Greenlee CMPL-100 User manual

999 3280.6 © 1999 Greenlee Textron IM 1415 8/99
CMPL-100
CLAMP-ON METER
MEDIDOR CON PINZA
COMPTEUR A PINCES
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
MANUEL D’INSTRUCTIONS
Read and understand all of the instructions and safety
information in this manual before operating or servicing this tool.
Lea y entienda todas las instrucciones y la información sobre
seguridad que aparecen en este manual, antes de manejar estas
herramientas o darles mantenimiento.
Lire attentivement et bien comprendre toutes les instructions et
les informations sur la sécurité de ce manuel avant d’utiliser ou de
procéder à l’entretien de cet outil.

2
Description
The Greenlee CMPL-100 Clamp-on Meter is a hand-held testing device with the following
measurement capabilities: AC and DC voltage, AC and DC current, AC power, frequency and
resistance. The unit is also intended to check diodes and continuity.
Specialized functions include:
• Bar graph display, which responds more quickly than the numeric display
• PC computer interface capability
• Data recording and retrieval options
Optional accessories include:
• RS-232 interface adapter and software to review and analyze recorded data
• Three-phase adapter for specialized applications
Safety
Safety is essential in the use and maintenance of Greenlee tools and equipment. This
instruction manual and any markings on the tool provide information for avoiding hazards and
unsafe practices related to the use of this tool. Observe all of the safety information provided.
Purpose
This instruction manual is intended to familiarize all personnel with the safe operation and
maintenance procedures for the Greenlee CMPL-100 Clamp-on Meter.
Keep this manual available to all personnel.
Replacement manuals are available upon request at no charge.
and are registered trademarks of Greenlee Textron.
KEEP THIS MANUAL

CMPL-100
3
Important Safety Information
This symbol is used to call your attention to hazards or unsafe practices which could
result in an injury or property damage. The signal word, defined below, indicates the
severity of the hazard. The message after the signal word provides information for
preventing or avoiding the hazard.
SAFETY ALERT SYMBOL
Immediate hazards which, if not avoided, WILL result in severe injury or death.
Hazards which, if not avoided, COULD result in severe injury or death.
Hazards or unsafe practices which, if not avoided, MAY result in injury or property
damage.
Read and understand this material before operating or servicing
this equipment. Failure to understand how to safely operate this
tool can result in an accident causing serious injury or death.
Electric shock hazard:
Contact with live circuits can result in severe injury or death.

4
Important Safety Information
Electric shock hazard:
• Do not use the unit if it is wet or damaged.
• Use test leads or accessories that are appropriate for the application. See the
category and voltage rating of the test lead or accessory.
• Inspect the test leads or accessory before use. The item(s) must be clean and dry,
and the insulation must be in good condition.
Failure to observe these warnings can result in severe injury or death.
• Do not operate with the case open.
• Before opening the case, remove the test leads (or jaw) from the circuit and shut off
the unit.
Failure to observe these warnings can result in severe injury or death.
Electric shock hazard:
• Do not apply more than the rated voltage between any two input terminals, or
between any input terminal and earth ground.
• Do not contact the test lead tips or any uninsulated portion of the accessory.
Failure to observe these warnings can result in severe injury or death.

CMPL-100
5
Important Safety Information
Do not change the measurement function while the test leads are connected to a
component or circuit.
Failure to observe this precaution can result in injury and can damage the instrument.
• Do not attempt to repair this unit. It contains no user-serviceable parts.
• Do not expose the unit to extremes in temperature or high humidity.
See Specifications.
Failure to observe these precautions can result in injury and can damage the unit.
Unless measuring voltage, current, power, power factor or frequency, shut off and lock
out power. Make sure that all capacitors are discharged. Voltage must not be present.
Using this unit near equipment that generates electromagnetic interference can result
in unstable or inaccurate readings.

6
Identification
1. Display
2. Lever
3. Jaw
4. Selector
5. HOLD Button
6. Record Button
7. ∆REL Button
8. MIN/MAX/AVG/PEAKButton
9. Mode Button
10. PC Interface Connector
11. Positive Input Terminal
12. Common Input Terminal
13. Polarity Indicator for DC Amps
3
1
6
7
5
13
4
2
9
8
111210

CMPL-100
7
Symbols on the Unit
Read the instruction manual.
Double Insulation
Battery
Display Icons
14. Low Battery
15. — Polarity indicator
16. Hold function is enabled.
17. ∆Relative Zero function is
enabled.
18. DC measurement is selected.
19. AC measurement is selected.
20. MIN MIN Hold function is enabled.
21. MAX MAX Hold function is enabled.
22. AVG AVG Hold function is enabled.
23. PEAK Peak Hold function is enabled.
24. Diode
25. Continuity
26. RECORD Record function is enabled.
27. COS φPower Factor
28. cap Capacitive Circuit
29. ind Inductive Circuit
30. KW True Power
31. KVA Apparent Power
32. Hz Hertz
33. m Milli (10-3)
34. V Volts
35. A Amps
36. ΩOhms
37. Overload (Bar Graph Display)
38. Bar graph element
39. OL Overload (except when
measuring current and voltage)
Other Icons
CAL Self-calibration active
CLEP Clear memory
K Kilo (103)
M Meg (106)
18–19
17
16
15
14
32
30
31
33–35
36
37
39 38
20 21 22 23 24 25 26–29

