E240 VISCOUNT 1 1000cc Open 300 (2.1, 21.0) npt SST Ultralife™Ultralife™
17E241 VISCOUNT 1 1000cc Open 300 (2.1, 21.0) tri-clamp SST Ultralife™Ultralife™
17E234 VISCOUNT 1 1500cc Open 225 (1.6, 16.0) npt CS Chrome Chrome
17E235 VISCOUNT 1 1500cc Sealed 225 (1.6, 16.0) tri-clamp SST Ultralife™Ultralife™
17E236 VISCOUNT 1 1500cc Open 225 (1.6, 16.0) npt SST Ultralife™Ultralife™
17E237 VISCOUNT 1 1500cc Open 225 (1.6, 16.0) tri-clamp SST Ultralife™Ultralife™
17E230 VISCOUNT 1 2000cc Open 167 (1.2, 12.0) npt CS Chrome Chrome
17E231 VISCOUNT 1 2000cc Sealed 167 (1.2, 12.0) tri-clamp SST Ultralife™Ultralife™
17E232 VISCOUNT 1 2000cc Open 167 (1.2, 12.0) npt SST Ultralife™Ultralife™
17E233 VISCOUNT 1 2000cc Open 167 (1.2, 12.0) tri-clamp SST Ultralife™Ultralife™
17E242 VISCOUNT 2 2000cc Open 460 (3.2, 32.0) npt CS Chrome Chrome
17E243 VISCOUNT 2 2000cc Sealed 460 (3.2, 32.0) tri-clamp SST Ultralife™Ultralife™
17E244 VISCOUNT 2 2000cc Open 460 (3.2, 32.0) npt SST Ultralife™Ultralife™
17E245 VISCOUNT 2 2000cc Open 460 (3.2, 32.0) tri-clamp SST Ultralife™Ultralife™

Warnings
43A3381E
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-
tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When
these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific
hazard symbols and warnings not covered in this section may appear throughout the body of this manual where
applicable.
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. Paint or sol-
vent flowing through the equipment can cause static sparking. To help prevent fire and explosion:
• Use equipment only in well ventilated area.
• Eliminateallignitionsources;such aspilotlights,cigarettes,portableelectriclamps,andplasticdrop
cloths (potential static sparking).
• Ground all equipment in the work area. See Grounding instructions.
• Never spray or flush solvent at high pressure.
• Keep work area free of debris, including solvent, rags and gasoline.
• Do not plug or unplug power cords, or turn power or light switches on or off when flammable fumes
are present.
• Use only grounded hoses.
• Hold gun firmly to side of grounded pail when triggering into pail. Do not use pail liners unless they
are anti-static or conductive.
•Stop operation immediately if static sparking occurs or you feel a shock.Do not use equipment
until you identify and correct the problem.
• Keep a working fire extinguisher in the work area.
PRESSURIZED EQUIPMENT HAZARD
Fluid from the equipment, leaks, or ruptured components can splash in the eyes or on skin and cause
serious injury.
• Follow the Pressure Relief Procedure when you stop spraying/dispensing and before cleaning,
checking, or servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses, tubes, and couplings daily. Replace worn or damaged parts immediately.

Warnings
3A3381E 5
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Donotexceedthemaximumworkingpressureor temperatureratingofthelowestratedsystemcom-
ponent. See Technical Data in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Data in all
equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete information
about your material, request Safety Data Sheet (SDS) from distributor or retailer.
• Turn off all equipment and follow the Pressure Relief Procedure when equipment is not in use.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine manu-
facturer’s replacement parts only.
• Donotalterormodifyequipment.Alterationsormodificationsmayvoidagencyapprovalsandcreate
safety hazards.
• Make sure all equipment is rated and approved for the environment in which you are using it.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
MOVING PARTS HAZARD
Moving parts can pinch, cut or amputate fingers and other body parts.
• Keep clear of moving parts.
• Do not operate equipment with protective guards or covers removed.
• Pressurizedequipmentcan startwithoutwarning. Before checking, moving, or servicing equipment,
follow the Pressure Relief Procedure and disconnect all power sources.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or
swallowed.
• Read Safety Data Sheet (SDS) to know the specific hazards of the fluids you are using.
• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury, including
eye injury, hearing loss, inhalation of toxic fumes, and burns. Protective equipment includes but is not
limited to:
• Protective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and solvent manufacturer.

