0.5 GALLON
MULTI-PURPOSE
SPRAYER
56167
®
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 18l
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2018 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly an d se rv ic e may n ot b e in cl uded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 56167
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
IMPORTANT SAFETY INFORMATION
Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in serious injury.
Work Area
1. Keep your work area clean and well lit.
Cluttered dark areas invite accidents.
2. The work area should have adequate
drainage to reduce the possibility of
a fall due to slippery surfaces.
3. Keep bystanders, children, and visitors
away while operating the Sprayer.
Distractions can cause you to lose control.
Personal Safety
1. Follow all guidelines regarding
chemicals sprayed, including MSDS
instructions and EPA regulations.
2. Stay alert. Watch what you are doing and use
common sense when operating the Sprayer.
Do not use the Sprayer while tired or under
the influence of drugs, alcohol, or medication.
A moment of inattention while operating the
Sprayer may result in serious personal injury.
3. Dress properly. Do not wear loose clothing or
jewelry. Contain long hair. Keep your hair and
clothing away from moving parts. Loose clothes,
jewelry, or long hair can be caught in moving parts.
4. Do not overreach. Keep proper
footing and balance at all times.
Proper footing and balance enable better
control of the tool in unexpected situations.
5. Always wear eye protection.
Wear ANSI-approved safety goggles.

Page 3For technical questions, please call 1-888-866-5797.Item 56167
Use
1. Use only for water or weed killer, household
cleaning, fertilizer and insecticide.
2. Release pressure in Bottle by pulling up
on the Pump Handle before loosening
or removing parts. Contents are under
pressure and may spurt forcefully.
3. Do not point the Sprayer at yourself,
other people or animals.
4. Do not allow access to treated
areas by people or animals.
5. Industrial applications must follow
OSHA requirements.
6. Make sure the liquid used in the
Sprayer is not dirty or sandy.
7. This product is not a toy. Do not allow
children to play with or near this item.
8. Use as intended only.
9. Inspect before every use; do not use
if parts are loose or damaged.
10. Before filling, pull up on Pump Handle to ensure
that it operates properly and does not stick.
11. Maintain product labels and nameplates.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
12. The warnings and cautions discussed in this
manual cannot cover all possible conditions
and situations that may occur. The operator
must understand that common sense and
caution are factors that cannot be built into this
product, but must be supplied by the operator.
Service
1. Have your Sprayer serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of
the tool is maintained.
2. Store idle tools and equipment out of
reach of children and other untrained
people. Tools and equipment are dangerous
in the hands of untrained users.
3. Maintain the Sprayer with care. Keep
this product clean. A properly maintained
Sprayer is easier to control.
SAVE THESE INSTRUCTIONS.

Page 4 For technical questions, please call 1-888-866-5797. Item 56167
Specifications
Capacity 0.5 gallon
Components and Controls
Nozzle
Trigger
Handle
Pump
Bottle
Lid
Trigger
Lock
®

Page 5For technical questions, please call 1-888-866-5797.Item 56167
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document
including all text under subheadings therein before set up or use of this product.
Inspect Sprayer before use, looking for damaged, loose, and missing parts.
If any problems are found, do not use Sprayer until repaired.
Follow all guidelines regarding chemicals sprayed, including MSDS instructions and EPA regulations.
Release pressure in Bottle by pulling up on the Pump Handle and slowly twisting Lid
before fully removing it. Contents are under pressure and may spurt forcefully.
1. Before filling, pull up on Pump Handle to ensure
that it operates properly and does not stick.
2. Twist the Lid counter clockwise and remove it,
along with the Pump assembly, from the Bottle.
3. Pour liquid into the Bottle’s top opening.
Fill no higher than the Max fill line.
WARNING! Use only for water or weed killer,
household cleaning, fertilizer and insecticide.
4. Insert the Pump assembly all the way down into the
Bottle and twist the Lid clockwise to tighten securely.
5. Press and pull the Pump Handle a few times to build
pressure then point the Nozzle toward the area to
be sprayed. Depress the Trigger to begin spraying.
6. Turn the Nozzle to adjust spray pattern.
7. For continuous spray, press the Trigger Lock
down and forward until it locks, then release it.
8. To stop continuous spray, press down
and pull back on the Trigger Lock.
9. The Sprayer will depressurize during operation.
When the decreased pressure affects the spray
pattern, press and pull the Pump Handle until proper
pressure is achieved, then resume spraying.
10. When finished spraying:
• Depressurize the Sprayer.
• Dispose of liquid.
• Clean the Sprayer according to
Maintenance Instructions.
• Store Sprayer indoors out of children’s reach.
®

Page 6 For technical questions, please call 1-888-866-5797. Item 56167
Inspection, Maintenance, and Cleaning
Procedures not specifically explained in this manual must
be performed only by a qualified technician.
Do not use damaged equipment. If abnormal noise, vibration, or
leaking air occurs, have the problem corrected before further use.
Follow all guidelines regarding chemicals sprayed, including MSDS instructions and EPA regulations.
Release pressure in Bottle by pulling up on the Pump Handle and slowly twisting Lid
before fully removing it. Contents are under pressure and may spurt forcefully.
1. BEFORE EACH USE, inspect the general
condition of the Sprayer. Check for:
• loose hardware
• misalignment or binding of moving parts
• cracked or broken parts
• any other condition that may
affect its safe operation
2. AFTER EVERY USE, clean the Sprayer:
a. Flush with water.
b. Clean Nozzle and Filter.
c. Rinse with water and allow to air-dry.
3. PERIODICALLY, lubricate all moving parts of
the pump assembly with petroleum jelly.
4. Store the Sprayer in a safe, dry, clean location
out of reach of children and out of sunlight.
Troubleshooting
Problem Possible Causes Likely Solutions
Unit does not spray
1. Inlet Hose detached.
2. Not enough liquid in Bottle.
3. Lid is loose.
4. Nozzle is closed.
5. Sprayer not pressurized.
6. Nozzle and/or Filter clogged.
1. Reattach Inlet Hose.
2. Add liquid to Bottle.
3. Tighten Lid.
4. Turn Nozzle to open and adjust spray.
5. Press and pull Pump Handle
to pressurize Sprayer.
6. Disassemble, clean, then reassemble
Nozzle and/or Filter.
Spray pattern is undesirable
1. Nozzle needs adjustment.
2. Spray fluid contains
particles or sand.
3. Nozzle and/or Filter clogged.
1. Adjust Nozzle.
2. Disassemble, clean, then reassemble
Nozzle and/or Filter. Empty, clean, then
refill bottle with properly strained fluid.
3. Disassemble, clean, then reassemble
Nozzle and/or Filter.
Follow all safety precautions whenever diagnosing or servicing the Sprayer.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.

Page 7For technical questions, please call 1-888-866-5797.Item 56167
Parts List and Diagram
Part Description Qty
1 Pump Handle 1
2 Pump Rod 1
3 Fastener 1
4 O-Ring 1
5 Pump Cover 1
6 Trigger Lock 1
7 Trigger 1
8 Lid 1
9 O-Ring 1
10 O-Ring 1
11 Pump Hose 1
12 Piston 1
13 Glass Ball 1
Part Description Qty
14 Piston Seal 1
15 Inlet Tube 1
16 Bottle 1
17 Filter 1
18 O-Ring 1
19 Fixing Plate 1
20 Spring 1
21 Piston Rod 1
22 Pad 1
23 Nozzle Screw 1
24 O-Ring 1
25 Nozzle 1

®
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • 1-888-866-5797
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