8
Using the Features
• HOLD Press momentarily to hold the present value on the display and store it in the
memory. Press again to exit this mode.
•Mode Button (Unlabeled) Press momentarily to toggle between AC, DC and frequency
when measuring current and volts.
•MIN MAX AVG PEAK Holds the minimum or maximum value on the display. Press once to
hold the minimum value; press again to hold the maximum value; press again to hold the
average value (press again to hold peak value, if measuring an AC signal). Press and hold to
exit this mode.
•∆REL Finds the difference between two measurements. While taking a measurement,
press ∆to set the display to zero. The ∆icon will appear on the display. Take the second
measurement. The value on the display will be the difference between the two measure-
ments. Press and hold to exit this mode.
•RECORD Press momentarily to begin recording the input. RECORD will appear on the
display. The CMPL-100 will record up to 1600 events; when the memory is full, RECORD
will flash on the display. To save the recorded data in the memory, exit the RECORD mode
before turning the meter off. Use the CMPL-100-1A PC interface kit (purchased separately)
to retrieve the data from the memory.
To clear the memory, turn off the unit. Then press and hold the RECORD button while
turning the unit on. Release the RECORD button after “CLEP” appears on the display.

CMPL-100
9
Operation
Electric shock hazard:
Contact with live circuits can result in severe injury or death.
1. Set the selector according to the Settings Table and connect the test leads to the unit.
Start with the highest measurement range.
2. See Typical Measurements for illustrations of typical uses.
3. Test the unit on a known functioning circuit or component.
• If the unit does not function as expected on a known functioning circuit, replace the
battery.
• If the unit still does not function as expected, send the unit to Greenlee for repair.
4. Take the reading from the circuit to be tested.

10
Operation (cont’d)
Settings Table
To measure set the selector this icon will connect and connect
this value … to this symbol … appear on the red the black
the display … lead to … lead to …
DC Voltage VV + COM
AC Voltage VV + COM
and press the Mode button
DC Current AA N/A N/A
AC Current AA N/A N/A
and press the Mode button
V
and press the Mode Hz + COM
Frequency button twice
A
and press the Mode Hz N/A N/A
button twice
True Power* kW KW + COM
Apparent Power* kVA KVA + COM
Power Factor* PF COS † + COM
Resistance ΩKΩ+ COM
Continuity** Ω+ COM
Diode V + COM
and press the Mode button
*The jaw and the test leads are used simultaneously for these measurements – see Typical
Measurements.
**Tone indicates circuit resistance is less than 100 Ω.
†Power factor is the cosine of the phase angle between voltage and current. This angle is
represented by the Greek letter .

CMPL-100
11
Typical Measurements
Voltage Measurement
Current Measurement—
Clamp Around Wire
Notes:
• Clamp the jaw around one
conductor only.
• Close the jaw completely.
• Center the wire in the jaw for
highest accuracy.
Note: DC Current flowing
through the jaw in the
direction indicated by the
arrow produces a positive
reading. (AC current always
reads positive.)

12
Typical Measurements (cont’d)
True Power Apparent Power
Power Factor

CMPL-100
13
Typical Measurements (cont’d)
Diode Measurement
Continuity CheckResistance Measurement
Forward Bias
Reverse Bias

14
Typical Measurements (cont’d)
Single-Phase Three-Wire Measurements:
True Power, Power Factor and Apparent Power Measurement
The selector is set for Power Factor in the illustrations.
Use the correct setting for the desired measurement.
L1 1ø3W
N
L2
A1ø
Load
1ø
Load
L1–N = 110V
L2–N = 110V
L1–L2 = 220V
W L1N
L1 1ø3W
N
L2 A
1ø
Load
1ø
Load
L1–N = 110V
L2–N = 110V
L1–L2 = 220V
W L2N
W1Ø3W = WL1L2 = WL1N + WL2N

CMPL-100
15
Typical Measurements (cont’d)
Three-Phase Three-Wire Measurements:
True Power, Power Factor and Apparent Power Measurement
The selector is set for Power Factor in the illustrations.
Use the correct setting for the desired measurement.
R (L1) 3ø3W
S (L2)
T (L3)
A
3ø
Load
W RS
R (L1) 3ø3W
S (L2)
T (L3) A3ø
Load
W TS

