Grandstream Networks HandyTone-486 User manual

User Manual
HandyTone-486
Analog Telephone Adaptor
For Firmware Version 1.0.8.32
Grandstream Networks, Inc.
www.grandstream.com
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
2
Table of Contents
1WELCOME.....................................................................................................................4
2INSTALLATION............................................................................................................ 5
3WHAT IS INCLUDED IN THE PACKAGE...............................................................7
3.1 SAFETY COMPLIANCES................................................................................................7
3.2 WARRANTY.................................................................................................................7
4PRODUCT OVERVIEW...............................................................................................8
4.1 KEY FEATURES............................................................................................................ 8
4.2 HARDWARE SPECIFICATION ........................................................................................9
5BASIC OPERATIONS.................................................................................................10
5.1 GET FAMILIAR WITH KEY PAD AND VOICE PROMPT .................................................10
5.2 MAKE PHONE CALLS.................................................................................................11
5.2.1 Calling phone or extension numbers.................................................................11
5.2.2 Direct IP calls....................................................................................................12
5.2.3 Call Hold ...........................................................................................................12
5.2.4 Call Waiting.......................................................................................................12
5.2.5 Call Transfer...................................................................................................... 13
5.2.5.1 Blind Transfer ........................................................................................................................................13
5.2.5.2 Attended Transfer................................................................................................................................... 13
5.2.6 3-way Conferencing...........................................................................................14
5.2.6.1 Star Code Style 3-way Conference......................................................................................................... 14
5.2.6.2 Bellcore Style 3-way Conference........................................................................................................... 14
5.2.7 PSTN Pass Through/Life line ............................................................................ 14
5.3 CALL FEATURES........................................................................................................14
5.3.1 Call Features Table (star code)......................................................................... 14
5.4 FAX..........................................................................................................................15
5.5 LED LIGHT PATTERN INDICATION ............................................................................16
6CONFIGURATION GUIDE........................................................................................ 17
6.1 CONFIGURING HANDYTONE-486 THROUGH VOICE PROMPT .....................................17
6.1.1 DHCP Mode ......................................................................................................17
6.1.2 STATIC IP Mode................................................................................................17
6.1.3 Firmware Server IP Address.............................................................................17
6.1.4 Configuration Server IP Address.......................................................................17
6.1.5 Upgrade Protocol..............................................................................................17
6.1.6 Firmware Upgrade Mode..................................................................................17
6.1.7 WAN Port Web Access.......................................................................................17
6.2 CONFIGURING HANDYTONE-486 WITH WEB BROWSER ............................................ 18
6.2.1 Access the Web Configuration Menu................................................................. 18
6.2.2 End User Configuration ....................................................................................18
6.2.3 Advanced User Configuration...........................................................................24
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
3
6.2.4 Saving the Configuration Changes.................................................................... 35
6.2.5 Rebooting the HandyTone-486 from remote ..................................................... 36
6.3 CONFIGURATION THROUGH A CENTRAL SERVER.......................................................36
7SOFTWARE UPGRADE.............................................................................................37
7.1 FIRMWARE UPGRADE THROUGH TFTP/HTTP........................................................... 37
7.2 CONFIGURATION FILE DOWNLOAD ........................................................................... 38
7.3 FIRMWARE AND CONFIGURATION FILE PREFIX AND POSTFIX....................................38
7.4 MANAGING FIRMWARE AND CONFIGURATION FILE DOWNLOAD ..............................38
8RESTORE FACTORY DEFAULT SETTING..........................................................39
9GLOSSARY OF TERMS.............................................................................................40
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
4
1Welcome
Congratulations on becoming an owner of HandyTone-486. You made an excellent choice and we
hope you will enjoy all its capabilities.
Grandstream's award-wining HandyTone-486 is an all-in-one VoIP integrated access device that
features superb audio quality, rich functionalities, high level of integration, compactness and ultra-
affordability. The HandyTone-486 is fully compatible with SIP industry standard and can interoperate
with many other SIP compliant devices and software on the market.
