Grand Silver Line S470N User manual

stna

CONTENTS
Edition 5/June 2023

TABLE OF CONTENTS
4
1. SAFETY INFORMATION ............................................................................... 9
Introduction ..............................................................................................................9
Precautionary symbols.............................................................................................. 10
General information.................................................................................................. 12
Maximum number of persons .................................................................................... 13
Maximum loading capacity ........................................................................................ 13
Engine information................................................................................................... 14
Risk of flooding and stability ..................................................................................... 15
Bilge pumps and bailing............................................................................................ 17
Stability and buoyancy.............................................................................................. 18
Risk of fire or explosion ............................................................................................ 20
Fire prevention ........................................................................................................ 21
Battery.................................................................................................................... 23
Fuel ........................................................................................................................ 24
Fire-fighting equipment ............................................................................................ 25
Electrical systems - Safety rules ................................................................................ 26

TABLE OF CONTENTS
5 Silver Line S470N Owner’s Manual
Engine starting ........................................................................................................ 26
Man-overboard prevention and recovery .................................................................... 26
Means of reboarding ................................................................................................ 27
Danger from moving parts ........................................................................................ 27
Safety equipment..................................................................................................... 28
Safety driving rules .................................................................................................. 29
2. BOAT IDENTIFICATION............................................................................. 31
Boat’s identification number...................................................................................... 31
Builder’s plate.......................................................................................................... 32
3. BEFORE OPERATING YOUR CRAFT ............................................................ 34
Weather.................................................................................................................. 34
Checklist before departure ........................................................................................ 34
Checking the boat and equipment ............................................................................. 36
Rules to observe when afloat .................................................................................... 37
4. OPERATING THE CRAFT............................................................................. 38
CL-14 steering console installation............................................................................. 39

TABLE OF CONTENTS
6
CS-03 steering console installation............................................................................. 40
Container installation................................................................................................ 41
Tube inflation .......................................................................................................... 42
Overpressure valve (if fitted)..................................................................................... 49
Motor installation ..................................................................................................... 50
Electrics .................................................................................................................. 53
Navigation lights ...................................................................................................... 59
Horn ....................................................................................................................... 59
Anchoring and mooring ............................................................................................ 61
Anchoring................................................................................................................ 61
Mooring .................................................................................................................. 62
Towing.................................................................................................................... 65
5. TECHNICAL INFORMATION ....................................................................... 73
Technical specifications ............................................................................................ 73
Standard and optional equipment .............................................................................. 75
Compartment chart .................................................................................................. 77
General arrangement of a boat S470N (S470NF) ........................................................ 78

TABLE OF CONTENTS
7 Silver Line S470N Owner’s Manual
General arrangement of a boat S470NS (S470NSF)..................................................... 79
General arrangement of a boat S470NL (S470NLF) ..................................................... 80
Steering console components.................................................................................... 81
General view of a boat S470N ................................................................................... 82
General view of a boat S470NS ................................................................................. 83
General view of a boat S470NL ................................................................................. 84
Loading passengers for S470NS (S470NSF)................................................................ 85
Loading passengers for S470NL (S470NLF) ................................................................ 86
Electrical schematic diagram ..................................................................................... 87
6. SERVICE AND MAINTENANCE ................................................................... 89
Cleaning of tube ...................................................................................................... 91
Plastic preservation .................................................................................................. 93
Cleaning.................................................................................................................. 93
Salt removal ............................................................................................................ 94
Polishing ................................................................................................................. 94
Waxing ................................................................................................................... 94
Cleaning of the underwater part of the hull from deposits............................................ 95

TABLE OF CONTENTS
8
Upholstery care........................................................................................................ 96
Acrylic glass windshield care ..................................................................................... 97
Airtightness of the inflatable tube .............................................................................. 98
Maintenance of stainless steel ................................................................................. 100
Winterizing and storage.......................................................................................... 100
Regular inspections ................................................................................................ 101
7. TRAILERING ............................................................................................ 102
Lifting the boat ...................................................................................................... 102
Boat towing........................................................................................................... 103
8. RESPECTING THE ENVIRONMENT ........................................................... 104
9. GRAND’S WARRANTY .............................................................................. 105
Warranty period..................................................................................................... 105
Warranty coverage................................................................................................. 106
Warranty exclusions ............................................................................................... 107
FOR YOUR NOTES........................................................................................... 109

