Grandstream Networks GXP2130v2 User manual

Grandstream Networks, Inc.
GXP2130v2/GXP2140/GXP2160
Bluetooth User Guide

P a g e |2
Bluetooth User Guide
Table of Content
OVERVIEW.....................................................................................................................4
BASIC FUNCTIONS.......................................................................................................5
Turn Bluetooth ON or OFF.....................................................................................................................6
Change GXP2130v2/GXP2140/GXP2160 Bluetooth Name..................................................................6
Pairing to a Bluetooth device.................................................................................................................6
Connecting to a Bluetooth device...................................................................................................8
Unpairing and disconnecting a Bluetooth device ...........................................................................8
USE BLUETOOTH HEADSET........................................................................................9
BT ON and BT OFF ...............................................................................................................................9
Turn ON/OFF Hands free mode ..........................................................................................................10
Connect to Hands free device .............................................................................................................11
Use Bluetooth Phonebook...................................................................................................................11
Initiate a call with Hands free mode.....................................................................................................12

P a g e |3
Bluetooth User Guide
Table of Figures
Figure 1: Bluetooth Configuration .................................................................................................................5
Figure 2: Scan Bluetooth Device ..................................................................................................................7
Figure 3: Pairing to Bluetooth Device ...........................................................................................................7
Figure 4: Bluetooth Device Connected .........................................................................................................8
Figure 5: Disconnect Bluetooth Device.........................................................................................................8
Figure 6: BT is OFF.......................................................................................................................................9
Figure 7: BT is ON ........................................................................................................................................9
Figure 8: Turn On Hands Free Mode..........................................................................................................10
Figure 9: Hand Free Enabled......................................................................................................................10
Figure 10: Hands Free Account Connected................................................................................................ 11
Figure 11: Bluetooth Phonebook.................................................................................................................11
Table of Figures
Table 1: Bluetooth Configuration...................................................................................................................5

P a g e |4
Bluetooth User Guide
OVERVIEW
Bluetooth is a proprietary, open wireless technology standard for exchanging data over short distances
from fixed and mobile devices, creating personal area networks with high levels of security.
GXP2130v2/GXP2140/GXP2160 supports Bluetooth Class 2 of version 2.1. On GXP color phones, users
could connect to mobile phones (which support Bluetooth function) via hands free mode, or use Bluetooth
headset to answer calls.
This document serves as an end user guide on how to use Bluetooth headset and hands free mode on
GXP2130v2/GXP2140/GXP2160.
Please ensure your GXP2130v2/GXP2140/GXP2160 is using the latest firmware. The firmware release
information can be found here:
http://www.grandstream.com/support/firmware
Software release reference:
The first released firmware 1.0.1.6 build only supports connecting to Bluetooth Headsets.
The current official firmware supports both connecting to Bluetooth Headsets and Bluetooth Phones
(one at a time).

P a g e |5
Bluetooth User Guide
BASIC FUNCTIONS
Bluetooth related settings are under GXP2130v2/GXP2140/GXP2160's LCD MenuSystemBluetooth.
To connect to a Bluetooth device, turn on GXP2130v2/GXP2140/GXP2160’s Bluetooth power first. The
first time when using a new Bluetooth device with GXP2130v2/GXP2140/GXP2160, the device and the
phone must be paired so that both devices know how to connect securely to each other. After that, users
could simply connect to the paired device.
Figure 1: Bluetooth Configuration
Table 1: Bluetooth Configuration
System Bluetooth
Bluetooth Status
Displays the status of Bluetooth. When “Power”is on, the status is
“Discoverable”; when Bluetooth power is off, the status is “Off”.
Bluetooth MAC
Displays the GXP phone’s MAC address.
Power
Configure Bluetooth to power on, off, or off with hiding menu from LCD.
Handsfree Mode
Enables/Disables Handsfree mode.
Note: By enabling the handsfree Mode, the user can sync up cellphone
phonebook to the GXP phone and also make calls on GXP phone via the
cellphone account.
Important: GXP Phones can connect to at most one handsfree device each
time.
Bluetooth Name
Defines the GXP2130v2/GXP2140/GXP2160 Bluetooth name.

P a g e |6
Bluetooth User Guide
Start Scan
Starts to scan other Bluetooth devices in range. If new device is found, user
could press “Pair”soft key, and enter Pin code to pair to other Bluetooth
devices.
Discoverable
Defines whether the phone is discoverable by other Bluetooth devices, when
Bluetooth power is on.
Turn Bluetooth ON or OFF
1. Go to GXP2130v2/GXP2140/GXP2160's LCD MENUSystemBluetooth
2. Highlight Power option by pressing Up/Down arrow key.
3. When the Power option is highlighted, pressing LEFT/RIGHT arrow keys to turn on/off Bluetooth.
Note: While Bluetooth is turned on, GXP2130v2/GXP2140/GXP2160 is discoverable by other Bluetooth
devices. To make the phone undiscoverable, user needs to turn off Bluetooth.
Change GXP2130v2/GXP2140/GXP2160 Bluetooth Name
Under Bluetooth Name option, user can change the Bluetooth name of GXP2130v2/GXP2140/GXP2160
showed when discovered by other Bluetooth devices.
1. Go to GXP2130v2/GXP2140/GXP2160's LCD MENUSystemBluetooth.
2. Highlight Bluetooth Name option by pressing Up/Down arrow keys.
3. Enter the desired Bluetooth name from keypad.
Pairing to a Bluetooth device
Before connecting GXP2130v2/GXP2140/GXP2160 with other Bluetooth device, users must pair them first.
Both devices will stay paired afterwards unless they are unpaired.
1. Go to GXP2130v2/GXP2140/GXP2160's LCD MENUSystemBluetooth.
2. Enter Start Scan option
3. GXP2130v2/GXP2140/GXP2160 scans and displays the names of all available Bluetooth devices.