Grandstream HandyTone-486 has been awarded the Best of Show product in 2004 Internet Telephony
Conference and Expo.
This document is subject to changes without notice. The latest electronic version of this user manual
can be downloaded from the following location:
http://www.grandstream.com/user_manuals/HandyTone-486UserManual.pdf
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
5
2Installation
HandyTone-486 Analog Telephone Adaptor is an all-in-one VoIP integrated device designed to be a
total solution for networks providing VoIP services.
The HandyTone-486 VoIP functionalities are available via a regular analog telephone.
The following photo illustrates the appearance of a HandyTone-486.
Top View Side Views
Interconnection Diagram of the HandyTone-486:
Fax
Cordless Phone
Analog Phone
Internet ADSL/Cable
Modem Ethernet
PSTN
PC PCPC
LAN
WAN
LINE PHONE
BUTTON
RED LED
GREEN LED
RJ45
10M Ethernet
LAN
-
WAN
RJ11
Telephone
(Phone)
+5V/1200mA
RJ11
Phone Line
(Line)
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
6
Following are the steps to install a HandyTone-486:
1. Connect a standard touch-tone analog telephone (or fax machine) to PHONE port.
2. Connect a PSTN telephone line to LINE port (optional).
3. Insert the Ethernet cable into the WAN port of HandyTone-486 and connect the other end of
the Ethernet cable to an uplink port (a router or a modem, etc.)
4. Connect a PC to the LAN port of HandyTone-486.
5. Insert the power adapter into the HandyTone-486 and connect it to a wall outlet.
Please follow the instructions in section 6.2.1 to configure the HandyTone-486.
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
7
3What is Included in the Package
The HandyTone-486 package contains:
1) One HandyTone-486
2) One universal power adaptor
3) One Ethernet cable
3.1 Safety Compliances
The HandyTone-486 is compliant with various safety standards including FCC/CE and C-tick. Its
power adaptor is compliant with UL standard. The HandyTone-486 should only operate with the
universal power adaptor provided in the package.
3.2 Warranty
Grandstream has a reseller agreement with our reseller customer. End users should contact the
company from whom you purchased the product for replacement, repair or refund.
If you purchased the product directly from Grandstream, contact your Grandstream Sales and Service
Representative for a RMA (Return Materials Authorization) number.
Grandstream reserves the right to remedy warranty policy without prior notification.
Warning: Please do not attempt to use a different power adaptor. Using other power adaptor may
damage the HandyTone-486 and will void the manufacturer warranty.
Caution: Changes or modifications to this product not expressly approved by Grandstream, or
operation of this product in any way other than as detailed by this User Manual, could void your
manufacturer warranty.
Information in this document is subject to change without notice. No part of this document may be
reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose without the
express written permission of Grandstream Networks, Inc..
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
8
4Product Overview
4.1 Key Features
•Supports SIP 2.0(RFC 3261), TCP/UDP/IP, RTP/RTCP, HTTP, ICMP, ARP/RARP, DNS,
DHCP (both client and server), NTP, PPPoE, STUN, TFTP, etc.
•Built-in router, NAT, Gateway and DMZ port forwarding. Can also be configured to function
as a two Ethernet ports bridge (NAT function is disabled)
•Device bridge mode support
•Powerful digital signal processing (DSP) to ensure superb audio quality; advanced adaptive
jitter control and packet loss concealment technology
•Support various codecs including G.711 (PCM a-law and u-law), G.723.1 (5.3K/6.3K), G.726
(32K), as well as G.729A and iLBC
•Support Caller ID/name display or block, Call waiting caller ID, Hold, Call Waiting/Flash, Call
Transfer, 3-way conference (on Rev. 2.0), Call Forward, in-band and out-of-band DTMF, etc.
