Gree GWHD(48S)NM3CO User manual

SUPER FREE MATCH SERIES
SERVICE MANUAL
T1/R410A/50Hz
( GC201405 - )
CENTRAL AIR CONDITIONERS

Contents
PRODUCT ................................................................................................................... 2
1MODELS LIST......................................................................................................................2
1.1Outdoor Unit ..........................................................................................................................2
1.2BU Module.............................................................................................................................2
1.3Indoor Unit.............................................................................................................................2
2NOMENCLATURE ...............................................................................................................5
2.1Nomenclature of Outdoor Unit ..............................................................................................5
2.2Nomenclature of BU Module.................................................................................................5
2.3Nomenclature of Indoor Unit.................................................................................................5
3FUNCTION ...........................................................................................................................6
4PRODUCT DATA..................................................................................................................7
4.1Product Data of Outdoor Unit................................................................................................7
4.2Product Data of Indoor Unit...................................................................................................8
4.3Product Data of BU Module ................................................................................................21
5Working Temperature Range ...............................................................................................21
6PIPING DIAGRAM.............................................................................................................22
Control........................................................................................................................ 24
1OPERATION FLOWCHART..............................................................................................24
1.1Cooling/Dry Operation ........................................................................................................25
1.2Heating Operation ................................................................................................................ 26
2MAIN LOGIC......................................................................................................................27
2.1Control Function of Outdoor Unit .......................................................................................27
2.2Protection Function..............................................................................................................28
2.3Other function ......................................................................................................................29
2.4Control Function of Indoor Unit ..........................................................................................30
3REMOTE CONTROLLER..................................................................................................33
3.1Wired Remote Controller.....................................................................................................33
3.2Wireless Remote Controller YT1F (MOTO) .......................................................................38
3.3Wireless Remote Controller YAA1FB1...............................................................................41
3.4Wireless Remote Controller YAG1FB.................................................................................45
3.5Wireless Remote Controller YB1F2 (XFAN) ......................................................................51
4Smart Zone Controller (CE50-24/E)....................................................................................55
4.1General Introduction ............................................................................................................55
4.2Communication Network.....................................................................................................56
4.3LCD......................................................................................................................................57
4.4Buttons .................................................................................................................................58
INSTALLATION ....................................................................................................... 61
1PRECAUTIONS FOR INSTALLATION ............................................................................61
1.1Precautions for Installation ..................................................................................................61
1.2Key Points of Installation.....................................................................................................63

Super Free Match
Service Manual
2FLOW CHART OF INSTALLATION.................................................................................65
3OUTDOOR UNIT INSTALLATION ..................................................................................66
3.1Precautions for R410A.........................................................................................................66
3.2Precaution for Installation....................................................................................................66
3.3Precaution for Operation Test .............................................................................................. 66
3.4Names of Main Parts............................................................................................................66
3.5Parts and Components of Unit .............................................................................................67
3.6Selection of Installation Location ........................................................................................67
3.7Outline Dimension of the Outdoor Unit ..............................................................................68
3.8Installation and Servicing Space .......................................................................................... 68
3.9Installation of the Outdoor Unit...........................................................................................69
4INDOOR UNIT INSTALLATION ......................................................................................70
4.1Installation of Wall Mounted Type.......................................................................................70
4.2Installation of Duct Type......................................................................................................72
4.3Installation of Cassette Type ................................................................................................80
4.4Installation of Floor Ceiling Type ........................................................................................85
4.5Installation of Console Type ................................................................................................ 88
5BU MODULE INSTALLATION.........................................................................................93
5.1Precaution for Installation....................................................................................................93
5.2Names of Main Parts............................................................................................................93
5.3Selection of Installation Location ........................................................................................93
5.4Outline Dimension and Servicing Space of FXB3A-K .......................................................94
5.5Outline Dimension and Servicing Space of FXB5A-K .......................................................95
5.6Installation Instruction .........................................................................................................96
6REFRIGERATION PIPING WORK ...................................................................................97
6.1Allowable Length and Drop Height of Connecting Pipe..................................................... 97
6.2Dimension of Connecting Pipe ............................................................................................97
6.3Connection of Branch Pipe ..................................................................................................98
6.4Design Requirements for Oil Trap .......................................................................................98
6.5Connection of Outdoor Unit Refrigerant Pipe ...................................................................100
6.6Installation of Piping Adapter ............................................................................................100
6.7Precaution for Connection .................................................................................................101
6.8Leak Test ............................................................................................................................103
6.9Vacuum Operation..............................................................................................................103
6.10Refrigerant Charging...................................................................................................104
7Electrical Wiring Work.......................................................................................................107
7.1Wiring Connection .............................................................................................................107
7.2Requirements of Power Circuit and Cable.........................................................................108
7.3Ground Requirements ........................................................................................................108
7.4Precautions of Electrical Wiring Work ..............................................................................108
7.5Precaution of Laying Wires................................................................................................109
7.6Electrical Wiring Work for Outdoor Unit ..........................................................................109
7.7Electrical Wiring Work for BU Module............................................................................. 110
7.8Instructions for DIP Switch................................................................................................ 112
7.9Electrical Wiring Work for Indoor Unit ............................................................................. 112
8INSTALLATION OF DRAINAGE PIPELINE ................................................................. 113

