Grandstream Networks HandyTone-488 User manual

User Manual
HandyTone-488
Analog Telephone Adaptor
For SW Release Version 1.0.0.4
Grandstream Networks, Inc.
www.grandstream.com

HandyTone-488 User Manual Grandstream Networks, Inc.
2
Table of Contents
1WELCOME......................................................................................................... 3
2INSTALLATION ................................................................................................. 4
3WHAT IS INCLUDED IN THE PACKAGE ......................................................... 6
3.1 SAFETY COMPLIANCES....................................................................................6
4PRODUCT OVERVIEW...................................................................................... 7
4.1 KEY FEATURES...............................................................................................7
4.2 HARDWARE SPECIFICATION ............................................................................. 8
5BASIC OPERATIONS........................................................................................ 9
5.1 GET FAMILIAR WITH VOICE PROMPT ................................................................. 9
5.2 MAKE PHONE CALLS ..................................................................................... 10
5.2.1 Calling phone or extension numbers .................................................... 10
5.2.2 Direct IP calls........................................................................................ 10
5.2.3 Blind Transfer ....................................................................................... 11
5.2.4 Attended Transfer................................................................................. 11
5.2.5 Send and Receive PSTN Calls............................................................. 12
5.2.6 VoIP-to-PSTN Calls.............................................................................. 12
5.2.7 PSTN-to-VoIP Calls.............................................................................. 12
5.3 CALL FEATURES............................................................................................ 12
5.3.1 Call Features Table .............................................................................. 12
5.3.2 PSTN Pass Through............................................................................. 13
5.4 LED LIGHT PATTERN INDICATION ................................................................... 13
6CONFIGURATION GUIDE............................................................................... 15
6.1 CONFIGURING HANDYTONE-488 WANIP THROUGH VOICE PROMPT ................ 15
6.1.1 DHCP Mode ......................................................................................... 15
6.1.2 STATIC IP Mode................................................................................... 15
6.2 CONFIGURING HANDYTONE-488 WITH WEB BROWSER .................................... 15
6.2.1 Access the Web Configuration Menu.................................................... 15
6.2.2 End User Configuration ........................................................................ 15
6.2.3 Advanced User Configuration............................................................... 19
6.2.4 Saving the Configuration Changes....................................................... 28
6.2.5 Rebooting the HandyTone-488 From Remote...................................... 28
6.3 CONFIGURATION THROUGH A CENTRAL SERVER.............................................. 29
7SOFTWARE UPGRADE.................................................................................. 30
7.1 UPGRADE THROUGH HTTP............................................................................ 30
7.2 UPGRADE THROUGH TFTP............................................................................ 30
8RESTORE FACTORY DEFAULT SETTING.................................................... 32

HandyTone-488 User Manual Grandstream Networks, Inc.
3
1 Welcome
Congratulations on becoming an owner of HandyTone-488. You made an excellent choice
and we hope you enjoy all of its capabilities.
Grandstream's HandyTone-488 is an all-in-one VoIP integrated access device that features
superb audio quality, rich functionalities, high level of integration, compactness and ultra-
affordability. The HandyTone-488 is fully compatible with SIP industry standard and can
interoperate with many other SIP compliant devices and software on the market.
Grandstream HandyTone-488 is a new addition to the popular HandyTone product family. It
is an enhanced model compared to the award-winning HandyTone-486 in that it allows call
origination and termination from/to the PSTN network (via FXO port) remotely and automated
emergency call routing through PSTN network.

