Grand G340 User manual

CONTENTS

4
Edition 5/April 2023

TABLE OF CONTENTS
5Golden Line G340/G380 Owner’s Manual
1. SAFETY INFORMATION ..................................................................................... 10
Introduction .....................................................................................................................10
Precautionary symbols.......................................................................................................11
General information...........................................................................................................13
Maximum number of persons .............................................................................................14
Maximum loading capacity .................................................................................................14
Distribution of load............................................................................................................15
Loading passengers...........................................................................................................16
Stability and buoyancy.......................................................................................................18
Engine information............................................................................................................18
Risk of flooding and stability ..............................................................................................19
Risk of fire or explosion .....................................................................................................23
Fire prevention .................................................................................................................23
Fuel system ......................................................................................................................24
Before fueling ...................................................................................................................26
While fueling ....................................................................................................................27

TABLE OF CONTENTS
6
Fire-fighting equipment (for G380) ............................................................................ 28
Electrical systems - safety rules................................................................................. 30
Battery.................................................................................................................... 31
Man-overboard prevention and recovery .................................................................... 33
Means of reboarding ................................................................................................ 34
Safety equipment..................................................................................................... 35
Safety driving rules .................................................................................................. 37
Safety labels............................................................................................................ 39
2. BOAT IDENTIFICATION............................................................................. 41
Boat’s identification number...................................................................................... 41
Builder’s plate.......................................................................................................... 42
Location of the builder’s plate ................................................................................... 44
3. BEFORE OPERATING YOUR CRAFT ............................................................ 45
Checklist before departure ........................................................................................ 45
Weather.................................................................................................................. 46
General ................................................................................................................... 46

TABLE OF CONTENTS
7Golden Line G340/G380 Owner’s Manual
Rules to observe when afloat .............................................................................................47
4. OPERATING THE CRAFT..................................................................................... 48
Tube inflation ...................................................................................................................48
Overpressure valve (if fitted)..............................................................................................53
Motor installation ..............................................................................................................54
Motor start&stop...............................................................................................................56
Electrics ...........................................................................................................................58
Battery isolator switch .......................................................................................................58
Components of a boat .......................................................................................................64
Anchoring and mooring .....................................................................................................70
Anchoring.........................................................................................................................70
Mooring ...........................................................................................................................71
Towing.............................................................................................................................73
Beaching ..........................................................................................................................75
5. TECHNICAL INFORMATION ............................................................................... 76
Technical specifications .....................................................................................................76

TABLE OF CONTENTS
8
Standard and optional equipment .............................................................................. 78
Compartment chart .................................................................................................. 80
General arrangement of a boat ................................................................................. 81
Steering console components.................................................................................... 83
General view of a boat G340 ..................................................................................... 85
General view of a boat G380 ..................................................................................... 86
Electrical schematic diagram of G340......................................................................... 87
Electrical schematic diagram of G380......................................................................... 88
6. SERVICE AND MAINTENANCE ................................................................... 89
Cleaning.................................................................................................................. 90
Cleaning of tube ...................................................................................................... 91
Plastic preservation .................................................................................................. 93
Cleaning.................................................................................................................. 93
Salt removal ............................................................................................................ 94
Polishing ................................................................................................................. 94
Waxing ................................................................................................................... 94

TABLE OF CONTENTS
9Golden Line G340/G380 Owner’s Manual
Cleaning of the underwater part of the hull from deposits.....................................................95
Antifouling hull protection ..................................................................................................95
Upholstery care.................................................................................................................96
Airtightness of the inflatable tube .......................................................................................97
Maintenance of stainless steel ............................................................................................99
Winterizing and storage.....................................................................................................99
Regular inspections .........................................................................................................100
7. TRAILERING .................................................................................................... 101
Boat towing....................................................................................................................105
8. RESPECTING THE ENVIRONMENT ................................................................... 106
9. GRAND’S WARRANTY ...................................................................................... 107
General ..........................................................................................................................107
Warranty period..............................................................................................................107
Warranty coverage..........................................................................................................108
Warranty exclusions ........................................................................................................109
Warranty certificate.........................................................................................................110
FOR YOUR NOTES................................................................................................... 111