•Support fax pass through (via PCMU or PCMA) and T.38 FoIP (Fax over IP)
•Support Silence Suppression, VAD (Voice Activity Detection), CNG (Comfort Noise
Generation), Line Echo Cancellation (G.168), and AGC (Automatic Gain Control)
•Support standard encryption and authentication (DIGEST using MD5 and MD5-sess)
•Support for Layer 2 (802.1Q VLAN, 802.1p) and Layer 3 QoS (ToS, DiffServ, MPLS)
•Support automated NAT traversal without manual manipulation of firewall/NAT
•Support device configuration via built-in IVR, Web browser or encrypted configuration files
through TFTP or HTTP server
•Support firmware upgrade via TFTP or HTTP
•Support PSTN pass through (on Rev.2.0)
•Support SIP Session Timer
•Support Syslog (on Rev.2.0)
•Support volume amplification
•Support configurable Call Progress Tones
•Ultra compact (wallet size) and lightweight design, great companion for travelers
•Compact, lightweight Universal Power adapter
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
9
4.2 Hardware Specification
The table below lists the hardware specification of HandyTone-486.
Model HandyTone-486
LAN interface 1xRJ45 10Base-T
WAN interface 1xRJ45 10Base-T
FXS telephone port 1xFXS
PSTN port 1x PSTN pass through or life line port
Button 1
LED Green and red color
Universal Switching
Power Adaptor Input: 100-240VAC 50-60 Hz Output: +5VDC, 1200mA,
UL certified
Dimension 70mm (W)
130mm (D)
27mm (H)
Weight 0.6lbs (0.3kg)
Temperature 40 - 130oF
5 – 45oC
Humidity 10% - 90%
(non-condensing)
Compliance
NOTE:
•HandyTone-486 has two hardware revisions. This information can be found on the label at the
bottom of the device. The difference between HandyTone-486 Rev.1.0 and HandyTone-486
Rev.2.0 is that a HandyTone-486 Rev.2.0 line port can function as PSTN pass through while a
HandyTone-486 (Rev.1.0, old model, no longer shipped) line port is just a life line port and will
bridge to PSTN only when the device is out of power.
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
10
5Basic Operations
5.1 Get Familiar with Key Pad and Voice Prompt
HandyTone-486 stores a voice prompt menu (Interactive Voice Response or IVR) for quick browsing
and simple configuration. To enter this voice prompt menu, simply press the button on the
HandyTone-486 or pick up the phone and dial “***”. The following table shows how to use the voice
prompt menu to configure the device.
Menu Voice Prompt User’s Options
Main Menu “Enter a Menu Option” Enter “*” for the next menu option
Enter “#” to return to the main menu
Enter 01 – 06, 47, 86 or 99 Menu option
01 “DHCP Mode”, or
“Static IP Mode” Enter ‘9’ to toggle the selection
If user selects “Static IP Mode”, user need
configure all the IP address information
through menu 02 to 05. If user selects
“Dynamic IP Mode”, the device will retrieve
all IP address information from DHCP server
automatically when user reboots the device.
02 “IP Address “ + IP address The current WAN IP address is announced
Enter 12-digit new IP address if in Static IP
Mode.
03 “Subnet “ + IP address Same as Menu option 02
04 “Gateway “ + IP address Same as Menu option 02
05 “DNS Server “ + IP address Same as Menu option 02
07 Preferred Vocoder Enter “9” to go to the next selection in the list:
- PCM U
- PCM A
- G-723
- G-729
- iLBC
- G-726
12 WAN Port Web Access Enter “9” to toggle between:
- enable
- disable
13 Firmware Server IP Address The current Firmware Server IP address is
announced. Enter 12 digit new IP address.
14 Configuration Server IP
Address The current Config Server Path IP address is announced. Enter 12 digit new IP address.
15 Upgrade Protocol Upgrade protocol for firmware and
configuration update. Enter “9” to toggle
between:
- TFTP
- HTTP
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
11
16 Firmware Version Firmware version information.
17 Firmware Upgrade Firmware upgrade mode. Enter “9” to rotate
among the following three options:
- always check
- check when pre/suffix changes
- never upgrade
47 “Direct IP Calling” When entered, user will be prompted a dial
tone, dial a 12-digit IP address to make a direct
IP call.