Installation
63A3381E
Installation
Grounding
Pump: use a ground wire and clamp. See FIG. 1 Loosen
the locknut (W) of the grounding lug (Z). Insert one end
of the wire (Y) in the ground lug and tighten the locknut
securely. Connect the ground clamp to a true earth
ground. Order Part No. 237569, Ground Wire and
Clamp.
.
Air and fluid hoses: use only electrically conductive
hoses with a maximum of 500 ft. (150 m) combined
hose length to ensure grounding continuity. Check the
electrical resistance of hoses. If total resistance to
ground exceeds 25 megohms, replace hose immedi-
ately.
Hydraulic power supply: follow manufacturer’s recom-
mendations.
Surge tank: use a ground wire and clamp.
Dispense valve: ground through a connection to a
properly grounded fluid hose and pump.
Fluid supply container: follow local code.
Object being sprayed: follow local code.
Solvent pails used when flushing: follow local code.
Use only conductive metal pails, placed on a grounded
surface. Do not place the pail on a non-conductive sur-
face, such as paper or cardboard, which interrupts
grounding continuity.
To maintain grounding continuity when flushing or
relieving pressure: hold metal part of the spray gun or
valve firmly to the side of a grounded metal pail, then
trigger the gun or open the valve.
The equipment must be grounded to reduce the risk
of static sparking. Static sparking can cause fumes to
ignite or explode. Grounding provides an escape wire
for the electric current.
FIG. 1 Ground Wire
TI15854a
Z
Y
W

Installation
3A3381E 7
Mounting
Stand Mount
Mount the pump in the accessory pump stand (B). Use
Part No. 253692 Stand for the Viscount 1 Pumps (see
FIG. 2) and PartNo. 218742 Stand for Viscount 2 Pumps
(see FIG. 3).
See Mounting Stand Hole Layouts on page 22.
Secure the stand to the floor with M19 (5/8 in.) bolts
which engage at least 152 mm (6 in.) into the concrete
floor to prevent the pump from tipping.
Wall Mount
1. Ensure the wall is strong enough to support the
weight of the pump assembly and accessories, fluid,
hoses, and stress caused during pump operation.
2. Ensure that the mounting location has sufficient
clearance for easy operator access.
3. Position the wall bracket at a convenient height,
ensuring that there is sufficient clearance for fluid
connections and for servicing the lower.
4. Drill four 7/16in. (11 mm) holes using the bracket as
a template. Use any of the three mounting hole
groupings in the bracket. See 255143 Wall Mount
Bracket,page 23.
5. Bolt the bracket securely to the wall using bolts and
washers designed to hold in the wall’s construction.
6. Attach the pump assembly to the mounting bracket.
7. Connect air and fluid hoses.
Plumbing
Install a fluid shutoff valve (D) between the mix tank (A)
and the pump.
When using a stainless steel pump, use stainless steel
plumbing to maintain a corrosion-resistant system.
Flush Before Using Equipment
The equipment was tested with lightweight oil, which is
left in the fluid passages to protect parts. To avoid con-
taminating your fluid with oil, flush the equipment with a
compatible solvent before using the equipment. See
Flushing, page 12.

Installation
83A3381E
Accessories
Install the following accessories in the order shown in
FIG. 2, using adapters as necessary.
Hydraulic Power Supply
Be sure the power supply can provide sufficient power to
the motor. Be sure the power supply is equipped with a
suction filter to the hydraulic pump.
Hydraulic Supply Line
• For Viscount I Plus motors, the hydraulic inlet on the
motor is 3/4 in. (20mm), 37° flare. Use a minimum
1/2 in. (13 mm) ID hydraulic supply line (L).
• For Viscount II motors, use a minimum 1/2 in.
(13 mm) ID supply line (L). The motor has a 3/4in.
3/4 in. (20mm) npt(f) hydraulic oil supply fitting.
•Supply line shutoff valve (S): isolates the motor
when servicing the system.
•Hydraulic fluid pressure gauge (P): monitors the
hydraulic oil pressure to the motor to avoid
over-pressurizing the motor or lower.
•Pressure- and temperature-compensated flow
control valve (T): prevents the motor from running
too fast, which can damage it. Pressure reducing
valve (N), which has a drain line (M) running to
the return line (K): controls the hydraulic pressure
to the motor.Hydraulic Return Line
• For Viscount I Plus motors, the hydraulic outlet on
the motor is 7/8 in.(22 mm), 37° flare. Use a mini-
mum 5/8 in. (16 mm) ID hydraulic return line (K).
• For Viscount II motors, use a minimum 7/8 in.
(22 mm) ID return line (K). The motor has a 1 in. npt
(f) hydraulic oil return fitting.
•Return line shutoff valve (R): isolates the motor
when servicing the system.
•Return fluid filter (J): removes residue from the
hydraulic fluid to help keep the system running
smoothly (10 micron size).
Fluid Line
For typical installation, see FIG. 2.
•Fluid filter: with a 60 mesh (250 micron) stainless
steel element to filter particles from the fluid as it
leaves the pump.
•Fluid drain valve (U): required in your system, to
relieve fluid pressure in the hose and gun.
•Fluid shutoff valve (D): shuts off fluid flow.
NOTICE
The hydraulic power supply must be kept clean at all
times to avoid damage to the motor and hydraulic
power supply.
1. Blow out hydraulic lines with air and flush thor-
oughly before connection to the motor.
2. Plug hydraulic inlets, outlets, and line ends when
disconnecting them for any reason.
NOTICE
To avoid damage to the pump, never use the return
line shutoff valve to control the hydraulic flow. Do not
install any flow control devices on the hydraulic return
line.

