GreenTec HX 170 User manual

5th Edition 2017

Cutterbar HX 170-230-270
2

Cutterbar HX 170-230-270
3
IMPORTANT INFORMATION
GreenTec HX 170-230-270
Handbook
5. Edition – October 2017
NOTICE: Please ensure that this manual is handed to the operator before
using the machine for the first time. If the machine is resold, the Parts list
must be given to the new owner!
The information contained in this Parts list is correct at the time of publication.
However, in the course of constant development, changes in specification are
inevitable. Should you find the information given in this book different to the machine it
relates to please contact the “After Sales Department” for advice
Merkurvej 25
DK 6000 Kolding
Denmark
Tel: [phone]
Email: [e-mail]
web: www.greentec.eu

Cutterbar HX 170-230-270
4
Contents
IMPORTANT INFORMATION .......................................................................................3
Contents .......................................................................................................................4
Introduction..................................................................................................................5
Useful information.......................................................................................................6
General Information.....................................................................................................7
CE Declaration of Conformity.....................................................................................8
Ordering parts..............................................................................................................9
Safety..........................................................................................................................10
Recommendations.....................................................................................................12
Pay attention to the following risks...........................................................................12
Do's.............................................................................................................................12
Dont´s.......................................................................................................................13
Product Description...................................................................................................14
Specifications...........................................................................................................14
Prior to start-up of work............................................................................................15
Setting of Working Posture.......................................................................................15
Starting the Tool.......................................................................................................15
Stopping the Tool.....................................................................................................15
Driving Instructions...................................................................................................15
High-Voltage Cables ................................................................................................16
Mounting / Dismounting............................................................................................16
Field of Application...................................................................................................17
Charts .........................................................................................................................18
Maintenance...............................................................................................................19
Service Check / Re-tightening..................................................................................19
Lubrication................................................................................................................19
Hydraulic Hoses.......................................................................................................19
Oil Supply.................................................................................................................21
Table: Regular Maintenance....................................................................................21
Bolts and Bushings...................................................................................................21
Storage.....................................................................................................................22
Troubleshooting.........................................................................................................23
Noise Measurement...................................................................................................23
Supplier Details and CE Marking..............................................................................24
Bans - Cautions - Regulations..................................................................................24
Dismantling ................................................................................................................25
GreenTec Warranty Provisions.................................................................................26

Cutterbar HX 170-230-270
5
Introduction
Dear customer!
Your new GreenTec machine is constructed with background in more than 20 years
experience with tractor mounted machines to maintenance of green areas. This
machine is produced by the latest technology and recognized safety regulations,
standards and regulations.
We want to make a product available in such a way, that neither the use of the
machine during transportation or maintenance of the machine causes any damage or
misunderstandings.
This parts list contains information that are important and useful for maintaining your
GreenTec machine's reliability, dependability and value.
You are welcome to visit our website www.greentec.eu - where the login via the
dealer's access gives you the latest updates on instructional and part books on our
entire product range.
We hope, you will be pleased with your new GreenTec machine.
Best regards,
John Christensen
Sales Director GreenTec A/S
GreenTec’s vision is to develop and sell quality machines for the maintenance of
green areas, including in agriculture, in industry, at airports and in the local sector.
Through innovative product development, we will strive to become a leader in our field.
All machines are developed in a simple and functional design in close cooperation with
dealers and end users. It is our goal to cover every need in the market segment with
preferably 2 different solutions. In-depth analysis of requirements and serious advice to
the customer is offered the best solution, where individual needs can be met through
the modularity of the product program.
Our goal is also to offer the best possible after sales service, and a quick and efficient
spare parts supply.

Cutterbar HX 170-230-270
6
Useful information
Before using the machine for the first time, it’s the seller’s responsibility that the buyer
is given this parts list. If the machine is resold, the parts list must be transferred to the
new owner.
Please fill out the list below to ensure that the necessary information is at hand when
ordering spare parts etc.
Serial No
Delivery date
Dealer
E-mail
Tel.
Merkurvej 25
DK 6000 Kolding
Denmark
Tel: [phone]
Email: [e-mail]
web: www.greentec.eu
Opening hours: Mon-Fri 8-16

Cutterbar HX 170-230-270
7
General Information
Read this manual before fitting or operating the machine or accessory. Whenever any
doubt exists contact your local dealer or the GreenTec Service Department for
assistance.
Only use ‘Genuine GreenTec Parts’ on GreenTec machinery and
equipment.
DEFINITIONS: The following definitions apply throughout this manual;
DANGER: Alerts to a hazardous situation which will result in death or serious injury if
not
observed carefully.
WARNING: Alerts to a hazardous situation which could result in death or serious injury
if not
observed carefully.
CAUTION: Alerts to a hazardous situation which could result in damage to the
machine
and/or equipment if not observed carefully.
NOTICE: Specific or general information considered important or useful to emphasise.
LEFT HAND (LH) & RIGHT HAND (RH): These terms are applicable to the machine
when
fitted to the tractor and viewed from the rear; these terms also apply to tractor
references.
SERIAL PLATE
All machines are equipped with a serial number plate containing important information
relating to the machine including a unique serial number used for identification
purposes.
Note: Images in this manual are provided for instruction and informational purposes
only and may not show components in their entirety. In certain instances images may
appear different to the actual
machine; where this occurs the general procedure will be basically the same.

