INTRODUCTION
A Virtual Private Network (VPN) is used to create an encrypted connection tunnel, enabling users to
exchange data across shared or public networks while acting as clients connected to a private network.
The benefit of using a VPN is to ensure the appropriate level of security to connected systems when the
underlying network infrastructure alone cannot provide it. The most common types of VPNs are remote-
access VPNs and site-to-site VPNs.
Figure 1: VPN Architecture Overview
The VPN security model provides:
✓Client authentication to forbid any unauthorized user from accessing the VPN network.
✓Encryption, that will prevent man in middle attacks and eavesdropping on the network traffic.
✓Data integrity to maintain the consistency, and trustworthiness of the messages exchanged.
The purpose of this guide is to underline VPN client/server feature on Grandstream GWN7000 Router and
use this feature to implement Site-to-Site VPN using OpenVPN® to connect multiple locations.
© 2002-2014 OpenVPN Technologies, Inc.
OpenVPN is a registered trademark of OpenVPN Technologies, Inc

GWN7000 OpenVPN® Site-to-Site VPN Guide
P a g e | 5
SCENARIO OVERVIEW
Company ABC has several locations offices connected to the Internet using Grandstream GWN7000
routers and for security reasons the traffic between the main office in LA and one of the branch offices in
NY, the admin has decided to establish a VPN Site-to-Site between the two sites to ensure that sensitive
data between the two networks is forwarded securely into the encrypted tunnel. This will allow also phone
calls to go encrypted and protected against possible rogue eavesdropping of phone calls between the two
offices.
✓The main office has a LAN subnet with range of: 192.168.1.0/24
✓The branch office has a LAN Subnet with range of: 192.168.3.0/24
✓The VPN tunnel will have the following IP range: 10.1.1.0/24
The figure below shows the actual diagram of the network:
Figure 2: Network Diagram
The main design is to set the client/server architecture to implement the VPN Tunnel, currently GWN
supports client/server for both OpenVPN® and PPTP technologies, we will cover through this guide the
necessary configurations that are needed to establish the connection and provide at the end some
verification procedures.

GWN7000 OpenVPN® Site-to-Site VPN Guide
P a g e | 6
CONFIGURATION STEPS
In this guide, we are providing necessary steps configuration needed to achieve the described scenario on
the first section. For more detailed descriptions for each configuration field/parameter, please refer to
GWN7000 User Manual or GWN7000 VPN Guide.
Core Site Configuration
First, we start by setting up the core site side, we will need to implement an OpenVPN® Server which will
be accepting connection from OpenVPN® clients enabled on remote branch offices/sites.
Generate Self-Issued Certificate Authority (CA)
Acertificate authority (CA) is a trusted entity that issues electronic documents that verify a digital entity's
identity on the Internet. The electronic documents (a.k.a. digital certificates) are an essential part of secure
communication and play an important part in the public key infrastructure (PKI).
To create a Certification Authority (CA), follow below steps:
1. Go to “System SettingsCert. ManagerCAs” on the GWN7000 web GUI.
2. Click on button. A popup window will appear.
3. Enter the CA values including CN, Key Length, Digest algorithm… depending on your needs.
Refer to below figure showing an example of configuration.

GWN7000 OpenVPN® Site-to-Site VPN Guide
P a g e | 7
Figure 3: Create CA Certificate
4. Click on button after completing all the fields for the CA certificate.
5. Click on button to export the CA to local computer. The CA file has extension “.crt”.
Generate Server/Client Certificates
Administrator needs to create both server and client certificates for encrypted communication between
clients and GWN7000 acting as an OpenVPN® server at the core site.
✓Creating Server Certificate
To create server certificate, follow below steps:
1. Go to “System SettingsCert. ManagerCertificates”.
2. Click on button. A popup window will appear.
Refer to below figure showing an example of configuration.

GWN7000 OpenVPN® Site-to-Site VPN Guide
P a g e | 8
Figure 4: Generate Server Certificates
3. Click on button after completing all the fields for the server certificate.
✓Creating Client Certificate
To create client certificate, follow below steps:
1- Create Users
a. Go to “System SettingsUser Manager”.
b. Click on button. The following window will pop up.

GWN7000 OpenVPN® Site-to-Site VPN Guide
P a g e | 9
Figure 5: Create Users
c. Make sure to enter the branch site LAN IP range in the field “OpenVPN Subnet”. This will
allow the GWN7000 acting as OpenVPN® server to build a route pointing to that network
and send all traffic destined to that IP range to the GWN7000 located on the branch site.
d. Repeat above steps for each Site.
2- Generate Client Certificate
a. Go to “System SettingsCert. ManagerCertificates”.
b. Click on button. The following window will pop up.
c. Enter client certificate information based on below descriptions.

GWN7000 OpenVPN® Site-to-Site VPN Guide
P a g e | 10
Figure 6: Client Certificate
d. Click on after completing all the fields for the client certificate.
e. Click on to export the client certificate file in “.crt” format.
f. Click on to export the client key file in “.key” format.
Notes:
•Client certificates generated from the GWN7000 server need to be uploaded to the GWN client.
•For security improvement, each client needs to have his own username and certificate; this way
even if a user is compromised, other users will not be affected.

