Grandstream Networks GWN7664LR User manual

~ 1 ~ ~ 2 ~
Grandstream Networks, Inc.
126 Brookline Ave, 3rd Floor
Boston, MA 02215. USA
Tel : [phone] - 9300
Fax: [phone] - 1987
www.grandstream.com
For Certification, Warranty and RMA information, please visit
www.grandstream.com
GWN7664LR
High-Performance Outdoor Long-Range Wi-Fi 6 Access
Point
Quick Installation Guide

~ 3 ~ ~ 4 ~
Content
English ...........................................................................................1
简体中文.......................................................................................9

~ 1 ~ ~ 2 ~
OVERVIEW
The GWN7664LR is an outdoor 802.11ax 4×4:4 Wi-Fi 6 access point
for medium-to-large business and enterprises who need to provide
long-range coverage in both indoor and outdoor spaces. It offers
weatherproof casing and heat resistant technology, dual-band 4×4:4
MU-MIMO with DL/UL OFDMA technology and a sophisticated
antenna design for maximum network through that supports 512
clients and an expanded 300-meter coverage range. To ensure easy
installation and management, the GWN7664LR includes a built-in
controller embedded within the product’s web user interface. It is
also supported by GWN.Cloud and GWN Manager, Grandstream’s
free cloud and on-premise Wi-Fi management platform. The
GWN7664LR is the ideal Wi-Fi AP for voice-over Wi-Fi deployment
and offers a seamless connection with Grandstream’s Wi-Fi capable
voice and video IP phones. With support for advanced QoS,
low-latency real-time applications, mesh networks, captive portals
and dual Gigabit networks ports with PoE/PoE+, the GWN7664LR is
an ideal outdoor Wi-Fi access point for enterprises, multiple floor
offices, warehouses, hospitals, schools and more.
PRECAUTIONS
•Do not attempt to open, disassemble, or modify the device.
•Do not expose this device to temperature outside range of -30 °C to 60 °C for
operation and -30 °C to 60 °C for storage.
•Do not expose the GWN7664LR to environments outside of the following
humidity range: 10-90% RH (non-condensing).
•Do not power cycle your GWN7664LR during system boot up or firmware
upgrade. You may corrupt firmware images and cause the unit to malfunction.
PAKEAGE CONTENTS
GWN7660 PORTS
Port
Description
NET/POE
2.5G
Ethernet RJ45 port (10Mbps /100Mbps /1Gbps
/2.5Gbps) supporting PoE/PoE+.
NET/POE
1G
Ethernet RJ45 port (10Mbps/100Mbps/1Gbps) to your
router or another GWN76xx, support PoE/PoE+.
RESET
Factory reset button.
Press for 7 seconds to reset factory default settings.
POWERING AND CONNECTING THE GWN7664LR
GWN7664LR can be powered on using PoE/PoE+ switch using
following steps.
Step 1: Plug a RJ45 Ethernet cable into the network port of
GWN7664LR.
Wall
EN
1x GWN7664LR
Access Point
4x Antennas
1x Base
Bracket
4x Screw
(PM 3.0x7)
4x Screw
Anchors
4x Screws
(PA 3.5 x 33)
2x Metal
Straps
1x Quick
Installation
Guide

~ 3 ~ ~ 4 ~
Step 2: Plug the other end into the uplink port of the power over
Ethernet (PoE/PoE+) switch.
HARDWARE INSTALLATION
GWN7664LR can be mounted on the wall or on a metal bar. Please
refer to the following steps for the appropriate installation.
Wall Mount
1. Connect the Ethernet cable (RJ45) to the correct ports of your
GWN7664LR and insert the cover bracket.
2. Connect each antenna to an antenna connector by rotating it
clockwise.
3. Attach the Base Bracket with screws (PM 3.0 x 7) on the back of
GWN7664LR access point.
Insert screws (PA 3.5x33) through the Base Bracket and mark the
mounting screw holes on the wall using a pencil.
4. Drill the holes in the spots that you have marked and slide the
anchors into the wall. Secure the GWN7664LR access point to
the wall by inserting the screws into the anchors.
Pole Mount
1. Connect the Ethernet cable (RJ45) to the correct ports of your
GWN7664LR and insert the cover bracket.
2. Connect each antenna to an antenna connector by rotating it
clockwise.
3. Attach the Base Bracket with screws (PM 3.0x7) on the back of
GWN7664LR access point.
RJ45 Ethernet Cable to
power over Ethernet
(PoE/PoE+) Switch

