Gravity Measurement AWT User manual

WEIGHING SCALE user manual
Please read this manual carefully before operation
----Important safety info
----Operating condition and other attentions
----Guarantee info
Model: AWT
GRAVITY MEASUREMENT, INC.
All manuals and user guides at all-guides.com

@AWT USER MANUAL
2
Please read the manual in details before operation Please use the right plug and right voltage
Be much attention of 110V or 220V!!!
Adjust the bubble level on the balance position Don’t hit the platform rudely and overload
Don’t put the chemical liquid or other liquids Don’t open the scale by yourself and please call
to avoid damage to the scale the service people or our distributor when you get
the problem
Please recharge the scale on time to assure the health of the battery, and replace the battery if it runs out of
life. The replaced battery must be handled correctly.
Important Safety And Operation Info
All manuals and user guides at all-guides.com

@AWT USER MANUAL
3
Specifications
4
Power
4
Before using
4
System power consumption
4
Display description
4
Basic function operation
5
Basic parameter setting
5
UF-1 Internal value and battery voltage
5
UF-2 High / Low limits setting
6
UF-3 Auto-power off
6
UF-4 Standby time setting
7
UF-5 No function
7
UF-6 No function
7
UF-7 Speed setting
7
UF-8 Zero tracking
7
UF-9 G Value setting
8
Weight Calibrations
8
ECF-1 Zero and Span Calibration
8
ECF-2 Zero Calibration
8
ECF-3 Span Calibration
9
Guarantee
9
INDEX
All manuals and user guides at all-guides.com

@AWT USER MANUAL
4
SPECIFICATIONS
Accuracy: Class III
Nonlinear: ≤0.01%F.S
System working voltage: DC:5V
Maximum A/D converting: 24bit
Sample rate: 30 times per second (can select)
POWER
Input: 120 ~ 240 V
Output: 8 V/ 1A
Rechargeable battery: 6 V/ 5AH
BEFORE USING
1) Place this product on a firm and smooth place, don´t place it in vibration or shaking,
use bench for use on four only adjust foot, adjust the balance using the bubble level.
2) Use independent source, avoid other electrical disturbance.
3) Don´t put any object on the platter when turn on the balance.
4) Please, turn on 2-3 minutes before using.
5) Avoid temperature change too large and air flow strenuous sites.
6) Don´t overload the balance, don´t exceed the maximal capacity.
SYSTEM POWER CONSUMPTION
Main system power consumption: about 20mA
Battery life: about 250 hours.
DISPLAY DESCRIPTION
AWT Model:
All manuals and user guides at all-guides.com

@AWT USER MANUAL
5
BASIC FUNCTION OPERATION
Press and hold this key for 2 seconds to turn off the balance.
Function 1. Press this key to turn on the balance.
Function 2. To reset the weight to 0 ,but the displayed weight value has to
be less than ± 2% of maximum capacity.
Function 3. To subtract the container weight,tare range is 2% of full
capacity till full capacity.
Function 4. Key of confirmation in setup mode.
Function 5. To move one space to right.
Function 1. To select the desired weight unit.
Function 2. To exit from setup mode.
Function 1. In weighing status,press this key in external function setup
mode UF-1.
Function 2. In weighing status,press this key for more than 2 seconds in
external calibration function setup mode ECF-1.
Function 3. To increase values upward in setup mode.
BASIC PARAMETER SETTING
To access to functions setting, press the key in weighing mode.Press the
key to select the parameter (UF-1 ~ UF-9 )
UF-1 Internal value and battery voltage
1. Press the key to view the A/D count, such as 73286 .
2. Press the key to view the the battery voltage,such as bat 6.2 .
3. Press the key to return back to UF-1 .
All manuals and user guides at all-guides.com

@AWT USER MANUAL
6
4. To move to next parameter press the key.
5. To exit and return to normal weighing press the key.
UF-2 High / Low limits setting
1. Press the key to enter.
2. The display will show 00.000L (set low limit).
3. Use the key to move cursor and press the to select number.
4. Press the key to confirm.
5. The display will show 00.000H (set high limit).
6. Use the key to move cursor and press the to select number.
7. Press the key to confirm.
8. The display will show o.000 ,look at the remarks below.
9. Use the key to move cursor and press the to select number.
10. Press the key to confirm.
Remarks: 0 0 0
A B C
A --- Buzzer on: 0= Stable not required 1= Stable required
B –- LED indicator: 0= Stable not required 1= Stable required
C : Buzzer beeps when: 0= Buzzer off 1= OK 2= LO and HI
Low limit set as 0 will clear all check weigh values.
UF-3 Auto-power off
Modes: AoFF00 :Auto-turn off disable.
AoFF01 : The balance will automatically turn off after 1 minute of non use.
This time can be set up to 99 minutes.
1. Press the key to access to auto-power configuration.
2. Use the key to move cursor and press the to select number.
All manuals and user guides at all-guides.com

@AWT USER MANUAL
7
3. Press the key to confirm.
UF-4 Standby time setting
Modes: dsp 10 : The balance will standby time 10s.
1. Press the key to access to standby time configuration.
2. Use the key to move cursor and press the to select number.
3. Press the key to confirm.
UF-5 No function
UF-6 No function
UF-7 Speed setting
Modes: spEED1 : High speed
spEED2 : Standard speed
spEED3 : Low speed
1. Press the key to access to enter.
2. Use the key to select number.
3. Press the key to confirm.
UF-8 Zero tracking
Modes: Zp 0 : OFF
Zp 1 : One division tracking at zero
Zp 2 : Two division tracking at zero
Zp 3 : Three division tracking at zero
Zp 4 : Four division tracking at zero
Zp 5 : Five division tracking at zero
1. Press the key to access to enter.
All manuals and user guides at all-guides.com

@AWT USER MANUAL
8
2. Use the key to select number.
3. Press the key to confirm.
UF-9 G Value setting
1. Press the key to display the G value of manufacture place.
2. Use the key to move cursor and press the to select number.
3. Press the key to confirm.
Weight Calibrations
1. In weight mode, press the key for more than 2 seconds, the display will
show ECF-1 .
2. Press the key to select ECF-1 , ECF-2 or ECF-3 .
ECF-1 Zero and Span Calibration
1. Press the key to enter, display will show cALZ .
2. Press the key to calibrate zero point.
3. The display will show the calibration weight 6.000 .
4. Use the key to select the digit,press key to input the weight value.
5. Put the calibration weight on the platter and press the key to calibrate.
The scale will return back to weighing mode automatically.
ECF-2 Zero Calibration
1. Press the key to enter, display will show cALZ .
All manuals and user guides at all-guides.com

@AWT USER MANUAL
9
2. Press the key to calibrate zero point.
3. The scale will return back to weighing mode automatically.
ECF-3 Span Calibration
1. Press the key to enter, display will show the calibration weight 6.000 .
4. Use the key to select the digit,press key to input the weight value.
5. Put the calibration weight on the platter and press the key to calibrate.
The scale will return back to weighing mode automatically.
GUARANTEE
This scale is guaranteed for one year from the delivery date. The guarantee covers
any fabrication defect of the material.
During this period Gravity covers the labour cost and the spare parts necessary for the
reparation of the scale.
This guarantee does not cover the failures caused by an inappropriate use or
overcharge.
The guarantee does not cover the freight cost (transport) necessary to repair
the scale.