HandyTone-488 User Manual Grandstream Networks, Inc.
4
2 Installation
HandyTone-488 Analog Telephone Adaptor is an all-in-one VoIP integrated device designed
to be a total solution for networks providing VoIP services.
The HandyTone-488 VoIP functionalities are available via a regular analog telephone.
The following photo illustrates the appearance of a HandyTone-488.
Top View Side Views
Interconnection Diagram of the HandyTone-488:
Fax
Cordless Phone
Analog Phone
Internet ADSL/Cable
Modem Ethernet
PSTN
PC PCPC
LAN
WAN
FXO FXS
BUTTON
RED LED
GREEN LED
RJ45
10M Ethernet
LAN - WAN
RJ11
FXS Port
(Phone)
+5V/1200mA
RJ11
FXO Port
(Phone Line)

HandyTone-488 User Manual Grandstream Networks, Inc.
5
HandyTone-488 has one FXS port and one FXO port. The RJ11 jack next to the LAN port
is a FXS port. The RJ11 jack on the side of the HandyTone-488 is a FXO port. Both the FXS
port and the FXO port can have a separate SIP account. This is a key feature of HandyTone-
488. Telephone calls can be originated or terminated from/to the PSTN network via FXO port.
Following are the steps to install a HandyTone-488:
1. Connect a standard touch-tone analog telephone to the FXS port.
2. Insert a standard RJ11 telephone cable into the FXO port and connect the other end of
the telephone cable to a wall jack.
3. Insert the Ethernet cable into the WAN port of HandyTone-488 and connect the other
end of the Ethernet cable to an uplink port (a router or a modem, etc.)
4. Connect a PC to the LAN port of HandyTone-488.
5. Insert the power adapter into the HandyTone-488 and connect it to a wall outlet.
Please follow the instructions in section 6.2.1 to configure the HandyTone-488.

HandyTone-488 User Manual Grandstream Networks, Inc.
6
3 What is Included in the Package
The HandyTone-488 package contains:
1) One HandyTone-488
2) One universal power adaptor
3) One Ethernet cable
3.1 Safety Compliances
The HandyTone-488 is compliant with various safety standards including FCC/CE and C-tick.
Its power adaptor is compliant with UL standard. The HandyTone-488 should only operate
with the universal power adaptor provided in the package.
Warning: Please do not attempt to use a different power adaptor. Using other power
adaptor may damage the HandyTone-488 and will void the manufacturer warranty.
Caution: Changes or modifications to this product not expressly approved by
Grandstream, or operation of this product in any way other than as detailed by this
User Manual, could void your manufacturer warranty.
Information in this document is subject to change without notice. No part of this document may be
reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose without the
express written permission of Grandstream Networks, Inc..

HandyTone-488 User Manual Grandstream Networks, Inc.
7
4 Product Overview
4.1 Key Features
•Supports SIP 2.0(RFC 3261), TCP/UDP/IP, RTP/RTCP, HTTP, ICMP, ARP/RARP,
DNS, DHCP (both client and server), NTP, PPPoE, STUN, TFTP, etc.
•Built-in router, NAT, Gateway and DMZ port forwarding
•Supports call origination and termination from/to the PSTN network (via FXO port)
•Powerful digital signal processing (DSP) to ensure superb audio quality; advanced
adaptive jitter control and packet loss concealment technology
•Support various vocoders including G.711 (a-law and u-law), G.723.1 (5.3K/6.3K),
G.726 (40K/32K/24K/16K), as well as G.728, G.729A/B, and iLBC.
•Support Caller ID/Name display or block, Hold, Call Waiting/Flash, Call Transfer, Call
Forward, in-band and out-of-band DTMF, Dial Plans, etc.
•Support fax pass through
•Support Silence Suppression, VAD (Voice Activity Detection), CNG (Comfort Noise
Generation), Line Echo Cancellation (G.168), and AGC (Automatic Gain Control)
•Support standard encryption and authentication (DIGEST using MD5 and MD5-sess)
•Support for Layer 2 (802.1Q VLAN, 802.1p) and Layer 3 QoS (ToS, DiffServ, MPLS)
•Support automated NAT traversal without manual manipulation of firewall/NAT
•Support device configuration via built-in IVR, Web browser or central configuration file
through TFTP or HTTP
•Support firmware upgrade via TFTP or HTTP with encrypted configuration files.
•Ultra compact (wallet size) and lightweight design, great companion for travelers
•Compact, lightweight Universal Power adapter.