(For details, see “4.2.2 Make a Direct IP
Call”.)
99 “RESET” Enter “9” to reboot the device; or
Enter MAC address to restore factory default
setting (For details, see section 8.)
“Invalid Entry” Automatically returns to Main Menu
NOTES:
•Once the LED button is pressed, it enters voice prompt main menu. If the button is pressed
again while it is already in the voice prompt menu state, it jumps to “Direct IP Calling” option
and dial tone plays in this state
•“*” shifts down to the next menu option
•“#” returns to the main menu
•“9” functions as the ENTER key in many cases to confirm an option
•All entered digit sequences have known lengths - 2 digits for menu option and 12 digits for IP
address. Once all digits are accumulated, the device will automatically process them
•For IP address input, omit the dot and enter the digits directly, add 0 for those octets with less
than three digits. e.g.: IP: 192.168.1.10, key in: 192168001010
•Key entry cannot be deleted but the phone may prompt error once it is detected
5.2 Make Phone Calls
5.2.1 Calling phone or extension numbers
There are currently two methods to make an extension number call:
a) Dial the numbers directly and wait for 4 seconds (Default “No Key Entry Timeout”). Or
b) Dial the numbers directly, and press # (assuming that “use #” as dial key is selected in web
configuration).
Examples:
To dial another extension on the same proxy, such as 1008, simply pick up attached phone, dial
1008 and then press the # or wait for 4 seconds.
To dial a PSTN number such as 6266667890, you might need to enter in some prefix number
followed by the phone number. Please check with your VoIP service provider to get the information. If
you phone is assigned with a PSTN-like number such as 6265556789, most likely you just follow the
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
12
rule to dial 16266667890 as if you were calling from a regular analog phone, followed by pressing the
# or wait for 4 seconds.
5.2.2 Direct IP calls
Direct IP calling allows two parties, that is, a HandyTone with an analog phone and another VoIP
Device, to talk to each other in an ad hoc fashion without a SIP proxy. This kind of VoIP calls can be
made between two parties if:
•Both HandyTone ATA and other VoIP Device(i.e., another HandyTone ATA or Budgetone SIP
phone or other VoIP unit) have public IP addresses, or
•Both HandyTone ATA and other VoIP Device are on the same LAN using private IP addresses,
or
•Both HandyTone ATA and other VoIP Device can be connected through a router using public
or private IP addresses (with necessary port forwarding or DMZ).
To make a direct IP to IP call, first pick up the analog phone or turn on the speakerphone on the analog
phone, then access the voice menu prompt by dial “***” or press the button on the HandyTone-286,
and dials “47” to access the direct IP call menu. User will hear a voice prompt “Direct IP Calling” and
a dial tone. Enter a 12-digit target IP address to make a call. Destination ports can be specified by
using “*4” (encoding for “:”) followed by the port number.
Examples:
If the target IP address is 192.168.0.10, the dialing convention is
Voice Prompt with option 47, then 192 168 000 010
followed by pressing the “#” key if it is configured as a send key or wait for more than 5 seconds.
If the target IP address/port is 192.168.1.20:5062, then the dialing convention would be:
Voice Prompt with option 47, then 192168001020*45062 followed by pressing the “#” key if it is
configured as a send key or wait for 4 seconds.
5.2.3 Call Hold
While in conversation, pressing the “FLASH” button on the attached phone will put the remote end on
hold. Pressing the “FLASH” button again will release the previously Hold party and the bi-directional
media will resume.
5.2.4 Call Waiting
If call waiting feature is enabled, while the user is in a conversation, he will hear a special stutter tone
if there is another incoming call. User can press the flash button to put the current call party on hold
and switch to the other call. Pressing flash button toggles between two active calls.
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
13
5.2.5 Call Transfer
5.2.5.1 Blind Transfer
Assuming that call party A and B are in conversation. A wants to Blind Transfer B to C:
1. A presses “FLASH” on the analog phone ( or Hook Flash for old model phones) to get a dial
tone.
