Grandhall T2 User manual

MODEL T2.
GAS BARBECUE
Assembly i structio s
I structio s d’assemblage
Mo tagea weisu ge
Istruzio i per il mo taggio
Mo tage-i structies
Mo teri g
Kokoamisohjeet
I struccio es de armado
I struções para Mo tagem
Mo teri gsvejled i g
Mo teri g
I strukcje 0086
GB
FR
DE
IT
NL
SE
FI
ES
PT
DK
NO
PL
IE
CH
CH
CH
BE
AT
Page 109/09/13 13:50PM
P80184044A

ASSEMBLY
2
NOTE: Where multiple screws are used in an assembly step, partially install all screws prior to tightening.
Attach bottom shelf support bracket.
1
Attach trolley panels to bottom shelf.
3
Phillips-head screw 3/16" x 3/8"
Qty: 8
Black
Attach upper bracket.
4
Phillips-head screw 3/16" x 3/8"
Qty: 2
Black
Attach trolley front panel to trolley panels.
2
Phillips-head screw 3/16" x 3/8"
Qty: 2
Black
Phillips-head screw 3/16" x 3/8"
Qty: 2
Black
Ref # 45
Ref # 47
crew
Ref # 52
Ref # 53
Upper bracket
Right trolley panel
Ref # 44
Ref # 47
crewdriver
Ref # 46
Ref # 47
NOTE: The upper bracket
must be inside the trolley
panels.
Page 209/09/13 13:50PM
P80184044A

3
Attach castors.
5
Install rear trolley frame bracket.
7
Wrench 14 mm
Qty: 1
Black
Phillips-head screw 1/4" x 23/8"
Qty: 2
Stainless steel colour
Attach front trolley frame bracket.
6
Phillips-head screw 1/4" x 23/8"
Qty: 2
Stainless steel colour
Rear, Ref # 50
Front, Ref # 51
Ref # 54
Ref # 51
Ref # 50
Page 309/09/13 13:50PM
P80184044A

4
Attach side shelves.
9
Phillips-head screw 1/4" x 1/2"
Qty: 8
Black
Ref # 37, 39a, 39b, 41
Ref # 36, 38a, 38b, 40
Ref # 51
Attach grill head to trolley.
8
Phillips-head screw 1/4" x 3/8"
Qty: 2
Black
Phillips-head screw 3/16" x 3/8"
Qty: 2
Black
A
A
A
B
B
B
B
Page 409/09/13 13:50PM
P80184044A

5
Install cylinder holder.
10
Phillips-head screw 3/16" x 3/8"
Qty: 2
Black
Ref # 48, 49
1ST
2ND
Install ignition battery.
Unscrew the cap from the ignition module.
Insert the AA battery with the ‘+’ terminal
facing outwards. Screw cap on.
11
AA battery
pring
Cap
Page 509/09/13 13:50PM
P80184044A

6
NOTE: Locate the pin on
the flame tamer into the
hole in the bowl ledge.
The flame tamer locates
underneath the grill plate.
Grill plate
Ref # 8
Flame tamer
Ref # 9
COOKING COMPONENT INSTALLATION INSTALL GREASE TRAY / RECEPTACLE
After installing grease tray, secure with the two wing-head screws
supplied.
Ref # 32
Ref # 34.
Do not line
this tray with
foil
Wing-head screw 3/16" x 5/8"
Qty: 2
Black
Page 609/09/13 13:50PM
P80184044A

INSTALLING GAS CYLINDER AND
CONNECTING TO GAS SO RCE
7
DO NOT OBSTR CT THE VENTILATION
OPENINGS IN THE TROLLEY.
NE PAS BO CHER LES O VERT RES DE
VENTILATION DANS LE CHARIOT.
NICHT DIE VENTILATIONSÖFFN NGEN IM
WAGEN BLOCKIEREN.
NON OSTR IRE LE APERT RE DI
VENTILAZIONE DEL CARRELLO.
DE VENTILATIEOPENINGEN IN DE TROLLEY
NIET BLOKKEREN.
BLOCKERA EJ VENTILATIONSHÅLEN
I GRILLBAREN.
KÄRRYN T LET SA KKOJA EI SAA
PEITTÄÄ.
NO OBSTR YA LAS ABERT RAS DE
VENTILACIÓN DEL CARRITO.
NÃO OBSTR A AS ABERT RAS DE
VENTILAÇÃO NO TRÓLEI.
VENTILATIONSÅBNINGEN I TROLLEYEN MÅ
IKKE SPÆRRES.
VENTILASJONSÅPNINGENE PÅ TRALLEN MÅ
IKKE TILDEKKES.
NIE BLOKOWAC OTWORÓW
WENTYLACYJNYCH NA WÓZK
WARNINGS INFORMATION
PT
DK
NO
GB
FR
NL
SE
FI
ES
DE
IT PL ´
LEAK CHECK GAS CONNECTIONS
Page 709/09/13 13:50PM
P80184044A

