Gregoire Besson Tetra 3001 L User manual

EN: Operating Instructions
Implement serial no.
Mounted - Seed bed harrow
Tetra 3001 L, 4501 L, 6001 L, 7500 L, 9000 L
Tetra 4501 LS, 6001 LS
Series 0

© Copyright Grégoire Besson GmbH, Germany. Copying or
reproducing of this publication in other media, translations
or use of extracts or parts are not permitted without the
express permission of Grégoire Besson GmbH.
All rights reserved. The contents of these operating
instructions may change without notice. Subject to technical
modications

3
05.2012
Tetra
Subject to technical modications
The design and construction of this Tetra seed bed combination harrow, which you have
purchased, places great value on ease of use and a long service life.
Our range of products is completed by a comprehensive range of accessories, which
provides for a multitude of different uses.
The operating instructions are intended to familiarise you with the functions of the Tetra
seed bed combination harrow and provides descriptions on setup, operation, care and
maintenance tasks.
It is an integral part of the implement, and must always be carried on it or in the tractor's cab.
These operating instructions are intended for skilled agricultural workers and individuals,
who are employed in other qualied positions in the agricultural industry.
They assume that the user has already received instruction on how to operate this implement.
The individual descriptions are complemented by photographs and diagrams, illustrating the
Tetra seed bed combination harrow. The implement illustrated in these diagrams may differ
from the implement before you, due to the different equipment variants which exist.
All instructions pertaining to direction should be taken to mean in the direction of travel.
This document was produced using the information with respect to equipment and
operation, which was known at the time of printing.
Changes due to technical improvements are reserved.
In order to conrm that the initial commissioning and orientation on the implement with
respect to:
• Completeness of the scope of delivery
• Instruction/training on the safety instructions
• Instruction/training on operation
have taken place, please ll out the whole of the enclosed delivery declaration.
Return the original (see details on the declaration itself) to Grégoire Besson GmbH.
There is a copy of the delivery declaration in the Appendix. If the declaration is missing,
you can ll this out, then copy it and send it in.
NOTE
Should you decide to sell or hand on the used implement, the operating
instructions must be provided with it, and the purchaser should be instructed/
trained as to the safety instructions and how to operate it.
If you have any questions, contact your specialist dealer or us directly at:
Grégoire Besson GmbH • Am Rabewerk 1 • D-49152 Bad Essen • Germany
Phone: [phone] • Fax: [phone]
[email protected] • www.rabe-agri.eu
Before start-up, read and take note of the operating instructions and safety
instructions!
Introduction
Introduction

05.2012
4
Tetra
Subject to technical modications

5
05.2012
Tetra
Subject to technical modications
Contents
Introduction ......................................................................................................3
1.0 For your safety .................................................................................................9
1.1 Explanations about these operating instructions ............................................................9
1.2 Symbol descriptions........................................................................................................9
1.3 Target audience of these operating instructions .............................................................9
1.4 General safety information............................................................................................10
1.5 Intended use .................................................................................................................10
1.6 Who may operate the implement ..................................................................................10
1.6.1 Denition of personnel qualication .................................................................. 11
1.7 Operator's position........................................................................................................ 11
1.8 Safety instructions - General usage.............................................................................. 11
1.9 Safety instructions - Loading.........................................................................................12
1.10 Safety instructions - Coupling and uncoupling..............................................................13
1.11 Safety instructions - Hydraulics.....................................................................................13
1.12 Ballast calculation .........................................................................................................14
1.13 Safety instructions - Travelling by road / transport........................................................14
1.14 Safety instructions - Field use.......................................................................................14
1.15 Safety instructions - Care, maintenance and repair......................................................15
1.16 Meaning of the safety symbols on the implement.........................................................17
2.0 Variants ...........................................................................................................19
3.0 Scope of delivery............................................................................................20
3.1 Basic equipment ...........................................................................................................20
3.2 Additional equipment ....................................................................................................22
4.0 Description of the implement........................................................................23
4.1 Functional description ..................................................................................................23
4.2 Description of the components .....................................................................................24
4.3 Description of the components .....................................................................................24
4.3.1 Tower ................................................................................................................24
4.3.2 Tine eld ...........................................................................................................25
4.3.3 Tines .................................................................................................................26
4.3.4 Spike disc harrow or crosskill roller ..................................................................26
4.3.5 Tine trailer.........................................................................................................27
4.3.6 Wheel mark eradicator [additional equipment] .................................................28
4.3.7 Lighting (additional equipment)........................................................................28
4.3.8 Support wheel (additional equipment) - Tetra 7500 L, 9000 L ..........................28
4.4 Technical data ...............................................................................................................29
4.4.1 Dimensions in basic conguration ....................................................................29
4.4.2 Weight and data in basic conguration............................................................30
4.4.3 Maximum permissible dimensions and weights for transport by road ..............30
4.4.4 Required electrical connection (for additional equipment)................................30
4.4.5 Required hydraulic connection .........................................................................30
4.5 The type plate and its position ......................................................................................31
4.6 Safety components .......................................................................................................31
4.6.1 Transport lock - Only for folding variants with spike disc harrow......................31
4.6.2 Side arm locking - Tetra 7500 L, 9000 L ...........................................................32
4.6.3 Roller binder .....................................................................................................32
Contents