16
Typical Measurements (cont’d)
Three-Phase Three-Wire Measurements:
True Power, Power Factor and Apparent Power Measurement
Notes:
• The + sign on the jaw must face the power source.
• COM connection (black lead) should remain connected to the same phase during both
measurements.
• A positive (+) PF indicates an inductive load. A negative (–) PF indicates a capacitive load.
Power factor value is correct for balanced loads only.
• Both power measurements may be positive, or one may be negative. Make sure all
connections are correct to obtain proper measurements.
Three-Phase Three-Wire Balanced Loads
W3Ø3W =W
RS + WTS
KVA3Ø3W = 3 (KVARS)
KVAR3Ø3W = [KVA3Ø3W]2– [KW3Ø3W]2
PF3Ø3W =KW
3Ø3W
KVA3Ø3W

CMPL-100
17
Typical Measurements (cont’d)
Three-Phase Four-Wire Measurements:
True Power, Power Factor and Apparent Power Measurement
The selector is set for Power Factor in the illustrations.
Use the correct setting for the desired measurement.
R (L1) 3ø4W
S (L2)
T (L3)
N
A
3ø
Load
W R (L1)
R (L1) 3ø4W
S (L2)
T (L3)
N
A
3ø
Load
WS (L2)

18
Typical Measurements (cont’d)
Three-Phase Four-Wire Measurements:
True Power, Power Factor and Apparent Power Measurement
The selector is set for Power Factor in the illustrations.
Use the correct setting for the desired measurement.
R (L1) 3ø4W
S (L2)
T (L3)
N
A3ø
Load
W T (L3)
Notes:
• The + sign on the jaw must face the power source.
• A positive (+) PF indicates an inductive load. A negative (–) PF indicates a capacitive load.
Power factor value is correct for balanced loads only.
• All three power measurements (WR, WSand WT) should be positive. Check test lead
connection and clamping of jaw if any power measurement is negative.
Three-Phase Four-Wire Balanced Loads
W3Ø4W =W
R
+ WS + WT
KVA3Ø4W = 3 (KVAR)
KVAR3Ø4W = [KVA3Ø4W]2– [KW3Ø4W]2
PF3Ø4W =KW
3Ø4W
KVA3Ø4W

CMPL-100
19
Accuracy
See the Specifications section for operating conditions.
Accuracy is specified as follows: ±(a percentage of the reading + the value of the rightmost
decimal place) at 18 °C to 28 °C (64 °F to 82 °F), 0% to 80% relative humidity.
Accuracy Table
* Peak detect acquisition time ≤100 ms
** Input impedance is 1 MΩ.
*** Peak detect acquisition time ≤200 ms
† Sensitivity is 10 V or 10 A.
†† AC-coupled, true RMS measurement,
additional error for crest factors > 1:
Value Range Accuracy Frequency Range
True Power 600.0 kW ±(2% + 0.5 kW) 40 to 400 Hz
Apparent Power 600.0 kVA ±(2% + 0.5 kVA) 40 to 400 Hz
0.3 to 1.0 ±3°
Power Factor (= 72.5°to 0°)10 to 60 Hz
0.0 to 0.3 Not
( = 90°to 72.5°) Specified
DCA 999.9 A ±(2% + 0.5 A) N/A
ACA†† 999.9 A ±(2% + 1.0 A) 40 to 400 Hz
Peak Current* 999.9 A ±(2.5% + 1.0 A) 40 to 400 Hz
DCV** 600.0 V ±(0.75% + 0.2 V) N/A
ACV** †† 600.0 V ±(1.2% + 1.0 V) 40 to 400 Hz
Peak Voltage*** 600.0 V ±(2.5% + 1.0 V) 40 to 400 Hz
Continuity 999.9 Ω±(1% + 0.5 Ω) N/A
Resistance 9.999 kΩ±(1% + 0.005 kΩ) N/A
Frequency† 999.9 Hz ±(0.5% + 0.5 Hz) 0 to 1 kHz
Crest Factor Error (% of reading)
1 to 3 0.5%
3 to 5 3%
5 to 7 6%

20
Specifications
Display: 4-digit LCD (9999 maximum reading) and 40-segment bar graph
Sampling Rate:
Numeric Display: 2 per second
Bar Graph Display: 10 per second
Continuity Indication: Buzzer sounds for resistance less than 100 Ω±10%
Diode and Continuity Modes:
Open Circuit Voltage: 4.5 V typical
Test Current: 1.0 mA typical
Resistance Mode:
Open Circuit Voltage: 4.5 V typical
Test Current: 0.1 mA typical
Automatic Power-Off: After 20 minutes of inactivity
Over Range Indication: OL appears on the display (except for ranges of 1000 A
and 1000 VDC and 750 VAC)
Jaw Opening: 46 mm (1.811’’)
Overvoltage Category: Category III, 600 Volts
Operating Conditions: 0 °C to 40 °C (32 °F to 104 °F), 0% to 80% relative humidity
(non-condensing)
Indoor use only
Elevation: 2000 m (6500’) maximum
Storage Conditions: –10 °C to 60 °C (14 °F to 140°F), 0% to 70% relative humidity
(non-condensing)
Remove battery.
Pollution Degree: 2
Battery: 9-Volt battery (NEDA 1604, JIS 006P or IEC 6LF22)