Super Free Match
Service Manual
8.1Material Quality Requirements for Condensate Pipe ........................................................ 113
8.2Key Points for Condensate Pipe Installation...................................................................... 113
9Installation of Protective Layer on Connection Pipe ......................................................... 117
MAINTENANCE .................................................................................................... 119
1Testing Board Introduction ................................................................................................ 119
1.1Compose of Testing Board................................................................................................. 119
1.2Instruction of Function and Data Section ..........................................................................119
1.3Process Control Setting......................................................................................................120
2Troubleshooting .................................................................................................................123
2.1Check before Contacting Maintenance Serviceman ..........................................................123
2.2Problem Handling ..............................................................................................................124
2.3Error description ................................................................................................................124
3FLOW CHART OF TROUBLESHOOTING ....................................................................127
3.1Malfunction display: High Pressure Protection .................................................................127
3.2Malfunction display: Low Pressure Protection..................................................................128
3.3Malfunction display: Discharge temperature protection....................................................129
3.4Malfunction display: Current protection............................................................................129
3.5Malfunction display: Communication error.......................................................................130
3.6Malfunction display: Indoor unit water full protection......................................................131
3.7Malfunction display: Temperature sensor error.................................................................131
3.8Malfunction display: High/Low pressure sensor error ......................................................132
4POWER DISTRIBUTION.................................................................................................132
4.1Diagram of Power Distribution..........................................................................................132
4.2Wiring diagram ..................................................................................................................133
5THE RESISTANCES OF COMMON TEMPERATURE SENSORS ...............................142
5.115 KΩ.................................................................................................................................142
5.220 KΩ.................................................................................................................................143
5.350 KΩ.................................................................................................................................144
6DISASSEMBLY AND ASSEMBLY PROCEDURE OF MAIN PARTS ..........................147
6.1Outdoor Unit ......................................................................................................................147
6.2Indoor unit..........................................................................................................................152
7EXPLODED VIEWS AND PART LIST............................................................................162
7.1Outdoor unit .......................................................................................................................162
7.2Indoor unit..........................................................................................................................165
7.3BU Module.........................................................................................................................201

Super Free Match
Service Manual
PRODUCT
1
PRODUCT

Super Free Match
Service Manual
PRODUCT 2
PRODUCT
1MODELS LIST
1.1 Outdoor Unit
Capacity Capacity Power supply
Model Product code Cooling
(kW)
Heating
(kW)
Refriger
ant Ph, V, Hz Appearance
GWHD(48S)NM
3CO CN860W0110 14.0 16.0
GWHD(56S)NM
3CO CN860W0120 16.0 18.0
R410A 3,380~415,50
1.2 BU Module
Number of connectable
indoor units Power supply
Model Product code
Min Max
Refrigerant
Ph, V, Hz
Appearance
FXB3A-K EN0130050 1 3
FXB5A-K LN01300220 1 5
R410A 1,220~240,50
1.3 Indoor Unit
1.3.1 Wall mounted type
¾Hansol
Capacity Power supply
Model Product code Cooling
(kW)
Heating
(kW)
Refrige
rant Ph, V, Hz Appearance
GWH(07)TA-K3DNA1E/I CB148N05201 2.1 2.6
GWH(09)TA-K3DNA1E/I CB148N05301 2.5 2.75
GWH(12)TB-K3DNA1E/I CB148N05401 3.5 3.65
GWH(18)TC-K3DNA1E/I CB148N05501 5.3 5.6
GWH(28)TD-K3DNA1C/I CB148N07900 8.4 8.6
R410A 1,220~240,50

