Grantech SYM86360V4GA User manual

SYM86360V4GA Quick Installation Guide
SYM86360V4GA 简易说明书
1、System Board Layout

SYM86360V4GA Quick Installation Guide
2、Connectors:
Label Connectors
JGPIO1 GPIO Header
SATA1 ~ SATA4 Serial ATA Connector
JUSB1, JUSB2 USB 2.0 Connector
JFP1 Front Panel Connector:
JTPM1 Trusted Platform Module Header
JSPD1 Sony & Ph l ps D g tal Interconnect Format
JSPK1 Audio Amplifier Header:
JAUD1 Front Audio Connector:
JCASE1 Chassis Intrusion Header:
JLPT1 Parallel Port Connector
PCI1 PCI slot
PCIe_X8 PCI-E x8 slot
PCIe_X16 PCI-E x16 slot
SYS_FAN1 System FAN Pin Header
CPU FAN1 CPU FAN Pin Header
3、Jumper List
Jumper Function
JCMOS1 Clear CMOS Jumper:
JATX1 AT/ATX Select Jumper:
JIAMT1 AMT Jumper:
JCOMP1,JCOMP2 Serial Port Pin 9 Function Select Jumper

SYM86360V4GA Quick Installation Guide
4、Front Panel Connector setting :
Pin Define Function Pin Define Function
1HDD+
HDD Power
2Power LED+ Power
LED
3HDD- 4Power LED-
5Reset-
Reset button
6Power button+
Power
button
7Reset+ 8Power button-
9NC 10 NC
5、Jumper Setting (JCMOS1):
Jumper status
Short 1~2 Normal Operation (default)
Short 2~3 Clear CMOS
6、COM5/COM6 RS232/422/485 Connector:

SYM86360V4GA Quick Installation Guide
Packing list:
SYM86360V4GA Mainboard *1pcs
Utility CD for SYM86360V4GA *1pcs
Installation Guide *1pcs
USB cable *1 pcs
SATA cable *2pcs;
Com extension cables *3pcs
I/O Shield *1pcs
