Greenheck FSD-3XXV Series Installation and operating instructions

Installation, Operation and Maintenance Instructions
Part Number 461666
Safety Warning:
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, injury or
death. Read the installation, operating, and maintenance
instructions thoroughly before installing or servicing this
equipment.
This manual is the property of the owner, and is required for future maintenance. Please leave it with the owner when
the job is complete.
Warranty
Greenheck warrants this equipment to be free from
defects in material and workmanship for a period of one
year from the purchase date. Any units or parts which
prove to be defective during the warranty period will
be repaired or replaced at our option. Greenheck shall
not be liable for damages resulting from misapplication
or misuse of its products. Greenheck will not be
responsible for any installation or removal costs.
Greenheck will not be responsible for any service work
or backcharges without prior written authorization.
Due to continuing research, Greenheck reserves the right to change specifications without notice.
“UL CLASSIFIED (see complete marking on
product)”
“UL CLASSIFIED to Canadian safety standards
(see complete marking on product)”
UL Standard 555 & 555S (Classification R13317)
FSD-3XXV Series Dampers are intended for installation
in accordance with combination fire smoke damper
requirements established by:
National Fire Protection Association
NFPA Standards 80, 90A, 92A, 92B, 101, & 105
BOCA National Building Codes
ICBO Uniform Building Codes
IBC International Building Codes
SBCCI Standard Building Codes
New York City (MEA listing #260-91-M)
California State Fire Marshal
Listing #3225-0981:103 and 3230-0981:104
Receiving and Handling
Upon receiving dampers, check for both obvious
and hidden damage. If damage is found, record all
necessary information on the bill of lading and file
a claim with the final carrier. Check to be sure that
all parts of the shipment, including accessories, are
accounted for.
Dampers must be kept dry and clean. Indoor storage
and protection from dirt, dust and the weather is highly
recommended. Do not store at temperatures in excess
of 100°F (38°C).
Typical
Actuator
RRL Control
Device Standard
FSD-3XXV Series
1 1/2 Hour
Combination Fire Smoke Dampers
( with factory installed sleeve and actuator)
Vertical Blade
Installation Supplements
Refer to the appropriate Greenheck installation
supplements for special requirements:
• Metal Stud in Shaftwall
• Metal Stud in Drywall
• Wood Stud in Shaftwall
• Smoke Detector
• No Flow Smoke Detector
• Tunnel Corridor
• Single Side Retaining Angle
• Grille Installation
• Field Installed Sleeve
• Quick Connect Breakaway Connections
• Sealant Supplement
• Fire Resistant Ventilated Duct Assembly
• Drive Slip Breakaway Connection
• Concrete Floor with Steel Deck
• Sleeve Extension
• Open or Close Indicator
• Resettable Link

Table of Contents
Pre-Installation Guidelines................................................................................................................................ 2
Electrical Guidelines.......................................................................................................................................... 2
Installation ...................................................................................................................................................... 3-7
• Clearances Required Between Fire Damper Sleeves and Wall/Floor Openings ............................ 3
• Sleeve Length and Wall Thickness .................................. .................................................................3
• Duct to Sleeve Connections...................................... ........................................................................4
• Securing the Damper/Sleeve Assembly to Wall and Floor Openings ........................ .....................4
• Actuator Connections..................................... ...................................................................................5
• Connection and Operation of Temperature Control Devices ....................................................... 5-6
• Recommended Preparation of Openings in Wood and Metal Stud Walls...................................6-7
• Breakaway Connections ..................................... ...........................................................................7-8
Maintenance ...................................................................................................................................................... 7
Troubleshooting................................................................................................................................................. 7
Pre-Installation Guidelines
The basic intent of a proper installation is to secure the
fire or fire smoke damper in, not to, the opening in such a
manner as to prevent distortion and disruption of damper
operation. This is accomplished by allowing the fire or fire
smoke damper in rated separation openings to expand
and for the connecting duct to separate in the event of the
collapse of the hanging system. The following items will
aid in completing the damper installation in a timely and
effective manner.
1) Check the schedules for proper damper locations
within the building. Visually inspect the damper for
damage and verify that the Reusable Resettable Link
(RRL) is in place or has not activated. Never install
a fire damper without the proper UL approved RRL
in place. (RRL is standard control option. These
electric links have a button for resetting.) If damper
is furnished with fusible link, visually inspect the link
to verify its not missing or broken. Replace link as
necessary.
