Grandstream Networks GXV 3006 User manual

Step 1: Connect the handset to the phone with the provided phone cord.
Step 2: Connect the WAN port to a switch, router or modem using the Ethernet cable.
Step 3: Connect the power adapter to the 12V DC input on the back of the phone.
Step 4: Connect a switch or computer to the PC port (optional).
For a complete users guide: http://www.grandstream.com/user_manuals/
Grandstream 3005 or 3006
Basic Installation Instructions:
for connecting the GXV-3005 or 3006
video phone to the Internet via a router
connected to a cable or DSL modem
Your Start-up Kit should include:
GXV-3005 or 3006 Main Case
Handset
Phone Cord
Universal Power Adapter
Ethernet Cable
Two Wall Mount Sustaining Brackets
Quick Installation Guide
5
2
3
4
34
2
Installation Guide: Setting Up Your Grandstream GXV 3005/3006
1
1
5
(optional)
Computer
Video Phone
Video/Audio Ports
Network
Port
PC Port
Note: The 3005 has an FXO port and 3006 has an FXS port
Power
Jack
Jack
Headset
FXO
or
FXS
Port
QUICK
INSTALLATION
GUIDE