HandyTone-488 User Manual Grandstream Networks, Inc.
8
4.2 Hardware Specification
The table below describes the difference among these models.
Model HandyTone-488
LAN interface 1xRJ45 10Base-T
WAN interface 1xRJ45 10Base-T
FXS telephone port 1xFXS
FXO port 1xFXO
Button 1
LED Green and red color
Universal Switching
Power Adaptor Input: 100-240VAC 50-60 Hz Output: +5VDC, 1200mA,
UL certified
Dimension 70mm (W)
130mm (D)
27mm (H)
Weight 0.6lbs (0.3kg)
Temperature 40 - 130oF
5 – 45oC
Humidity 10% - 90%
(non-condensing)
Compliance

HandyTone-488 User Manual Grandstream Networks, Inc.
9
5 Basic Operations
5.1 Get Familiar with Voice Prompt
HandyTone-488 has stored a voice prompt menu for quick browsing and simple
configuration.
To enter this voice prompt menu, simply press the button or “***” from the analog phone.
Menu Voice Prompt User’s Options
Main Menu “Enter a Menu Option” Enter “*” for the next menu option
Enter “#” to return to the main menu
Enter 01-06, 47, 86, 99 menu option
01 “DHCP Mode”,
“Static IP Mode” Enter “9” to toggle the selection
02 “IP Address “ + IP address The current WAN IP address is
announced
Enter 12 digit new IP address if in Static IP
Mode
03 “Subnet “ + IP address Same as menu 02
04 “Gateway “ + IP address Same as menu 02
05 “DNS Server “ + IP address Same as menu 02
06 “TFTP Server “ + IP address Same as menu 02
47 “Direct IP Calling” When entered, you will be prompted a dial
tone, then enter 12 digit IP address
This menu can also be entered by
pressing the button again
86 “Voice Messages Pending”
“No Voice Messages” Enter “9” to dial pre-configured phone number to retrieve VM
99 “RESET” Enter “9” to reboot the phone
Enter encoded MAC address to restore
factory default setting
“Invalid Entry” Automatically returns to main menu
Notes:
•Once the button is pressed, it enters the voice prompt main menu. If the button is
pressed again, while it is already in the voice prompt menu, it jumps to “Direct IP Call”
option and a dial tone is prompted
•“*” always shifts down to the next menu option
•“#” always returns to the main menu
•“9” functions as the ENTER key in many cases to confirm an option
•All entered digit sequences have known lengths - 2 digits for menu option and 12 digits
for IP address. Once all of the digits are collected, the input will be processed.
•Key entry can not be deleted but the phone may prompt error once it is detected

HandyTone-488 User Manual Grandstream Networks, Inc.
10
5.2 Make Phone Calls
5.2.1 Calling phone or extension numbers
To make a phone or extension number call:
a) Dial the number directly and wait for 4 seconds (default “No Key Entry Timeout”) .
Or b) Dial the number directly, and press # (assuming that “Use # as dial key” is selected
in web configuration).
Other functions available during the call are call-waiting/flash, call-transfer, and call-forward.
5.2.2 Direct IP calls
Direct IP calling allows two phones, that is, a HandyTone with an analog phone and another
VoIP Device, to talk to each other in an ad hoc fashion without a SIP proxy. VoIP calls can be
made between two phones if:
•Both HandyTone ATA and the other VoIP device (i.e., another HandyTone ATA or
other SIP products) have public IP addresses, or
•Both HandyTone ATA and the other VoIP device (i.e., another HandyTone ATA or
other SIP produces) are on the same LAN using private or public IP addresses, or
•Both HandyTone ATA and the other VoIP device (i.e., another HandyTone ATA or
other SIP products) can be connected through a router using public or private IP
addresses.
To make a direct IP call, first pick up the analog phone or turn on the speakerphone on the
analog phone, then follow Section 5.1 with voice prompt 47, followed by the 12-digit target IP
address. Destination ports can be specified by using “*4” (encoding for “:”) followed by the
encoded port number. Following is a table of the encoding scheme for the most commonly
used characters:
Input Meaning
00 0
01 1
02 2
03 3
04 4
05 5
06 6
07 7
08 8
09 9
*0 . (dot character)