Super Free Match
Service Manual
PRODUCT
3
¾U-cool
Capacity Power supply
Model Product code Cooling
(kW)
Heating
(kW)
Refrige
rant Ph, V, Hz Appearance
GWH(07)UA-K3DNA1B/I CB204N02600 2.1 2.6
GWH(09)UA-K3DNA1B/I CB204N02700 2.6 2.8
GWH(12)UB-K3DNA1B/I CB204N02800 3.5 3.8
GWH(18)UC-K3DNA1B/I CB204N02900 5.3 5.8
R410A 1,220~240,50
¾Cozy
Capacity Power supply
Model Product code Cooling
(kW)
Heating
(kW)
Refrige
rant Ph, V, Hz Appearance
GWH(07)MA-K3DNA3E/I CB171N08600 2.1 2.6
GWH(09)MA-K3DNA3E/I CB171N08501 2.6 2.8
GWH(12)MB-K3DNA3E/I CB171N08701 3.5 3.8
GWH(18)MC-K3DNA3E/I CB171N08401 5.3 5.8
R410A 1,220~240,50
¾Change
Capacity Power supply
Model Product code Cooling
(kW)
Heating
(kW)
Refrige
rant Ph, V, Hz Appearance
GWH(07)KF-K3DNA6E/I CB146N26201 2.1 2.6
GWH(09)KF-K3DNA6E/I CB146N26301 2.6 2.8
GWH(12)KF-K3DNA6E/I CB146N26401 3.5 3.8
GWH(18)KG-K3DNA6E/I CB146N26501 5.3 5.8
R410A 1,220~240,50

¾Viola
Capacity Power supply
Model Product code Cooling
(kW)
Heating
(kW)
Refrige
rant Ph, V, Hz Appearance
GWH(07)RA-K3DNA3E/I CB302N01501 2.1 2.6
GWH(09)RA-K3DNA3E/I CB302N01601 2.6 2.8
GWH(12)RB-K3DNA3E/I CB302N01701 3.5 3.8
GWH(18)RC-K3DNA3E/I CB302N01801 5.3 5.8
GWH(24)RC-K3DNA1A/I CB144N01100 6.45 7.1
R410A 1,220~240,50
1.3.2 Duct type
Capacity Power supply
Model Product code Cooling
(kW)
Heating
(kW)
Refrige
rant Ph, V, Hz Appearance
GFH(09)EA-K3DNA1A/I CN210N0010 2.5 2.8
GFH(12)EA-K3DNA1A/I CN210N0020 3.5 3.85
GFH(18)EA-K3DNA1A/I CN210N0030 5.0 5.5
GFH(21)EA-K3DNA1A/I CN210N0040 6.0 6.6
GFH(24)EA-K3DNA1A/I CN210N0050 7.1 8.0
R410A 1,220~240,50

Super Free Match
Service Manual
PRODUCT 4
1.3.3 Cassette type
Capacity Power supply
Model Product code Cooling
(kW)
Heating
(kW)
Refrige
rant Ph, V, Hz Appearance
GKH(12)BA-K3DNA2A/I CN510N0040 3.5 4.0
GKH(18)BA-K3DNA2A/I CN510N0050 4.5 5.0
GKH(12)BA-K3DNA1A/I CN510N0010 3.5 3.85
GKH(18)BA-K3DNA1A/I CN510N0020 5.0 5.5
GKH(24)BA-K3DNA1A/I CN510N0030 7.1 8.0
R410A 1,220~240,50
1.3.4 Floor ceiling type
Capacity Power supply
Model Product code Cooling
(kW)
Heating
(kW)
Refrige
rant Ph, V, Hz Appearance
GTH(09)BA-K3DNA1A/I CN610N0010 2.5 2.8
GTH(12)BA-K3DNA1A/I CN610N0020 3.5 3.85
GTH(18)BA-K3DNA1A/I CN610N0030 5.0 5.5
GTH(24)BA-K3DNA1A/I CN610N0040 7.1 8.0
R410A 1,220~240,50
1.3.5 Console type
Capacity Power supply
Model Product code Cooling
(kW)
Heating
(kW)
Refrige
rant Ph, V, Hz Appearance
GEH(09)AA-K3DNA1C/I CV010N01500 2.6 2.8
GEH(12)AA-K3DNA1C/I CV010N01600 3.5 3.8
GEH(18)AA-K3DNA1C/I CV010N01700 5.3 5.8
R410A 1,220~240,50