2) Lift or handle damper using sleeve or frame. Do not
lift damper using blades or actuators.
3) Damper has label on outside of sleeve indicating a
‘No Screw’ area. Do not install screws into this area
as screws may interfere with unexposed blade linkage
and prevent damper blades from opening and/or
closing.
4) Damper has label indicating position of damper
and sleeve assembly in the wall. Install accordingly
to comply with manufacturer’s appropriate UL
Classification file number.
5) Damper must be installed into duct or opening square
and free of twist or other misalignment. Damper must
not be squeezed or stretched into duct or
opening. Out of square, racked, twisted or misaligned
installations can cause excessive leakage and/or torque
requirements to exceed damper/actuator design.
6) Damper and actuator must be kept clean and
protected from dirt, dust and other foreign materials
prior to and after installation. Examples of such foreign
materials include but are not limited to:
a) Mortar dust
b) Drywall dust
c) Firesafing materials
d) Wall texture
e) Paint overspray
7) Damper should be sufficiently covered as to prevent
overspray if wall texturing or spray painting will be
performed within 5 feet of the damper. Excessive dirt
or foreign material deposits on damper can cause
excessive leakage and/or torque requirements to
exceed damper/actuator design.
8) Caulking is not necessary, nor is it allowed, between
the damper sleeve and the wall or floor opening
(annular space). However, caulking may be applied to
the retaining angles.
9) ACCESS: Suitable access (such that RRL’s and
actuators can be maintained, etc.) must be provided
for damper inspection and servicing. Where it is not
possible to achieve sufficient size access, it will be
necessary to install a removable section of duct. (Refer
to NFPA 90A).
10) The Code Authority Having Jurisdiction (AHJ) must
evaluate and provide approval of final installation
where variations to these instructions are necessary.
Electrical Guidelines
All wiring shall be done in accordance with the National
Electrical Code ANSI/NFPA-70 latest edition, any local
codes that may apply, and wiring diagrams developed
in compliance with the job or project design and
specifications.
Safety Caution!
Electrical input may be needed for this equipment. This
work should be performed by a qualified electrician.
Verify power before wiring actuator. Greenheck is not
responsible for any damage to, or failure of the unit
caused by incorrect field wiring. To avoid causing death
or serious bodily harm to building occupants, follow all
instructions carefully. Dampers must close completely to
preserve the integrity of the fire smoke separation.
Electrical Guidelines
2

These instructions apply to 11 /2hour rated combination fire smoke dampers mounted (blades must be vertical) in: masonry,
block, or stud walls. Specific requirements in these instructions are mandatory. Dampers must be installed in accordance with
these instructions to meet the requirements of UL555 and UL555S. The installation of the damper and all duct connections
to the damper sleeve shall conform to the latest editions of NFPA90A, Standard for the Installation of Air Conditioning
and Ventilating Systems, and the SMACNA Fire, Smoke and Radiation Damper Installation Guide, and UL Classifications
R13317.
Installation - Failure to follow these instructions will void all warranties.
Example: A 12 in. x 12 in. (305mm x 305mm)damper
would require a minimum clearance of 1 /4in.
(6mm.)
A 36 in. x 12 in. (914mm x 350mm) damper
would require a minimum clearance of 1 /2
in. (13mm) on width and 1 /4in. (6mm) on
height.
Clearance for Expansion
(1/4in. Min, 1 1/2in. Max.)
Retaining Angles
(See Section 4)
6 in. max.
Detail 1
(Located on Bottom of Damper)
Airlfow
Sleeve Length (L)
16 in. max
"A" Dim.
(Distance from
end of Sleeve to
Face of Damper)
Actuator
Damper
Sleeve
Standard RRL Control Device
with Optional Blade Indication
Jackshaft
Tw
Line of Wall
Do not install screws
between these lines
around entire damper
Fig. 1
1. CLEARANCES REQUIRED BETWEEN FIRE DAMPER
SLEEVES AND WALL/FLOOR OPENINGS
Fire damper and sleeve assemblies expand during
periods of intense heat. Therefore, it is essential that
openings in walls or floors be larger than the fire damper
and sleeve assembly to allow for this expansion.
Minimum clearances required between the outside of
fire damper sleeve assemblies and wall/floor openings
are:
• Galvanized steel fire dampers and sleeves: 1⁄8in.
(3mm) per foot of damper width and height with a
minimum clearance of 1⁄4in. (6mm), maximum of 1
1⁄2in. (38mm).