2. A dials *87 followed by C’s number, then #(or wait for 4 seconds)
3. A can hang up.
NOTE: “Enable Call Feature” has to be set to “Yes” in web configuration page.
A can hold on to the phone and wait for one of the three following behaviors:
•A quick confirmation tone (temporarily using the call waiting indication tone) followed by a
dial tone. This indicates the transfer is successful (transferee has received a 200 OK from
transfer target). At this point, A can either hang up or make another call.
•A quick busy tone followed by a restored call (on supported platforms only). This means the
transferee has received a 4xx response for the INVITE and we will try to recover the call. The
busy tone is just to indicate to the transferor that the transfer has failed.
•Busy tone keeps playing. This means we have failed to receive the second NOTIFY from the
transferee and decided to time out. Note: this does not indicate the transfer has been
successful, nor does it indicate the transfer has failed. When transferee is a client that does not
support the second NOTIFY (such as our own earlier firmware), this will be the case. In bad
network scenarios, this could also happen, although the transfer may have been completed
successfully.
5.2.5.2 Attended Transfer
Assuming that call party A and B are in conversation. A wants to Attend Transfer B to C:
1. A presses “FLASH” on the analog phone (or Hook Flash for old model phones) to get a dial
tone
2. A then dial C’s number followed by # (or wait for 4 seconds).
3. If C answers the call, A and C are in conversation. Then A can hang up to complete transfer.
4. If C does not answer the call, A can press “FLASH” back to talk to B.
NOTE:
•When Attended Transfer failed and A hang up, HandyTone- 486 will ring user A back again to
remind A that B is still on the call. A can pick up the phone to restore conversation with B.
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
14
5.2.6 3-way Conferencing
HandyTone-496 supports 3-way conference in two styles: star code style or Bellcore style.
5.2.6.1 Star Code Style 3-way Conference
Assuming that call party A and B are in conversation. A wants to bring C in a conference:
1. A presses FLASH (on the analog phone, or Hook Flash for old model phones) to get a dial
tone.
2. A dials *23 then C’s number then # (or wait for 4 seconds).
3. If C answers the call, then A press “flash” to bring B, C in the conference.
4. If C does not answer the call, A can press “flash” back to talk to B.
5.2.6.2 Bellcore Style 3-way Conference
Bellcore style 3-way conference is also supported. To do this, user needs to enable “Use Bell-style 3-
way Conference” in FXS1 or FXS2 web configuration.
Assuming that call party A and B are in conversation. A wants to bring C in a conference:
1. A presses FLASH (on the analog phone, or Hook Flash for old model phones) to get a dial
tone.
2. A dials C’s number then # (or wait for 4 seconds).
3. If C answers the call, then A press “flash” to bring B, C in the conference.
4. If C does not answer the call, A can press “flash” back to talk to B.
5.2.7 PSTN Pass Through/Life line
HandyTone-486 Rev. 2.0 supports PSTN pass through. User can send and receive PSTN calls with the
attached analog phone.
To receive PSTN calls, simply make phone off hook when the analog phone rings.
To make a PSTN call, press the PSTN access code (*00 by default, or any number configured in web
configuration page) to switch to PSTN line and get a dial tone, then dial the PSTN number.
When HandyTone-486 is out of power, it will function as a jack. User can use the same analog phone
for PSTN calls.
5.3 Call Features
5.3.1 Call Features Table (star code)
Following table shows the call features (* code) of HandyTone-486.
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
15
Key Call Features
*23 3-way conference
*87 Blind Transfer
*30 Block CallerID (for all-config change)
*31 Send CallerID (for all-config change)
*67 Block CallerID (per call)
*82 Send CallerID (per call)
*50 Disable Call Waiting (for all-config change)
*51 Enable Call Waiting (for all-config change)
*70 Disable Call Waiting. (Per Call)
*71 Enable Call Waiting (Per Call)
*72 Unconditional Call Forward.