SAFETY
10
1. SAFETY INFORMATION
INTRODUCTION
Thank you for choosing a Grand boat.
If you need assistance or advice please contact your Grand Dealer or Distributor who has qualified
specialists, special tools, original spare parts and accessories and will be happy to assist.
This Manual provides an overview for the safe operation of your Grand boat and is not intended to
teach you how to repair it . Please take time to read it carefully so as to become familiar with your
new boat. Make sure that you fully understand the controls and instructions before operating the
boat. Improper operation can be extremely dangerous!
Please, note that most boating-related accidents happen when safety instructions are ignored. We
want you to enjoy your experience on your boat so please be sure to take our guidance seriously
and comply with safety instructions at all times.
The basic safety rules are stated throughout the Manual, additional precautions are indicated by the
special PRECAUTIONARY SYMBOLS:

SAFETY
11 Golden Line G340/G380 Owner’s Manual
PRECAUTIONARY SYMBOLS
The following precautionary symbols are used throughout this Manual:
Indicates an imminently hazardous situation that, if not avoided,
will result in death or serious injury. This signal word is to be
limited to the most extreme situations.
Indicates a potentially hazardous situation that, if not avoided,
could result in death or serious injury.
Indicates a potentially hazardous situation that, if not avoided,
could result in minor or moderate injury.
Please note that in some countries a boat operating license or other form of authorization
may be required.
We strongly recommend that your boat is inspected at least once a year by an
authorized Grand agent.

SAFETY
12
Helmsmen should be familiar with the use of all safety equipment and emergency procedures (e.g.
man overboard recovery, towing etc.). We strongly recommend that appropriate training is
undertaken from a recognized boating and/or safety organization prior using your boat.
Please note that in some countries it is a mandatory requirement to wear a buoyancy aid.
Some information may not apply to your boat since standard and optional equipment may vary from
model to model.
Data sheets and specifications given in this manual relate to the boat's characteristics at the time of
publishing. Grand reserve the right to introduce changes in specifications and equipment without
notice and without obligation.
We continually work with our customers to improve quality and to ensure you will be completely
satisfied with your Grand boat.
If you have any additional questions after reading this manual, please feel free to ask for your dealer.
PLEASE KEEP THIS MANUAL IN A SECURE PLACE, AND HAND IT OVER TO THE NEW
OWNER WHEN YOU SELL THE CRAFT.

SAFETY
13 Golden Line G340/G380 Owner’s Manual
GENERAL INFORMATION
Name of craft Manufacture: GRAND MARINE. Model: G340 and G380.
According to the Recreational Craft Directive 2013/53/EU of the European Parliament and
of the Council of 20th November 2013, which is in force, your boat has design category: C,
i.e., the craft is designed to operate in the following conditions:
Wind (Beaufort scale) up to and including Force 6;
Significant wave height (H1/3, meters) up to and including 2 meters.
Explanatory note:
A watercraft given design category C is considered to be designed for a wind speed up to
and including Force 6 and significant wave height up to and including 2 m.
BE RESPONSIBLE, TAKE NOTICE OF THESE PARAMETERS WHEN YOU PLAN YOUR
NAVIGATION PROGRAM AND DO NOT BOAT IF THE WIND/WAVE CONDITIONS ARE
LIKELY TO EXCEED THESE PARAMETERS.

SAFETY
14
MAXIMUM NUMBER OF PERSONS
The Maximum number of people (adults + children) authorized to be on board according to design
standards ISO 14946 and ISO 12217 is given in the technical data sheet in the “TECHNICAL
INFORMATION” section.
DO NOT EXCEED THE MAXIMUM RECOMMENDED NUMBER OF PEOPLE. REGARDLESS OF THE
NUMBER OF PEOPLE ON BOARD, THE TOTAL WEIGHT OF PEOPLE AND EQUIPMENT MUST NEVER
EXCEED THE MAXIMUM RECOMMENDED LOAD. ALWAYS USE THE SEATS/SEATING SPACES
PROVIDED.
MAXIMUM LOADING CAPACITY
You can find the maximum load capacity in the “TECHNICAL INFORMATION” section in this Manual.
It is also shown on the builder’s plate affixed to the hull. Please note that the maximum load capacity
includes the weight of all people onboard, outboard engine, provisions, personal effects, and
additional equipment, minus liquids in fixed tanks. Note that excess and unevenly distributed load
within the boat can create unstable steering conditions and even loss of control.