~ 5 ~ ~ 6 ~
4. Open the metal straps by truning the locking mechanism
counter-clockwise. You can loosen it by hand or use a flathead
screwdriver.
5. Straighten out the end of the metal straps and slide it through
the back of the base bracket.
6. Wrap the metal strap around the pole and use a flathead
screwdriver to tighten the locking mechanism by truning it
clockwise.
CONNECT TO GWN7664LR DEFAULT Wi-Fi NETWORK
GWN7664LR can be used as standalone access point out of box, or
after factory reset with Wi-Fi enabled by default.
After powering the GWN7664LR and connecting it to the network,
GWN7664LR will broadcast a default SSID based on its MAC address
GWN[MAC’s last 6 digits] and a random password.
Note: GWN7664LR’s default SSID and password information are
printed on the sticker at the back of the unit.
ACCESSING THE CONFIGURATION INTERFACE
A computer connected to the GWN7664LR’s SSID, or to the same
network as the GWN7664LR can discover and access its
configuration interface using one of the below methods:
Method 1: Discover GWN7664LR using its MAC Address
1. Locate the MAC address on the MAC tag of the unit, which is on
the underside of the device, or on the package.
2. Form a computer connected to same network as the
GWN7664LR, type in following address using GWN7664LR’s
MAC address on your browser: https://gwn_<mac>.local
Example: If a GWN7664LR has the MAC address 00:0B:82:8C:4D:F8,
this unit can be accessed by typing
https://gwn_000b828c4df8.local on the browser.
Method 2: Discover GWN7664LR using GWN Discovery Tool
1. Download and install GWN Discovery Tool from the following
link:
http://www.grandstream.com/tools/GWNDiscoveryTool.zip

~ 7 ~ ~ 8 ~
2. Open the GWN Discovery Tool, and click on Scan.
3. The tool will discover all GWN76XX Access Points connected on
the network showing their MAC and IP addresses.
4. Click on Manage Device to be redirected to the GWN7664LR’s
configuration interface, or type in manually the displayed IP
address on your browser.
5. Enter username and password to login. (The default
administrator username is “admin” and the default random
password can be found at the sticker on the GWN7660).
Notes:
Make sure that the GWN7664LR is not already paired with another
GWN76xx Access Point as slave, GWN7000 Router Series, GWN.Cloud or
GWN Manager, otherwise the configuration interface cannot be
accessed.
If the GWN7664LR is already paired, make sure to unpair it first, or do a
factory reset.
It is customer’s responsibility to ensure compliance with local regulations
for frequency bands, transmit power and others.
To manage GWN7664LR over cloud, please refer to
https://www.gwn.cloud.
The GNU GPL license terms are incorporated into the device
firmware and can be accessed via the Web user interface of the
device at my_device_ip/gpl_license. It can also be accessed here:
http://www.grandstream.com/legal/open-source-software
To obtain a CD with GPL source code information please submit a
written request to [e-mail]
Refer to online documents and FAQ for more detailed information:
http://www.grandstream.com/our-products

