Assembly Manual
Adaptor Package
Turbo Seeder
Turbo Max 2400TM - 3000TM
Terra Max HT1100-20 - HT1100-25
Read the Operator's manual entirely. When you see this symbol, the subsequent
instructions and warnings are serious - follow without exception.Your life and the
lives of others depend on it!
Cover illustration may show optional equipment not supplied with standard unit.
© Copyright 2021 892-122Q-ENG

Further Assistance
For additional help with understanding these assembly instructions or for any other assembly or
setup related questions, please contact our service department at the following address:
Great Plains Service Department
1525 E. North St.
P.O. Box 5060
Salina, KS 67402-5060
Or call us at [phone] to speak over the phone with a service representative.
Copies of this machine’s operator manual are available by mail or online. Please visit
www.greatplainsag.com and follow the product link for information on your machine.
See next page for contents of package.

Page 1 of 4
Parts List & Instructions
62320
Adaptor Package
For Great Plains Terra-Max 20 & 25-Ft Models
& For Turbo-Max 24 & 30-Ft Models
Contents of Adaptor Package (62320)
Item # Part Number Description Qty
1 C01-0375-041 Nylon Lock Nut (3/8) 2
2 C02-0375-010 Lock Washer (3/8) 2
3 C03-0375-211 Hex Bolt 3/8 x 6-1/2 2
4 62253-2 Plate Mount 2
5 62303-30 Mount Strap 2
62320 (7/28/21)

Page 2 of 4
Mounting Instructions for Terra-Max 20, & 25-Ft & for Turbo-Max 24 & 30-Ft Models
Step #1
Mount run\hold switch as shown to left wheel lift. Tighten all hardware securely.
Note: The following components are from package 62312-A
Run/Hold Switch & 3/8 bolts, lock washers and lock nuts.
62320-A1 (10/26/21)

Page 3 of 4
Step #2
Install the two mount straps (62303-30) to wheel lift arm as shown. See installed view below. Tighten all hardware
securely.
62320-A2 (10/26/21)

Page 4 of 4
Step #3
62312-ASEMBLY (8/16/21)
Connect the s-hook as shown and clinch s-hook so it cannot come off.
Connect s-hook to sash chain and clinch end to s-hook. Connect key ring to spring on run\hold switch.
Note: Chain may have to be shortened to meet desired length needed. Make sure implement can float and that there
is no tension on spring when lowered so Run/Hold switch is not starting and stopping the electric motor when
traveling.
Route wire (62253-5) from Run/Hold Switch along frame to front corner of hopper and connect
wire adaptor (62253-6) to end of wire (62253-5). Connector wire adaptor to white plug (electric motor) in front
corner of hopper.
The Run/Hold switch is wired from the factory to be nominally closed.
The chain has to be pulled to release the switch to stop the electric motor.
Note: The Run/Hold switch only turns on or off the electric motor.
For stopping for long periods of time shut-off the center master switch to cut all power to motor and clutches.