HandyTone-488 User Manual Grandstream Networks, Inc.
11
*4 : (column character)
Examples:
If the target IP address is 192.168.0.160, the dialing convention is
Voice Prompt with option 47, then 192168000160
followed by pressing the “#” key if it is configured as a send key or wait 4 seconds. In this
case, the default destination port 5060 is used if no port is specified.
If the target IP address/port is 192.168.1.20:5062, then the dialing convention would be:
Voice Prompt with option 47, then 192168001020*45062 followed by pressing the “#” key if
it is configured as a send key or wait for 4 seconds.
5.2.3 Blind Transfer
Assuming that call party A and B are in conversation. A wants to Blind Transfer B to C:
1. A presses FLASH (on the analog phone, or Hook Flash for old model phones) to get a
dial tone.
2. Then A dials *87 then dials C’s number, and then #(or wait for 4 seconds)
3. A can hang up.
Note: Call Feature has to be set to YES.
A can hold on to the phone and wait for one of the three following behaviors:
•A quick confirmation tone (temporarily using the call waiting indication tone) followed
by a dial tone. This indicates the transfer is successful (transferee has received a 200
OK from transfer target). At this point, A can either hang up or make another call.
•A quick busy tone followed by a restored call (on supported platforms only). This
means the transferee has received a 4xx response for the INVITE and we will try to
recover the call. The busy tone is just to indicate to the transferor that the transfer has
failed.
•Busy tone keeps playing. This means we have failed to receive the second NOTIFY
from the transferee and decided to time out. Note: this does not indicate the transfer
has been successful, nor does it indicate the transfer has failed. When transferee is a
client that does not support the second NOTIFY (such as our own earlier firmware),
this will be the case. In bad network scenarios, this could also happen, although the
transfer may have been completed successfully.
5.2.4 Attended Transfer
Assuming that call party A and B are in conversation. A wants to Attend Transfer B to C:

HandyTone-488 User Manual Grandstream Networks, Inc.
12
1. A presses FLASH (on the analog phone, or Hook Flash for old model phones) to get a
dial tone
2. A then dial C’s number then # (or wait for 4 seconds). A and C now in conversation.
3. A can hang up.
Note: When intended Transfer failed, if A hangs up, the HandyTone-488 will ring user A
again to remind A that B is still on the call, by pressing FLASH or Hook again will restore the
conversation between A and B.
5.2.5 Send and Receive PSTN Calls
Users can send and receive calls from PSTN. To receive PSTN calls, simply take the phone
off hook when the analog phone rings. To make a PSTN call, first press *00 (or your own
PSTN Access Code) to get the PSTN line dial tone and dial the PSTN number.
5.2.6 VoIP-to-PSTN Calls
To make a VoIP-to-PSTN call, users need to dial the FXO SIP account phone number first. A
ring tone is played once followed by a dial tone. At this time, users can dial a PSTN
telephone number or a mobile telephone number then # (or wait for 4 seconds). The call will
be established afterwards. If no PSTN number is entered after the dial tone, HandyTone-488
will hang up automatically in 10 seconds.
5.2.7 PSTN-to-VoIP Calls
To make a PSTN-to-VoIP call, PSTN callers need to originate a call to the FXO port
telephone number first. If no one answers the FXS phone after 4 ring tones, a dial tone is
played. At this time, users can dial a VoIP telephone number then # (or wait for 4 seconds).
The call will be established afterwards. If no VoIP number is entered after the dial tone,
HandyTone-488 will hang up automatically in 10 seconds.
5.3 Call Features
5.3.1 Call Features Table
Following table shows the call features of HandyTone-488.
Key Call Features
*30 Block Caller ID (for all subsequent calls)
*31 Send Caller ID (for all subsequent calls)
*67 Block Caller ID (per call)
*82 Send Caller ID (per call)