~ 9 ~ ~ 10 ~
概述
GWN7664LR 是一款具有防水和耐高温特性的无线接入点，可为
户外场景提供大范围 Wi-Fi 信号覆盖的解决方案。采用 4×4:4
MU-MIMO 束波成形技术和精密的天线设计，以扩大网络吞吐量、
实现高达 300 米的 Wi-Fi 覆盖范围。为了安装和管理更便捷，
GWN7664LR 既支持使用无控制器的分布式网络管理设计，内嵌
AC 控制器（嵌入 Web 用户界面中），也支持 GWN.Cloud 和GWN
Manager 以实现大规模的部署管理。凭借高级 QoS、低延时实时
应用、512+客户端接入、集成 PoE/PoE+ 双千 兆 网络 端 口 ，
GWN7664LR 成为了中高级用户密码的中等无线网络环境部署的
理想选择。
注意事项
•不要尝试打开，拆解或修改设备。
•不要将本设备暴露在温度超出 -30℃至 60℃的工作环境或超
出-30℃至 60℃的储存环境。
•不要将本设备暴露在环境湿度如下范围以外：10-90％RH （无
冷凝）。
•系统启动或固件升级期间不要中断电源。这可能会损坏设备固
件，并导致设备故障。
包装清单
GWN7664LR 无线接入点 4x 天线 1x 安装支架 2x 捆带 1x 快速安装手册
4x 机牙螺丝 4x 壁虎胶塞 4x 自攻螺丝
（PM 3.0x7）（PA 3.5x33）
GWN7664LR 端口
端口
描述
NET/POE
2.5G
以 太 网 RJ45 端 口 （ 10Mbps/100Mbps
/1Gbps/2.5Gbps），需要支持 PoE/PoE+。
NET/POE
1G
以 太 网 RJ45 端 口 （ 10Mbps/100Mbps
/1Gbps）， 支持连接至路由器或另一个
GWN76xx，支持 PoE/PoE+。
RESET
恢复出厂设置按钮。
按7秒恢复出厂默认设置。
上电和连接 GWN7664LR
GWN7664LR 可以通过以下步骤使用 PoE 或PoE+来供电：
ZH

~ 11 ~ ~ 12 ~
步骤 1：将 RJ45 以太网电缆插入 GWN7664LR 的网络端口。
步骤 2：将 RJ45 以太网电缆的另一端插入有 PoE/PoE+供电的交
换机口。
硬件安装
GWN7664LR 可安装在墙壁或金属杆上，请参阅下列步骤进行安
装。
壁挂式安装
1. 将以太网电缆（RJ45）连接到正确的 GWN7664LR 端口并合
上后盖。
2. 将天线对准天线连接口并顺时针拧紧。
3. 使用机牙螺丝（PM 3.0x7）将安装支架固定在 GWN7664LR
后壳上。
4. 将自攻螺丝（PA 3.5x33）插入安装支架并用铅笔在墙上标注
出螺丝孔的安装位置。
5. 在标注处钻孔并将壁虎胶塞置入墙内，通过将在壁虎胶塞中
拧入自攻螺丝将 GWN7664LR 固定在墙上。
纵杆安装
1. 将以太网电缆（RJ45）连接到正确的 GWN7664LR 端口并合
上后盖。
2. 将天线对准天线连接口并顺时针拧紧。
3. 使用机牙螺丝（PM 3.0x7）将安装支架固定在 GWN7664LR
后客商。
网络端口
RJ45 电缆连接到以太网
供电的（PoE/PoE+）交
换机或者 PoE/PoE+供电
转换头