Cutterbar HX 170-230-270
8
Merkurvej 25, DK-6000 Kolding, Denmark
CE Declaration of Conformity
Adapted EEC directive EG Guideline 2006/42/EF
We, GreenTec A/S, Merkurvej 25, 6000 Kolding, hereby declare that in terms of its design,
method of construction and our execution thereof, the item of machinery described below
complies with the basic health and safety regulations of the respective EU Directives. The
Machinery Directive is supported by the following harmonized standards:
DS/EN ISO 12100 3rd edition 2011. Safety of Machinery – General principles for
design – Risk assessment and risk reduction.
DS/EN 953+A1 4th edition 2010. Safety of Machinery – Guards-General
requirements for the design and construction of fixed and movable guards.
DS/EN ISO 4413 1th edition 2010. Hydraulic fluid power – General rules and
safety requirements for systems and their components.
Product: GreenTec HX 170-230-270
Product code: 9995230
Serial no: ____________
Type: Cutterbar
The EC Declaration only applies if the machine stated above is used in accordance
with the operating instructions.
on behalf of
Date: 26.09.2014 Signature:________ _________________________
John Christensen Sales Director

Cutterbar HX 170-230-270
9
Ordering parts
When ordering parts please refer to your parts list to help your dealer with your order.
Part number and quantity
Description
Machine model number
Serial number of the machine
Delivery instructions (e.g. next day).
Delivery is normally via carrier direct to your dealer. Please check with your dealer for
stock availability and arrangement of dispatch. Ensure you or your dealer has sufficient
cover for parts requirement outside factory hours.
Important Note
The information contained in this manual is correct at the time of publication. However,
in the course of constant development, changes in specification are inevitable. Should
you find the information given in this book different to the machine it relates to, please
contact the “After Sales Department” for advice.

Cutterbar HX 170-230-270
10
Safety
Caution
Liquids under pressure.
Please refer to the
Technical Manual for
information about service
procedures.
Caution
Flying objects. Keep
a safe distance from
the machine when in
use.
Caution
Keep a safe distance
from the cutter
knives when the
machine is in use.
Never remove safety
guards / guarded
Caution
Stay outside the swivel
range of the tools.
Caution
Turn off the engine and
remove the key before
performing any
maintenance or repair work
on the machine.
Caution
Check that all bolts and
nuts are tightened every 8
hours.
Caution
Read the User Manual prior
to operating the machine.
Follow all instructions and
safety provisions when using
the machine.

Cutterbar HX 170-230-270
11
This User Manual contains basic references to construction, operation and
maintenance. Thus, this User Manual should be studied by and made available to the
staff prior to start-up.
Never allow the HX 170 – 230 - 270 to be operated or maintained by individuals that
are not familiar with this User Manual or the associated risks. The driver is responsible
for and must monitor the staff. Should the staff not be sufficiently trained, such training
must be provided. Furthermore, the driver must ensure that the staff knows and fully
understands the contents of this User Manual.
Maintenance tasks that are not mentioned in this User Manual must be performed by
authorized technicians only.
Failure to observe the safety signs may result in the following risks:
Danger to people near non-secured work areas
Failure of vital machine functions
Failure of designated methods of maintenance or repair
Danger to people in case of mechanical or chemical impact.
Environmental hazards due to hydraulic oil spills
Never work in the vicinity of the machine unless it is completely stopped. The
procedure mentioned in this User Manual to completely halt the machine must be
followed.
Maintenance work with a raised tool is allowed only when appropriate support
elements have been applied. Use appropriate tools and work gloves when replacing
spare parts.
Oil and grease must be discarded properly and responsibly.