Installation
3A3381E 9
Key:
A Mix Tank
B 253692 Pump Stand
C Fluid Supply Line; 1-1/2 in. (38 mm) minimum diameter
D Fluid Shutoff Valve
E Fluid Line; 1 in. (25 mm) minimum diameter
F Surge Tank Stand
G Surge Tank
J 10 Micron Return Filter
K Hydraulic Return Line
L Hydraulic Supply Line
MDrainLine
N Pressure Reducing Valve
P Hydraulic Pressure Gauge
R Return Line Shutoff Valve
S Supply Line Shutoff Valve
T Flow Control Valve
U Fluid Drain Valve (required)
Y Ground Wire (required see page 6 for installation)
FIG. 2. Typical Installation for Viscount I.
K
L
A
B
D
E
D
D
R
NPS
J
C
M
T
Y
F
G
E
U

Installation
10 3A3381E
Key:
A Mix Tank
B 218742 Pump Stand
C Fluid Supply Line; 1-1/2 in. (38 mm) minimum diameter
D Fluid Shutoff Valve
E Fluid Line; 1 in. (25 mm) minimum diameter
F Surge Tank Stand
G Surge Tank
J 10 Micron Return Filter
K Hydraulic Return Line
L Hydraulic Supply Line
MDrainLine
N Pressure Reducing Valve
P Hydraulic Pressure Gauge
R Return Line Shutoff Valve
S Supply Line Shutoff Valve
T Flow Control Valve
U Fluid Drain Valve (required)
Y Ground Wire (required see page 6 for installation)
FIG. 3. Typical Installation for Viscount II.
K
L
A
B
D
E
D
D
R
NPS
J
C
MT
Y
UF
G

Operation
3A3381E 11
Operation
Pressure Relief Procedure
Follow the Pressure Relief Procedure when-
ever you see this symbol.
1. Shut off the hydraulic supply line valve (S) first, then
the return line valve (R).
2. Open the dispensing valve, if used.
3. Open all fluid drain valves (U) in the system, having
a waste container ready to catch drainage. Leave
drain valve(s) open until you are ready to pump
again.
Prime the Pump
1. Fill the wet cup with Throat Seal Liquid (TSL).
NOTE: Sealed 4 ball lowers with bellows do not require
TSL.
2. Close the flow control valve (T) by turning knob
counterclockwise reducing pressure to zero. Close
the supply line shutoff valve (S) and the return line
shutoff valve (R). Also verify that all drain valves (U)
are closed.
3. Check that all fittings throughout system are tight-
ened securely.
4. Start the hydraulic power supply.
5. Open the return line shutoff valve (R), then the sup-
ply line shutoff valve (S). Slowly turn the flow control
valve (T) clockwise, increasing pressure until pump
starts.
6. Cycle pump slowly until all air is pushed out and
pump and hoses are fully primed.
7. Close the fluid shutoff valve (D) downstream of the
pump. The pump should stall against pressure.
NOTE: In a circulation system, the pump operates con-
tinuously until the power supply is shut off. In a
direct-supply system, the pump starts when the dis-
pense valve is opened, and stops when the dispense
valve is closed.
Stop Pump at Bottom of Stroke
Relieve the pressure when you stop the pump for any
reason. Stop the pump on the down stroke, before the
motor changes over.
Shutdown
Follow the Pressure Relief Procedure, page 11.
Always flush the pump before the fluid dries on the dis-
placement rod. See Flushing on page 12.
This equipment stays pressurized until pressure is
manually relieved. To help prevent serious injury from
splashing fluid and moving parts, follow the Pressure
Relief Procedure when you stop spraying and before
cleaning, checking, or servicing the equipment.
NOTICE
When shutting down the hydraulic system, always
shut off the hydraulic supply line shutoff valve (S) first,
and then the return line shutoff valve (R) to prevent
over pressurizing the motor or its seals. When starting
the hydraulic system, open the return line shutoff
valve first.
NOTICE
Failure to stop the pump at the bottom of its stroke
allows fluid to dry on the piston rod, which can dam-
age the throat packings when the pump is restarted.