Super Free Match
Service Manual
PRODUCT
5
2NOMENCLATURE
2.1 Nomenclature of Outdoor Unit
GW □ □ (□) □ □ □ □ O
1 2 3 4 5 6 7 8 9
NO. Description Options
1 GW Free-Match Code
2 Cooling Function C: Cooling Only H: Heat pump
3 Compressor Frequency D:DC inverter rotor type
4 Cooling Capacity 48 represents 48000Btu/h 1kW=3.412KBtu
Srepresents super free match
5 Climate Type T1
6 Power Supply M:380-415V-3Ph-50Hz; D: 208/230V-1Ph-60Hz
K:220-240V-1Ph-50Hz
7 Refrigerant 3-R410A
8 Design No. C :Third generation
9 O O:Outdoor unit
2.2 Nomenclature of BU Module
2.3 Nomenclature of Indoor Unit
G □ □ (□)□ - □ □ □ □ □ □ / I
1 2 3 4 5 6 7 8 9 10 11 12
NO. Description Options
1 G GREE
2 Product Type
W: Wall mounted type F:Duct type
K:Cassette type E:Console T:Floor ceiling type
3 Cooling Function C: Cooling Only H: Heat pump
4 Cooling Capacity 12 represents 12000Btu/h 1kW=3.412KBtu
5 Series Alphabets: Series code + Shell code
6 Power Supply K:220-240V-1Ph-50Hz; D: 208/230V-1Ph-60Hz
7 Refrigerant 3-R410A
8 Compressor Frequency D:DC inverter rotor type
9 Climate Type T1
10 Panel Code 1 Alphabet +1 Numeral
11 Design No. A :First generation
12 I I:indoor Unit
FX □ □ □
1 2 3 4
No. Description Options
1 Assembly type FX-branch module
2 Body code A、B、C……
3 Number of port 2-two ports; 3-three ports; 5-five ports
4 Connection method A-Flare; B-Braze

Super Free Match
Service Manual
PRODUCT 6
3FUNCTION
Function Wall
mounted Duct type Cassette
type
Floor
ceiling type
Console
type
Fan operation Mode ●● ● ● ●
Auto Swing Controller ●/ ● ● ●
Timer Selector ●● ● ● ●
Auto Mode Operation ●● ● ● ●
Cool Mode Operation ●● ● ● ●
Heat Mode Operation ●● ● ● ●
Dry Mode Operation ●● ● ● ●
Fan Mode Operation ●● ● ● ●
Sleep mode setting ●● ● ● ●
For Comfortable
Air Conditioning
Drain Pump /● ● / /
Wired Controller / ● ● ● /
For Flexible Control
Wireless Remote Controller ●● ● ● ●
●: Have Functions
/ : No Functions