GWN7000 OpenVPN® Site-to-Site VPN Guide
P a g e | 11
Create OpenVPN® Server
Once client and server certificates are successfully created, administrator can create the OpenVPN® server
at the core site router, so that remote branch sites can be connected to it via OpenVPN® client instances.
To create a new VPN server, follow below steps:
1. Go under “VPNOpenVPN®Server”.
2. Click on and fill in the required information as shown on the figure below.
Figure 7: Create OpenVPN® Server

GWN7000 OpenVPN® Site-to-Site VPN Guide
P a g e | 12
The table below gives the description for each option.
Table 1: OpenVPN® Server Parameters
Field
Description
Enable
Click on the checkbox to enable the OpenVPN® server.
VPN Name
Enter a name for the OpenVPN® server.
Server Mode
Choose the server mode the OpenVPN® server will operate with.
4 modes are available:
•PSK: used to establish a point-to-point OpenVPN®
configuration.
•SSL: Authentication is made using certificates only (no
user/pass authentication).
•User Auth: Authentication is made using only CA, user and
password, no certificates. Useful if the clients should not
have individual certificates.
•SSL + User Auth: Requires both certificate and username /
password. Each user has a unique client configuration that
includes their personal certificate and key.
Protocol
Choose the Transport protocol from the dropdown list, either TCP or
UDP. The default protocol is UDP.
Interface
Select the interface used to connect the GWN7000 to the uplink,
either WAN1, WAN2 or All.
Local Port
Configure the listening port for OpenVPN® server.
The default value is 1194.
Encryption Algorithm
Choose the encryption algorithm from the dropdown list to encrypt
data so that the receiver can decrypt it using same algorithm.
Digest Algorithm
Choose digest algorithm from the dropdown list, which will uniquely
identify the data to provide data integrity and ensure that the receiver
has an unmodified data from the one sent by the original host.
TLS Authentication
This option uses a static Pre-Shared Key (PSK) that must be
generated in advance and shared among all peers.
This feature adds extra protection to the TLS channel by requiring
that incoming packets have a valid signature generated using the
PSK key.
TLS Pre-Shared Key
Enter the generated TLS Pre-Shared Key when using TLS
Authentication.
Certificate Authority
Select a generated CA from the dropdown list.
Server Certificate
Select a generated Server Certificate from the dropdown list.

GWN7000 OpenVPN® Site-to-Site VPN Guide
P a g e | 13
IPv4 Tunnel Network
Enter the network range on which the GWN7000 OpenVPN®
instance will be running and serving IPs to connected clients.
Note: In our example, we are using 10.1.1.0/24
Redirect Gateway
When redirect-gateway is used, OpenVPN® clients will route DNS
queries through the VPN, and the VPN server will need to handle
them.
Automatic Firewall Rule
Enable automatic firewall rule.
Auto Forward Group Traffic
If enabled, choose which groups you want to forward and allow
access from the VPN tunnel, if not, you can manually configure the
forward rules under firewall settings.
LZO Compression
Select whether to activate LZO compression or no, if set to
“Adaptive”, the server will make the decision whether this option will
be enabled or no.
Allow Peer to Change IP
Allow remote change the IP and/or Port, often applicable to the
situation when the remote IP address changes frequently.
3. Click after completing all the fields.
4. Click on top of the web GUI to apply changes.
Server status can be checked after this under “VPNOpenVPN®Server”.
Figure 8: OpenVPN® Server
Branch Site Configuration
Now that the GWN7000 router at the core site is up and running, we move on to configure an OpenVPN®
client instance under the GWN7000 router on the branch site. Please follow below steps to set it up.
1. Go to “VPNOpenVPN®Client” and follow steps below.
2. Click on and the following window will pop up.

GWN7000 OpenVPN® Site-to-Site VPN Guide
P a g e | 14
Figure 9: OpenVPN® Client
3. Under Remote OpenVPN® Server field, put the public IP of the core site router to where the client
will initiate tunnel connection.
Figure 10: OpenVPN® Client - Routes

GWN7000 OpenVPN® Site-to-Site VPN Guide
P a g e | 15
4. In Routes field, add the list of networks that are reachable through the GWN7000 running
OpenVPN® server. Here we set the IP range for the core site LAN (i.e. 192.168.1.0/24).
5. The final step would be to upload the client certificate and key, along with CA file which was used
to sign the certificates.
Figure 11: OpenVPN® Client – Upload Certificate and Key
6. Once this done, press save and apply then check the OpenVPN® client status.
Figure 12: OpenVPN® Client Status from Client Side
Administrator could check the connected client(s) under the OpenVPN® server
under VPNOpenVPN®Server. hit edit and check the connected clients as shown below:
Figure 13: OpenVPN® Client Status from Server Side
Public IP of branch site
should be displayed here.

GWN7000 OpenVPN® Site-to-Site VPN Guide
P a g e | 16
VERIFICATION
For verification purpose, we can do the following:
1. On branch office site, log onto the router and check the routing table to verify that core office LAN
is listed as reachable though OpenVPN® tunnel.
Figure 14: Verification – OpenVPN® Tunnel
2. Ping from branch site to core site using connected devices to each LAN. Below is a screenshot
showing a UCM6102 (IP= 192.168.1.115) on core site initiating successful ping requests to a
GXP2140 phone (IP=192.168.3.61) on branch site.

GWN7000 OpenVPN® Site-to-Site VPN Guide
P a g e | 17
Figure 15: Verification – Ping Test
3. Finally, users could successfully register phones on branch office to the UCM located on the core
site and make phones calls with phones located on core site as well.
Figure 16: Verification – SIP Registration
© 2002-2014 OpenVPN Technologies, Inc.
OpenVPN is a registered trademark of OpenVPN Technologies, Inc