HandyTone-488 User Manual Grandstream Networks, Inc.
13
*50 Disable Call Waiting (for all subsequent calls)
*51 Enable Call Waiting (for all subsequent calls)
*70 Disable Call Waiting. (Per Call)
*71 Enable Call Waiting (Per Call)
*72 Unconditional Call Forward.
To use this feature, dial “*72” and get the dial tone. Then
dial the forward number and “#” for a dial tone, then hang
up.
*73 Cancel Unconditional Call Forward
To cancel “Unconditional Call Forward”, dial “*73” and get
the dial tone, then hang up.
*90 Busy Call Forward
To use this feature, dial “*90” and get the dial tone. Then
dial the forward number and “#” for a dial tone, then hang
up.
*91 Cancel Busy Call Forward
To cancel “Busy Call Forward”, dial “*91” and get the dial
tone, then hang up
*92 Delayed Call Forward
To use this feature, dial “*92” and get the dial tone. Then
dial the forward number and “#” for a dial tone, then hang
up.
*93 Cancel Delayed Call Forward
To cancel this Forward, dial “*93” and get the dial tone,
then hang up
Flash/Hook When in conversation, this action will switch to the new
incoming call if there is a call waiting indication.
When in conversation without an incoming call, this action
will switch to a new channel for a new call.
5.3.2 PSTN Pass Through
When HandyTone-488 is out of power, the RJ 11 line jack on the HandyTone-488 side will
function as a pass through jack. Users will be able to use the same analog phone for PSTN
calls.
5.4 LED Light Pattern Indication
Following tables show the LED light pattern indication.
RED LED always indicates abnormal status
DHCP Failed or WAN No Cable Button flashes every 2 seconds (if DHCP is configured)
HandyTone-488 fails to register Button flashes every 2 seconds (if SIP server is
configured)

HandyTone-488 User Manual Grandstream Networks, Inc.
14
GREEN LED always indicates normal working status
Message Waiting Indication Button flashes every 2 seconds
RINGING Button flashes at 1/10 second
RINGING INTERVAL Button flashes every second

HandyTone-488 User Manual Grandstream Networks, Inc.
15
6 Configuration Guide
6.1 Configuring HandyTone-488 WAN IP through Voice Prompt
6.1.1 DHCP Mode
Follow section 5.1 with voice menu option 01 to enable HandyTone-488 to use DHCP.
6.1.2 STATIC IP Mode
Follow section 5.1 with voice menu option 01 to enable HandyTone-488 to use STATIC IP
mode, then use option 02, 03, 04 to set up HandyTone-488’s IP, Subnet Mask, Gateway
respectively.
6.2 Configuring HandyTone-488 with Web Browser
HandyTone-488 series ATA has an embedded Web server that will respond to HTTP
GET/POST requests. It also has embedded HTML pages that allow users to configure the
HandyTone-488 through a Web browser such as Microsoft’s IE and AOL’s Netscape.
6.2.1 Access the Web Configuration Menu
The HandyTone-488 HTML configuration menu can be accessed via LAN or WAN port:
•From the LAN port use the default LAN gateway IP address:
http://192.168.2.1
•The WAN port HTML configuration option is disabled by default from factory. To
access the HTML configuration menu from the WAN port, first enable the “WAN side
HTTP access” option by accessing the configuration via LAN port. With the WAN side
HTTP access enabled, then get the WAN IP address of the HandyTone-488 through
section 5.1 with menu option 02. The HandyTone-488’s Web Configuration page can
be accessed by the following URI via WAN port:
http://HandyTone-IP-Address,
where the HandyTone-IP-Address is the WAN IP address of the HandyTone-488.
6.2.2 End User Configuration
Once this HTTP request is entered and sent from a Web browser, the HandyTone-488 will
respond with the following login screen:

