Grantech SYS8F600VGGA-8265U User manual

Ver 1.0
User's Manual
SYS8F600VGGA-8265U
1

Contents
1. Models and Attentions ................................................................................................... 2
1.1 Models ........................................................................................................................................... 2
1.2 Attentions ...................................................................................................................................... 2
2. Specification .................................................................................................................. 3
3. Functional Block Diagram .............................................................................................. 5
4. Mechanical Drawing ...................................................................................................... 6
5. Jumpers / Headers and Connectors .............................................................................. 7
6. Definition of Jumpers /Headers and Connectors ......................................................... 10
1) SYSRST1 (System Reset Header 2*1 Pin 1.25mm) ................................................................ 10
2) HDD_LED1 (HDD LED Header 2*1 Pin 1.25mm) ..................................................................... 10
3) PWR_LED1 (Power LED Header 2*1 Pin 1.25mm) .................................................................. 10
4) PANSW1 (Power Button Header 2*1 Pin 1.25mm) ................................................................... 10
5) J_AUDIO1 (Front Audio Header (Line-Out + MIC) 4*2 Pin 2.00mm) ....................................... 10
6) F_USB1 (Front USB2.0 Header1 4*1 Pin 2.00mm) ................................................................... 11
7) F_USB2 (Front USB2.0 Header2 4*1 Pin 2.00mm) ................................................................... 11
8) F_USB3 (Front USB2.0 Header3 4*1 Pin 2.00mm) ................................................................... 11
9) F_USB4* (Front USB2.0 Header4 4*1 Pin 2.00mm) ................................................................. 11
10) F_USB5 (Front USB2.0 Header5 5*2 Pin 2.00mm) ................................................................... 11
11) F_USB6* (Front USB2.0 Header6 5*2 Pin 2.00mm) ................................................................ 12
12) SIM1 (SIM Card Header 6*1 Pin 2.00mm) ................................................................................ 12
13) JC_LVDS1 (eDP/LVDS VDD Select Jumper 3*2 Pin 2.54 mm) ................................................ 12
14) P_SATA1 (SATA Power Header 4*1 Pin 2.00mm) .................................................................... 12
15) J_COM2 (COM2 Header 9*1 Pin 1.25mm) ............................................................................... 13
16) LVDS_P1 (eDP/LVDS Backlight Control Header 6*1 Pin 2.00mm) .......................................... 13
17) J_COM4 (COM4 Header 9*1 Pin 1.25mm) ............................................................................... 13
18) J_COM3 (COM3 Header 9*1 Pin 1.25mm) ............................................................................... 14
19) LVDS1 (eDP/LVDS Signal Header 20*2 Pin 1.25mm) .............................................................. 14
20) J_COM6_485* (COM6 RS485 Header 3*1 Pin 2.00mm) ......................................................... 15
21) J_COM5 (COM5 Header 3*1 Pin 2.00mm) ............................................................................... 15
22) J_COM6* (COM6 RS232 Header 3*1 Pin 2.00mm) ................................................................. 15
23) J_GPIO1 (GPIO Header 5*2 Pin 2.00mm) ................................................................................ 16
24) SYS_FAN1 (System FAN Header 4*1 Pin 2.54mm) ................................................................. 16
25) J_DCIN1 (DC 12V Power Input Header 4*1 Pin 2.54mm) ........................................................ 16
26) JSEL1 (COM1 RS232/485 Select Jumper 3*2 Pin 2.54 mm) ................................................... 16
27) CLRCMOS1 (CMOS Clear Jumper 3*1 Pin 2.54mm) ............................................................... 17
34) COM1 (COM1 DB9/M Connector) ............................................................................................. 17
39) LAN2* (GBE LAN RJ45 Connector2 8Pin) ................................................................................ 17
40) LAN1 (GBE LAN RJ45 Connector1 8Pin) ................................................................................. 18
7. BIOS setup .................................................................................................................. 19
2

