Nova C Series Add Ons
Nova C Table Wireless

Product desription
Recycling
Assembly instructions Nova C Table Wireless
Electrical instructions Nova C Table Wireless
p1
p2
p3-6
p7-10

Nova C Add Ons Green Furniture Concept
Product description
Add ons
Nova C Table Wireless
Nova C Table Wireless can be placed in
the middle of any Nova C Back or Nova
C Double module.
Material Table top: Massive oak treated
with hardwax oil.
Material table holder: Powder coated
steel.

Legs, strips, armrest, table holder and
small parts are made of steel and are
sorted as metal.
Recycling
Nova C Add Ons Green Furniture Concept2
Ribs and table tops are made of wood
and adhesive and are sorted as
combustible.
Glides are made of HDPE and are
sorted as plastic.

Nova C Add Ons Green Furniture Concept3
Screv A 5x20 Torx
x11
Cable kit
x1
Cable clip
x2
ZENS Wireless Charger
x1
(x2 Charger screws included)
Screw-nut A x5
Washer A x1
Bolt B x5
Metal plate
x1
Assembly instructions
Nova C Table Wireless
Table Stand
x1
Table Top
x1
Cable Channel
x1
Domehead-nut
x4
Charger Cable Box
x1
Grommet x1
Bend protection x1

Nova C Add Ons Green Furniture Concept4
1 2
5 6
3 4
Assembly instructions
Nova C Table Wireless
Start with placing the ZENS carger in the table top.
Turn the cable agenst the direction where
the bench will be.
Use the two includes Charger screws to attach
the ZENS cherger by screwing the in tho the
charger. The sides will expand and keep
the charger in place.
Attach the Table top to the Table stand using
Screw A in all seven holes. Note: make sure that
the logo on the table top is placed in correct
direction.
Thread the charger cable through the hole in
the Table stand.
Cut one side of the Grommet open to be able to
thread it on to the cable.
Place the cable with the Grommet om it in the
hole of the Table stand.

Nova C Add Ons Green Furniture Concept5
7 8
8
Place the Cable channel over the charger cable
and loosely attach with Domehead-nut. Make
sure that the Bend protection is attached under
the Cable channel.
9
Pull the cable trough the rib before attaching
the table to the bench.
11
Metal plate
10
Assemble table with Bolt B, Screw-nut A, Metal
plate and Washer A.
Attach the Charger Cable Box to the wide rib on
your bench using screw A.
Cut half of the Bend Protection open ant thread
the cable trough it.
Make sure that you attach the Bend protection
under the Cable channel.

Nova C Add Ons Green Furniture Concept6
Finnished assembly of Nova C
Table Wireless.
9
Assembly instructions
Nova C Table Wireless

Product Description
Nova C Table Wireless
Wieland Connector
Nova C Table Wireless uses a Wieland
connector cable to be able to link more than
one charger to one electrisity source. The ZENS
Charger comes with a CE marked cable that
connects to the Wieland Connector. The length
of the cable is 300mm by standard but can be
made with a custom length if needed..
Nova C Add Ons Green Furniture Concept7
Place the mobile end device over the charging
logotype on the table top. A low tone confirms
the correct positioning.
The ZENZ Charger is used for
inductive charging of suitable mobile devices
with a correspondingly fitted receiver inductor
e.g. QI-certified smartphones, smartwatches
and tablets.
Wireless Charging

Product Description
Nova C Table Wireless
Nova C Table Wireless Connecting Cables
Cable Kit (Standard: 1 kit per bench)
Starter Cable (Standard: 1 cable per configuration)
When connecting Nova C Table Wireless to your electricity source, you will need the following parts.
Important! Always shut off power to the circuit before starting installation work. In some countries electrical
installation work may only be carried out by a authorised electrical contractor. Contact your local electricity
authority for advice.
1 x Interconnector Cable
(Yellow)
1 x Starter Cable
(Orange)
1 x Slimline Male Wieland
(Red)
1 x Wieland Adaptor Block
(Purple)
7 x Cable Clip
(Blue)
ZENS Charger
1 x ZENS Charger
(Green)
Nova C Add Ons Green Furniture Concept8

1 2
Electrical components instruction
Nova C Table Wireless
4
5
3
Electrician will adjust the length of the
Interconnector cable to fit the
bench configuration and connect the cut
end to the male Wieland.
Follow assembly instructions to attach
the Nova C Table Wireless to you bench.
Attach four Cable clips to the metall strip
using the existing screws. Screw in the
other two Cable clipt to the ribs uring
screw A.
Pull the cable from the ZENS carger
trough the Cable clips to the Cable box.
Attach the Interconnection cable to the
bench using the Cable clips.
6
Connect the Wieland cable from the Carger box
and the Interconnection cable to the
Wieland Adaptor Block.
Nova C Add Ons Green Furniture Concept9

Product description
Nova C Table Wireless
Nova C Table Wireless
Nova C Table Wireless on a straight Nova C Back configuration.
Nova C Add Ons Green Furniture Concept10