Maintenance
12 3A3381E
Maintenance
Preventive Maintenance
Schedule
The operating conditions of your particular system
determine how often maintenance is required. Establish
a preventive maintenance schedule by recording when
and what kind of maintenance is needed, and then
determine a regular schedule for checking your system.
Flushing
• Flush before changing colors, before fluid can dry in
the equipment, at the end of the day, before storing,
and before repairing equipment.
• Flush at the lowest pressure possible. Check con-
nectors for leaks and tighten as necessary.
• Flush with a fluid that is compatible with the fluid
being dispensed and the equipment wetted parts.
Mix Tank Volume
Don't let the mix tank run dry. When the tank is empty,
the pump demands more power as it tries to suck in
some fluid. This causes the pump to run too fast, which
can seriously damage the pump.
Hydraulic Power Supply Check
Carefully follow the hydraulic power supply manufac-
turer's recommendations on reservoir and filter cleaning,
and periodic changes of hydraulic fluid.
Stall Test
Perform a stall test periodically to ensure the piston seal
is in good working condition and prevent system pres-
surization:
Close the fluid shutoff valve (D) closest to the pump on
the down stroke and be sure that the pump stalls. Open
the fluid shutoff valve to restart the pump. Close the fluid
shutoff valve (D) closest to the pump on the upstroke
and be sure that the pump stalls.
Stop the pump on the down stroke, before the air motor
changes over.
Changing the TSL On Wet Cup
Models
On Wet Cup Models check the condition of the TSL and
the level in the reservoir every week, minimum. TSL
should be changed at least every month.
To avoid fire and explosion, always ground equipment
and waste container. To avoid static sparking and
injury from splashing, always flush at the lowest pos-
sible pressure.
NOTICE
Do not allow the pump to run quickly for a long period
of time as this may damage the packings.
NOTICE
Failure to stop the pump at the bottom of its stroke
allows fluid to dry on the piston rod, which can dam-
age the throat packings and the TSL pump piston seal
when the pump is restarted.

Troubleshooting
3A3381E 13
Troubleshooting
Problem Cause Solution
Pump output low on both strokes. Restricted hydraulic supply lines. Clear any obstructions; be sure all shutoff
valves are open; increase pressure, but
do not exceed maximum working pres-
sure.
Exhausted fluid supply. Refill and re-prime pump.
Clogged fluid outlet line, valves, etc. Clear.
Worn piston packing. Replace. See lower manual.
Pump output low on only one stroke. Held open or worn ball check valves. Check and repair.
Worn piston packings. Replace. See lower manual.
No output. Improperly installed ball check valves. Check and repair.
Pump operates erratically. Exhausted fluid supply. Refill and re-prime pump.
Held open or worn ball check valves. Check and repair.
Worn piston packing. Replace. See lower manual.
Excessive hydraulic fluid supply pressure
to motor. See motor manual.
Pump will not operate. Restricted hydraulic supply lines. Clear any obstructions; be sure all shut
off valves are open; increase pressure,
but do not exceed maximum working
pressure.
Exhausted fluid supply. Refill and re-prime pump.
Clogged fluid outlet line, valves, etc. Clear.
Damaged hydraulic motor. See motor manual.
Fluid dried on piston rod. Disassemble and clean pump. See lower
manual. In future, stop pump at bottom of
stroke.