Super Free Match
Service Manual
PRODUCT
7
4PRODUCT DATA
4.1 Product Data of Outdoor Unit
Model Heat pump GWHD(48S)NM3CO GWHD(56S)NM3CO
Cooling capacity KW 14.0 16.0
Heating capacity KW 16.0 18.0
Cooling KW 4.40 5.0
Nominal input Heating KW 4.25 4.7
EER/COP 2.9/3.2 2.8/3.5
Minimum NO. of connectable indoor units 2 2
Maximum NO. of connectable indoor units 8 9
Minimum No. of BU modules to be connected 1 1
Maximum No. of BU modules to be connected 3 3
Min 50 50
Total capacity index of to be connected
indoor units Max 135 135
Power supply 3Ph,380~415V, 50Hz
Dimensions (H×W×D) mm 1345×900×340 1345×900×340
Net weight/Gross weight kg 116/125 116/125
Sound pressure level cooling/heating dB(A) 58 58
Type Axial-flow
Fan Air Flow Volume m3/h 7000 7000
Name R410A
Charge kg 4.95 4.95
Refrigerant
Control Electronic expansion valve
Type FV50S FV50S
Refrigerant oil Charge L 1.35 1.35
Type Inverter Rotary
Compressor Quantity 1
Gas mm Φ15.9 Φ19.05
Piping connections Liquid mm Φ9.52 Φ9.52
System total m 135 145
OU-BU m 55
total BU-IN m 80 90
Piping length
1 room BU-IN m 15
OU-BU m 30
OU-IN m 30
Height BU-BU/
IN-IN m 15
Cooling DB℃18~48
Operation range Heating ℃DB -10～24
20' GP 25 25
40' GP 50 50
Loading quantity
40' HQ 50 50

Super Free Match
Service Manual
PRODUCT 8
Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
4.2 Product Data of Indoor Unit
4.2.1 Wall mounted type
¾Hansol
Model GWH(07)TA-K3DN
A1E/I
GWH(09)TA-K3DN
A1E/I
GWH(12)TB-K3DN
A1E/I
Cooling kW 2.1 2.5 3.50
Capacity Heating kW 2.6 2.75 3.65
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Motor power input kW 0.029 0.029 0.029
m3/h 550 550 770
Air flow volume CFM 324 324 430
Sound pressure level
(SH/H/MH/M/ML/L/SL) dB(A) 41/36/34/32/28/24/21 41/36/34/32/28/24/21 43/36/34/32/28/24/21
Output kW 0.015 0.015 0.015
Fan motor Running
current A 0.07 0.07 0.07
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting
pipe Connection method Flare Connection Flare Connection Flare Connection
External dia. mm Φ20 Φ20 Φ20
Drain pipe Thickness mm 1.5 1.5 1.5
Outline
dimension W×D×H mm 806×209×292 806×209×292 866×209×292
Package
dimension W×D×H mm 888×297×377 888×297×377 945×297×377
Net Weight/Gross weight kg 10.5/13.0 10.5/13.0 11.0/13.5
20'GP 266 266 252
40' GP 553 553 518
Loading quantity
40' HQ 632 632 592

Super Free Match
Service Manual
PRODUCT
9
Model GWH(18)TC-K3DNA1E/I GWH(28)TD-K3DNA1C/I
Cooling kW 5.3 8.4
Capacity Heating kW 5.6 8.6
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50
Motor power input kW 0.045 0.1
m3/h 950 1200
Air flow volume CFM 559 706
Sound pressure level
(SH/H/MH/M/ML/L/SL) dB(A) 49/44/41/39/36/33/30 52/50/48/45/42/39/35
Output kW 0.025 0.07
Fan motor Running current A 0.1 0.24
Gas inch 5/8″(Φ15.9mm) 5/8″(Φ15.9mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting pipe
Connection method Flare Connection Flare Connection
External dia. mm Φ20 Φ20
Drain pipe Thickness mm 1.5 1.5
Outline dimension W×D×H mm 1018×230×319 1178×264×326
Package dimension W×D×H mm 1097×397×340 1256×414×364
Net Weight/Gross weight kg 15.0/18.5 17.0/23.0
20'GP 174 138
40' GP 366 303
Loading quantity
40' HQ 427 349
Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.