Cutterbar HX 170-230-270
12
Recommendations
Pay attention to the following risks
You may get stuck when the machine is coupled or decoupled.
The machine may fall over when the wing/wings is/are raised (not all models).
You may get caught by the rotating shaft from the power take-off.(not all
models)
You may get hit or caught by moving parts such as knives, saw blades, driving
shaft or wings.
You may get hit by flying objects or machine parts in case of breakdowns.
The machine may fall over when not in use (not all models).
Sprays of oil under high pressure from damaged screw-joints or hydraulic
hoses.
Accidents from collisions with other machines or lost objects on the ground.
Pay attention to the freely swinging knives when the wings are folded up. Crush
hazard! (not all models)
Do's
Ensure that the operator has read this Manual and has been trained in the
use of the machine.
Ensure that all guards are in place and that the tractor's windows are closed.
We recommend using impact-proof guards on the tractor.
Before leaving the driver's cab, ensure that the machine is resting on the
ground, that its hydraulics is not pressurized and that the saw blades /
knives have stopped rotating (not all models).
Check that all guards are correct mounted and that the equipment is free
from damaged or loose parts. Take extra care to ensure that all knives, flails
and saw blades are present and free from cracks or other damage.
Check the work area and remove any cords, poles, large stones or other
dangerous objects prior to starting the work.
Ensure that all warning signs are visible, present, undamaged and legible.
Use ear protection when operating the machine from a non-soundproof cab
or with the cab windows opened.
Ensure that all tractor guards are undamaged and adequately fitted.
Drive at speeds suited for the terrain and any other vehicles or obstacles.
Ensure that the tractor complies with the manufacturer's minimum weight
recommendations - use extra ballast if necessary.
Check that all fittings, connectors and couplings are in good condition.
Follow the manufacturer's instructions for coupling and decoupling the
machine to/from the tractor.
Always use knives that are recommended by the manufacturer and ensure
that they are adequately fitted and undamaged.
Ensure that all hydraulic tubes and hoses are correctly placed in order to
avoiding rubbing, stretching, crushing or bending (not all models).
Check that all knives, flails and saw blades have stopped rotating before
folding the machine to its transport position (not all models).
Disconnect the machine, stop the engine and remove the key before exiting
the cab, notwithstanding the reason for exiting.
Remove remaining plant debris and loose objects from the work area.
Always secure the machine using the provided holders when it is not
connected to the tractor (not all models).

Cutterbar HX 170-230-270
13
Dont´s
Never operate the machine with people standing nearby due to the risk of
debris or stones being thrown out in front of and behind the machine.
Never operate the machine prior to having read and understood this Manual
and familiarized yourself with the maneuvering handles.
Never use a machine that is not properly maintained or which has missing or
damaged guards.
Never allow an inexperienced person to operate the machine without
supervision.
Never use or mount the machine on a tractor that does not comply with the
manufacturer's specifications.
Never use the machine if the hydraulic system appears damaged.
Never attempt to locate a hydraulics leak using your hand; use a piece of
cardboard instead.
Never allow children to play on or near the machine.
Never perform maintenance or adjustments without disengaging the
hydraulics and power take-off, lowering the machine to ground, turning off
the tractor's engine and activating the tractor's parking brake.
Never leave the cab without removing the key from the ignition.
Never operate the tractor or the maneuvering handles from any other
position but the driver's seat.
Never stop the engine while the power take-off is engaged.
Never use the machine with missing knives, flails or saw blades.
Never use the machine with string or steel wire caught around a rotor. If so,
stop immediately. (not all models)
Never drive with the wing up as this increases the risk of stones or plant
debris being thrown towards the cab (not all models).
Never attempt to use the machine for any other purpose but the intended
purpose.
Never transport the machine with the hydraulics engaged.
Never enter the work area (risk of injury to persons)
Never activate the power take-off with the wings folded (not all models)
Never exceed the specified oil flow.

Cutterbar HX 170-230-270
14
Product Description
The Cutterbar primarily consists of a non-movable lower knife and a movable upper
knife that both are made from Hardox steel and driven by an hydraulic ram. The
double-effect cylinder is controlled by a reversing valve with a nonadjustable splitter
valve that is operated over a suspended bottom adjustment. The suspended bottom
adjustments are directly connected to the ramrod, thereby allowing the smooth rotation
of the cutting direction.
The basic tool is mounted using a mounting arm with high pressure hydraulic hoses
The knife guard may be mounted on the Hedge cutter using the extension spring.
Specifications
Cutterbar for mounting on hydraulically driven Armmowers.
Consists of two Hardox cuttings edges that are hydraulically driven over a flow divider,
two-way valve and hydraulic ram. The cutting edges are operated via external oil
supply from the hydraulically driven vehicle.
The Cutterbar may be fitted with an adapter to facilitate mounting on various vehicles.
The hydraulic system is completely covered.
Description
GreenTec HX 170 – 230 - 270
Operating width
1700 - 2300 - 2700mm
Oil level
45-85 L/min (integrated flow divider)
Operating pressure
200 bar
Hydraulic Mode
Soft turn control
Weight
190 – 220 - 250kg
Steel quality, cutting edge
Hardox
Work output
5 – 110mm branches
Stroke frequency
55-65 double strokes per minute
Work application
Vertically +/- 450