1. Models and Attentions
1.1 Models
This manual is applied to following models:
1.2 Attentions
1) Notes under a table or figure indicate the difference of models, or alternative definition of
specific pin of the header (jumper/connector).
2) How to identify the first pin of a header or jumper
Usually, there is a thick line or a triangle near the header’s or jumper’s pin 1.
Square pad, which you can find on the back of the motherboard, is usually used for pin 1.
Model CPU COM LAN USB HDMI
LVDS
/eDP
M.2
Key-B
M.2
Key-M/B
M.2
Key-E
SATA
3.0
8F600-4205U 4205U 6 2 9 2 LVDS
5G/4G SATA SSD WIFI+
BT 1
8F600-8145U i3-
8145U 6 2 11 2 LVDS
5G/4G
PCIE/ SATA
SSD
WIFI+
BT 1
8F600-8265U i5-
8265U 6 2 11 2 LVDS
5G/4G
PCIE/ SATA
SSD
WIFI+
BT 1
8F600-8565U i7-
8565U 6 2 11 2 LVDS
5G/4G
PCIE/ SATA
SSD
WIFI+
BT 1
3

2. Specification
Model 8F600-8565U 8F600-8265U 8F600-8145U 8F600-4205U
CPU
CPU Model
Core TM (Premium-U) Celeron®
(Base-U)
i7-8565U i5-8265U i3-8145U 4205U
Clock Speed
1.8GHz, up to
4.6GHz
1.6GHz, up to
3.9GHz
2.1GHz, up to
3.9GHz 1.80GHz
Multi-Core Quad Quad Dual Dual
TDP 15W Base, 25W Max 15W
Display [1]
1 * LVDS/eDP (Header): LVDS up to 1920x1200@60Hz (default)
or eDP up to 3840x2160@60Hz
2 * HDMI (Upright TYPE-A): max resolution up to 4096x2160@30Hz
Memory [2] Support DDR4-1866/2133/2400 MHz, 1 * non-ECC SO-DIMM Slot, Up to 16GB
Storage 1 * SATA3.0 7P Connector (with 1 * SATA Power Header)
1 * M.2 (NGFF) Key-M/B Slot (PCIe x4 NVMe/ SATA SSD, 2242/2280) [3]
Ethernet [4]
LAN1: 1 * I219 GBE LAN Chip (RJ45, 10/100/1000 Mbps)
LAN2: 1 * I211 GBE LAN Chip (RJ45, 10/100/1000 Mbps)
(LAN2 colay with R_USB3 on the same position, default support LAN2)
Audio Realtek ALC897 Channel HDA Codec,
1 * Front Audio Header (Line-Out + MIC)
Expansion Slots
1 * M.2 (NGFF) Key-B Slot (3042/3052, PCIE + USB3.0(Premium-U) + USB2.0,
support 4G/5G, with1 * SIM Card Header) [5]
1 * M.2 (NGFF) Key-E Slot (PCIE+USB2.0, WIFI+BT, 2230)
COM
1 * RS232/485 (COM1, Full lanes, DB9/M, RS232/485 SEL by Jumper, PIN1
DCD/5V/12V SEL by res, DCD# default, PIN9 RI/5V SEL by res, RI# default)
2 * RS232 (COM2/3, Full lanes, Header, PIN1 DCD/5V/12V SEL by res, DCD#
default, PIN9 RI/5V SEL by res, RI# default)
1 * RS232 (COM4, 7 lanes, Header, PIN1 N/C /5V/12V SEL by res, N/C default,
PIN9 N/C /5V SEL by res, N/C default)
1 * RS232 (COM5, 3 lanes, Header, only TX/RX/GND)
1 * RS232/485 (COM6, 3 lanes, Header, only TX/RX/GND)
USB [4][5][6]
4 * USB3.0 (TYPE-A, Rear IO)
7* USB2.0 (Header, Internal) 5* USB2.0
(Header, Internal)
Other Ports
8 * GPIO
1 * System FAN Header
1 * System Reset Header
1 * HDD LED Header
1 * Power LED Header
1 * Power Button Header
1 * CMOS Clear Jumper
System Windows 10 64-bit, Linux
Temperature Storage: -20~80℃
Operating: -10~70℃
BIOS AMI UEFI BIOS (Support Watchdog Timer)
4

Power Supply
DC 12V
1 * DC 12V Power Input Thread Connector [7]
1 * DC 12V Power Input Header
Factor 3.5-inch Standard (146mm * 105mm)
Notes:
[1]: Up to three independent displays can be activated at the same time.
[2]: Supported memory frequency is determined by the CPU, supports up to 2400MHz
[3]: Only SATA for Base-U or NVMe/ SATA Auto detected for Premium-U.
[4]: F_USB1 and F_USB2 signal colay with R_USB3. And LAN2 colay with R_USB3 on the same position, support LAN2 &
F_USB1/2 by default (R_USB3 not support).
[5]: USB3.0 of M.2_B1_5G1 only support by Premium-U. And USB2_7 Signal of F_USB4 colay with M.2_B1_5G1, default
support M.2_B1_5G1. (resistor selectable)
[6]: F_USB6 only support by Premium U.
[7]: DC_IN2(DC 12V Power Input Thread Connector) colay with DC_IN1(DC 12V Power Input Φ2.5mm Jack) on the same
position, support DC_IN2 by default.
5