8
•Main 1.15 mm – I 3+ (28-30/37)
– I 3B/P (30)
1.00 mm – I 3B/P (50)
•Main 11.6 kW – 842 grams / h
• MINIM M CLEARANCES FROM COMB STIBLE MATERIALS M ST BE:
REAR - 450 mm
SIDES - 250 mm
TOP - 1000 mm
WARNINGS INFORMATION
INJECTOR
INP T
DIMENSIONS
1200 mm 600 mm
450 mm
1160 mm
675 mm
1565 mm
1000 mm
250 mm
Page 809/09/13 13:50PM
P80184044A

9
COOKING WITH HOOD DOWN
COOKING WITH HOOD OPEN
250˚
Page 909/09/13 13:50PM
P80184044A

10
This diagram is provided to assist you identify parts
if replacement is necessary. Contact your place of
purchase or the manufacturer to enquire about
parts, availability and or service.
Items included in your barbecue may differ from the
Parts List, depending on region or specific dealer
specifications.
PARTS DIAGRAM
1
2
4
3
11
4
1a
5
7
7
13
8
9
12
16
17
18
15
19
20
23
24
25
26
29
35b
30
42 35a
46
50
41
54
37
34
32
14
12
53
49
48
47
51
55
54
52
45
44
40
38a
38b
39a
39b
36
28
27
Page 10
56
09/09/13 13:50PM
P80184044A

1 Hood assembly P00153059B 1
1a Hood handle heat shield P06917006M 1
2 Temperature gauge P00601484C 1
3 Hood hinge pin P05501138A 2
4 Protective pad – front / rear P05518046I 4
5 Hood handle P00202023B 1
7 Cooking rack – secondary P01504020G 1
8 Grill plate P01615039H 2
9 Flame tamer P01705038E 2
11 Bowl wind shield P00748039A 1
12 Protective pad bracket – rear P03320009D 2
13 Bowl panel – left P0072096JA 1
14 Bowl panel – right P0072197JA 1
15 Bowl panel – front P0073884 A 1
16 Bowl panel – rear P0075805 A 1
17 Burner bracket P0220433ED 1
18 H burner – 30 mbar P02008073B 2
H burner –50 mbar P02008074B 2
19 Gas collector with electrode P02609010B 2
20 Electronic wire set P02615171A 1
23 Gas valve manifold assembly – 30 mbar Y0060719 1
Gas valve manifold assembly –50 mbar Y0060720 1
23a Gas valve w/o jet – 30 mbar P03234075A 2
Gas valve w/o jet –50 mbar P03234076A 2
23b Manifold P05001352H 1
23c Gas jet – 30 mbar P06519097A 2
Gas jet –50 mbar P06519105A 2
23d Gas valve heat shield P03006141B 1
24 Control panel – upper, 3O mbar P02906512A 1
24 Control panel –upper, 5O mbar P02906512B 1
25 Control panel – lower P0290652BU 1
26 nob seat P03415014S 2
27 nob seat spring P05504115A 2
28 nob P03401487 2
29 Electronic igniter protector P03343006A 1
30 Electronic igniter – 2 port P02502252C 1
32 Grease receptacle P02701317B 1
34 Grease tray P02717645B 1
35a Bowl bracket – front P01321001C 1
35b Bowl bracket – rear P01319005C 1
36 Side shelf – left P01102063C 1
37 Side shelf – right P01103054C 1
38a Side shelf hinge brackets – LF P03327092U 1
38b Side shelf hinge brackets – LR P03327093U 1
39a Side shelf hinge brackets – RF P03327094U 1
39b Side shelf hinge brackets – RR P03327095U 1
40 Side shelf trim plate – left P07503025T 1
41 Side shelf trim plate – right P07502034T 1
42 Universal hose barb P03901024A 1
44 Trolley panel – left P07605037H 1
45 Trolley panel – right P07606040H 1
46 Trolley rear upper bracket P03301066D 1
47 Trolley panel – front P00927009D 1
48 Gas cylinder holder bracket P04009009N 1
49 Gas cylinder holder strap P05314015V 1
50 Trolley frame bracket – rear P03334011E 1
51 Trolley frame bracket – front P03334012E 1
52 Trolley bottom shelf support bracket P03327089U 1
53 Trolley bottom shelf P01001076R 1
54 Castor wheel P05112008A 4
55 Gas cylinder frame P04021013N 1
Name plate P00407036A 1
11
PARTS LIST
Ref Description Part No. Qty
Page 11
Hardware pack P06003133A 1
56
09/09/13 13:50PM
P80184044A

