Greenheck AMPLIFY DS User manual

®
Overhead Ceiling Fans
®
Installation, Operation and Maintenance Manual
Please read and save these instructions for future reference. Read carefully before attempting to assemble, install,
operate or maintain the product described. Protect yourself and others by observing all safety information. Failure
to comply with these instructions will result in voiding of the product warranty and may result in personal injury
and/or property damage.
1
Document 483568
AMPLIFY™ Model DS
Overhead Ceiling Fans
AMPLIFY™ Models DS-3 and DS-6 are the ideal choice for providing year-round comfort in air circulation and
destratification applications. Featuring an aerodynamic, extruded aluminum airfoil design and a high efficiency direct
drive motor, model DS delivers maximum airflow at a fraction of the operating cost of other HVLS fans. And, with its
universal ceiling mount, the DS fan is the easiest HVLS fan to install in the market!
IMPORTANT: DS fans must be installed with the supplied CAT-5e communication cable or shielded CAT-5e
(by others) that complies with the following specifications. Cable must be twisted pair, shielded 26 ga. CAT-5e
cable with a drain wire and must be compliant with ISO 11801. Cable must use shielded RJ45 connectors with
a soldered drain and wiring configuration must follow EIA/TIA T568B wiring pinout. Individual CAT-5e cable
lengths must not exceed 200 ft. in order to prevent network communication issues.
Required Tools
The following tools will be required to complete the
installation of every DS fan. Additional tools may be
required depending on the application and installation
location of the fan.
• Socket Wrench with 7/16 in., 1/2 in., 9/16 in.,
3/4 in. and 17mm Sockets
• 7/16 in., 1/2 in., 9/16 in. and 3/4 in. Wrenches
• Adjustable Wrench
• Torque Wrench (up to 50 ft∙lbf)
• Torque Wrench (up to 120 in∙lbf)
• Drill and 9/16 in. Drill Bit
• Phillips Screwdriver
• Level
• Impact Driver
• #2 Phillips Bit and Driver
• 3/8 in. Magnetic Nut Driver
• Magnetic Nut Driver Extension
NOTE: AMPLIFY™ Model DS fan components can
weigh 90 lbs. or greater depending upon the fan size
and accessories that are provided. A suitable means
for lifting the weight of the fan to the mounting point,
such as a scissor lift, should be used for all DS fan
installations.
Quick Start
Guide
General
Information Pre-Installation Mechanical
Installation
Fire System
Integration
Electrical
Installation
Fan
Networking
Operation And
Maintenance Troubleshooting Reference

Overhead Ceiling Fans2
®
Reference Troubleshooting Operation And
Maintenance
Fan
Networking
Electrical
Installation
Fire System
Integration
Mechanical
Installation Pre-Installation General
Information
Quick Start
Guide
Quick Start Guide
Step 1 - Step 12 . . . . . . . . . . . . . . . . . . 3-10
General Information
Required Tools . . . . . . . . . . . . . . . . . . . . . 1
General Safety Information . . . . . . . . . . . . 11-12
Receiving. . . . . . . . . . . . . . . . . . . . . . . .12
Unpacking . . . . . . . . . . . . . . . . . . . . . . .12
Storage. . . . . . . . . . . . . . . . . . . . . . . . .12
Inspection and Maintenance During Storage . . . . .12
Removing from Storage . . . . . . . . . . . . . . . .12
Fan Components. . . . . . . . . . . . . . . . . .13-14
Pre-Installation
Pre-Installation Checks . . . . . . . . . . . . . . . .15
Minimum Spacing Requirements . . . . . . . . . . .16
Mechanical Installation
Mounting Installation. . . . . . . . . . . . . . . .17-21
I-Beam Mounting . . . . . . . . . . . . . . . . . .17
Steel Truss Mounting . . . . . . . . . . . . . . . .18
Wood Beam Mounting . . . . . . . . . . . . . . . .19
Z-Purlin Mounting . . . . . . . . . . . . . . . . . .20
Unistrut Mounting. . . . . . . . . . . . . . . . . . .21
Motor/Hub to Downtube Installation. . . . . . . .22-23
Safety Retention Cable Installation . . . . . . . . 23-24
Standard Steel Cable Clamp . . . . . . . . . . . .23
Gripple® Hardware (Optional) . . . . . . . . . . . .24
Guy Wire Installation . . . . . . . . . . . . . . . .25-26
Standard Steel Cable Clamp . . . . . . . . . . . .25
Gripple® Hardware (Optional) . . . . . . . . . . . .26
Airfoil Blade and Winglet Installation . . . . . . . 26-27
Hub Plate Installation . . . . . . . . . . . . . . . . .27
LED Light Installation (Optional) . . . . . . . . . . . .28
Fire System Integration
Fire System Integration (Optional) . . . . . . . . . . .29
Electrical Installation
Motor Cable Connection. . . . . . . . . . . . . .30-32
Power Wiring . . . . . . . . . . . . . . . . . . . . . .33
With Optional Electrical Plug . . . . . . . . . . . .33
Without Optional Electrical Plug . . . . . . . . . . .33
Disconnect and Fuse Installation . . . . . . . . . . .33
LED Light Wiring (Optional) . . . . . . . . . . . . . .34
Communication Wiring. . . . . . . . . . . . . . .34-35
With Pre-Built CAT-5e Cable. . . . . . . . . . . . .34
With Optional 1,000 ft. Bulk Spool of CAT-5e Cable
. . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Fan Networking
First Fan . . . . . . . . . . . . . . . . . . . . . . 36-37
All Remaining Fans. . . . . . . . . . . . . . . . .38-39
Operation And Maintenance
Pre-Start-Up Checks. . . . . . . . . . . . . . . . . .40
Fan Operation . . . . . . . . . . . . . . . . . . . . .40
Fan Inspection . . . . . . . . . . . . . . . . . . . . .40
Fan Maintenance. . . . . . . . . . . . . . . . . . . .40
Troubleshooting
General Troubleshooting . . . . . . . . . . . . . . . .41
Controls Troubleshooting . . . . . . . . . . . . . 42-43
Fan Troubleshooting . . . . . . . . . . . . . . . . 44-47
LED Light Troubleshooting. . . . . . . . . . . . .48-49
Reference
Fault Code Causes and Possible Solutions . . . . . .50
Modbus Register List . . . . . . . . . . . . . . . . .51
Installation Checklist . . . . . . . . . . . . . . . .52-54
Maintenance Log. . . . . . . . . . . . . . . . . . . .55
Table of Contents

Overhead Ceiling Fans 3
®
Quick Start
Guide
General
Information Pre-Installation Mechanical
Installation
Fire System
Integration
Electrical
Installation
Fan
Networking
Operation And
Maintenance Troubleshooting Reference
Quick Start Guide
REFER TO INSTALLATION MANUAL FOR COMPLETE INSTALLATION INSTRUCTIONS.