Super Free Match
Service Manual
PRODUCT 10
¾U-cool
Model GWH(07)UA-K
3DNA1B/I
GWH(09)UA-K
3DNA1B/I
GWH(12)UB-K
3DNA1B/I
GWH(18)UC-K
3DNA1B/I
Cooling kW 2.1 2.6 3.5 5.3
Capacity Heating kW 2.6 2.8 3.8 5.8
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50 220~240-1-50
Motor power input kW 0.03 0.03 0.04 0.06
m3/h 450 450 560 850
Air flow volume CFM 265 265 330 500
Sound pressure level
(SH/H/MH/M/ML/L/SL) dB(A) 37/35/32/30/28/
26/24
38/35/32/30/28/
26/25
39/37/34/31/29/
27/26
44/40/37/35/33/
31/28
Output kW 0.01 0.01 0.02 0.025
Fan motor Running
current A 0.136 0.136 0.2 0.31
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting
pipe Connection method Flare
Connection
Flare
Connection
Flare
Connection
Flare
Connection
External dia. mm Φ20 Φ20 Φ20 Φ20
Drain pipe Thickness mm 1.5 1.5 1.5 1.5
Outline
dimension W×D×H mm 860×153×299 860×153×299 896×159×320 998×178×340
Package
dimension W×D×H mm 944×247×386 944×247×386 973×255×403 1083×283×428
Net Weight/ Gross weight kg 9.5/12.5 9.5/12.5 10/13 14.0/17.0
20'GP 324 324 279 216
40' GP 666 666 585 440
Loading quantity
40' HQ 740 740 650 495
Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.

Super Free Match
Service Manual
PRODUCT
11
¾Cozy
Model GWH(07)MA-K
3DNA3E/I
GWH(09)MA-K
3DNA3E/I
GWH(12)MB-K
3DNA3E/I
GWH(18)MC-K
3DNA3E/I
Cooling kW 2.1 2.6 3.5 5.3
Capacity Heating kW 2.6 2.8 3.8 5.8
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50 220~240-1-50
Motor power input kW 0.03 0.03 0.04 0.045
m3/h 450 500 630 850
Air flow volume CFM 265 294 371 500
Sound pressure level
(SH/H/M/L) dB(A) 36/34/31/28/- 37/34/31/28/- 38/34/32/30/- 46/43/40/36/-
Output kW 0.01 0.01 0.02 0.02
Fan motor Running
current A 0.14 0.14 0.22 0.31
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting
pipe Connection method Flare Connection Flare Connection Flare Connection Flare Connection
External
dia. mm Φ20 Φ20 Φ20 Φ20
Drain pipe
Thickness mm 1.5 1.5 1.5 1.5
Outline
dimension W×D×H mm 790×170×265 790×170×265 845×180×275 940×200×298
Package
dimension W×D×H mm 873×251×370 873×251×370 918×258×370 1013×288×395
Net Weight/ Gross weight kg 9/11 9/11 10/12.5 13/16
20'GP 348 348 336 254
40' GP 732 732 684 541
Loading quantity
40' HQ 852 852 798 609
Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.

Super Free Match
Service Manual
PRODUCT 12
¾Change
Model GWH(07)KF-K
3DNA6E/I
GWH(09)KF-K
3DNA6E/I
GWH(12)KF-K
3DNA6E/I
GWH(18)KG-K
3DNA6E/I
Cooling kW 2.1 2.6 3.5 5.3
Capacity Heating kW 2.6 2.8 3.8 5.8
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50 220~240-1-50
Motor power input kW 0.03 0.03 0.03 0.06
m3/h 550 600 680 800
Air flow volume CFM 324 353 400 471
Sound pressure level
(SH/H/M/L) dB(A) 40/38/30/24/- 41/38/30/24/- 42/39/31/25/- 45/40/37/32/-
Output kW 0.01 0.01 0.01 0.02
Fan motor Running
current A 0.16 0.16 0.16 0.31
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting
pipe Connection method Flare
Connection
Flare
Connection
Flare
Connection
Flare
Connection
External dia. mm Φ20 Φ20 Φ20 Φ20
Drain pipe Thickness mm 1.5 1.5 1.5 1.5
Outline
dimension W×D×H mm 770×201×283 770×201×283 770×201×283 865×215×305
Package
dimension W×D×H mm 847×264×357 847×264×357 847×264×357 948×298×395
Net Weight/ Gross weight kg 8/10 8/10 9/11 12/15
20'GP 328 328 328 264
40' GP 688 688 688 542
Loading quantity
40' HQ 774 774 774 616
Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.