SAFETY
15 Golden Line G340/G380 Owner’s Manual
WHEN LOADING THE CRAFT, NEVER EXCEED THE MAXIMUM RECOMMENDED LOAD.
ALWAYS LOAD THE CRAFT CAREFULLY AND DISTRIBUTE LOADS APPROPRIATELY TO
MAINTAIN DESIGN TRIM (APPROXIMATELY LEVEL). AVOID PLACING HEAVY WEIGHTS
HIGH UP.
DISTRIBUTION OF LOAD
Evenly distribute the load within the boat.
1. POORLY DISTRIBUTED LOADS CAN DESTABILIZE THE BOAT AND MAY RESULT IN A
LOSS OF CONTROL.
2. THE CRAFT’S HANDLING WILL CHANGE SIGNIFICANTLY DEPENDING ON THE LOAD
CARRIED.
3. BE PARTICULARLY CAREFUL WHEN ACCELERATING OR CHANGING DIRECTION.
IT MAY BE NECESSARY TO ADJUST LOAD DISTRIBUTION AND TRIM WHEN
NAVIGATION CONDITIONS OR THE CRAFT’S DIRECTION THROUGH WAVES CHANGE.

SAFETY
16
LOADING PASSENGERS
G340
G380
4 passengers.
5 passengers.
Fig. 1. Recommended seating arrangement.

SAFETY
17 Golden Line G340/G380 Owner’s Manual
IN CASE OF AN ACCIDENT
In case of an accident, do not panic and reassure passengers.
▪Be aware that your boat, even if damaged, may provide the best shelter and facilitate
your rescue. Never leave the boat whilst it remains afloat. Remember that an inflatable
boat, even when full of water, is virtually unsinkable.
▪If, after an accident, a tube compartment deflates, bring it inside the boat, restore the
load balance to the opposite side of the deflated compartment and return to port at
reduced speed.
▪In case of a collision or an impact with a floating object, stop to examine the hull, the
buoyancy tubes, the motor and its attachments and return to shore at a low speed.
▪Signal for help.
Following an accident and before using the craft again, make sure that it is examined by
your dealer or a qualified technician and any defects are repaired.
NEGLECTING REGULAR INSPECTIONS AND REPAIRS MAY LEAD TO A SERIOUS
INJURY OR DAMAGE AND WILL REDUCE THE LIFE OF YOUR BOAT.

SAFETY
18
STABILITY AND BUOYANCY
The stability and buoyancy of the craft have been thoroughly assessed by the builder in compliance
with the requirements of the Recreational Craft Directive 2013/53/EU. The craft builder guarantees
that the boat meets all safety criteria during normal operating conditions. However, the person
responsible for operating the craft must always keep in mind that the safety of the craft and crew
should be their priority at all times and that conditions on the water can change suddenly with little
prior notice. Before using your boat, it is strongly recommended that appropriate training is given
to all crew members in the safe operation of the craft.
ENGINE INFORMATION
Information about recommended engine capacities, maximum engine capacities, maximum engine
weights for each model are given in the technical data sheet of “TECHNICAL INFORMATION” section.
NEVER USE A MOTOR WITH A POWER OUTPUT GREATER THAN THE MAXIMUM RECOMMENDED,
OR HEAVIER THEN INDICATED ON THE BUILDER'S PLATE. THIS COULD RESULT IN LOSS OF
CONTROL.

SAFETY
19 Golden Line G340/G380 Owner’s Manual
RISK OF FLOODING AND STABILITY
The drainage system consists of cockpit drainage (a hose with plug + valve) and hull
drainage (drain plug + bilge pump, which can operate in manual/automatic mode).
COCKPIT DRAINAGE
Fig. 2. Cockpit drainage.
In water at rest
In water in motion
Out of water
Cockpit drain plug
Closed
Open
Open
WHEN THE BOAT IS ON LAND/DAVIT OR TRAILER, OPEN THE
COCKPIT DRAIN PLUG SO THAT WATER (RAINWATER, FOR INSTANCE) CAN EASILY
DRAIN OUT OF THE BOAT THROUGH THE VALVES AND NO DAMAGE TO THE INTERNAL
COMPONENTS (E.G THE BATTERY) WILL OCCUR.
Cockpit
drain valve
Cockpit
drain plug

SAFETY
20
HULL DRAINAGE
NEVER OPEN THE HULL DRAIN PLUG WHEN
AFLOAT.
Fig. 3. Hull drain plug.
In water at rest
In water in motion
Out of water
Hull drain plug
Closed
Closed
Open
To drain the hull unscrew the plug (fig. 3). After removal refit and re-tighten (do not
over-tighten) the plug before using the boat.
WHEN THE BOAT IS ON LAND/DAVIT OR TRAILER, OPEN THE HULL DRAIN PLUG SO THAT
WATER CAN EASILY DRAIN OUT OF THE BOAT.
Hull drain plug