To use this feature, dial “*72”, wait for the dial tone. Then dial
the forward number ended with #, wait for dial tone, hang up.
*73 Cancel Unconditional Call Forward
To cancel “Unconditional Call Forward”, dial “*73” and get the
dial tone, then hang up.
*90 Busy Call Forward
To use this feature, dial “*90”, wait for the dial tone. Then dial
the forward number ended with #, wait for dial tone, hang up.
*91 Cancel Busy Call Forward
To cancel “Busy Call Forward”, dial “*91” and get the dial
tone, then hang up
*92 Delayed Call Forward
To use this feature, dial “*92”, wait for the dial tone. Then dial
the forward number ended with #, wait for dial tone, hang up.
*93 Cancel Delayed Call Forward
To cancel this Forward, dial “*93” and get the dial tone, then
hang up
Flash/Hook When in conversation, this action will switch to the new
incoming call if user heard the call waiting sound.
When in conversation and no incoming call heard, this action
will switch to a new channel for a new call.
5.4 FAX
HandyTone-486 supports FAX in two modes: T.38 (Fax over IP) and fax pass through. T.38 is the
preferred method because it is more reliable and works well in most network conditions. If the service
provider supports T.38, please use this method by selecting Fax mode to be T.38. If the service
provider does not support T.38, pass-through mode may be used. To send or receive faxes in fax pass
through mode, users will need to select all the Preferred Codecs to be PCMU/PCMA.
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
16
5.5 LED Light Pattern Indication
Following are the LED light pattern indications.
RED LED always indicates not abnormal status
DHCP Failed or WAN No Cable Button flashes every 2 seconds (if DHCP is configured)
HandyTone-486 fails to register Button flashes every 2 seconds (if SIP server is configured)
Firmware Upgrading Button flashes every 2 seconds
Device Malfunctions Red light steady on
GREEN LED mostly indicates normal working status
Message Waiting Indication Button flashes every 2 seconds
RINGING Button flashes at 1/10 second
RINGING INTERVAL Button flashes every second
In Conversation Green light steady on
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
17
6Configuration Guide
6.1 Configuring HandyTone-486 through Voice Prompt
6.1.1 DHCP Mode
Follow section 5.1 with voice menu option 01 to enable HandyTone-486 to use DHCP.
6.1.2 STATIC IP Mode
Follow section 5.1 with voice menu option 01 to enable HandyTone-486 to use STATIC IP mode, then
use option 02, 03, 04, 05 to set up IP address, Subnet Mask, Gateway, and DNS server respectively.
6.1.3 Firmware Server IP Address
Follow section 5.1 with voice menu option 13 to configure the IP address of the firmware server.
6.1.4 Configuration Server IP Address
Follow section 5.1 with voice menu option 14 to configure the IP address of the configuration server.
6.1.5 Upgrade Protocol
Follow section 5.1 with voice menu option 15 to choose firmware and configuration upgrade protocol.
User can choose between TFTP and HTTP.
6.1.6 Firmware Upgrade Mode
Follow section 5.1 with voice menu option 17 to choose firmware upgrade mode among the following
three options:
- always check
- check when pre/suffix changes
- never upgrade
6.1.7 WAN Port Web Access
Follow section 5.1 with voice menu option 12 to enable WAN Port Wed Access of the device
configuration pages.
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
18
6.2 Configuring HandyTone-486 with Web Browser
HandyTone-486 has an embedded Web server that will respond to HTTP GET/POST requests. It also
has embedded HTML pages that allow a user to configure the HandyTone-486 through a Web browser
such as Microsoft’s IE and AOL’s Netscape.
6.2.1 Access the Web Configuration Menu
HandyTone-486’s web configuration page can be accessed via LAN or WAN port:
•From the LAN port:
Directly connect a computer to the LAN port.
Open a command window on the computer
Type in “ipconfig /release”, the IP address etc. become 0.0.0.0.
