GrainWood CLFS0703 User manual

19 ¼"
31 ¾"
48 ½"
Assembly Instructions
2-person assembly
PH #2
Made in Brazil
REV - 11/2023
Loft
5-Drawer Chest
CLFS0703
CLFS0740
Brushed White
Brushed Grey
Finish
Model #
CLFS0768 Weathered Pine
CLFS0789 Acacia
page 1/18
Thank you for choosing Grain Wood Furniture, it is an honor to be in your home! If you
have any questions, feedback, or need replacement parts please contact us at:
grainwoodfurniture.com/help or [email protected]

Enjoy your 100% solid wood furniture!
PLEASE READ BELOW BEFORE BEGINNING ASSEMBLY
ŸEnlist help from a friend or family member as most items require two
people for proper assembly.
ŸChoose a spacious, open area near where the piece will be located once
assembled. It is easier to move parts than to relocate the furniture after it
is fully assembled.
ŸDo not throw away packaging material until assembly is complete.
ŸAssemble the item on a soft surface, such as cardboard or an old blanket
in order to protect the finish from possible dents or scratches.
ŸLay out the parts in order and count them twice. In case any parts are
missing or damaged, document the problem with pictures and contact
support so we can make it right.
ŸSolid wood furniture may present imperfections such as wood knots,
minor splits or cracks which are a natural aspect of the material.
Whenever stability of the furniture is not compromised, we recommend
customers perform cosmetic touch-ups with wax crayon fillers sold at all
major hardware stores.
ŸIt is best to use the tools provided in the box, such as a hex key, because
they may be specially sized for the piece of furniture.
ŸWe do not recommend the use of power drills as they can damage your
furniture if not used correctly.
ŸUse a carpenter's square or hardcover book to check angles when
assembling drawers and doors. If they are not at 90 degrees, they will not
close properly.
ŸIf you have any problems, we are here to help. Just go to
grainwoodfurniture.com/help.
ŸSee grainwoodfurniture.com/care-guide for suggestions that will help
your furniture last for years.
grainwoodfurniture.com/assembly-troubleshooting
page 2/18

HARDWARE LIST
4,0x30 50 + 3
3,5x14 14 + 1
8,0x30 56 + 3
4,0x45 8 + 1
6,0x10 40 + 2
A1
A4
C1
A40
B31
1/4’’x40
4
B25
M4x25 10 + 1A25
G1 10x10 28
G8 1Before starting assembly
please verify the hardware
set is complete.
For missing hardware please
contact us at
grainwoodfurniture.com/help
WARNING:
CHOKING HAZARD
Small parts, not for children.
To be assembled by an adult.
!ATTENTION
3,5x16 21+ 2
A9
E24 286,7mm - 11 ¹⁄" 5
5
E21
5
E22
982mm - 38 ³⁄"
I2 01
H17 5
G18 4
40x40
385mm - 15 ¹⁄"
page 3/18
A47 3,0x203,0x20 2 + 1
F15 1
F8 2
ANTI-TIPPING RESTRAINT KIT
250 - 9 ³⁄"

09
Part # Part #
Qty. Qty.
DescriptionDescription
03 1
Right side
02 1
Left side
09
12
14
15
HW
5
5
5
2
1
Drawer right side
Drawer Left side
Drawer back
Back panel
Profile “H”
1
Hardware
10
Top
04 1
01 1
Base
05
06
07
08
11
13
4
1
1
5
5
5
Foot
Stabilizing panel
Rear panel
Drawer front
Drawer bottom
Drawer bottom support
BOX A - 1 of 2 BOX B - 2 of 2
12
10 08
04
01
02
03
07
06
14
14
15
05
05
05
05
11
13
5x
page 4/18

C1 8,0x30 56
1)
C1
Tip:
Use a hammer in case dowels
are hard to install by hand.
C1
03
C1
C1
C1
C1
06
C1C1
C1C1
13 5x
C1
C1
C1
C1
C1
C1
C1
C1
C1
10
09
5x
page 5/18
02
C1
C1
C1
C1
C1
C1