HandyTone-488 User Manual Grandstream Networks, Inc.
16
Grandstream Device Configuration
Password
Login
All Rights Reserved Grandstream Networks, Inc. 2004
The password is case sensitive and the factory default password for End User is ‘123’.
After a correct password is entered in the login screen, the embedded Web server inside the
HandyTone-488 will respond with the Configuration page which is explained in details below.
Grandstream Device Configuration
STATUS BASIC SETTINGS ADVANCED SETTINGS
End User
Password: (purposely not displayed for security protection)
IP Address: dynamically assigned via DHCP (default) or
PPPoE
(will attempt PPPoE if DHCP fails and following is
non-blank)
PPPoE account ID:
PPPoE password:
Preferred DNS server: 0.0.0.0
statically configured as:
IP Address: 192 .168 .1.12
Subnet Mask: 255 .255 .255 .0
Default Router: 192 .168 .1.1
DNS Server 1: 129 .105 .5.1
DNS Server 2: 204 .127 .198 .4
Time Zone: current setting is " GMT-6:00 (US Central Time, Chicago)"
Da
y
li
g
ht Savin
g
s
Time: No Yes (if set to Yes, display time will be 1 hour ahead of normal
time)

HandyTone-488 User Manual Grandstream Networks, Inc.
17
NAT/DHCP Server Information & Configuration:
Cloned WAN MAC
Addr: (in hex format)
LAN Subnet Mask: 255.255.255.0 (default is 255.255.255.0)
LAN DHCP Base
I
P: 192.168.2.1 (base IP for the LAN port, default is 192.168.2.1)
DHCP IP Lease
Time: 120 (in units of hours, default is 120 hours or 5 days)
D
M
Z IP:
Port Forwarding:
WAN port 0LAN IP LAN port 0Protocol " UDPOnly"
WAN port 0LAN IP LAN port 0Protocol " UDPOnly"
WAN port 0LAN IP LAN port 0Protocol " UDPOnly"
WAN port 0LAN IP LAN port 0Protocol " UDPOnly"
WAN port 0LAN IP LAN port 0Protocol " UDPOnly"
WAN port 0LAN IP LAN port 0Protocol " UDPOnly"
WAN port 0LAN IP LAN port 0Protocol " UDPOnly"
WAN port 0LAN IP LAN port 0Protocol " UDPOnly"
Update
All Rights Reserved Grandstream Networks, Inc. 2004
End User
Password This contains the password to access the Web Configuration Menu.
This field is case sensitive.
IP Address There are 2 modes under which the HandyTone ATA can operate:
- If DHCP mode is enabled, then all the field values for the Static IP
mode are not used (even though they are still saved in the Flash
memory.) The HandyTone ATA will acquire its IP address from the
first DHCP server it discovers from the LAN it is connected.
To use the PPPoE feature the PPPoE account settings need to be
set. The HandyTone will attempt to establish a PPPoE session if any
of the PPPoE fields is set.
- If Static IP mode is enabled, then the IP address, Subnet Mask,
Default Router IP address, DNS Server 1 (primary), DNS Server 2
(secondary) fields will need to be configured. These fields are reset to
zero by default.