Type in “ipconfig /renew”, the computer gets an IP address in 192.168.2.1 by default
Open a web browser, type in the default gateway IP address. You will see the login
page of the device.
http://192.168.2.1
•From the WAN port:
The WAN port HTML configuration option is disabled by default from factory. To access the
HTML configuration menu from the WAN port, first enable the “WAN side HTTP access” option
via IVR option 12. With the WAN side HTTP access enabled, then get the WAN IP address of the
HandyTone-486 through section 5.1 with menu option 02. The HandyTone-486’s Web
Configuration page can be accessed by the following URI via WAN port:
http://HandyTone-IP-Address
where the HandyTone-IP-Address is the WAN IP address of the HandyTone-486.
NOTE:
•To type IP address into browser to get into the configuration page, please strip out the leading
“0”s as the browser will parse in octet. e.g.: if the IP address is: 192.168.001.014, please type
in: 192.168.1.14.
6.2.2 End User Configuration
Once this request is entered and sent from a Web browser, the HandyTone-486 will respond with the
following login screen:
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
19
Grandstream Device Configuration
Password
Login
All Rights Reserved Grandstream Networks, Inc. 2005
The password is case sensitive with a maximum length of 25 characters. The factory default password
for End User and administrator is “123” and “admin” respectively. Only administrator can get access
to “ADVANCED SETTINGS” configuration page.
NOTE:
•If you can not log into the configuration page by using the default password, please check with
your VoIP service provider. Most likely, the service provider has provisioned the device and
configured for you and changed the default password.
After the correct password is entered into the login screen, the embedded Web server inside the device
will respond with the following BASIC SETTINGS configuration page:
Grandstream Device Configuration
STATUS BASIC SETTINGS ADVANCED SETTINGS
End User
Password: (purposely not displayed for security protection)
Web Port: 80 (default for HTTP is 80)
IP Address: dynamically assigned via DHCP (default) or PPPoE
(will attempt PPPoE if DHCP fails and following is non-blank)
DHCP hostname:
DHCP domain:
DHCP vendor class ID:
PPPoE account ID:
PPPoE password:
Preferred DNS server: 0.0.0.0
statically configured as:
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

HandyTone-486 User Manual Grandstream Networks, Inc.
20
IP Address: 19
2
.16
8
.1.16
0
Subnet Mask: 25
5
.25
5
.25
5
.0
Default Router: 19
2
.16
8
.1.1
DNS Server 1: 19
2
.16
8
.1.1
DNS Server 2: 0.0.0.0
Time Zone: GMT-5:00 (US Eastern Time, New York)
Da
y
li
g
ht
Savings Time: No Yes Optional Rule: 4,1,7,2,0;10,-1,7,2,0;60
PSTN Access
Code: (key pattern to use the PSTN line, default is "*00")
NAT/Bridge/DHCP Server Information & Configuration:
Device Mode: NAT Router Bridge
WAN Side HTTP
A
ccess: No Yes (WAN side access to http server will be rejected if set to No)
Reply to ICMP
on WAN port: No Yes (Unit will not respond to PING from WAN side if set to No)
Cloned WAN
M
AC Addr: (in hex format)
LAN Subnet
M
ask: 255.255.255.0 (default is 255.255.255.0)
LAN DHCP Base
I
P: 192.168.2.1 (base IP for the LAN port, default is 192.168.2.1)
DHCP IP Lease
Time: 120 (in units of hours, default is 120 hours or 5 days)
DMZ IP:
Port
F
orwarding:
WAN port 0LAN IP LAN port 0Protocol UDP Only
WAN port 0LAN IP LAN port 0Protocol UDP Only
WAN port 0LAN IP LAN port 0Protocol UDP Only
WAN port 0LAN IP LAN port 0Protocol UDP Only
WAN port 0LAN IP LAN port 0Protocol UDP Only
WAN port 0LAN IP LAN port 0Protocol UDP Only
WAN port 0LAN IP LAN port 0Protocol UDP Only
WAN port 0LAN IP LAN port 0Protocol UDP Only
Update Cancel Reboot
All Rights Reserved Grandstream Networks, Inc. 2005
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]
