SYS76992VGGA Quick Installation Guide
1
SYS76992VGGA 简易说明书
1、System Board Layout

SYS76992VGGA Quick Installation Guide
2
2、Connectors:
Label Connectors
JPC1/JPC2 Pin 9 Switch Headers for COM5/COM6
JFRONT_USB1 Header for USB 3.0 Ports
SATA1~SATA2 Serial ATA Header
PCI1 PCI Slot
PE1 Mini PCI-E Slot
JDIO1 Digital I/O Connector
SYS_FAN1 System fan header
CPU_FAN1 CPU fan header
JCMOS1 Clear CMOS setting
JPANEL1 Front Panel Header
F_AUDIO1 Front Panel Audio Header
JAT-ATX AT/ATX Power Switch Header
JPRNT1 Printer Port Connector
3、Jumper List
Jumper Function
JPC1/JPC2 Pin 9 Switch Headers for COM5/COM6
JAT-ATX AT/ATX Power Switch Header
JCMOS1 Clear CMOS Header

SYS76992VGGA Quick Installation Guide
3
4、Front Panel Connector setting :
Pin Define Function Pin Define Function
JPANEL1
1Key N/A 2Power LED+ Power
LED
3HD LED+ HDD LED 4Power LED+
5HD LED- 6Power LED-
7Reset Reset
Button
8Power Power
Button
9GND 10 Power GND
5、Jumper Setting (JCMOS1 and JAT1 and JPC1/JPC2):
A、Clear CMOS setting:
B、AT/ATX Power setting:

SYS76992VGGA Quick Installation Guide
4
C、Pin 9 Switch Headers for COM5/COM6
Checklist:
ØSYS76992VGGA Mainboard*1pcs
ØUtility CD for SYS76992VGGA*1pcs
ØInstallation Guide*1pcs
ØSATA Cable *2pcs;
ØCOM cable and Print cable*5pcs
ØI/O Shield * 1pcs