Repair
14 3A3381E
Repair
Disassembly
1. Follow the Pressure Relief Procedure, page 11.
2. Disconnect the hoses from the lower and plug the
ends to prevent fluid contamination.
3. Models with Sealed Lowers: Remove the 2-piece
shield (9) by inserting a screwdriver straight into the
slot, and using it as a lever to release the tab.
Repeat for all tabs. Do not use the screwdriver to
pry the shields apart. See FIG. 4.
4. Remove the hose clamp holding the drain bottle to
the tie rod (3). Loosen the coupling nut (5) and
remove the collars (6). Remove the coupling nut
from the piston rod (R). Unscrew the lock nuts (4)
from the tie rods (3). Separate the motor (1) and
lower (2). See FIG. 6.
5. To repair the air motor or lower, see the separate
manuals listed under Related Manuals on page 2.
This equipment stays pressurized until pressure is
manually relieved. To help prevent serious injury from
splashing fluid and moving parts, follow the Pressure
Relief Procedure when you stop spraying and before
cleaning, checking, or servicing the equipment.
FIG. 4. Shield Disassembly
ti15759a
ti15770a
Step 1
Step 2

Repair
3A3381E 15
Reassembly
1. If the coupling adapter (8) and tie rods (3) have not
been disassembled from the motor (1), skip to step
2.
If the coupling adapter (8) and tie rods (3) have
been disassembled from the motor (1), follow these
steps:
a. Loosen, but do not remove, the screws holding
the mounting plate (12) to the motor (1).
b. Install the tie rods (3) as follows:
• Viscount I Pumps: Screw the tie rods (3)
through the mounting plate (12) and into the
threaded holes in the base of the motor (1).
Torque to 50-55 ft-lb (68-75 N•m).
• Viscount II Pumps: Screw the tie rods (3)
into the mounting plate (12) and torque to
50-55 ft-lb (68-75 N•m).
c. Install o-ring (15) into o-ring groove on coupling
adapter.
d. Fill the cavity in the bottom of the motor shaft
with grease.
e. Lubricate the threads of the coupling adapter
(8). Install the coupling adapter as follows:
• Viscount I Plus motors: Screw the coupling
adapter (8) into the motor shaft until the pin
holes align. Install the pin (7) in the first hole
from the end of the coupling.
• Viscount II motors: Slide the adapter nut (7)
onto the coupling adapter (8). Screw the
adapter nut (7) onto the motor shaft (S) and
torque to 75-80 ft-lb (102-109 N•m).
f. Continue to step 2.
2. Assemble the coupling nut (5) over the piston rod
(R).
3. Orient the lower (2) to the motor (1). Position the
lower on the tie rods (3).
4. If you are reusing lock nuts (4) and the nylon of the
lock nut is worn or cut, add blue thread locker to the
tie rod threads.
5. Screw the lock nuts (4) onto the tie rods. Leave the
lock nuts (4) loose enough to allow the lower to
move so that it can be aligned correctly.
6. Tighten the mounting plate screws.
• Viscount I Plus motors: Torque the screws (13)
to 15-17 ft-lb (20-23 N•m)
• Viscount II motors: Torque the screws (13) to to
50-55 ft-lb (68-75 N•m).
7. Insert the collars (6) into the coupling nut (5).
Tighten the coupling nut onto the coupling adapter
(8). Torque to 90-100 ft-lb (122-135 N•m) to allow
the pump rod to align the lower on the tie rods.
8. Tighten the lock nuts and torque to 50-60 ft-lb
(68-81 N•m).
9. Models with Sealed Lowers: Install the shields (9)
by engaging the bottom lips with the groove in the
top plate. Snap the two shields together.
10. Flush and test the pump before reinstalling it in the
system. Connect hoses and flush the pump. While it
is pressurized, check for smooth operation and
leaks. Adjust or repair as necessary before reinstall-
ing in the system.
11. Reconnect the pump ground wire before operating.
FIG. 5. Shield Reassembly
4
6
8
5
3R
99

Repair
16 3A3381E
FIG. 6. Disconnect or Reconnect the Motor and Lower
Torque to 90-100 ft-lb (122-135 N•m).
Torque to 50-55 ft-lb (68-75 N•m).
Lubricate threads.
Torque to 75-80 ft-lb (102-109 N•m).
Torque to 15-17 ft-lb (20-23 N•m).
Fill cavity with grease.
1
2
3
4
6
7
1
2
3
Models with Open Wet
Cup Lowers (Viscount II
motor shown)
Models with Sealed,
4-Ball Lowers (Viscount 1
motor shown)
1
7
4
5
9
8
13
14
Part of 1
2
12
3
66
1
4
5
8
13
2
12
3
6
2
3
1
7
32
2
2
3
4
15
7