Recommended clearances, for width and/or height
dimensions of:
1) 36 in. (914mm) or less: 1⁄2in. (13mm) clearance
These are total clearances (ignoring fastener heads) and
do not need to be equally spaced around the damper.
2. SLEEVE LENGTH AND WALL THICKNESS
Insert the sleeved damper assembly into the prepared
opening, to appropriate depth (refer to label on outside
of sleeve for location of damper in wall; see Page 3,
Dimension A and Detail 1, Fig. 1).
Recommended maximum and minimum insertion depth
can be exceeded if:
1) The operation of the damper is not impeded and
2) The C
Lof the damper frame remains within the plane
of the wall and
3) Attachments made through the retaining angle do
not penetrate the ‘No Screw’ area designated on the
damper sleeve.
IMPORTANT SAFETY DANGER! : To avoid causing
death or serious bodily harm to building occupants, do
not penetrate the ‘No Screw’ area designated on the
damper sleeve or the damper may not close properly.
The sleeve may extend a maximum of 16 in. beyond the
wall on the actuator side of the damper and a maximum
of 6 in. on the opposite side. Recommended standard
sleeve lengths for various wall thicknesses are:
Clearance for Expansion
(1/4in. Min, 1 1/2in. Max.)
Retaining Angles
(See Section 4)
6 in. max.
Detail 1
(Located on Bottom of Damper)
Airlfow
Sleeve Length (L)
16 in. max
"A" Dim.
(Distance from
end of Sleeve to
Face of Damper)
Actuator
Damper
Sleeve
Standard RRL Control Device
with Optional Blade Indication
Jackshaft
Tw
Line of Wall
Do not install screws
between these lines
around entire damper
3
Wall Thickness
Dimension (TW)
Sleeve Length
Dimension (L)
4 - 6 in.
(102mm - 152mm)
16 in.
(406mm)
7 - 10 in.
(178mm - 254mm)
21 in.
(533mm)
11 - 13 in.
(279mm - 330mm)
24 in.
(610mm)

3. DUCT TO SLEEVE CONNECTIONS
Dampers are supplied with sleeves and actuators from
the factory and can be installed without the need for
additional field installed sleeves.
Gauge of factory furnished sleeve determines the type
of duct to sleeve connections required (see table below).
Any duct connection other than those breakaway
connections described on page 6 are considered rigid.
Factory furnished duct collars, type R and O, are also
considered breakaway (see Fig. 2).
Sleeve Gauge Duct Dimension
Type of Duct
to Sleeve
Connection
Permitted
14 ga. (0.075 in.)
- 10 ga. (0.138
in.)
[2mm - 3.5mm]
All duct sizes Rigid or
Breakaway
16 ga. (0.060 in.)
[1.5mm]
36 in. (914mm) max. width
24 in. (610mm) max. width
24 in. (610mm) diameter
Rigid only
16 ga. (0.060 in.)
[1.5mm] All duct sizes
Breakaway only
18 ga. (0.048 in.)
[1.2mm]
85 in. (2159mm) wide and
over
20 ga. (0.036 in.)
[0.9mm]
55 in. - 84 in. wide
(1397mm - 2134mm)
22 ga. (.030 in.)
[0.76mm]
31 in. - 54 in. wide
(787mm - 1372mm)
24 ga. (0.024)
[0.6mm]
13 in. - 30 in. wide
(330mm - 762mm)
26 ga. (0.018 in.)
[0.46mm]
12 in. wide and under
(305mm)
See page 6 for additional information on breakaway sleeve connections.
Sleeve thickness must not be less than the gauge of the connecting duct.
UL Standard 555 requires all ducts to terminate at fire damper sleeves.
4. SECURING THE DAMPER/SLEEVE ASSEMBLY TO
WALL OPENINGS
Damper/sleeve assemblies must be installed in wall
openings using retaining angles on at least one side of
the wall as described below:
• Retaining angle must be a minimum of 16 gauge
(1.5mm) steel and have a minimum of 1
1
/2in. x 1
1
/2in.
(38mm x 38mm) legs.