SAFETY
9 Silver Line S470N Owner’s Manual
1. SAFETY INFORMATION
INTRODUCTION
Thank you for choosing a Grand boat.
If you need assistance or advice please contact your Grand Dealer or Distributor who has qualified
specialists, special tools, original spare parts and accessories and will be happy to assist.
This Manual provides an overview for the safe operation of your Grand boat and is not intended to
teach you how to repair it . Please take time to read it carefully so as to become familiar with your
new boat. Make sure that you fully understand the controls and instructions before operating the
boat. Improper operation can be extremely dangerous!
Please, note that most boating-related accidents happen when safety instructions are ignored. We
want you to enjoy your experience on your boat so please be sure to take our guidance seriously
and comply with safety instructions at all times.
The basic safety rules are stated throughout the Manual, additional precautions are indicated by the
special PRECAUTIONARY SYMBOLS:

SAFETY
10
PRECAUTIONARY SYMBOLS
The following precautionary symbols are used throughout this Manual:
Indicates an imminently hazardous situation that, if not avoided,
will result in death or serious injury. This signal word is to be
limited to the most extreme situations.
Indicates a potentially hazardous situation that, if not avoided,
could result in death or serious injury.
Indicates a potentially hazardous situation that, if not avoided,
could result in minor or moderate injury.
Please note that in some countries a boat operating license or other form of authorization may be
required.
We strongly recommend that your boat is inspected at least once a year by an authorized
Grand agent.

SAFETY
11 Silver Line S470N Owner’s Manual
Helmsmen should be familiar with the use of all safety equipment and emergency procedures
(e.g. man overboard recovery, towing etc.). We strongly recommend that appropriate training is
undertaken from a recognized boating and/or safety organization prior using your boat.
Please note that in some countries it is a mandatory requirement to wear a buoyancy aid.
Some information may not apply to your boat since standard and optional equipment may vary
from model to model.
Data sheets and specifications given in this manual relate to the boat's characteristics at the time
of publishing. Grand reserve the right to introduce changes in specifications and equipment
without notice and without obligation.
We continually work with our customers to improve quality and to ensure you will be completely
satisfied with your Grand boat.
If you have any additional questions after reading this manual, please feel free to ask for your
dealer.
PLEASE KEEP THIS MANUAL IN A SECURE PLACE, AND HAND IT OVER TO THE NEW
OWNER WHEN YOU SELL THE CRAFT.

SAFETY
12
GENERAL INFORMATION
Name of craft Manufacture: GRAND MARINE. Models: S470N, S470NF, S470NS, S470NSF,
S470NL, S470NLF.
According to the Recreational Craft Directive 2013/53/EU of the European Parliament and of the
Council of 20th November 2013, which is in force, your boat has design category: C, i.e., the craft
is designed to operate in the following conditions:
Wind (Beaufort scale) up to and including Force 6.
Significant wave height (H1/3, meters) up to and including 2 meters.
Explanatory note:
A watercraft given design category C is considered to be designed for a wind speed up to and
including Force 6 and significant wave height up to and including 2 m.
BE RESPONSIBLE, TAKE NOTICE OF THESE PARAMETERS WHEN YOU PLAN YOUR NAVIGATION
PROGRAM AND DO NOT BOAT IF THE WIND/WAVE CONDITIONS ARE LIKELY TO EXCEED THESE
PARAMETERS.

SAFETY
13 Silver Line S470N Owner’s Manual
MAXIMUM NUMBER OF PERSONS
The Maximum number of people (adults + children) authorized to be on board according to design
standards ISO 6185, ISO 14946 and ISO 12217 is given in the technical data sheet in the
“TECHNICAL INFORMATION” section.
DO NOT EXCEED THE MAXIMUM RECOMMENDED NUMBER OF PEOPLE. REGARDLESS OF THE
NUMBER OF PEOPLE ON BOARD, THE TOTAL WEIGHT OF PEOPLE AND EQUIPMENT MUST NEVER
EXCEED THE MAXIMUM RECOMMENDED LOAD. ALWAYS USE THE SEATS/SEATING SPACES
PROVIDED.
MAXIMUM LOADING CAPACITY
You can find the maximum load capacity in the “TECHNICAL INFORMATION” section in this Manual.
It is also shown on the manufacturer’s plate affixed to the hull. Please note that the maximum load
capacity includes the weight of all people onboard, outboard engine, provisions, personal effects,
and additional equipment minus liquids in fixed tanks. Note that excess and unevenly distributed
load within the boat can create unstable steering conditions and even loss of control.