Cutterbar HX 170-230-270
15
Prior to start-up of work
Setting of Working Posture
Remove any transport protection and swing the arm into working posture.
Start the tool with a low oil flow (low RPMs / low oil flow).
Adjust the HX 170 - 230 – 270 to vertical hedge cutting and raise it to the
working posture.
Starting the Tool
Select low engine RPMs
Ensure that the area around the tool is secured.
Warm start – Start the tool.
Cold start – Never start with max. oil flow. Allow the tool to run without too
much load for about 15 min. to heat up the oil.
Slowly increase the amount of oil until the relevant speed has been achieved.
Never attempt to restart a loaded tool. Remove whatever is stuck before
restarting the tool.
Stopping the Tool
Reduce the engine RPM to fast idling. Stop the tool.
Never quickly increase or reduce the amount of oil as this may damage the
hydraulic system in the long term.
Place the tool on the ground when taking a break.
Driving Instructions
We recommend that you drive slowly at first and pay attention to the terrain and
whether the hedge is free from fencing wire, steel poles and other foreign objects.
Adjust the cutting angle to a position approx. 90 degrees relative to the branches. In
case of large branches, adjust the cutting height to the center of the cutting opening.
Never drive too fast to allow clean cutting.
Low speeds = Nice cuts, nothing sticks out.
High speeds = Frayed cuts, twigs sticking out.

Cutterbar HX 170-230-270
16
High-Voltage Cables
Mounting / Dismounting
Turn the arm system to a position next to the HX 170 – 230 - 270
Mount the bolts or snap the Quickshift (optional) together
Mount the hydraulic hoses
Lift the tool free
Dismount the knife guard
Test the function. Count the strokes (optional) 55-65 double strokes per minute (45 - 85
L/min.)
Always pay attention to overhead cables. You may
hit the overhead cables between the power poles.
When in doubt - contact the local power plant and
inquire about the safety distance

Cutterbar HX 170-230-270
17
Field of Application
The tool is designed for cutting hedges and branches with a max. diameter of 100mm
without fraying the branches. Branches over 70mm in diameter should be cut
individually.
Vertical cutting is allowed up to a 45 degree angle. Horizontal cutting is possible on
hedges with a max. width of 1m and a branch thickness of max. 40mm. In case of
larger branches, the cutting edges may stop and get stuck in the machine.

Cutterbar HX 170-230-270
18
Charts
Reversing valve with a nonadjustable splitter valve
Hydraulic
Chart

Cutterbar HX 170-230-270
19
Maintenance
Service Check / Re-tightening
Re-tighten everything after 2 hours of operation. Pay special attention to
hydraulics and cutting edges.
Re-tighten everything after 10 hours of operation.
Re-tighten / check all bolts every 8 hours.
Dismount the hydraulic system protective cover and remove twigs and dirt from
the housing.
Following service, remount all shields, guards and protective plates.
Check the spring stop bolt tension. Adjust to 52 mm. See Illustration 2.
Illustration 2.
Lubrication
Lubricate the machine every 8 operating hours. Use more lubrication when working in
a particularly demanding environment.
Following cleaning:
Lubricate all machine parts and auxiliary equipment each time the machine has been
cleaned.
Hydraulic Hoses
Carefully check the condition of all hoses regularly. Ensure that hoses are not rubbing
against machine edges, bolts or similar.
Check the condition of all hydraulic hoses and fittings daily. Immediately correct any
and all damaged or leaking parts. This is part of the daily maintenance routine and it is
your responsibility to ensure that the machine will have a long service life.
Replace hoses with broken metal bands.
The hydraulic system uses a very high pressure. Always use original hoses. Ruptured
hoses may be lethal.

Cutterbar HX 170-230-270
20
Avoid twisting the fittings when replacing a hose. Use two single-head wrenches to
loosen and tighten hoses etc. Hoses will be impaired if they are twisted during
installation. Pressure pulses in twisted hoses tend to stress the steel net of the hose.
See Illustration 1.
Always ensure that protective hoses are in good condition. It is cheaper to replace a
protective hose than to replace valuable hoses.
Illustration 1.
The warranty on the hoses covers only the replacement of hoses due to defective
materials or manufacturing defects. The warranty does not cover the following:
1. Hoses that are damaged due to rubbing
2. Wear and tear
3. Hoses that have been cut or crushed during operation
4. Damage to threads due to excessive tightening
BSP
(size)
Tightening torque
¼”
24 Nm
18 ibs/ft
⅜”
33 Nm
24 ibs/ft
½”
44 Nm
35 ibs/ft
¾”
84 Nm
62 ibs/ft
1”
115 Nm
85 ibs/ft