QUICK START GUIDE DOES NOT REPLACE INSTALLATION MANUAL INSTRUCTIONS.
STEEL BEAM
DOWNTUBE AND MOUNT ASSEMBLY
1/2 in. - 13 GRADE 8 NYLON LOCKNUT
1/2 in. WASHER
I-BEAM CLAMPING PLATE SHIM
I-BEAM CLAMPING PLATE
1/2 in. - 13 x 2.5 GRADE 8 BOLT
UNIVERSAL MOUNTING PLATE
STEEL I-BEAM INSTALLATION
MANUAL PAGE 17
FASTENER KIT 915428
IMPORTANT: I-BEAM MUST HAVE MINIMUM 5 IN.
FLANGE WIDTH AND 1/2 IN. FLANGE THICKNESS
IMPORTANT: DO NOT INSTALL ON FABRICATED
I-BEAMS
STEP #1 - MOUNT INSTALLATION
DOWNTUBE AND MOUNT ASSEMBLY
1/2 in. - 13 x 1.75 GRADE 8 BOLT
1/2 in. WASHER
1/2 in. - 13 GRADE 8 NYLON LOCKNUT
1/2 in. - 13 GRADE 8 BOLT
(BY OTHERS)
1/2 in. - 13 GRADE 8
NYLON LOCKNUT
1/2 in. WASHER
SQUARE WASHER PLATE
STEEL TRUSS - BAR JOIST
STEEL TRUSS - BAR JOIST
STRUCTURAL STEEL ANGLES
(BY OTHERS)
STEEL TRUSS INSTALLATION
MANUAL PAGE 18
FASTENER KIT 915429
IMPORTANT: TRUSSES MUST HAVE
MINIMUM 5 IN. CHORD WIDTH
IMPORTANT: STEEL ANGLES MUST BE
MINIMUM OF 4 x 4 x 1/4 IN. THICK
IMPORTANT: SPAN LENGTH MUST NOT
EXCEED 8 FT.
1/2 in. - 13 GRADE 8 NYLON LOCKNUT
1/2 in. WASHER
DOWNTUBE AND MOUNT ASSEMBLY
1/2 in. - 13 x 1.5 GRADE 8 BOLT
WOOD BEAM
(BY OTHERS)
UNIVERSAL MOUNTING PLATE
WOOD BEAM BRACKET
1/2 in. - 13 GRADE 8 BOLT
(BY OTHERS)
1/2 in. WASHER
WOOD BEAM INSTALLATION
MANUAL PAGE 19
FASTENER KIT 915429
IMPORTANT: WOOD BEAM MUST BE 4-1/2 TO
8-7/8 IN. WIDE
IMPORTANT: TORQUE ALL BOLTS TO 80 FT-LBF (108.5 N-m)
IMPORTANT: TORQUE ALL BOLTS TO 80 FT-LBF (108.5 N-m)
IMPORTANT: TORQUE ALL BOLTS TO 45 FT-LBF (61.0 N-m)

Overhead Ceiling Fans4
®
UNISTRUT COMPONENTS
(BY OTHERS)
UNISTRUT INSTALLATION
MANUAL PAGE 21
FASTENERS PROVIDED BY OTHERS
IMPORTANT: UNISTRUT MUST BE MINIMUM OF
1-5/8 x 1-5/8 IN. STEEL WITH 12 GAUGE THICKNESS
IMPORTANT: SPAN LENGTH MUST NOT
EXCEED 8 FT.
IMPORTANT: DO NOT HANG OR SUSPEND
UNISTRUT FROM STRUCTURE. UNISTRUT MUST
REST ON TOP OF STRUCTURE AND BE DIRECTLY
FASTENED TO STRUCTURE WITH THREADED
CONNECTION. USE LOCKTITE ON FASTENERS.