3. Functional Block Diagram
Intel®
8
th
GEN
Whiskey Lake-U
Platform
Core
TM
Pentium®
Celeron®
Processor
ALC897
PCIE*1
Audio
Wafer
Lout,MIC
Enternet
GbE LAN
RJ45
SATA/NVMe(Premium-U Only)
SATA*1
SATA 7P Port
LPC
COM5 / 6
Wafer
Super
I/O
COM1
DB9M
RS232/RS485
HDMI
TYPE-A*2
GPIO
Wafer
HDA
DDI*2
eDP/LVDS Converter eDP
PCIE*1
Enternet
GbE LAN
RJ45(or USB)
M.2 SSD
Key-B+M 224 2/2280
FAN
Header
COM6
Wafer
RS232
RS485
GPIO*8
PCIE+USB2.0
M.2 Wifi+BT
Key-E 2230
PCIE+USB3.0(Premium-U Only)
M.2 5G/4G
Key-B 3052/42
SIM
Header
Power LED
Wafer
RESET
USB2.0(4G)
USB2.0
Wafer*2
USB2.0
HUB
USB2.0*2
Dual USB2.0
Wafer
USB2.0
Wafer*2
Dual USB2.0
TYPE-A(or RJ45)
Dual USB3.0
TYPE-A
USB3.0*2+USB2.0*2
DDR4
SO-DIMM*1
CH A
USB2.0*2
USB2.0*1
USB2.0
USB2.0(4G)
FAN
COM2 / 3 / 4
Wafer*3
RS232
USB2.0*2(Premium-U only)
Dual USB2.0
Wafer
USB2.0*1
USB2.0*1
Dual USB3.0
TYPE-A
USB3.0*2+USB2.0*2
USB2.0*1
Power Button
Wafer
System Reset
Wafer
HDD LED
Wafer
POWER-ON
HDD LED
POWER LED
SATA(Base-U Only)
6

4. Mechanical Drawing
7

5. Jumpers / Headers and Connectors
8

Jumpers / Headers and Connectors
SYSRST1 System Reset Header
HDD_LED1 HDD LED Header
PWR_LED1 Power LED Header
PANSW1 Power Button Header
J_AUDIO1 Front Audio Header (Line-Out + MIC)
F_USB1 Front USB2.0 Header1
F_USB2 Front USB2.0 Header2
F_USB3 Front USB2.0 Header3
F_USB4 Front USB2.0 Header4
(Colay with M.2_B1_5G1, Default not on board)
F_USB5 Front USB2.0 Header5
F_USB6 Front USB2.0 Header6
(Only support by Premium-U)
SIM1 SIM Card Header
JC_LVDS1 eDP/LVDS VDD Select Jumper
P_SATA1 SATA Power Header
J_COM2 COM2 Header
LVDS_P1 eDP/LVDS Backlight Control Header
J_COM4 COM4 Header
J_COM3 COM3 Header
LVDS1 eDP/LVDS Signal Header
J_COM6_485 COM6 RS485 Header
J_COM5 COM5 Header
J_COM6 COM6 RS232 Header
J_GPIO1 GPIO Header
SYS_FAN1 System FAN Header
J_DCIN1 DC 12V Power Input Header
JSEL1 COM1 RS232/485 Select Jumper
CLRCMOS1 CMOS Clear Jumper
SATA1 SATA3.0 7P Connector
M.2_B1_5G1 M.2 (NGFF) Key-B Slot (3042/3052, PCIE + USB3.0(Premium-U) +
USB2.0, support 4G/5G)
M.2_PCIESSD_M1 M.2 (NGFF) Key-M/B Slot (PCIe x4 NVMe/ SATA SSD, 2242/2280)
Only SATA for Base-U or NVMe/ SATA Auto detected for Premium-U
9