• Retaining angle must be attached to the damper using
one or more of the following methods of attachment
(refer to label on outside of sleeve for ‘No Screw’
area):
• Tack or spot welds
• #10 (3/4in. max. [19mm]) sheet metal screws
• 1/4in. (6mm) bolts and nuts
•3/16 in. (5mm) steel pop rivets
A minimum of two connections per side, top, and
bottom, 12 in. (305mm) O.C. maximum for openings of
48 in. W x 32 in. H (1219mm x 812mm) and less, and
6 in. (152mm) O.C. for openings 100 in. W x 32 in. H
(2540mm x 32mm) or less. The angles must be attached
to all 4 sides of the sleeve with butt joints at each
corner. A minimum of two attachments are required
on each side, top and bottom. Ensure that attachment
device does not interfere with the operation of the
damper and the free movement of the damper blades.
The angles need not be attached to each other at the
corners. Do not secure the retaining angle to the fire
separation (see Fig. 3).
• Retaining angles must completely cover the
clearance space between the damper and the wall
opening, plus overlap the wall a minimum of 1 in. This
coverage includes all corners.
• Retaining angles should not be fastened to the wall
material. The angles should only sandwich the wall
and allow for damper expansion during periods of
intense heat.
Damper
Model
Maximum Single
Section Size
Maximum Multiple
Section Size
FSD-311V 50 x 32 100 x 32
Type R and O
Factory Furnished
Duct Collars Qualify
As Breakaway
Connections
Duct
Dampe
r
Sleeve
Wall or Floor
Type C, O, R
Fig. 2 Damper with type R or O transition factory
furnished.
2 in. Max.
6 in. Max.
Sleeve
Retaining
Angle
Damper
Duct
Min. 1 in.
Overlap*
Wall or
Floor
Retaining
Angle
*only applicable for damper sizes above 36 in. x 36 in.
6 in. Max.
2 in. Max.
Both vertical and horizontal damper installations are
typified by these drawings.
Fig. 3
4

5. ACTUATOR CONNECTIONS
Electrical and/or pneumatic connections to damper
actuators should be made in accordance with wiring
and piping diagrams developed in compliance with
applicable codes, ordinances and regulations (see
Electrical Guidelines).
6. CONNECTION AND OPERATION OF TEMPERATURE
RESPONSE DEVICES (RRL STANDARD, OCI OPTION,
AND TOR OPTION)
RRL - Dampers will be supplied with a thermostat-
type temperature response device, as a standard. The
device is a RRL (resettable link device), which only
incorporates one thermostat and therefore the damper
remains closed as soon as its sensor temperature is
reached. The RRL does not contain blade indication
switches. Refer to Fig. 4 for wiring of the RRL
thermostat.
OCI - The OCI (open or closed indicator) option contains
a single pole, double throw switch used to indicate the
damper blade position. The switch provides a positive
open or closed signal when used in conjunction with
remote indicator lights. Refer to Fig. 5 for wiring of the
OCI option.
TOR - The TOR (temperature override device) option
incorporates two thermostats with fixed settings (usually
165°F [74°C] and 350°F[177°]). The primary sensor
(the sensor with the lower temperature setting) can be
bypassed by an external electrical signal allowing the
damper to reopen until the temperature reaches the
setting of the secondary sensor (the sensor with the
higher temperature setting). When the temperature of
the secondary sensor is exceeded the damper closes
and remains closed thereafter (Figure 6).
The TOR assembly also contains a single pole, double
throw switch used to indicate damper blade position.
The switch provides a positive open or closed signal
when used in conjunction with remote indicator lights.
See page 6, Fig. 6 for wiring of the TOR thermostats and
indicator switches.
If either the TOR or the RRL is ordered with a pneumatic
actuator, an EP switch is required with an appropriate
electric power circuit to allow the electric thermostat to
control the pneumatic actuator.
PRV - The PRV (pneumatic relief valve) option is heat
responsive device used with pneumatic actuators. This
can be used in place of EP switch where a RRL is used.
The PRV activates when temperature in excess of the
temperature of the fusible link are detected. When the
fusible link melts, air from the actuator is exhausted to
close the dampers. Pneumatic actuators are to be piped
per local code.
7. RECOMMENDED PREPARATION OF OPENINGS IN
WOOD AND METAL STUD WALLS
• Frame wall openings as shown. (see Fig. 7 & 8)
• Double vertical studs are not required for openings
36 in. x 36 in. (914mm x 914mm) or smaller.
• Gypsum wall board must be fastened 12 in. (350mm)
on center to all stud and runner flanges surrounding
opening. (see Fig. 9)
• All construction and fasteners must meet the
requirements of the appropriate wall design (See UL
Fire Resistance Directory) and/or local codes.
