GrainWood MC1305 User manual

Assembly Instructions
Thank you for choosing Grain Wood Furniture, it is an honor to be in your home!
If you have any questions, feedback, or need replacement parts please contact us at:
grainwoodfurniture.com/help or [email protected]
2-person assembly
PH #2
Made in Brazil
REV - 02/2023
Mid Century
Queen Spindle Bed
48 ½"
Finish
Model #
MC1305 Brushed Walnut
63 ½"
84 ¼"
page 1/12

Enjoy your 100% solid wood furniture!
PLEASE READ BELOW BEFORE BEGINNING ASSEMBLY
grainwoodfurniture.com/assembly-troubleshooting
page 2/12
ŸEnlist help from a friend or family member, as most items require two
people for proper assembly.
ŸChoose a spacious, open area near where the piece will be located once
assembled. Moving parts is easier than relocating the fully assembled
furniture.
ŸOnly throw away packaging material once assembly is complete.
ŸAssemble the item on a soft surface, such as cardboard or an old blanket,
to protect the finish from possible dents or scratches.
ŸLay out the parts in order and count them twice. If any parts are missing
or damaged, document the problem with pictures and contact support
so we can make it right.
ŸSolid wood furniture may present imperfections such as wood knots,
minor splits, or cracks which are a natural aspect of the material.
Whenever the stability of the furniture is not compromised, we
recommend customers perform cosmetic touch-ups with wax crayon
fillers sold at all major hardware stores.
ŸIt is best to use the tools provided in the box, such as a hex key, because
they may be specially sized for the piece of furniture.
ŸWe do not recommend using power drills as they can damage your
furniture if not used correctly.
ŸUse a carpenter's square or hardcover book to check angles when
assembling drawers and doors. If they are not at 90 degrees, they will not
close properly.
ŸIf you have any problems, we are here to help. Just go to
grainwoodfurniture.com/help.
ŸSee grainwoodfurniture.com/care-guide for suggestions that will help
your furniture last for years.

HARDWARE LIST
3,5x16
A9 16 + 1
3,5x35
A14 16 + 1
1/4"x100/Ø13
B12 10
7,0x70/Ø17
B19 6
10x40
C3 12 + 1
D43 2
G8 1
G14 7
!ATTENTION
WARNING:
CHOKING HAZARD
Small parts, not for children.
To be assembled by an adult.
Before starting assembly
please verify the hardware
set is complete.
For missing hardware please
contact us at
grainwoodfurniture.com/help
B5 8 + 1
1/4"
Ø20
H21 10 + 4
1/4"x60/Ø13
B14 8
page 3/12

01
02
03
05
08
14
11
11
09
10
06
12
07
04
08
10
10
13
page 4/12
Part # Part #
11 2
Slat roll
07 1
Headboard lower crosspiece
12
HW
1
09 1
08 2
Side rail
Center rail
Upper crosspiece
1
Hardware
Description Description
Qty. Qty.
Box A - 1 of 2 Box B - 2 of 2
05 1
Footboard cross piece
03 1
02
Left headboard post
1
04 1
01 1
Right headboard post
Right footboard post
Left footboard post
06 1
Headboard crosspiece
14 1
Metal angle
10 3
Center support
13 10
Spindles

1)
2)
G8 1 B14 1/4"x60 4
05
03
04
B14 B14
B14
B14
G8
05
04
B14
B14
!
C3
Tip:
Use a hammer in case dowels
are hard to install by hand.
C3 10x40 12
08 2x
C3C3
C3C3
05
C3 C3
C3 C3
page 5/12
Tip:
Choose the side with the best
finish quality to be the top of
the footboard.

4)
G14
G14
3)
3,5x16
A9 3
A9
D43
!
A9
upper side
05
05
upper side
D43 1
D43
A9
A9
A9 A9
G14 Ø20 2
G14
05
03
04
G8
07
02
B14 G8
B14
07
02
G8
B14
G8 1 B14 1/4"x60 2
page 6/12
06
06
The part number label
marks the back side.
06
!

6)
5)
06
G8
07
02
!07
B14
G8
G8 1 B14 1/4"x60 2
01
G8 B14
B14
01
G8 1 B12 1/4"x100 2
06
07
02
01
G8
12
G8
B12
B12
B12
G8
12
02
!
page 7/12

7)
12 !
!
13
13
13
13
13
13
13
13
13
13
06
10x
13
06
02
01
01
13
13
page 8/12
12

8)
9)
3,5x16
A9 5
14
A9
A9
A9
A9
A9
A9
14
D43 1
A9
G14
G14
3,5x16
A9 3
D43
G14 Ø20 2
G14
!
D43
A9
A9
upper side
A9
07
07
01
02
A9
A9
page 9/12
Flip the headboard to
install support D43.
üû
14 14
!
14
A9
2"

10)
11)
G8 1
7,0x70
B19 6G14
10
10
10
G8
G8+B19 G8+B19
G8+B19 G8+B19
G8+B19 G8+B19
G14
G14
09
10
09
B19
B19
G14 Ø20 3
G14
G8 1 B12 1/4"x100 8
1/4"
B5 8
G8+B12
G8+B12
G8+B12
G8+B12
B12+G8
B12+G8
B12+G8
B12+G8
B5
B5
B5
B5
08
08
page 10/12
G8
B12
G8
B12
B5 08
B5

12)
13)
A9
3,5x16
A9 4
09
09
A9
Attention: There are
no predrilled holes
for the A9 screws on
part 09.
3,5x35
A14 16
11
08
Attention: There are
no predrilled holes
for the A14 screws
on parts 08 and 09.
11
11
11
A14
A14
A14
A14
A9
A9
A9 A9
page 11/12
A14
A14
A14
A14
A14
A14
A14
A14
A14
A14
A14
A14

14)
H21 10
H21H21
H21
H21
H21
H21
05
05
page 12/12
H21
H21
H21
H21
H21
H21
Tip:
Use a rubber mallet or a piece of
wood to protect the finish when
hammering the wood cap.
Tip:
Do not install wood caps in the back of the headboard posts.
Instead, save these 4 caps for eventual future use.