Z-PURLIN
(BY OTHERS)
1/2 in. - 13 x 1.75 GRADE 8 BOLT
Z-PURLIN BACKING PLATE
Z-PURLIN BRACKET
1/2 in. - 13 x 1.75 GRADE 8 BOLT
1/2 in. WASHER
1/2 in. - 13 x 1.75 GRADE 8 BOLT
1/2 in. - 13 GRADE 8 NYLON LOCKNUT
1/2 in. WASHER
1/2 in. - 13 GRADE 8
NYLON LOCKNUT
1/2 in. WASHER
1/2 in. - 13 GRADE 8 NYLON LOCKNUT
DOWNTUBE & MOUNT ASSEMBLY
Z-PURLIN
(BY OTHERS)
STRUCTURAL STEEL ANGLES
(BY OTHERS)
Z-PURLIN INSTALLATION
MANUAL PAGE 20
FASTENER KIT 915431
IMPORTANT: Z-PURLINS MUST HAVE
MINIMUM 2 IN. FLANGE WITH 12
GAUGE THICKNESS
IMPORTANT: STEEL ANGLES MUST
BE MINIMUM OF 4 x 4 x 1/4 IN. THICK
IMPORTANT: SPAN LENGTH MUST
NOT EXCEED 8 FT.
IMPORTANT: TORQUE ALL BOLTS TO 80 FT-LBF (108.5 N-m)
IMPORTANT: TORQUE ALL BOLTS TO 80 FT-LBF (108.5 N-m)
Reference Troubleshooting Operation And
Maintenance
Fan
Networking
Electrical
Installation
Fire System
Integration
Mechanical
Installation Pre-Installation General
Information
Quick Start
Guide

Overhead Ceiling Fans 5
®
Quick Start
Guide
General
Information Pre-Installation Mechanical
Installation
Fire System
Integration
Electrical
Installation
Fan
Networking
Operation And
Maintenance Troubleshooting Reference
STEP #2 - MOTOR INSTALLATION
STEP #3 - SAFETY CABLE AND GUY WIRE INSTALLATION
3/8 in. - 16 x 2.75 GRADE 8 BOLT
1
2
1
POWER
GROUND
POWER
2
GROUND
M4 - 0.7 x 10 MACHINE SCREW
FRONT VFD COVER
DOWNTUBE AND MOUNT ASSEMBLY
3
HALL CONNECTION
NOTE:
HALL CABLE PLUG HAS
BUILT-IN ALIGNMENT TAB
DO NOT FORCE THIS PLUG
3HALL
CONNECTION
MOTOR INSTALLATION
MANUAL PAGES 22-23
FASTENER KIT 915065
IMPORTANT: ELECTRICAL CABLES
FROM MOTOR MUST BE ON SAME
SIDE AS BLACK PLASTIC VFD COVER.
CABLES ARE NOT LONG ENOUGH
TO REACH CIRCUIT BOARD FROM
OPPOSITE SIDE. MOTOR MUST BE
REMOVED AND ROTATED 180° IF
INSTALLED INCORRECTLY.
TURNBUCKLE
CABLE CLAMP
GUY WIRE
QUICK LINK
EYEBOLT
BEAM CLAMP
ASSEMBLY
SAFETY CABLE
CABLE CLAMP
DOWNTUBE AND
MOUNT ASSEMBLY
DEAD END
LIVE END
CABLE CLAMP
U- BOLT
CABLE CLAMP
SADDLE
45° TO 60°
5-1/2 IN.
MIN.
SAFETY CABLE AND GUY WIRE
INSTALLATION
MANUAL PAGES 23 AND 25
FASTENER KIT 916290
OPTIONAL GRIPPLE
HARDWARE – MANUAL
PAGES 24 AND 26
IMPORTANT: PLACE A LEVEL AGAINST
DOWNTUBE AND TIGHTEN ALL (4)
TURNBUCKLES BY HAND UNTIL GUY WIRES
ARE TIGHT AND FAN IS PLUMB. MOVE LEVEL
AROUND DOWNTUBE TO ENSURE THAT FAN
IS PLUMB.
IMPORTANT: TORQUE BOLTS TO 33 FT-LBF (44.75 N-m)

Overhead Ceiling Fans6
®
STEP #6 - FIRE ALARM RELAY INSTALLATION
TO NEXT FAN
(IF APPLICABLE)
TO CONTROL
SHIELDED CAT-5e CONNECTION
FAN 1
CONTROL
FAN 2
TORQUE TO 96 IN∙LBF
(10.8 N∙m)
HUB PLATE INSTALLATION
MANUAL PAGE 27
OPTIONAL LED LIGHT - MANUAL PAGE 28
HARDWARE KIT 854832 (3 AIRFOILS) OR
915066 (6 AIRFOILS)
IMPORTANT: ROTATE FAN BY HAND TO ENSURE
THAT IT MOVES FREELY AND DOES NOT RUB OR
CONTACT ANY OBSTRUCTIONS.