DIMM1 DDR4 SO-DIMM Slot
M.2_KEYE_WLAN1 M.2 (NGFF) Key-E Slot (PCIE+USB2.0, WIFI+BT, 2230)
DC_IN2 (DC_IN1) DC 12V Power Input Thread Connector
(DC 12V Power Input Φ2.5mm Jack Optional)
COM1 COM1 DB9/M Connector
R_USB2 Dual USB3.0 TYPE-A Connector2
R_USB1 Dual USB3.0 TYPE-A Connector1
HDMI2 HDMI Upright TYPE-A Connector2
HDMI1 HDMI Upright TYPE-A Connector1
LAN2 (R_USB3) GBE LAN RJ45 Connector2
(Dual USB2.0 TYPE-A Connector Optional)
LAN1 GBE LAN RJ45 Connector1
10

6. Definition of Jumpers /Headers and Connectors
1) SYSRST1 (System Reset Header 2*1 Pin 1.25mm)
Graphic Pin Definition Pin Definition
1 RESET+ 2 RESET-
2) HDD_LED1 (HDD LED Header 2*1 Pin 1.25mm)
Graphic Pin Definition Pin Definition
1 HDD 3.3V LED+ 2 HDD 3.3V LED-
3) PWR_LED1 (Power LED Header 2*1 Pin 1.25mm)
Graphic Pin Definition Pin Definition
1 POWER 3.3V LED+ 2 POWER 3.3V LED-
4) PANSW1 (Power Button Header 2*1 Pin 1.25mm)
Graphic Pin Definition Pin Definition
1 POWER+ 2 POWER-
5) J_AUDIO1 (Front Audio Header (Line-Out + MIC) 4*2 Pin 2.00mm)
Graphic Pin Definition Pin Definition
2 LINE_OUT_R 1 MIC_IN_R
4 GND_AUD 3 GND_AUD
6 GND_AUD 5 GND_AUD
8 LINE_OUT_L 7 MIC_IN_L
11

6) F_USB1 (Front USB2.0 Header1 4*1 Pin 2.00mm)
Graphic Pin Definition Pin Definition
1 + 5V 3 USB2_5+ [1]
2 USB2_5- [1] 4 GND
Notes:
[1]: USB2_5 Signal of F_USB1 colay with R_USB3, default support F_USB1. (resistor selectable)
7) F_USB2 (Front USB2.0 Header2 4*1 Pin 2.00mm)
Graphic Pin Definition Pin Definition
1 + 5V 3 HUB_USB2_1+ [1]
2 HUB_USB2_1- [1] 4 GND
Notes:
[1]: HUB_USB2_1 Signal of F_USB2 colay with R_USB3, default support F_USB2. (resistor selectable)
8) F_USB3 (Front USB2.0 Header3 4*1 Pin 2.00mm)
Graphic Pin Definition Pin Definition
1 + 5V 3 HUB_USB2_4+
2 HUB_USB2_4- 4 GND
9) F_USB4* (Front USB2.0 Header4 4*1 Pin 2.00mm)
Graphic Pin Definition Pin Definition
1 + 5V 3 USB2_7+ [1]
2 USB2_7- [1] 4 GND
Notes:
[*]: F_USB4 is not on board by default.
[1]: USB2_7 Signal of F_USB4 colay with M.2_B1_5G1, default support M.2_B1_5G1. (resistor selectable)
10) F_USB5 (Front USB2.0 Header5 5*2 Pin 2.00mm)
Graphic Pin Definition Pin Definition
2 + 5V 1 + 5V
4 HUB_USB2_2- 3 HUB_USB2_3-
6 HUB_USB2_2+ 5 HUB_USB2_3+
8 GND 7 GND
10 N/C 9 GND
12

11) F_USB6* (Front USB2.0 Header6 5*2 Pin 2.00mm)
Graphic Pin Definition Pin Definition
2 + 5V 1 + 5V
4 USB2_8- 3 USB2_9-
6 USB2_8+ 5 USB2_9+
8 GND 7 GND
10 N/C 9 GND
Notes:
[*]: F_USB6 only support by Premium U.
12) SIM1 (SIM Card Header 6*1 Pin 2.00mm)
Graphic Pin Definition Pin Definition
1 UIM_PWR 4 UIM_CLK
2 GND 5 UIM_RST
3 UIM_DAT 6 UIM_VPP
13) JC_LVDS1 (eDP/LVDS VDD Select Jumper 3*2 Pin 2.54 mm)
Graphic Setting Function
1-2(Default) + 3.3V
3-4 + 5V
5-6 + 12V
14) P_SATA1 (SATA Power Header 4*1 Pin 2.00mm)
Graphic Pin Definition Pin Definition
1 + 12V 3 GND
2 GND 4 + 5V
13