SAFETY
14
WHEN LOADING THE CRAFT, NEVER EXCEED THE MAXIMUM RECOMMENDED LOAD. ALWAYS LOAD
THE CRAFT CAREFULLY AND DISTRIBUTE LOADS APPROPRIATELY TO MAINTAIN DESIGN TRIM
(APPROXIMATELY LEVEL). AVOID PLACING HEAVY WEIGHTS HIGH UP.
ENGINE INFORMATION
Information about recommended engine capacities, maximum engine capacities, maximum engine
weights for each model are given in the technical data sheet of “TECHNICAL INFORMATION” section.
Please refer to the manual supplied by motor manufacturer before operating the motor
and craft.
Routine maintenance should be carried out in strict conformity with the instructions given
in the appropriate motor owner's manual.
NEVER USE A MOTOR WITH A POWER OUTPUT GREATER THAN THE MAXIMUM RECOMMENDED,
OR HEAVIER THEN INDICATED ON THE MANUFACTURER'S PLATE. THIS COULD RESULT IN LOSS
OF CONTROL.

SAFETY
15 Silver Line S470N Owner’s Manual
RISK OF FLOODING AND STABILITY
HULL DRAINAGE
NEVER OPEN THE HULL DRAIN PLUG WHEN AFLOAT.
To drain the hull, remove the plug (fig. 1).
Fig. 1. The hull drain plug is located on the transom.
After removal refit and re-tighten (do not over-tighten) the plug before using the boat.
Hull drain plug

SAFETY
16
COCKPIT DRAINAGE
The boat is equipped with two cockpit drain plugs located at the transom.
Fig. 2. Cockpit drain plugs.
WHEN THE BOAT IS ON LAND/DAVIT OR TRAILER, OPEN THE COCKPIT DRAIN PLUGS SO THAT
WATER (RAINWATER, FOR INSTANCE) CAN EASILY DRAIN OUT OF THE BOAT AND NO DAMAGE
TO THE INTERNAL COMPONENTS (E.G THE BATTERY) WILL OCCUR.
Main cockpit
drain plug
Additional cockpit
drain plug

SAFETY
17 Silver Line S470N Owner’s Manual
BILGE PUMPS AND BAILING
The craft is equipped with a bilge pump and drain pipe. To turn on/off the bilge pump use a
switch located on the steering console.
THE BILGE PUMP SYSTEM IS NOT DESIGNED FOR DAMAGE CONTROL.
CHECK BILGE PUMPS REGULARLY TO MAKE SURE THEY ARE WORKING. CLEAR DEBRIS FROM
PUMP INLETS.

SAFETY
18
STABILITY AND BUOYANCY
The stability and buoyancy of the craft have been thoroughly assessed by the Manufacture in
compliance with the requirements of the Recreational Craft Directive 2013/53/EU.
The craft manufacturer guarantees that the boat meets all safety criteria during normal operating
conditions.
However, the person responsible for operating the craft must always keep in mind that the safety
of the craft and crew should be their priority at all times and that conditions on the water can change
suddenly with little prior notice.
Before using your boat, it is strongly recommended that appropriate training is given to all crew
members in the safe operation of the craft.
IN CASE OF AN ACCIDENT, DO NOT PANIC AND REASSURE PASSENGERS
▪Be aware that your boat, even if damaged, may provide the best shelter and facilitate your
rescue. Never leave the boat whilst it remains afloat. Remember that an inflatable boat, even
when full of water, is virtually unsinkable.
▪If, after an accident, a tube compartment deflates, bring it inside the boat, restore the load
balance to the opposite side of the deflated compartment and return to port at reduced speed.

SAFETY
19 Silver Line S470N Owner’s Manual
▪In case of a collision or an impact with a floating object, stop to examine the hull, the buoyancy
tubes, the motor and its attachments and return to shore at a low speed.
▪Signal for help.
Following an accident and before using the craft again, make sure that it is examined by
your dealer or a qualified technician and any defects are repaired.
NEGLECTING REGULAR INSPECTIONS AND REPAIRS MAY LEAD TO A SERIOUS INJURY
OR DAMAGE AND WILL REDUCE THE LIFE OF YOUR BOAT.
For information concerning safe operation of the engine consult the manufacturers instruction
manual.
Consult your Dealer for more detailed information on this subject before operating your boat.

SAFETY
20
RISK OF FIRE OR EXPLOSION
For information concerning safe operation of the engine consult the manufacturers instruction
manual.
Consult your Dealer for more detailed information on this subject before operating your boat.
AVOID CONTACT OF FLAMMABLE MATERIALS WITH HOT ENGINE PARTS.
Most fires are caused by electrical problems or careless fueling.
In case of fire, we recommend to stop the motor and turn off the battery switch.
Pay particular attention to the fact that a fuel tank and electrical devices are installed on your boat.
This means that there is a risk of explosion or fire caused, for example, by a spark. Be careful and
check systems regularly with a view to identifying leaks or corrosion in the fuel tank and possible
damage to the electrical wiring.
For information concerning safe operation of the engine consult the manufacturers instruction
manual.