STEP #5 - HUB PLATE INSTALLATION
STEP #4 - AIRFOIL INSTALLATION
TORQUE SCREWS TO 96 IN-LBF
TORQUE TO 25 FT∙LBF
(34 N∙m)
TORQUE TO 60 IN∙LBF
(6.8 N∙m)
SUPPLIED FIRE RELAY
RED (+)
WHITE (-)
YELLOW (NC)
BLUE (COMMON)
BLACK
RED
FIRE ALARM
CONTROL PANEL
RED
WHITE
FIRE ALARM RELAY INSTALLATION
MANUAL PAGE 29
IMPORTANT: MUST USE PROVIDED PAM-1 RELAY OR OTHER
APPROVED ELECTROMECHANICAL RELAY
Reference Troubleshooting Operation And
Maintenance
Fan
Networking
Electrical
Installation
Fire System
Integration
Mechanical
Installation Pre-Installation General
Information
Quick Start
Guide
AIRFOIL INSTALLATION
MANUAL PAGES 26-27
FASTENER KIT 854832 (3 AIRFOILS) OR 915066 (6 AIRFOILS)

Overhead Ceiling Fans 7
®
Quick Start
Guide
General
Information Pre-Installation Mechanical
Installation
Fire System
Integration
Electrical
Installation
Fan
Networking
Operation And
Maintenance Troubleshooting Reference
HALL CABLE COLOR
PINOUT REFERENCE
HALL CONNECTION
NOTE: HALL CABLE PLUG
HAS BUILT-IN ALIGNMENT TAB
DO NOT FORCE THIS PLUG
MOTOR GROUND
MOTOR POWER
MOTOR CABLE CONNECTION TO VFD
MANUAL PAGES 30-32
IMPORTANT: PLUGS MUST BE FULLY SEATED AND
IN PROPER ORIENTATION FOR FAN OPERATION
STEP #7 - MOTOR CABLE CONNECTION TO VFD
RED
BLACK
WHITE
GREEN
POWER SOURCE
L3
L2
L1
GROUND
BLACK
WHITE
GREEN
POWER SOURCE
L2
L1
GROUND
1-PHASE INPUT POWER
OR
3-PHASE INPUT POWER
POWER WIRING
MANUAL PAGE 33
OPTIONAL LED LIGHT - MANUAL PAGE 34
IMPORTANT: SOURCE POWER MUST COMPLY
WITH REQUIRED SPECS
STEP #8 - POWER WIRING
TO NEXT FAN
(IF APPLICABLE)
TO CONTROL
SHIELDED CAT-5e CONNECTION
FAN 1
CONTROL
FAN 2
COMMUNICATION WIRING
MANUAL PAGES 34-35
IMPORTANT: MUST USE PROVIDED CAT-5e CABLE
OR SHIELDED CABLE THAT COMPLIES WITH
REQUIRED SPECS ON PAGE 34
STEP #9 - COMMUNICATION WIRING

Overhead Ceiling Fans8
®
GND
FIRE +
FIRE -
DATA +
DATA -
0-10V
GND (OPTIONAL)
ALL OTHER FANS IN SERIES
GND
FIRE +
FIRE -
DATA +
DATA -
0-10V
GND (OPTIONAL)
LOW VOLTAGE WIRING
24v
FIRST FAN IN SERIES
LOW VOLTAGE WIRING
DIP SWITCH BANK 2
1 2 345 6 78
ON
1 2 3
ON
DIP SWITCH BANK 3
DIP SWITCH BANK 2
1 2 345 6 78
ON
1 2 3
ON
DIP SWITCH BANK 3
EF
FIRST FAN IN DAISY-CHAIN
MANUAL PAGES 36-37
NO VFD WIRING MODIFICATIONS REQUIRED
VERIFY VFD WIRING MATCHES
MODIFY DIP SWITCH BANKS 2 AND 3
AS SHOWN
STEP #10 - FAN NETWORKING
ALL REMAINING FANS IN DAISY-CHAIN
MANUAL PAGES 38-39
REMOVE WHITE/BROWN 24V WIRE AND CAP
VERIFY VFD WIRING MATCHES
MODIFY DIP SWITCH BANKS 2 AND 3
AS SHOWN
IMPORTANT: DO NOT REMOVE BROWN GND WIRE
GND
FIRE +
FIRE -
DATA +
DATA -
0-10V
GND (OPTIONAL)
ALL OTHER FANS IN SERIES
GND
FIRE +
FIRE -
DATA +
DATA -
0-10V
GND (OPTIONAL)
LOW VOLTAGE WIRING
24v
FIRST FAN IN SERIES
LOW VOLTAGE WIRING
DIP SWITCH BANK 2
1 2 345 6 78
ON
1 2 3
ON
DIP SWITCH BANK 3
DIP SWITCH BANK 2
1 2 345 6 78
ON
1 2 3
ON
DIP SWITCH BANK 3
EF
DIPSWITCH BANK 2 SETTINGS DIPSWITCH BANK 3 SETTINGS
POST INSTALLATION CHECKLIST
□ALL BOLTS TIGHTENED PROPERLY
□ONLY USED SHIELDED NETWORKING COMPONENTS PROVIDED
□MODBUS ADDRESSES SET
□SAFETY CABLE INSTALLED PROPERLY
□VERIFY POWER AND NETWORKING CABLES CONNECTED
STEP #1 STEEL BEAM INSTALLATION
STEP #3 SAFETY CABLE
INSTALLATION
HARDWARE KIT 854832 OR 915066
TORQUE SCREWS TO 60 IN-LBF
(MANUAL PAGE 15-16)
HARDWARE KIT 915065
TORQUE BOLTS TO 33 FT-LBF
(MANUAL PAGES 10-11)
HARDWARE KIT 915428
TORQUE BOLTS TO 45 FT-LBF
(MANUAL PAGE 7)
HARDWARE KIT 916290
TORQUE U-BOLTS TO 54 IN-LBF
(MANUAL PAGE 12-13)
HARDWARE KIT 916290
TORQUE U-BOLTS TO 54 IN-LBF
(MANUAL PAGE 14-15)
QUICK START GUIDE FOR INDUSTRIAL FAN INSTALLATION
STEP #5 WINGLET
INSTALLATION
TOOL LIST:
- IMPACT DRIVER
- 7/16 IN., 1/2 IN., 9/16 IN. AND 3/4 IN. SOCKETS
- 1/2 IN. AND 3/4 IN. WRENCHES
- #2 PHILLIPS SCREWDRIVER
- #2 PHILLIPS IMPACT BIT
- MAGNETIC TORPEDO LEVEL
- TORQUE WRENCH (UP TO 50 FT-LBF)
- TORQUE WRENCH (UP TO 120 IN-LBF)
- REFER TO INSTALLATION MANUAL FOR COMPLETE INSTALLATION INFORMATION
- THIS QUICK START GUIDE DOES NOT REPLACE INSTALLATION MANUAL INSTRUCTIONS
HARDWARE KIT 854832 OR 915066
TORQUE TO 25 FT-LBF
(MANUAL PAGE 15-16)
STEP #6 AIRFOIL
INSTALLATION
STEP #2 MOTOR TO DOWNTUBE
STEP #7 HUB PLATE INSTALLATION
HARDWARE KIT 854832 OR 915066
TORQUE SCREWS TO 96 IN-LBF
(MANUAL PAGE 17)
STEP #4 GUY WIRE
INSTALLATION
ALTERNATE MOUNTING - MANUAL PAGES 7-9
FIRE
RELAY
FIRE SUPPRESSION SYSTEM
LANDING POINT AT FAN
FIRE ALARM LANDING POINT
FIRE RELAY INSTALLATION AND WIRING
TO FAN WIRING
BLUE - COMMON
YELLOW - NORMALLY CLOSED
ORANGE - NORMALLY OPEN
(FAN DISABLED WHEN RELAY OPEN)
20 TO 32 VDC
RED (+)
WHITE (-)
OPTIONAL LED LIGHT INSTALLATION - MANUAL PAGE 15
5-1/2 IN.
