Greenes RCP12S28B User manual

Questions?Email [e-mail] or call 800-622-5510 Monday - Friday 8am-5pm EST
ORIGINAL PINE RAISED GARDEN BED | ASSEMBLY INSTRUCTIONS
. ADD A SECOND AND THIRD BOARD TO ALL WALLS AND ADD THE
REMAINING SHORT POSTS.
Add Boards, one at a time, directly on top of each existing
Board in the Frame. Push the Boards down evenly between the
tops of the Short Posts. If needed, tap snugly into place with a
rubber mallet. The Boards should extend beyond the first set of
Short Posts by a few inches. Take the remaining Short Posts and
slide them down over the tops of the Boards.
PACKAGE CONTENTS + (6) Screws
x12 x6
8in. x 2.5in. x 2.5in.
Short Posts
4ft. x 3.5 in.
Boards
Decorative
Caps
x28
. CONNECT THREE SHORT POSTS TOGETHER WITH TWO BOARDS
Holding a Board in one hand with the notched ends facing up, line up
the groove on a Short Post and slide it down over one end of the Board.
Slide another Short Post down over the other end. With the same
Short Post, slide the second Board through the groove finishing with
another Short Post at the end to complete one 8ft. wall.
Repeat step one to complete a second wall.
. CONNECT THE TWO WALLS TOGETHER WITH THREE BOARDS
Take a Board and slide down over the top of a Short Post.
Connect the same Board to an adjacent Short Post on the second
wall. Do the same with two more Boards completing a 4ft. x 8ft.
rectangle or two connected 4ft. x 4ft. squares.
. FINISH WALLS & ATTACH DECORATIVE CAPS
Now slide the remaining Boards down into the Short Posts to
finish each of the walls. Attach each Decorative Cap to a Short
Post with a screwdriver and one Screw. We recommend drilling a
pilot hole first for each Screw.
MODEL #
RCPSB
DIMENSIONS
4ft. wide x 8ft. long
x 14in. high
NEED HELP?
Contact customer service
instead of returing item to store.
800-622-5510 M–F 8–5
[e-mail]
INSTALL ATION SUPPORT
youtube.com/greenesfence
2 Stacked
Short Posts

Questions?Email [e-mail] or call 800-622-5510 Monday - Friday 8am-5pm EST
ORIGINAL PINE RAISED GARDEN BED | ASSEMBLY INSTRUCTIONS
. ADD A SECOND AND THIRD BOARD TO ALL WALLS AND
ADD THE SHORT POSTS.
Add Boards, one at a time, directly on top of each existing Board in
the Frame. Push the Boards down evenly between the tops of the
Tall Posts. If needed, tap snugly into place with a rubber mallet.
The Boards should extend beyond the first set of Tall Posts by a
few inches. Take the Short Posts and slide them down over the
tops of the Boards.
PACKAGE CONTENTS + (6) Screws
x6 x6
8in. x 2.5in. x 2.5in.
Short Posts
4ft. x 3.5in.
Boards
Decorative
Caps
x35
. CONNECT THREE TALL POSTS TOGETHER WITH TWO BOARDS
Holding a Board in one hand with the notched ends facing up, line up
the groove on a Tall Post and slide it down over one end of the Board.
Slide another Tall Post down over the other end. With the same Tall
Post, slide the second Board through the groove finishing with another
Tall Post at the end to complete one 8ft. wall.
Repeat step one to complete a second wall.
. CONNECT THE TWO WALLS TOGETHER WITH THREE BOARDS
Take a Board and slide down over the top of a Tall Post. Connect
the same Board to an adjacent Tall Post on the second wall. Do the
same with two more Boards completing a 4ft. x 8ft. rectangle or
two connected 4ft. x 4ft. squares.
. FINISH WALLS & ATTACH DECORATIVE CAPS
Now slide the remaining Boards down into the Short Posts to
finish each of the walls. Attach each Decorative Cap to a Short
Post with a screwdriver and one Screw. We recommend drilling a
pilot hole first for each Screw.
MODEL #
RCPSTB
DIMENSIONS
4ft. wide x 8ft. long
x 17.5in. high
NEED HELP?
Contact customer service
instead of returing item to store.
800-622-5510 M–F 8–5
[e-mail]
INSTALL ATION SUPPORT
youtube.com/greenesfence
x6
11in. x 2.5in. x 2.5in.
Tall Posts
Short Posts Stacked
on top of Tall Posts
Tall Post
Short Post