~ 13 ~ ~ 14 ~
4. 逆时针旋转闭锁机制打开金属捆带。您可徒手打开或者借助
一字螺丝刀。
5. 拉直捆带的一端并将其穿过安装支架的背部。
6. 用捆带围住安装杆并借助一字螺丝刀顺时针拧紧闭锁机制。
连接到 GWN7664LR 默认的无线网络
GWN7664LR 有默认的 Wi-Fi 广播，恢复出厂设置也能使默认 Wi-Fi
启动。
将GWN7664LR 上电起机并连接至网络，GWN7664LR 会广播默认
的SSID。该 SSID 是基于 GWN 设备的 MAC 地址后六位以及一串
随机密码。
注意：GWN7664LR 的默认 SSID 和随机密码打印在设备的 MAC
地址贴纸上。
访问配置界面
将电脑连接到 GWN7664LR 广播的 SSID，或其所在的局域网后，
可用以下的几种方式发现并访问 GWN7664LR 的配置页面：
方法 1：用 MAC 地址来发现 GWN7664LR。
1. 在设备背面的贴纸上，或者设备的外包装盒上找到设备的
MAC 地址。
2. 在连接到 GWN7664LR 广播的 SSID，或 GWN7664LR 所在的局
域网的电脑上，用浏览器输入网址：https://gwn_<mac>.local。
例如：如果 GWN7664LR 的MAC 地址为 00:0B:82:8B:4E:28，
那么浏览器上输入 https://gwn_000b828b4e28.local。
方法 2：用 GWN Discovery Tool 发现 GWN7664LR。
1. 从下面的链接下载 GWN Discovery Tool:
http://www.grandstream.com/sites/default/files/Resources/GWNDi
scoveryTool.zip。
2. 打开 GWN Discovery Tool，并点击 Scan（扫描）。
3. GWN Discovery Tool 软件将帮助你发现局域网下所有的 GWN
接入点并显示他们的 MAC 地址和 IP 地址。
4. 点击 Manage Device （ 管 理 设 备 ） 后 ， 将 直 接 跳 转 到
GWN7664LR 的配置界面。或者也可以通过在浏览器中输入所
查找到的 GWN7664LR 的IP 地址。
5. 输入管理员用户名和密码登入管理界面（管理员用户名的默
认值为: admin；默认密码为随机值，写于 GWN7664LR 机体
的贴纸上）。
杆

~ 15 ~ ~ 16 ~
注意：
确认 GWN7664LR 并没有被配对到另一个 GWN76xx 或者
GWN7000 系列路由器或者 GWN.Cloud 或者 GWN Manager，
否则配置界面将会显示已配对，导致无法登录配置页面。
如果 GWN7664LR 已经被配对，请先解除配对，或者恢复该
设备的出厂设置。
请遵守当地关于频带、发射功率及其他相关法规。
请在 https://www.gwn.cloud 进行 GWN7664LR 的云端管理 。
GNU GPL 许可条款已包含在设备固件中，可以通过设备的 Web
用户界面 my_device_ip/gpl_license 进行访问。也可以通过以下
链接访问：
http://www.grandstream.com/legal/open-source-software。
如 果 需 要 包 含 GPL 源 代 码 信 息 的 CD ，请发邮件到
[e-mail] 提交请求 。
欲获取详细的话机使用信息，请在以下链接中下载 GWN7605 用户手册。
http://www.grandstream.com/support

For certification information, please refer to User Manuals:
http://www.grandstream.com
Common part：
This equipment complies with radiation exposure limits set forth for an uncontrolled
environment. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter. This equipment should be installed and operated with minimum
distance 25cm between the radiator& your body.
Après examen de ce matériel aux conformité ou aux limites d’intensité de champ RF, les
utilisateurs peuvent sur l’exposition aux radiofréquences et la conformité and compliance
d’acquérir les informations correspondantes. La distance minimale du corps à utiliser le
dispositif est de 25cm.
U.S. FCC Part 15 Regulatory Information
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Canada Regulatory Information
Radio equipment
Operation of 5150-5350 MHz is restricted to indoor use only.
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject
to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Le fonctionnement de 5150-5350 MHz est limité à une utilisation en intérieur uniquement.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux
CNR d’Innovation, Sciences et Développement économique Canada applicables aux
appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes :
1) L’appareil ne doit pas produire de brouillage;
2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
CAN ICES-3 (B)/NMB-3(B)

EU Regulatory Information
Support Frequency Bands and Power:
WLAN 2412-2472 MHz < 20 dBm;
WLAN
The simplified EU declaration of conformity referred to in Article 10(9) shall be provided as
follows:
Hereby, [Grandstream Networks, Inc.] declares that the radio equipment type [GWN7625] is in
compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
www.grandstream.com
UK Regulatory Information
5150-5250 MHz < 23dBm
WLAN
5250-5350 MHz < 20dBm
WLAN
5470-5725 MHz < 27dBm
Support Frequency Bands and Power:
WLAN 2412-2472 MHz < 20 dBm;
WLAN
5150-5250 MHz < 23dBm
WLAN
5250-5350 MHz < 20dBm
WLAN
5470-5725 MHz < 27dBm