Super Free Match
Service Manual
PRODUCT
13
¾Viola
Model GWH(07)RA-K3DNA3E/I GWH(09)RA-K3DNA3E/I
Cooling kW 2.1 2.6
Capacity Heating kW 2.6 2.8
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50
Motor power input kW 0.03 0.03
m3/h 500 500
Air flow volume CFM 294 294
Sound pressure level (SH/H/M/L) dB(A) 40/37/35/32/- 40/37/35/32/-
Output kW 0.01 0.01
Fan motor Running current A 0.14 0.14
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting pipe
Connection method Flare Connection Flare Connection
External dia. mm Φ20 Φ20
Drain pipe Thickness mm 1.5 1.5
Outline dimension W×D×H mm 794×186×265 794×186×265
Package dimension W×D×H mm 873×270×353 873×270×353
Net Weight/ Gross weight kg 9/11.5 9/11.5
20'GP 348 348
40' GP 720 720
Loading quantity
40' HQ 840 840

Super Free Match
Service Manual
PRODUCT 14
Model GWH(12)RB-K3DN
A3E/I
GWH(18)RC-K3DN
A3E/I
GWH(24)RC-K3DN
A1A/I
Cooling kW 3.5 5.3 6.45
Capacity Heating kW 3.8 5.8 7.1
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Motor power input kW 0.05 0.06 0.065
m3/h 630 850 1000
Air flow volume CFM 371 500 588
Sound pressure level
(SH/H/M/L) dB(A) 42/39/36/33/- 45/42/37/33/- 48/46/44/42/-
Output kW 0.02 0.02 0.035
Fan motor Running
current A 0.22 0.31 0.31
Gas inch 3/8″(Φ9.52mm) 1/2″(Φ12.7mm) 5/8″(Φ15.9mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 3/8″(Φ9.52mm)
Connecting
pipe Connection method Flare Connection Flare Connection Flare Connection
External dia. mm Φ20 Φ20 Φ20
Drain pipe Thickness mm 1.5 1.5 1.5
Outline
dimension W×D×H mm 848×189×274 945×208×298 1018×223×315
Package
dimension W×D×H mm 926×279×359 1013×300×383 1086×328×398
Net Weight/ Gross weight kg 10/12.5 13/16 15.5/20.5
20'GP 306 254 174
40' GP 636 541 366
Loading quantity
40' HQ 742 609 427
Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.

Super Free Match
Service Manual
PRODUCT
15
4.2.2 Duct type
Model Heat pump
GFH(09)EA-K3D
NA1A/I
GFH(12)EA-K3D
NA1A/I
GFH(18)EA-K3D
NA1A/I
Cooling KW 2.50 3.50 5.00
Capacity
Heating KW 2.80 3.85 5.50
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Motor power input kW 0.065 0.075 0.08
m3/h 450 500 700
Air flow volume
CFM 265 294 412
Sound pressure level (H/L) dB(A) 37/31 39/32 41/33
Output kW 0.03 0.04 0.05
Fan motor
Running current A 0.28 0.31 0.41
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting pipe
Connection method Flare Connection Flare Connection Flare Connection
External dia. mm Φ31 Φ31 Φ31
Drain pipe Thickness mm 3 3 3
Outline dimension W×D×H mm 700×615×200 700×615×200 900×615×200
Package dimension W×D×H mm 893×743×305 893×743×305 1123×743×305
Net Weight/ Gross weight kg 22/27 23/29 27/36
20'GP 108 108 90
40' GP 234 234 180
Loading quantity
40' HQ 234 234 180

Super Free Match
Service Manual
PRODUCT 16
Model Heat pump GFH(21)EA-K3DNA1A/I GFH(24)EA-K3DNA1A/I
Cooling KW 6.00 7.10
Capacity
Heating KW 6.60 8.00
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50
Motor power input kW 0.11 0.11
m3/h 1000 1000
Air flow volume
CFM 588.5 588.5
Sound pressure level dB(A) 42/34 42/34
Output kW 0.061 0.061
Fan motor
Running current A 0.5 0.5
Gas inch 5/8″(Φ15.9mm) 5/8″(Φ15.9mm)
Liquid inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm)
Connecting pipe
Connection method Flare Connection Flare Connection
External dia. mm Φ31 Φ31
Drain pipe Thickness mm 3 3
Outline dimension W×D×H mm 1100×615×200 1100×615×200
Package dimension W×D×H mm 1323×743×305 1323×743×305
Net Weight/ Gross weight kg 31/41 31/41
20'GP 72 72
40' GP 162 162
Loading quantity
40' HQ 162 162
Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