MIN.
FIRST FAN IN SERIES
ALL OTHER FANS IN SERIES
- REMOVE BROWN/WHITE 24V WIRE AND CAP
- DO NOT REMOVE BROWN GROUND WIRE
- REMOVE SILVER SHIELD AND SECURE IN A WAY
THAT PREVENTS CONTACT WITH VFD BOARD
NOTE
DO NOT CUT CABLE OR REMOVE CRIMP CAP IF NOT USING FIRE RELAY.
1 2 3
ON
1 2 3
ON
FAN 1 ALL OTHER FANS
IN SERIES
DIP SWITCH BANK 2 SETTINGS
HELPFUL HINT
ALL NETWORKING MODIFICATIONS CAN BE COMPLETED PRIOR TO BLADE INSTALLATION.
FAN NETWORKING
FOR ALL WIRING AND NETWORKING - SEE MANUAL PAGES 11-12 AND 18-20
1 2 345678
ON
1 2 3
ON
MOTOR-TO-VFD WIRING AND DIP SWITCH BANK LOCATIONS
3
3
DIP SWITCH BANK 3
DIP SWITCH BANK 2
NOTE
HALL CABLE PLUG HAS BUILT-IN
ALIGNMENT TAB. DO NOT FORCE
THIS PLUG.
2
1
1
2
DIP SWITCH BANK 3 SETTINGS (MODBUS ADDRESSES)
MODBUS
ADDRESS
2
3
4
5
6
7
8
9
10
11
SWITCH
1
SWITCH
2
SWITCH
3
SWITCH
4
SWITCH
5
ON OFF OFF OFF OFF
ON
ON ON
ON
ON ON
ON ON
ON ON ON
ON
ON ON
ON ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
DO
NOT
MODIFY
SWITCH
6, 7, 8
Fan
Number
Modbus
Address
Position
1
Position
2
Position
3
Position
4
Position
5
Position
6, 7, 8
N/A 1 Reserved for HVLS Fan Control
Do Not
Modify
1 2 On Off Off Off Off
2 3 Off On Off Off Off
3 4 On On Off Off Off
4 5 Off Off On Off Off
5 6 On Off On Off Off
6 7 Off On On Off Off
7 8 On On On Off Off
8 9 Off Off Off On Off
9 10 On Off Off On Off
10 11 Off On Off On Off
IMPORTANT: DO NOT MODIFY POSITIONS 6, 7, AND 8 ON
DIPSWITCH BANK 3. DEFAULT SETTINGS ARE ON, OFF, OFF
(UP, DOWN, DOWN)
Position
1
Position
2
Position
3
OFF ON ON
POST INSTALLATION CHECKLIST
□ALL BOLTS TIGHTENED PROPERLY
□ONLY USED SHIELDED NETWORKING COMPONENTS PROVIDED
□MODBUS ADDRESSES SET
□SAFETY CABLE INSTALLED PROPERLY
□VERIFY POWER AND NETWORKING CABLES CONNECTED
STEP #1 STEEL BEAM INSTALLATION
STEP #3 SAFETY CABLE
INSTALLATION
HARDWARE KIT 854832 OR 915066
TORQUE SCREWS TO 60 IN-LBF
(MANUAL PAGE 15-16)
HARDWARE KIT 915065
TORQUE BOLTS TO 33 FT-LBF
(MANUAL PAGES 10-11)
HARDWARE KIT 915428
TORQUE BOLTS TO 45 FT-LBF
(MANUAL PAGE 7)
HARDWARE KIT 916290
TORQUE U-BOLTS TO 54 IN-LBF
(MANUAL PAGE 12-13)
HARDWARE KIT 916290
TORQUE U-BOLTS TO 54 IN-LBF
(MANUAL PAGE 14-15)
QUICK START GUIDE FOR INDUSTRIAL FAN INSTALLATION
STEP #5 WINGLET
INSTALLATION
TOOL LIST:
- IMPACT DRIVER
- 7/16 IN., 1/2 IN., 9/16 IN. AND 3/4 IN. SOCKETS
- 1/2 IN. AND 3/4 IN. WRENCHES
- #2 PHILLIPS SCREWDRIVER
- #2 PHILLIPS IMPACT BIT
- MAGNETIC TORPEDO LEVEL
- TORQUE WRENCH (UP TO 50 FT-LBF)
- TORQUE WRENCH (UP TO 120 IN-LBF)
- REFER TO INSTALLATION MANUAL FOR COMPLETE INSTALLATION INFORMATION
- THIS QUICK START GUIDE DOES NOT REPLACE INSTALLATION MANUAL INSTRUCTIONS
HARDWARE KIT 854832 OR 915066
TORQUE TO 25 FT-LBF
(MANUAL PAGE 15-16)
STEP #6 AIRFOIL
INSTALLATION
STEP #2 MOTOR TO DOWNTUBE
STEP #7 HUB PLATE INSTALLATION
HARDWARE KIT 854832 OR 915066
TORQUE SCREWS TO 96 IN-LBF
(MANUAL PAGE 17)
STEP #4 GUY WIRE
INSTALLATION
ALTERNATE MOUNTING - MANUAL PAGES 7-9
FIRE
RELAY
FIRE SUPPRESSION SYSTEM
LANDING POINT AT FAN
FIRE ALARM LANDING POINT
FIRE RELAY INSTALLATION AND WIRING
TO FAN WIRING
BLUE - COMMON
YELLOW - NORMALLY CLOSED
ORANGE - NORMALLY OPEN
(FAN DISABLED WHEN RELAY OPEN)
20 TO 32 VDC
RED (+)
WHITE (-)
OPTIONAL LED LIGHT INSTALLATION - MANUAL PAGE 15
5-1/2 IN.