RATINGS (Fig. 4, 5 & 6)
Integral Switch Type: Single Pole, double throw
Electrical Capacity: 10 Amps, 1/3hp, 120 or 240 Vac
1/2Amp, 125 Vdc;
1/4Amp 250 Vdc
5 Amps, 120 Vac “L” (lamp load)
1.0 Amps, 24 Vac
1.5 Amps, 24 Vdc
Temperature Limit: 165°F ( standard primary sensor)
212° F (optional primary sensor)
250° F (secondary sensor )*
350º F (secondary sensor)*
* based on actuator temperature rating
Fig. 4 RRL Wiring
Fig. 5 OCI Wiring
L1
DAMPER
INDICATOR
LIGHTS
ELECTRIC DAMPER
ACTUATOR OR PNEU. SOLENOID
VALVE
M
L2
BROWN
YELLOW
YELLOW
ORANGE
HL=HIGH LIMIT SENSOR
P=PRIMARY TEMP SENSOR
OR = OVERRIDE
OR
ON
OFF
BY OTHERS
WHITE
NC
YELLOW
YELLOW
S1
S2
NO
NO
P
NC BROWN
HL
BLACK
CLOSED POSITION OF THE DAMPER.
A BLUE MARKER INDICATE THE
THE SWITCH WIRES WRAPPED WITH
ELECTRICAL CAPACITY = 10AMP @ 120 / 240 VAC
NOTE:
OPEN-CLOSED INDICATOR
TEMPERATURE LIMITED OVERRIDE/
Fig. 6 TOR Wiring
5

.FUBM4UVE$POTUSVDUJPO
8PPEFO4UVE$POTUSVDUJPO
*OXPPETUVEDPOTUSVDUJPO
HZQTVNXBMMCPBSENVTUDPWFS
BMMXPPETUVETVSGBDFT
(ZQTVN8BMMCPBSE
4UVEPS3VOOFS
3FUBJOJOH
"OHMF
JO.JO
%BNQFS
4MFFWF
*ONFUBMTUVEDPOTUSVDUJPO
FYQPTFETUFFMTVSGBDFTOFFE
OPUCFDPWFSFEXJUIHZQTVN
XBMMCPBSE
(ZQTVN8BMMCPBS E
4UVEPS3VOOFS
3FUBJOJOH
"OHMF
JO.JO
%BNQFS
4MFFWF
Fig. 7
.FUBM4UVE$POTUSVDUJPO
8PPEFO4UVE$POTUSVDUJPO
*OXPPETUVEDPOTUSVDUJPO
HZQTVNXBMMCPBSENVTUDPWFS
BMMXPPETUVETVSGBDFT
(ZQTVN8BMMCPBSE
4UVEPS3VOOFS
3FUBJOJOH
"OHMF
JO.JO
%BNQFS
4MFFWF
*ONFUBMTUVEDPOTUSVDUJPO
FYQPTFETUFFMTVSGBDFTOFFE
OPUCFDPWFSFEXJUIHZQTVN
XBMMCPBSE
(ZQTVN8BMMCPBS E
4UVEPS3VOOFS
3FUBJOJOH
"OHMF
JO.JO
%BNQFS
4MFFWF
Fig. 8
12 in.
24 in. o.c.
Maximum
Floor Runner
2 in.
Ceiling Runner
2 Panhead
Screws
24 in. o.c.
Maximum
(metal studs)
24 in. o.c.
Maximum
(metal studs)
16 in. o.c.
Maximum
(wood studs)
16 in. o.c.
Maximum
(wood studs)
2 in.
Fig. 9
8. BREAKAWAY CONNECTIONS
Traditional Breakaway Style Transverse Joints
Transverse joints illustrated at right have always been
approved as breakaway connections. SMACNA testing
has also approved the following variations as breakaway
connections.
• The breakaway connections shown to the right
(Fig. 11) can be applied with maximum of two #10
(19mm) sheet metal screws on each side and on the
bottom located in the center of the slip pocket and
penetrating both sides of the slip pocket.
• Transverse joints illustrated
can be applied as top and
bottom joints with Drive Slip
- side joints in duct heights
up to 20 inches (508mm)
see Fig. 10.
Round and Oval Duct Breakaway Connections
Round or flat oval ducts connected to Type R or O damper
collars shall be attached with #10 (19mm) sheet metal
screws as follows:
• Ducts to 22 in. (558mm) wide or diameter and smaller
shall have three screws.