15) J_COM2 (COM2 Header 9*1 Pin 1.25mm)
Graphic Pin Definition Pin Definition
1 COM2_PIN1 [1] 6 COM2_CTS#
2 COM2_DSR# 7 COM2_DTR#
3 COM2_RXD 8 COM2_PIN9 [2]
4 COM2_RTS# 9 GND
5 COM2_TXD
Notes:
[1]: Pin1 of COM2 is DCD# by default, 5V/12V is available if specified. (resistor selectable)
[2]: Pin9 of COM2 is RI# by default, 5V is available if specified. (resistor selectable)
16) LVDS_P1 (eDP/LVDS Backlight Control Header 6*1 Pin 2.00mm)
Graphic Pin Definition Pin Definition
1 GND 4 eDP/LVDS_BKLT_EN
2 GND 5 + 12V
3 eDP/LVDS_BKLT_CTL 6 + 12V
17) J_COM4 (COM4 Header 9*1 Pin 1.25mm)
Graphic Pin Definition Pin Definition
1 COM4_PIN1 [1] 6 COM4_CTS#
2 COM4_DSR# 7 COM4_DTR#
3 COM4_RXD 8 COM4_PIN9 [2]
4 COM4_RTS# 9 GND
5 COM4_TXD
Notes:
[1]: Pin1 of COM4 is N/C by default, 5V/12V is available if specified. (resistor selectable)
[2]: Pin9 of COM4 is N/C by default, 5V is available if specified. (resistor selectable)
14

18) J_COM3 (COM3 Header 9*1 Pin 1.25mm)
Graphic Pin Definition Pin Definition
1 COM3_PIN1 [1] 6 COM3_CTS#
2 COM3_DSR# 7 COM3_DTR#
3 COM3_RXD 8 COM3_PIN9 [2]
4 COM3_RTS# 9 GND
5 COM3_TXD
Notes:
[1]: Pin1 of COM3 is DCD# by default, 5V/12V is available if specified. (resistor selectable)
[2]: Pin9 of COM3 is RI# by default, 5V is available if specified. (resistor selectable)
19) LVDS1 (eDP/LVDS Signal Header 20*2 Pin 1.25mm)
Graphic Pin Definition Pin Definition
2 VDD_PANEL [1] 1 VDD_PANEL [1]
4 GND 3 LVDS_PRSNT#/
N/C [2]
6 VDD_PANEL [1] 5 VDD_PANEL [1]
8 LVDS_B_DATA0-/
EDP_TX0- [2] 7 LVDS_A_DATA0-/ N/C [2]
10
LVDS_B_DATA0+/
EDP_TX0+ [2] 9 LVDS_A_DATA0+/ N/C [2]
12 GND 11 GND
14
LVDS_B_DATA1-/
EDP_TX1- [2] 13
LVDS_A_DATA1-/
N/C [2]
16
LVDS_B_DATA1+/
EDP_TX1+ [2] 15
LVDS_A_DATA1+/
N/C [2]
18 GND 17 GND
20
LVDS_B_DATA2-/
EDP_TX2- [2] 19
LVDS_A_DATA2-/
N/C [2]
22
LVDS_B_DATA2+/
EDP_TX2+ [2] 21
LVDS_A_DATA2+/
N/C [2]
24 GND 23 GND
26
LVDS_B_CLK-/
EDP_TX3- [2] 25
LVDS_A_CLK-/
N/C [2]
28
LVDS_B_CLK+/
EDP_TX3+ [2] 27
LVDS_A_CLK+/
N/C [2]
30 GND 29 GND
32
N/C /
EDP_HPD# [2] 31
N/C
15

34 GND 33 GND
36
LVDS_B_DATA3-/
EDP_AUX- [2] 35
LVDS_A_DATA3-/
N/C [2]
38
LVDS_B_DATA3+/
EDP_AUX+ [2] 37
LVDS_A_DATA3+/
N/C [2]
40 GND 39 N/C
Notes:
[1]: Panel Power VDD is 3.3V by default, 5V/12V is selectable by “eDP/LVDS VDD Select Jumper” (JC_LVDS1, Table
13).
[2]: It supports LVDS by default and can supports eDP if specified. (resistor selectable)
20) J_COM6_485* (COM6 RS485 Header 3*1 Pin 2.00mm)
Graphic Pin Definition Pin Definition
1 COM6_RS485+ 3 GND
2 COM6_RS485-
Notes:
[*]: J_COM6_485 and J_COM6 can be on the board at the same time, but they can’t be accessed simultaneously.
21) J_COM5 (COM5 Header 3*1 Pin 2.00mm)
Graphic Pin Definition Pin Definition
1 COM5_RXD 3 GND
2 COM5_TXD
22) J_COM6* (COM6 RS232 Header 3*1 Pin 2.00mm)
Graphic Pin Definition Pin Definition
1 COM6_RXD 3 GND
2 COM6_TXD
Notes:
[*]: J_COM6_485 and J_COM6 can be on the board at the same time, but they can’t be accessed simultaneously.
16

