Green Furniture Concept nova c series User manual

Nova C Series Add Ons
Nova C Double Bench Endpiece

Index
Product desription
Recycling
Assembly instructions Nova C Double Bench Endpiece
p1
p2
p3-5

Nova C Add Ons Green Furniture Concept
Product description
Add ons
1
Nova C Double Endpice
Nova C Double Endpice can pe plaged at the end
of any Nova C Double configuration.
Material Ribs: Form pressed vereer treated with
hard wax oil.
Material Legs: Powder coated steel.

Recycling
Nova C Add Ons Green Furniture Concept2
Legs, strips, armrest, table holder and
small parts are made of steel and are
sorted as metal.
Ribs and table tops are made of wood
and adhesive and are sorted as
combustible.

Nova C Add Ons Green Furniture Concept3
Assembly instructions
Nova C Double Bench Endpice
Nova C Glides x4
Nova C Endpiece Leg x2 Nova C Slender Rib x14 Nova C Back Half Rib x12
Nova C Endpiece Clip x4 Nova C Back Metal
Strip 90 x2
Nova C Seat Metal
Strip 90 x2
Note:
Due to that the assembly of this
bench mostly is done with the ribs
upside down we recommend you
to use a blanket or simmilar to
prevent damage to the ribs and
metal parts.
Nova C Endpiece
Conection Plate x2
Bolt A x8
Screw B x28
Screw A x84
Bolt B x14

Nova C Add Ons Green Furniture Concept4
Nova C Double Bench Endpice
Assembly instructions
12
Use bolt A to attach glides to the leg.
Use screw A to attach metal strips to
the ribs. Start with the outer slender ribs,
continue with the rest of the ribs.
Leave the to most outwards holes on
the Seat Metal strip.
3
Use screw A to attach the leg to
the rib construction.
56
Repeat step 1-4 on both
Endpieces and the push them togeter.
Attach the to Endpieces to each other
with bolt B and the Endpiece
Conection Plate. Attach the piecec both
under the seat and in the front.
4
Attach the Endpiece Clip to the
leg and Seat Metal strip using screw B.

Nova C Add Ons Green Furniture Concept5
Nova C Double Bench Endpice
Assembly instructions
78
Attach the Endpiece whit screw B.
Replace the three screws that are
already in the Bench Metal Strip. One
screwshould be left in the strip.
!
Use bolt B to attach the Endpiece to
the rest of the configuration through the
Endpiece Clip.
Use screw A to attach the Endpiece to
the rib on the end in ther rest of your
configuration through the Endpiece Clip.
9 10