• Ducts larger than 22 in. wide (558mm) or diameter
up to and including 36 in. (914mm) wide or diameter
shall have five screws.
NOTE: All breakaway connections described may have duct
sealant applied, PA2084T duct sealant adhesive
manufactured by Precision, DP1010 water base duct
sealant manufactured by Design Polymetrics, or Grey
Pookie in accordance with SMACNA recommendations.
Manufactured Flanged System Breakaway
Connections (Fig. 12)
Flanged connection systems manufactured by Ductmate,
Ward, and Nexus are approved as breakaway connections
when installed as illustrated (Fig. 12).
%SJWF4MJQ+PJOU
Fig. 10
1MBJOi4w 4MJQ)FNNFEi4w 4MJQ%PVCMFi4w 4MJQ
*OTJEF4MJQ+PJOU4UBOEJOHi4w4UBOEJOHi4w"MU
4UBOEJOHi4w"MU4UBOEJOHi4w4UBOEJOHi4w
#BS3FJOGPSDFE"OHMF3FJOGPSDFE
Fig. 11
'JSF%BNQFS4MFFWF
/FPQSFOFHBTLFU
CFUXFFOBMMBOHMFT
'MBOHFETZTUFNBOHMFT
"UUBDIQFS
NBOVGBDUVSFShT
JOTUSVDUJPOT
%VDU
%POPUCPMUDPSOFST
JOMPOH JONBY
UIJDLOFTTQMBTUJDDMFBUT
JODDNJOQFSTJEF
Fig. 12
6

Proprietary Flange System Breakaway Connections
(TDC by Lockformer, TDF by Engle)
TDC and TDF systems are approved
as breakaway connections when
installed as described in the TDC or
TDF addendum to the SMACNA Duct
Construction. Standard 6 in. (152mm)
metal clip may be used with spacing as
shown in diagram (Fig. 13 & 14). 3/8 in.
(9.5mm) metal bolts and nuts may be
used to fasten together corner pieces.
(see Fig. 15)
%VDU
4MFFWF
JO
4UE$MJQ
-FOHUI
$
-
%VDU
JO%VDU
3FRE
JO%VDU
3FRE
JO%VDU
3FRE
JO%VDU
3FRE
JO%VDU
4NBMMFS
3FRE
$MJQ4QBDJOH
5ZQJDBM5%$5%'KPJOU
JO JO
JO
JOJO
JO JO
JOJO
Fig. 13
Fig. 14
%VDU
4MFFWF
JO
4UE$MJQ
-FOHUI
$
-
%VDU
JO%VDU
3FRE
JO%VDU
3FRE
JO%VDU
3FRE
JO%VDU
3FRE
JO%VDU
4NBMMFS
3FRE
$MJQ4QBDJOH
5ZQJDBM5%$5%'KPJOU
JO JO
JO
JOJO
JO JO
JOJO
Damper Maintenance
Dampers do not typically require maintenance as long as they are kept dry and clean. If cleaning is necessary, use mild
detergents or solvents. If lubrication is desired for components such as axle bearings, jackshaft bearings and jamb
seals, do not use oil-based lubricants or any other lubricants that attract contaminants such as dust.
Dampers and their actuator(s) must be maintained, cycled, and tested a minimum in accordance with:
• The latest editions of NFPA 80, 90A, 92A, 92B, 101, 105, UL864, AMCA 503-03 and local codes.
• Actuator manufacturer recommendations.
Damper Troubleshooting
The following is a possible cause and correction list for common concerns with the dampers.
Sympton Possible Cause Corrective Action
Damper does not
fully open and/or
close
Frame is 'racked' causing blades
to bind on jamb seals
Adjust frame such that it is square and plumb
Actuator linkage loose Close damper, disconnect power, adjust and
tighten linkage
Defective motor Replace
Screws in damper linkage Damper installed too far into wall. Move out
to line as designated on damper label
Contaminants on damper Clean with a non-oil based solvent (see
Damper Maintenance)
RRL or TOR sensor
tripped
Heat Push reset button located on backside of
RRL or TOR
Damper does not
operate
No power supplied to the actuator Add power supply
Copyright © 2008 Greenheck Fan Corporation
461666 FSD-3XXV Rev. 8 January 2008
7
Duct End
Flange
Corner Piece
3/8 in. bolt
(optional)
Fig. 15
