Green Digital Power-tech A500CM-XX User manual

CAUTION
1. SAVE THIS INSTRUCTIONS- This manual contains important safety and
operating instructions for theA500CM-XX battery charger.
Please read the caution ofbatteries or devices you want to charge firstly!
2. When charging, batteries can emit explosive gases, therefore it is essential to
prevent flames and sparks. The charger is designed for charging specified
Lead-acid type batteries . Do not use for any other purpose.
3. Always provide good ventilation when charging.
4. Use of an attachment not recommended or sold by Green-Digital Power-tech
may result in a risk of fire, electric shock or serious injury to persons.
5. To reduce risk of damage to electric plug and cord, pull by the plug rather than
by the cord when disconnecting charger.
6. An extension cord should not be used unless absolutely necessary. Use of an
improper extension cord could result in a risk of fire and electric shock. If
extension cord must be used, make sure that: a) Pins on plug of extension
cord are the same number, size and shape as those of plug on charger; b)
Extension cord is properly wired and in good electrical condition; and c) Wire
size is large enough for ac ampere rating as specified in “technical data”.
7. Do not operate charger with a damaged cord or plug-return the charger to the
place where purchased.
8. Never operate the charger if it has received a sharp blow, been dropped or
otherwise damaged in any way; take is to a qualified serviceman.
9. Do not disassemble the charger; take it to a qualified serviceman when
service or repair is required. Incorrect reassembly may result in a risk of
electrical shock or fire.
10. To reduce risk of electric shock, unplug charger from AC outlet before
attempting any maintenance or cleaning. Turning off controls will not reduce
the risk.
A500CM-XX 24~60V
Lead-Acid VRLA Battery Charger
User’s Manual
May, 2012 Rev:1.0
Green Digital Power-tech Co., Ltd.
Brief Introduction
A500CM-xx family is a main member of digital-chargers from Green Digital
Power-tech Co., Ltd. It is designed for 24V~60V Lead-Acid type battery such
as VRLA, AGM, GEL, SLA and Wet type battery. A500CM-xx programmed 3
auto stages ( CC-CV-Floating) charging process. “CC” means constant current
charging, the charge current is not changed during this stage. “CV” stage is
followed “CC”, the output voltage is limited on a specified value and not
changed at this stage, until the battery is charged completely and then charger
will enter floating stage, this stage also called “maintenance stage”.
For more safety, A500CM-xx has more protections function, such as
when the battery polarity reversed protection or the output connectors
shorted protection.
General Specification forA500CM-XX
Input Voltage: AC 110V or 240V 50/60Hz
Input Current: 8.0A at AC120V; 4A at AC 230V
Output A500CM-24 A500CM-36 A500CM-48 A500CM-60
C.V 27.6V 41.4V 55.2V 69.0V
C.C 15.0A 11.0A 8.0A 6.0A
Operating -10℃~40℃
Cooling Fan cooling design. Do not cover the charger during charging
Charge process Auto 3 stages: CC-CV-Floating
Battery 24V~60V 40 ~ 200Ah Lead-Acid type Batteries
Size 223X125X71mm
Enclosure Aluminum alloy housing
Connector AC inlet type C14; DC output terminals to be defined by user
Weight 1.2kg
How to use:
1) Connect the AC cord to the socket, The “Power” LED lamp will light on
and “Charging” LED lamp will be extinguished.
2) Connect DC plug with your matched Li-ion or LiFePO4 battery-pack,
then the “Charging” LED lamp will turn to solid “RED” color and the
charging process is working correctly. If the battery polarity reversed or
output shorted, this LED lamp will display “RED flashing”, please
check and remove errors connected.
3) When the battery full charged, the “Charging LED” lamp will turn to solid
“GREED” color. That means your battery is full charged and you can
disconnect DC plug and AC power line.
Charging LED Power LED
RED for charging RED for power on
GREEN for full charged OFF for no AC power input
RED FLASHING for errors
OFF for no battery connected