MIN.
FIRST FAN IN SERIES
ALL OTHER FANS IN SERIES
- REMOVE BROWN/WHITE 24V WIRE AND CAP
- DO NOT REMOVE BROWN GROUND WIRE
- REMOVE SILVER SHIELD AND SECURE IN A WAY
THAT PREVENTS CONTACT WITH VFD BOARD
NOTE
DO NOT CUT CABLE OR REMOVE CRIMP CAP IF NOT USING FIRE RELAY.
1 2 3
ON
1 2 3
ON
FAN 1 ALL OTHER FANS
IN SERIES
DIP SWITCH BANK 2 SETTINGS
HELPFUL HINT
ALL NETWORKING MODIFICATIONS CAN BE COMPLETED PRIOR TO BLADE INSTALLATION.
FAN NETWORKING
FOR ALL WIRING AND NETWORKING - SEE MANUAL PAGES 11-12 AND 18-20
1 2 345678
ON
1 2 3
ON
MOTOR-TO-VFD WIRING AND DIP SWITCH BANK LOCATIONS
3
3
DIP SWITCH BANK 3
DIP SWITCH BANK 2
NOTE
HALL CABLE PLUG HAS BUILT-IN
ALIGNMENT TAB. DO NOT FORCE
THIS PLUG.
2
1
1
2
DIP SWITCH BANK 3 SETTINGS (MODBUS ADDRESSES)
MODBUS
ADDRESS
2
3
4
5
6
7
8
9
10
11
SWITCH
1
SWITCH
2
SWITCH
3
SWITCH
4
SWITCH
5
ON OFF OFF OFF OFF
ON
ON ON
ON
ON ON
ON ON
ON ON ON
ON
ON ON
ON ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
DO
NOT
MODIFY
SWITCH
6, 7, 8
Position
1
Position
2
Position
3
OFF OFF OFF
POST INSTALLATION CHECKLIST
□ALL BOLTS TIGHTENED PROPERLY
□ONLY USED SHIELDED NETWORKING COMPONENTS PROVIDED
□MODBUS ADDRESSES SET
□SAFETY CABLE INSTALLED PROPERLY
□VERIFY POWER AND NETWORKING CABLES CONNECTED
STEP #1 STEEL BEAM INSTALLATION
STEP #3 SAFETY CABLE
INSTALLATION
HARDWARE KIT 854832 OR 915066
TORQUE SCREWS TO 60 IN-LBF
(MANUAL PAGE 15-16)
HARDWARE KIT 915065
TORQUE BOLTS TO 33 FT-LBF
(MANUAL PAGES 10-11)
HARDWARE KIT 915428
TORQUE BOLTS TO 45 FT-LBF
(MANUAL PAGE 7)
HARDWARE KIT 916290
TORQUE U-BOLTS TO 54 IN-LBF
(MANUAL PAGE 12-13)
HARDWARE KIT 916290
TORQUE U-BOLTS TO 54 IN-LBF
(MANUAL PAGE 14-15)
QUICK START GUIDE FOR INDUSTRIAL FAN INSTALLATION
STEP #5 WINGLET
INSTALLATION
TOOL LIST:
- IMPACT DRIVER
- 7/16 IN., 1/2 IN., 9/16 IN. AND 3/4 IN. SOCKETS
- 1/2 IN. AND 3/4 IN. WRENCHES
- #2 PHILLIPS SCREWDRIVER
- #2 PHILLIPS IMPACT BIT
- MAGNETIC TORPEDO LEVEL
- TORQUE WRENCH (UP TO 50 FT-LBF)
- TORQUE WRENCH (UP TO 120 IN-LBF)
- REFER TO INSTALLATION MANUAL FOR COMPLETE INSTALLATION INFORMATION
- THIS QUICK START GUIDE DOES NOT REPLACE INSTALLATION MANUAL INSTRUCTIONS
HARDWARE KIT 854832 OR 915066
TORQUE TO 25 FT-LBF
(MANUAL PAGE 15-16)
STEP #6 AIRFOIL
INSTALLATION
STEP #2 MOTOR TO DOWNTUBE
STEP #7 HUB PLATE INSTALLATION
HARDWARE KIT 854832 OR 915066
TORQUE SCREWS TO 96 IN-LBF
(MANUAL PAGE 17)
STEP #4 GUY WIRE
INSTALLATION
ALTERNATE MOUNTING - MANUAL PAGES 7-9
FIRE
RELAY
FIRE SUPPRESSION SYSTEM
LANDING POINT AT FAN
FIRE ALARM LANDING POINT
FIRE RELAY INSTALLATION AND WIRING
TO FAN WIRING
BLUE - COMMON
YELLOW - NORMALLY CLOSED
ORANGE - NORMALLY OPEN
(FAN DISABLED WHEN RELAY OPEN)
20 TO 32 VDC
RED (+)
WHITE (-)
OPTIONAL LED LIGHT INSTALLATION - MANUAL PAGE 15
5-1/2 IN.