P a g e |7
Bluetooth User Guide
Figure 2: Scan Bluetooth Device
Note: If the wanted device does not show up in the list, make sure the device is turned on and set to
be discoverable. User can also press “Clear” and “Rescan”softkeys to restart the scanning;
4. The discovered devices will show up in the scan result list with devices names. If it is not paired, it will
show the status "Unpaired" next to the device name. Select the wanted device, and press “Pair”
softkey to pair it with the GXP Phone. Then a window will prompt up where the user can find a random
PIN Code needed in the wanted device to pair it with the GXP Phone.
Figure 3: Pairing to Bluetooth Device
Note: Usually, the default Bluetooth headset Pin code is 0000.

P a g e |8
Bluetooth User Guide
Connecting to a Bluetooth device
After successfully paired, the GXP2130v2/GXP2140/GXP2160 will show the status "Paired" next to the
Bluetooth device name in the scan list. select the paired device and press “Connect”softkey.
Once connected, GXP2130v2/GXP2140/GXP2160 will show the status “Connected”next to the Bluetooth
device name in the scan list.
Figure 4: Bluetooth Device Connected
Unpairing and disconnecting a Bluetooth device
In the Bluetooth settings, highlight the Bluetooth device name and press “Disconnect”/”Unpair” softkey.
Once disconnected/Unpaired, the phone will show the status “Disconnected/unpaired” next to the
Bluetooth Device Name.
Figure 5: Disconnect Bluetooth Device

P a g e |9
Bluetooth User Guide
USE BLUETOOTH HEADSET
On GXP2130v2/GXP2140/GXP2160, user can answer/terminate incoming call from Bluetooth headset.
BT ON and BT OFF
After Bluetooth headset is successfully connected, GXP2130v2/GXP2140/GXP2160 will show “BT On”
softkey on call screen. User may press it to active Bluetooth headset.
Figure 6: BT is OFF
When “BT Off”softkey shows up in call screen and the Bluetooth icon on status bar changes to be solid, it
means the Bluetooth headset is ready to use.
Figure 7: BT is ON
When BT is on, both Bluetooth headset and GXP2130v2/GXP2140/GXP2160 will alert for incoming calls.
User may answer using the button on Bluetooth headset.
During an active call, user may switch the audio channel between Bluetooth headset and phone handset
by pressing “BT Off”/”BT On”softkey.

P a g e |10
Bluetooth User Guide
HANDSFREE MODE
By connecting cell phone to GXP2130v2/GXP2140/GXP2160 phone via hands free mode, user can sync
up cellphone phonebook to GXP phone and make calls on GXP phone via cell phone account.
GXP2130v2/GXP2140/GXP2160 plays the role of Bluetooth headset in hands free mode.
NOTE: The cell phone is required to support Bluetooth functions. GXP2130v2/GXP2140/GXP2160 can
connect to at most one hands free device each time.
Turn ON/OFF Hands free mode
On GXP2130v2/GXP2140/GXP2160 keypad menu, go to System Bluetooth Handsfree Mode.
Turn on/off Hands Free mode by pressing LEFT/RIGHT arrow keys.
Figure 8: Turn On Hands Free Mode
When “HandsFree mode”is on, the HandsFree Account will show up on idle screen. If no hands free
device is connected, the account will be highlighted in red background on main screen.
Figure 9: Hand Free Enabled

P a g e |11
Bluetooth User Guide
Connect to Hands free device
The hands free account virtually maps to Line 4. Press line key 4. It will bring up Bluetooth scan page. In
scan page, Press the desired Bluetooth device from discovered list. Then, it will be paired and connected
to the device. After connected successfully, the Hands Free Account will be highlighted in green
background, and the Bluetooth icon will turn to solid.
Figure 10: Hands Free Account Connected
Use Bluetooth Phonebook
After hands free account is connected, the cell phone phonebook will be loaded to
GXP2130v2/GXP2140/GXP2160.
1. Go to LCD Menu Contacts to see Bluetooth Phonebook option.
2. Press “Select”soft key to enter Bluetooth phonebook and see the connected cell phone’s contacts.
Figure 11: Bluetooth Phonebook
3. In Bluetooth phonebook, user can enter digits to search contacts and phone will list the matching
ones.
4. When one contact is highlighted, user can press round Menu button to check contact details.

P a g e |12
Bluetooth User Guide
Initiate a call with Hands free mode
When the contact entry is highlighted, user can call the contact by pressing “SEND”button. The call will be
initiated from hands free account (user’s cell phone).
On idle screen, when the hands free account is connected, pressing the last Line Key will bring up call
screen (the 4th Line Key for GXP2130v2/GXP2140 Phones; the 6th Line Key for GXP2160). User can enter
the destination number from key pad followed by “SEND”button to dial out.