23) J_GPIO1 (GPIO Header 5*2 Pin 2.00mm)
Graphic Pin Definition Pin Definition
2 SIO_GPI70
(0xA06 Bit0, H [1]) 1 SIO_GPI71 (0xA06 Bit1, H)
4 SIO_GPI72
(0xA06 Bit2, H) 3 SIO_GPI73 (0xA06 Bit3, H)
6 SIO_GPO74
(0xA06 Bit4, H) 5 SIO_GPO75 (0xA06 Bit5, H)
8 SIO_GPO76
(0xA06 Bit6, H) 7 SIO_GPO77 (0xA06 Bit7, H)
10 + 3.3V [2] 9 GND
Notes:
[1]: “H” or “L” means the default voltage is High or Low level. (3.3V GPIO)
[2]: Power on this Pin is 3.3V by default, 5V is available if specified. (resistor selectable)
24) SYS_FAN1 (System FAN Header 4*1 Pin 2.54mm)
Graphic Pin Definition Pin Definition
1 GND 3 FAN Speed Detection
2 + 12V 4 FAN Speed Control
25) J_DCIN1 (DC 12V Power Input Header 4*1 Pin 2.54mm)
Graphic Pin Definition Pin Definition
1 + 12V_IN 3 GND
2 + 12V_IN 4 GND
26) JSEL1 (COM1 RS232/485 Select Jumper 3*2 Pin 2.54 mm)
Graphic Setting Function
1-3, 2-4(Default)
RS232
(COM1_PIN1: DCD
COM1_PIN2: RXD)
3-5, 4-6
RS485
(COM1_PIN1: RS485-
COM1_PIN2: RS485+)
17

27) CLRCMOS1 (CMOS Clear Jumper 3*1 Pin 2.54mm)
Graphic Setting Function
1-2(Default) Normal
2-3 Clear CMOS
34) COM1 (COM1 DB9/M Connector)
Graphic Pin Definition Pin Definition
1 COM1_PIN1 [1] 6 COM1_DSR#
2 COM1_PIN2 [1] 7 COM1_RTS#
3 COM1_TXD 8 COM1_CTS#
4 COM1_DTR# 9 COM1_PIN9 [2]
5 GND
Notes:
[1]: COM1 can be RS232 / RS485 by selecting JSEL1 Jumper, check Table26 for detail. When COM1 support RS232,
Pin1 of COM1 is DCD# by default, 5V/12V is available if specified. (resistor selectable)
[2]: Pin9 of COM1 is RI# by default, 5V is available if specified. (resistor selectable)
39) LAN2* (GBE LAN RJ45 Connector2 8Pin)
Graphic Pin Definition Pin Definition
1 MDI0_2+ 5 MDI2_2-
2 MDI0_2- 6 MDI1_2-
3 MDI1_2+ 7 MDI3_2+
4 MDI2_2+ 8 MDI3_2-
A Active
LED
ACT: Twinkling Yellow
B Speed
LED
1000M: Turn Yellow
Only LINK: Lights On 100M: Turn Green
Stop: Lights Off 10M: Lights Off
Notes:
[*]: LAN2 colay with R_USB3, default support LAN2.
18

40) LAN1 (GBE LAN RJ45 Connector1 8Pin)
Graphic Pin Definition Pin Definition
1 MDI0_1+ 5 MDI2_1-
2 MDI0_1- 6 MDI1_1-
3 MDI1_1+ 7 MDI3_1+
4 MDI2_1+ 8 MDI3_1-
A Active
LED
ACT: Twinkling Yellow
B Speed
LED
1000M: Turn Yellow
Only LINK: Lights On 100M: Turn Green
Stop: Lights Off 10M: Lights Off
19

7. BIOS setup
See “BIOS Spec for SYS8F400VGGA-8265U Series” for detail information of BIOS setup.
【End】
20
