Grandstream Networks Grandstream GXP-2010 User manual

(optional)
Computer
GXP 2010 IP Phone
Power
Jack
Headset
Handset Jacks
GXP Ext
Connection
PC/LAN RJ-45
10/100Mpbs Ports
Step 1: Connect the handset to the phone using the provided phone cord.
Step 2: Connect the WAN port on the back of the phone to an available port on your switch or router using
an Ethernet cable.
Step 3: Plug the power adapter into the GXP-2010.
Step 4: Connect a computer or switch to the LAN port of the GXP-2010 using an Ethernet cable (optional).
Step 5: Connect the sidecar to the GXP Ext port on the back of the phone (optional).
For a complete users guide: http://www.grandstream.com/user_manuals/
Grandstream GXP 2010
Basic Installation Instructions:
for connecting the GXV-2010 video phone
to the Internet via a router connected to a
cable or DSL modem
Your Start-up Kit should include:
One GXP-2010 Main Case
One Handset
One Phone Cord
One Universal Power Adaptor
One Ethernet Cable
One Phone Stand
Two Wall Mount Spacers
1
2
3
4
3
4
2
Installation Guide: Setting Up Your Grandstream GXP 2010
1
2
QUICK
INSTALLATION
GUIDE