HandyTone-488 User Manual Grandstream Networks, Inc.
18
Time Zone This parameter controls how the displayed date/time will be adjusted
according to the specified time zone.
Daylight Savings
Time This parameter controls whether the displayed time will be daylight
savings time or not. If set to Yes, then the displayed time will be 1
hour ahead of normal time.
Cloned WAN MAC
Address: Allow the user to set a specific MAC address. Set in Hex format
LAN Subnet Mask
Sets the LAN subnet mask. Default value is 255.255.255.0
LAN DHCP Base IP:
Base IP for the LAN port which functions as a Gateway for the
subnet. Default value is 192.168.2.1
DHCP IP Lease
Time:
Value is set in units of hours. Default value is 120hr (5 Days.) The
time IP address are assigned to the LAN clients
DMZ IP:
Forward all WAN IP traffic to a specific IP address if no matching port
is used by HandyTone-488 itself or in the defined port forwarding.
Port Forwarding: Allow users to forward a matching (TCP/UDP) port to a specific LAN
IP address with a specific (TCP/UDP) port.
In addition to the Basic Settings configuration page, end users also have access to the device
Status page. The following is a snap shot of the device Status page. Details will be explained
next.
Grandstream Device Configuration
STATUS BASIC SETTINGS ADVANCED SETTINGS
MAC Address: 00.0B.82.02.B2.95
WAN IP Address: 192.168.1.12
Product Model: HT488
Software Version: Program-- 1.0.0.3 Bootloader-- 1.0.2.22 HTML-- 1.0.0.2 VOC-- 1.0.0.7
S
y
stem Up Time: 0 day(s) 3 hour(s) 23 minute(s)
Re
g
istered: Yes
PPPoE Link Up: disabled
detected NAT type is full cone
All Rights Reserved Grandstream Networks, Inc. 2004

HandyTone-488 User Manual Grandstream Networks, Inc.
19
MAC Address The device ID, in HEX format. This is a very important ID for ISP
troubleshooting.
WAN IP Address This field shows WAN port IP address.
Product Model This field contains the product model info.
Software Version Program: This is the main software release, its number is always
used for firmware upgrade.
Bootloader: This is normally not changed.
HTML: This is the user interface, normally not changed.
VOC: This is the codec program, normally not changed.
System Up Time This field indicates how long the device has been up since the last
reboot.
Registered This field indicates whether the device is registered to the SIP server.
PPPoE Link Up This field shows whether the PPPoE connection is enabled or not.
Detected NAT Type This field shows what kind NAT the HandyTone is connected to via its
WAN port. It is based on STUN protocol.
6.2.3 Advanced User Configuration
To login to the Advanced User Configuration page, please follow the instructions in section
6.2.1 to get to the following login page. The password is case sensitive and the factory
default password for Advanced User is “admin”.
Grandstream Device Configuration
Password
Login
All Rights Reserved Grandstream Networks, Inc. 2004

HandyTone-488 User Manual Grandstream Networks, Inc.
20
Advanced User configuration includes not only the end user configuration, but also advanced
configuration such as SIP configuration, Codec selection, NAT Traversal Setting and other
miscellaneous configuration. Following is a snap shot of the advanced configuration page.
Grandstream Device Configuration
STATUS BASIC SETTINGS ADVANCED SETTINGS
Admin Password: (purposely not displayed for security protection)
FXS Port:
SIP Server: sip.mycompany.com (e.g., sip.mycompany.com, or IP address)
Outbound Prox
y
: (e.g., proxy.myprovider.com, or IP address, if any)
SIP User ID: 3320 (the user part of an SIP address)
Authenticate ID: 3320 (can be identical to or different from SIP User ID)
Authenticate
Password: (purposely not displayed for security protection)
Name: John Doe (optional, e.g., John Doe)
Re
g
ister
Expiration: 60 (in minutes. default 1 hour, max 45 days)
local SIP port: 5060 (default 5060)
local RTP port: 5004 (1024-65535, default 5004)
Enable Call
Features: No Yes (if Yes, Call Forwarding & Call-Waiting-Disable are
supported locally)
Send DTMF: in-audio via RTP (RFC2833) via SIP INFO
DTMF Pa
y
load
T
y
pe: 101
FXO Port:
SIP Server: sip.mycompany.com (e.g., sip.mycompany.com, or IP address)
Outbound Prox
y
: (e.g., proxy.myprovider.com, or IP address, if any)
SIP User ID: 6602 (the user part of an SIP address)
Authenticate ID: 6602 (can be identical to or different from SIP User ID)
Authenticate
Password: (purposely not displayed for security protection)