MIN.
FIRST FAN IN SERIES
ALL OTHER FANS IN SERIES
- REMOVE BROWN/WHITE 24V WIRE AND CAP
- DO NOT REMOVE BROWN GROUND WIRE
- REMOVE SILVER SHIELD AND SECURE IN A WAY
THAT PREVENTS CONTACT WITH VFD BOARD
NOTE
DO NOT CUT CABLE OR REMOVE CRIMP CAP IF NOT USING FIRE RELAY.
1 2 3
ON
1 2 3
ON
FAN 1
ALL OTHER FANS
IN SERIES
DIP SWITCH BANK 2 SETTINGS
HELPFUL HINT
ALL NETWORKING MODIFICATIONS CAN BE COMPLETED PRIOR TO BLADE INSTALLATION.
FAN NETWORKING
FOR ALL WIRING AND NETWORKING - SEE MANUAL PAGES 11-12 AND 18-20
1 2 345678
ON
1 2 3
ON
MOTOR-TO-VFD WIRING AND DIP SWITCH BANK LOCATIONS
3
3
DIP SWITCH BANK 3
DIP SWITCH BANK 2
NOTE
HALL CABLE PLUG HAS BUILT-IN
ALIGNMENT TAB. DO NOT FORCE
THIS PLUG.
2
1
1
2
DIP SWITCH BANK 3 SETTINGS (MODBUS ADDRESSES)
MODBUS
ADDRESS
2
3
4
5
6
7
8
9
10
11
SWITCH
1
SWITCH
2
SWITCH
3
SWITCH
4
SWITCH
5
ON OFF OFF OFF OFF
ON
ON ON
ON
ON ON
ON ON
ON ON ON
ON
ON ON
ON ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
DO
NOT
MODIFY
SWITCH
6, 7, 8
POST INSTALLATION CHECKLIST
□ALL BOLTS TIGHTENED PROPERLY
□ONLY USED SHIELDED NETWORKING COMPONENTS PROVIDED
□MODBUS ADDRESSES SET
□SAFETY CABLE INSTALLED PROPERLY
□VERIFY POWER AND NETWORKING CABLES CONNECTED
STEP #1 STEEL BEAM INSTALLATION
STEP #3 SAFETY CABLE
INSTALLATION
HARDWARE KIT 854832 OR 915066
TORQUE SCREWS TO 60 IN-LBF
(MANUAL PAGE 15-16)
HARDWARE KIT 915065
TORQUE BOLTS TO 33 FT-LBF
(MANUAL PAGES 10-11)
HARDWARE KIT 915428
TORQUE BOLTS TO 45 FT-LBF
(MANUAL PAGE 7)
HARDWARE KIT 916290
TORQUE U-BOLTS TO 54 IN-LBF
(MANUAL PAGE 12-13)
HARDWARE KIT 916290
TORQUE U-BOLTS TO 54 IN-LBF
(MANUAL PAGE 14-15)
QUICK START GUIDE FOR INDUSTRIAL FAN INSTALLATION
STEP #5 WINGLET
INSTALLATION
TOOL LIST:
- IMPACT DRIVER
- 7/16 IN., 1/2 IN., 9/16 IN. AND 3/4 IN. SOCKETS
- 1/2 IN. AND 3/4 IN. WRENCHES
- #2 PHILLIPS SCREWDRIVER
- #2 PHILLIPS IMPACT BIT
- MAGNETIC TORPEDO LEVEL
- TORQUE WRENCH (UP TO 50 FT-LBF)
- TORQUE WRENCH (UP TO 120 IN-LBF)
- REFER TO INSTALLATION MANUAL FOR COMPLETE INSTALLATION INFORMATION
- THIS QUICK START GUIDE DOES NOT REPLACE INSTALLATION MANUAL INSTRUCTIONS
HARDWARE KIT 854832 OR 915066
TORQUE TO 25 FT-LBF
(MANUAL PAGE 15-16)
STEP #6 AIRFOIL
INSTALLATION
STEP #2 MOTOR TO DOWNTUBE
STEP #7 HUB PLATE INSTALLATION
HARDWARE KIT 854832 OR 915066
TORQUE SCREWS TO 96 IN-LBF
(MANUAL PAGE 17)
STEP #4 GUY WIRE
INSTALLATION
ALTERNATE MOUNTING - MANUAL PAGES 7-9
FIRE
RELAY
FIRE SUPPRESSION SYSTEM
LANDING POINT AT FAN
FIRE ALARM LANDING POINT
FIRE RELAY INSTALLATION AND WIRING
TO FAN WIRING
BLUE - COMMON
YELLOW - NORMALLY CLOSED
ORANGE - NORMALLY OPEN
(FAN DISABLED WHEN RELAY OPEN)
20 TO 32 VDC
RED (+)
WHITE (-)
OPTIONAL LED LIGHT INSTALLATION - MANUAL PAGE 15
5-1/2 IN.