DECH AT
FR
NOTE: This information is a guide only. Items included in your BBQ
specification may differ depending on region or specific dealer specification.
GB
NOTE: Ces renseignements sont donnés à titre indicatif. Il est possible
que les articles inclus dans les spécifications de votre barbecue diffèrent
selon la région ou les caractéristiques stipulées par le concessionnaire.
ANMERK NG: Diese Anleitung dient nur zu Informationszwecken. Einzelteile
der Grillspezifikation sind unter Umständen verschieden entsprechend der
Vertriebsregion oder bestimmten Händleranforderungen.
CH
NLBE
ITCH AVVERTENZA: Queste informazioni hanno il valore di guida soltanto.
Gli articoli compresi nelle caratteristiche tecniche del barbecue potrebbero
variare a seconda della regione o del concessionario.
ATTENTIE: Deze informatie is alleen bedoeld als gids. Onderdelen in uw
BBQ specificatie kunnen per regio of per dealer verschillen.
ANM.: Denna information är endast avsedd som handledning.
Specifikationerna för grillen kan variera regionalt eller beroende på de krav
som olika återförsäljare har.
SE
NOTA: Esta información es una guía únicamente. Es posible que las
indicaciones incluidas en las especificaciones de su Asador sean diferentes
según la región o las especificaciones específicas del representante.
ES
NOTA: Esta informação é simplesmente um guia. Os itens incluídos na
especificação do seu BBQ poderão diferir dependendo da especificação da
região ou do vendedor específico.
PT
NB: Denne information er kun vejledende. Specifikationer kan variere efter
ønske fra forhandler, eller i henhold til nationale regler.
DK
NB: Denne informasjon er kun veiledende. Spesifikasjoner kan variere som
stipulert av forhandler, eller i henhold til nasjonale krav.
NO
WAGA: Informacje te słu ą jedynie, jako wskazówki. Elementy wchodz ą ce
w skład specyfikacji twojego grilla mog
ą si ę ró  ni ć w zale  ności od rejonu
lub szczególnych specyfikacji dealera.
PL
H OMATKAA: Nämä tiedot ovat pelkästään suuntaa antavia. Ostamanne
grillin yksityiskohdat voivat olla erilaiset paikkakunnan tai erityisten
myyjäkohtaisten yksiyiskohtien mukaan.
FI
IE All specifications are subject to change
without notice.
Toutes les caractéristiques sont susceptibles d’être
modifiées sans préavis.
Änderungen ohne vorherige Bekanntgabe
vorbehalten.
Tutti i dati tecnici possono cambiare
senza preavviso.
Alle specificaties kunnen zonder voorafgaande
kennisgeving worden gewijzigd.
Kaikki oikeudet teknisten tietojen
muutoksiin pidätetään.
Kaikki yksityiskohdat voivat muuttua ilman,
etta niistä erikseen ilmoitetaan.
Todas las especificaciones están sujetas a
cambios sin previo aviso.
Todas as especificações estão sujeitas a
alteração sem aviso.
Alle specifikationer kan ændres foruden varsel.
P80184044A Printed 09/2013
Manufacturer:
Grand Hall Enterprises Co. Ltd.
9th Fl. No 298 Rueiguang Rd
Neihu, Taipei, Taiwan
[email protected]
Grand Hall Europe B.V.
Tolstraat 17a
7482 DC Haaksbergen The
Netherlands
Email: [e-mail]
SERVICE
Wszystkie specyfikacje mog ą ulec zmianie
bez uprzedzenia.
pesifikasjoner kan endres uten varsel.
0086
Page 1209/09/13 13:50PM
P80184044A
www. grandhall.eu