Questions?Email [e-mail] or call 800-622-5510 Monday - Friday 8am-5pm EST
ORIGINAL PINE RAISED GARDEN BED | ASSEMBLY INSTRUCTIONS
MODEL #
RCPTB
DIMENSIONS
4ft. wide x 8ft. long
x 10.5in. high
PACKAGE CONTENTS + (6) Screws
x6 x6
11in. x 2.5in. x 2.5in.
Tall Posts
4ft. x 3.5in.
Boards
3.5in. x 3.5in.
Decorative Caps
x21
NEED HELP?
Contact customer service
instead of returing item to store.
800-622-5510 M–F 8–5
[e-mail]
INSTALL ATION SUPPORT
youtube.com/greenesfence
. CONNECT THREE TALL POSTS TOGETHER WITH TWO BOARDS.
Holding a Board in one hand with the notched ends facing up, line up
the groove on a Tall Post and slide it down over one end of the Board.
Slide another Tall Post down over the other end. With the same Tall
Post, slide the second Board through the groove finishing with another
Tall Post at the end to complete one 8ft. wall.
Repeat step one to complete a second wall.
. CONNECT THE TWO WALLS TOGETHER WITH THREE BOARDS.
Take a Board and slide it down over the top of a Tall Post. Connect
the same Board to an adjacent Tall Post on the second wall. Do the
same with two more Boards completing a 4ft. x 8ft. rectangle or
two connected 4ft. x 4ft. squares.
. ADD A SECOND AND THIRD BOARD TO ALL WALLS
& ATTACH DECORATIVE CAPS
Add Boards, one at a time, directly on top of each existing Board in
the Frame. Push the Boards down evenly between the tops of the
Tall Posts. If needed, tap snugly into place with a rubber mallet.
Attach each Decorative Cap to a Tall Post with a screwdriver and
one Screw. We recommend drilling a pilot hole first for each Screw.
TO STACK GARDEN BEDS FOR MORE HEIGHT:
• Assemble the first Garden Bed without Decorative Caps, or remove Caps
from a completed Bed.
• The Corner Posts are designed to be taller than the Boards, so Beds can
be stacked securely.
• Slide a Board from the second Garden Bed into tops of the Corner Posts from
the first Bed, to extend one wall upwards.
• Slide Corner Posts from the second Bed down on both ends of the Board to lock in place.
• Continue assembling the second Bed, sliding Boards and Posts into place on top
of the first to complete another Rectangle.
• Attach Decorative Caps to the tops of each Corner Post.

Questions?Email [e-mail] or call 800-622-5510 Monday - Friday 8am-5pm EST
ORIGINAL PINE RAISED GARDEN BED | ASSEMBLY INSTRUCTIONS
MODEL #
RCP
DIMENSIONS
4ft. wide x 8ft. long
x 7in. high
PACKAGE CONTENTS + (6) Screws
x6 x6
8in. x 2.5in. x 2.5in.
Short Posts
4ft. x 3.5in.
Boards
3.5in. x 3.5in.
Decorative Caps
x14
. CONNECT THREE SHORT POSTS TOGETHER WITH TWO BOARDS
Holding a Board in one hand with the notched ends facing up, line
up the groove on a Short Post and slide it down over one end of the
Board. Slide another Short Post down over the other end. With the
same Short Post, slide the second Board through the groove finishing
with another Short Post at the end to complete one 8ft. wall.
Repeat step one to complete a second wall.
. CONNECT THE TWO WALLS TOGETHER WITH THREE BOARDS
Take a Board and slide it down over the top of a Short Post. Connect
the same Board to an adjacent Short Post on the second wall. Do
the same with two more Boards completing a 4ft. x 8ft. rectangle.
. ADD A SECOND BOARD TO ALL WALLS & ATTACH
DECORATIVE CAPS
Add Boards, one at a time, directly on top of each existing Board in
the Frame. Push the Boards down evenly between the tops of the
Short Posts. If needed, tap snugly into place with a rubber mallet.
Attach each Decorative Cap to a Short Post with a screwdriver and
one Screw. We recommend drilling a pilot hole first for each Screw.
NEED HELP?
Contact customer service
instead of returing item to store.
800-622-5510 M–F 8–5
[e-mail]
INSTALL ATION SUPPORT
youtube.com/greenesfence
TO STACK GARDEN BEDS FOR MORE HEIGHT:
• Assemble the first Garden Bed without Decorative Caps, or remove Caps
from a completed Bed.
• The Corner Posts are designed to be taller than the Boards, so Beds can
be stacked securely.
• Slide a Board from the second Garden Bed into tops of the Corner Posts from
the first Bed, to extend one wall upwards.
• Slide Corner Posts from the second Bed down on both ends of the Board to lock in place.
• Continue assembling the second Bed, sliding Boards and Posts into place on top
of the first to complete another rectangle.
• Attach Decorative Caps to the tops of each Corner Post.