MIN.
FIRST FAN IN SERIES
ALL OTHER FANS IN SERIES
- REMOVE BROWN/WHITE 24V WIRE AND CAP
- DO NOT REMOVE BROWN GROUND WIRE
- REMOVE SILVER SHIELD AND SECURE IN A WAY
THAT PREVENTS CONTACT WITH VFD BOARD
NOTE
DO NOT CUT CABLE OR REMOVE CRIMP CAP IF NOT USING FIRE RELAY.
1 2 3
ON
1 2 3
ON
FAN 1 ALL OTHER FANS
IN SERIES
DIP SWITCH BANK 2 SETTINGS
HELPFUL HINT
ALL NETWORKING MODIFICATIONS CAN BE COMPLETED PRIOR TO BLADE INSTALLATION.
FAN NETWORKING
FOR ALL WIRING AND NETWORKING - SEE MANUAL PAGES 11-12 AND 18-20
1 2 345678
ON
1 2 3
ON
MOTOR-TO-VFD WIRING AND DIP SWITCH BANK LOCATIONS
3
3
DIP SWITCH BANK 3
DIP SWITCH BANK 2
NOTE
HALL CABLE PLUG HAS BUILT-IN
ALIGNMENT TAB. DO NOT FORCE
THIS PLUG.
2
1
1
2
DIP SWITCH BANK 3 SETTINGS (MODBUS ADDRESSES)
MODBUS
ADDRESS
2
3
4
5
6
7
8
9
10
11
SWITCH
1
SWITCH
2
SWITCH
3
SWITCH
4
SWITCH
5
ON OFF OFF OFF OFF
ON
ON ON
ON
ON ON
ON ON
ON ON ON
ON
ON ON
ON ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
DO
NOT
MODIFY
SWITCH
6, 7, 8
Reference Troubleshooting Operation And
Maintenance
Fan
Networking
Electrical
Installation
Fire System
Integration
Mechanical
Installation Pre-Installation General
Information
Quick Start
Guide

Overhead Ceiling Fans 9
®
Quick Start
Guide
General
Information Pre-Installation Mechanical
Installation
Fire System
Integration
Electrical
Installation
Fan
Networking
Operation And
Maintenance Troubleshooting Reference
SURFACE MOUNT KEYPAD CONTROL
REFER TO CONTROL MANUAL PAGE 2
KEYPAD CONTROL
FACTORY-SUPPLIED SHIELDED
CAT-5e CABLE TO FAN(S)
RECESSED MOUNT KEYPAD CONTROL
REFER TO CONTROL MANUAL PAGES 2-3
FACTORY-SUPPLIED SHIELDED
CAT-5e CABLE TO FAN(S)
FACTORY-SUPPLIED SHIELDED
90° ADAPTER CAT-5e CABLE
STEP #11 - CONTROLS INSTALLATION
STANDARD TOUCHSCREEN CONTROL
REFER TO CONTROL MANUAL PAGE 2
FACTORY-INSTALLED RJ12 CABLE
TO TOUCHSCREEN INTERFACE
TOUCHSCREEN INTERFACE
TRIM PLATE
SURFACE MOUNT ENCLOSURE
FACTORY-SUPPLIED SHIELDED
CAT-5e CABLE TO FAN(S)
FACTORY-INSTALLED RJ12 CABLE
TO TOUCHSCREEN INTERFACE
FACTORY-INTALLED 115V
POWER SUPPLY CABLE
OPTIONAL BMS WIRING
SURFACE MOUNT ADV TOUCHSCREEN CONTROL
REFER TO CONTROL MANUAL PAGE 3
FACTORY-SUPPLIED SHIELDED
CAT-5e CABLE TO FAN(S)
COVER PLATE
TOUCHSCREEN CONTROL
INSTALLATION SCREW
JUNCTION BOX
(BY OTHERS)

Overhead Ceiling Fans10
®
Reference Troubleshooting Operation And
Maintenance
Fan
Networking
Electrical
Installation
Fire System
Integration
Mechanical
Installation Pre-Installation General
Information
Quick Start
Guide
FAN START-UP
KEYPAD - REFER TO CONTROL MANUAL
PAGE 5-7
STD TOUCHSCREEN - REFER TO CONTROL
MANUAL PAGES 5-6
ADV TOUCHSCREEN - REFER TO CONTROL
MANUAL PAGES 7-8
IMPORTANT: BLADE COUNT AND FAN SIZE
MUST BE SET APPROPRIATELY IN CONTROL
MENUS FOR PROPER FAN OPERATION.
STEP #12 - FAN START-UP
RECESSED MOUNT ADVANCED TOUCHSCREEN
CONTROL
REFER TO CONTROL
MANUAL PAGES 3-4
STEP #11 - CONTROLS INSTALLATION (CONTINUED)
FACTORY-SUPPLIED SHIELDED
CAT-5e CABLE TO FAN(S)
FACTORY-INSTALLED RJ12 CABLE
TO TOUCHSCREEN INTERFACE
FACTORY-INTALLED 115V
POWER SUPPLY CABLE
OPTIONAL BMS WIRING
FACTORY-INSTALLED RJ12 CABLE
TO TOUCHSCREEN INTERFACE
TOUCHSCREEN INTERFACE
TRIM PLATE
RECESSED MOUNT ENCLOSURE