Parts
3A3381E 17
Parts
Viscount I Pumps:
Models 17K963, 17E231, 17E235, and 17E239
750cc, 1000cc, 1500cc, or 2000cc with Sealed 4-Ball Lower
Parts List
1
7
4*
5
9
8
13
14
Part of 1
2*
12
3*
6
15
Ref.
No. Part No. Description Qty.
1 261466 MOTOR, Viscount I, see detailed parts
list in manual 308330 1
2 LOWER, Sealed 4-Ball, see detailed
parts list in manual 333022 1
17K656 For model 17K963
17K659 For model 17E231
17K658 For model 17E235
17K657 For model 17E239
3 17C261 TIE ROD, 8.49 in (215.6 mm) L; 6.2 in
(157.7 mm) between shoulders 3
4 108683 NUT, lock, hex 3
5 17F000 NUT, coupling 1
6 184128 COLLAR, coupling 2
7 100103 PIN, cotter 1
8 17E258 ADAPTER, coupling, M22 x 1.5 1
9 24A640 SHIELD KIT, coupler; includes 2
shields 1
12 16E086 PLATE, mounting 1
13 100001 SCREW, cap, hex head 1
14 100214 WASHER 1
15 156082 PACKING, o-ring, 112 1

Parts
18 3A3381E
Viscount I Pumps:
Models 17K964, 17K965, 17E230, 17E232, 17E233, 17E234, 17E236, 17E237,
17E238, 17E240, and 17E241
750cc, 1000cc 1500cc or 2000cc with 4-Ball Lower, Open Wet Cup
Parts List
1
7
4
5
6
8
1314
Part of 1
2
12
3
15
Ref.
No. Part No. Description Qty.
1 261466 MOTOR, Viscount I, see manual
308330 1
2 LOWER, 4-Ball, see manual 3A3452 1
17K668 For model 17K964
17K664 For model 17K965
17K663 For model 17E230
17K671 For model 17E232
17K667 For model 17E233
17K662 For model 17E234
17K670 For model 17E236
17K666 For model 17E237
17K661 For model 17E238
17K669 For model 17E240
17K665 For model 17E241
3 15G924 TIE ROD, 16.55 in (420.4 mm);
14.25 in (362 mm) between shoulders 3
4 108683 NUT, lock, hex 3
5 17F000 NUT, coupling 1
6 184128 COLLAR, coupling 2
7 100103 PIN, cotter 1
8 16C373 ADAPTER, coupling, M22 x 1.5 1
12 16E086 PLATE, mounting 1
13 100001 SCREW, cap, hex head 1
14 100214 WASHER 1
15 156082 PACKING, o-ring, 112 1

Parts
3A3381E 19
Viscount 2 Pump:
Model 17E243; 2000cc with Sealed 4-Ball Lower
Parts List
1
7
4
5
9
8
13
2
12
3* 6
Ref.
No. Part No. Description Qty.
1 223646 MOTOR, Viscount 2, see detailed parts
list in manual 308048 1
2 17K659 LOWER, 4-Ball, see detailed parts list
in manual 333022 1
3 16H434 TIE ROD, 10.80 in. (274.3 mm);
8.37 in (212.6 mm) between shoulders 3
4 108683 NUT, lock, hex 3
5 17F000 NUT, coupling 1
6 184128 COLLAR, coupling 2
7 183079 NUT, adapter 1
8 17E257 ADAPTER, coupling, 1
9 24F251 SHIELD KIT, coupler; includes 2 shields 1
12 120558 PLATE, mounting 1
13 C19789 SCREW, cap, hex head 1

Parts
20 3A3381E
Viscount 2 Pumps:
Models 17E242, 17E244, and 17E245
2000cc with 4-Ball Lower, Open Wet Cup
Parts
1
4
5
8
13
2
12
3
6
7*
Ref.
No. Part No. Description Qty.
1 223646 MOTOR, Viscount 2, see detailed parts
list in manual 308048 1
2LOWER, 4-Ball, see detailed parts list in
manual 3A3452 1
17K662 For model 17E234
17K670 For model 17E236
17K666 For model 17E237
17K663 For model 17E242
17K671 For model 17E244
17K667 For model 17E245
3 15G924 TIE ROD, 16.55 in (420.4 mm);
14.25 in (362 mm) between shoulders 3
4 108683 NUT, lock, hex 3
5 17F000 NUT, coupling 1
6 184128 COLLAR, coupling 2
7 183079 NUT, adapter 1
8 16C373 ADAPTER, 1
12 120558 PLATE, mounting 1
13 C19789 SCREW, cap, hex head 1