2)
page 6/18
BACK
TOP
BOTTOM
FINISHED FRONT
02
I2
A4 A4
A4
A4
3,5x14
A4 4
I2 1
!
02
I2
02
TOP
I2
A4
A4

3)
02
B31
E21
BACK
TOP
BOTTOM
FINISHED FRONT
B31
Glide wheels should be
positioned towards the
front and bottom of the
side panel.
E21
E21
E22
E22
B31 6,0x10 10
E21 5
RIGHT Side
02
B31
E21
B31
B31
E21
B31
B31
E21
B31
B31
E21
B31
B31
E21
B31
page 7/18

4)
BACK
TOP
BOTTOM
FINISHED FRONT
03
E22
E22
B31
B31
Glide wheels should be
positioned towards the
front and bottom of the
side panel.
B31 6,0x10 10
E22 5
LEFT Side
E21
E21
E22
E22
B31
B31 03
E22
B31
B31
E22
B31
B31
E22
B31
B31
E22
B31
B31
page 8/18

6)
03
02
5)
page 9/18
3,5x14
A4 10
A4
A4
A4
A4
A4
A4
A4
A4
A4
A4
G8 1 B25 1/4"x40 4
04
G8+B25
05
05
05
05
G8+B25
G8+B25
G8+B25
G8
B25
04
!
05
05
05
û
û
ü
04
04
04
BACK
Attention: There are no predrilled holes
for the A4 screws on parts 02 and 03.
03
02
A4
A4

7)
8)
page 10/18
A1 4,0x30 4
06
03
02
A1
A1
Attention: There are
no predrilled holes
for the A1 screws on
parts 02 and 03.
A1
A1
A1
06
A1 4,0x30 6
01
A1
A1
02
06
03
A1
A1
A1
Attention: There
are no predrilled
holes for the A1
screws on part 01.
A1

9)
10)
page 11/18
04
A40 4,0x45 6
Attention: There are
no predrilled holes
for the A40 screws
on parts 02 and 03.
02
03
!
04
A40
A40
A40
A40
A40
A40
BACK
03
04
A40
05
ü
G1
û
G1
ü
G1
G1
G1 10x10 4
G1
G1
G1
G1
14
14
Make sure back panels are perfectly aligned with
side panels and top and there are no gaps.
Gap present
No gap

11)
12)
page 12/18
G1 10x10 4
G1
G1
G1 G1
G1
14
14
ü
G1
û
G1
G18 4
15
14
14
14
14
15
G18
G18
G18
G18
G18
Gap
present
No gap

13)
14)
page 13/18
G1 10x10 12
07
G1
G1
G1
G1
G1
G1
G1
G1
G1
G1
G1
G1
07
04
G1
G1
07
A9
A9
A9
A9
A9
A9
A9
07
14
14
14
G1
G1
G1
G1
G1
G1
G1
G1 10x10 8
A40 4,0x45 2
A40
A40
Attention: There are no
predrilled holes for the A4
and A40 screws on part 07.
3,5x16
A9 6
¼"
14
14

15)
A1 4,0x30 40
page 14/18
A1
10
09
Attention: There are no
predrilled holes for the
A1 screws on part 08.
10
09
08
13
11
A1
A1
09
08
11
13
12
A1 A1
A1
A1
5x
13
A1 4,0x30 40
A1
08
Attention: There are no
predrilled holes for the
A1 screws on part 08.
10
09
08
13
11
A1
A1
09
08
11
13
12
A1 A1
A1
A1
5x

16)
E21
B31
B31 5x
B31
B31
E22
Flip the assembled drawer
upside down to install glides.
B31 6,0x10 20 E21 5
Drawer RIGHT
E22 5
Drawer LEFT
E21
E21
E22
E22
B31
B31
E22
B31
B31
E21
08
page 15/18

18)
17)
5x
09
A9 3,5x16 10 E24 5
E24
5x
A25
A25
H17
A9
A9
08
08
page 16/18
!
09
A9
E24
Observe the correct
orientation as shown below.
ü
û
A9
A9
!
H17 5
A25 10
M4 x 25
A9 3,5x16 5

19) Place the labeled drawer in the top position
page 17/18
!

20)
!
ANTI-TIPPING RESTRAINT KIT
page 18/18
Install against the
furniture
A47
A47
F8 F8
Anchors and screws are not included,
choose best type based on your wall
on the wall
F15
F8
A47 3,0x20 2
F15 1
F8 2
Install both parts F8
Tighten them together
using the safety strap
WALLBOARDWALLBOARD