05.2012
6
Tetra
Subject to technical modications
5.0 Loading ...........................................................................................................33
6.0 Preparations ...................................................................................................35
6.1 Checking requirements for the tractor ..........................................................................35
6.2 Ballast weight ...............................................................................................................35
6.3 Adjusting the track width of the wheel mark eradicator (additional equipment) ............36
7.0 Coupling the implement ................................................................................37
7.1 Coupling the bottom links..............................................................................................37
7.2 Coupling the top link .....................................................................................................38
7.3 Install the cable for releasing the side arm locking on Tetra 7500 L, 9000 L ................39
7.4 Connecting lighting (additional equipment)...................................................................39
7.5 Connecting hydraulic lines - Folding cylinder and additional equipment ......................40
7.5.1 Required hydraulic connections........................................................................40
7.5.2 Connecting hydraulic lines................................................................................41
7.6 Insert the supports ........................................................................................................42
8.0 Travelling by road...........................................................................................43
8.1 Transport instructions....................................................................................................43
8.2 Machine identification / lighting .....................................................................................44
8.3 Preparations for travelling by road ................................................................................45
8.4 Travelling by road..........................................................................................................45
9.0 Workingintheeld ........................................................................................46
9.1 Safety during operation.................................................................................................46
9.2 Working speed .............................................................................................................46
9.3 Preparations in the field ................................................................................................46
9.4 Fold machine out into working position.........................................................................47
9.5 Adjust the working depth of the tine fields ....................................................................48
9.6 Adjust the height of the tine trailer ................................................................................49
9.6.1 Tine trailer.........................................................................................................49
9.6.2 Hydraulic tine trailer (additional equipment) .....................................................50
9.7 Adjusting the working depth of the wheel mark eradicator (additional equipment).......51
9.8 Adjust the height of the support wheels - Tetra 7500 L, 9000 L....................................52
9.9 Working information ......................................................................................................52
9.10 Adjustments during operation .......................................................................................52
9.11 Remove wall of earth in front of tine trailer ...................................................................53
9.12 Rectifying blockages .....................................................................................................53
10.0 After working - fold in the implement...........................................................54
10.1 Preparations for folding in the implement .....................................................................54
10.2 Folding the Tetra to the transport position.....................................................................55
11.0 Set implement down and uncouple..............................................................57
11.1 Note the following before setting down .........................................................................57
11.2 Pull out the set-down supports and lower the implement .............................................58
11.3 Separating hydraulic connections - Folding cylinder and additional equipment ...........59
11.4 Separating lighting (additional equipment)....................................................................59
11.5 Uncoupling the top link..................................................................................................60
11.6 Uncoupling the bottom links..........................................................................................60
Contents

7
05.2012
Tetra
Subject to technical modications
12.0 Cleaning ..........................................................................................................61
12.1 Safety instructions, cleaning .........................................................................................61
12.2 Cleaning........................................................................................................................61
13.0 Storing the implement ...................................................................................61
14.0 Maintenance....................................................................................................62
14.1 Safety instructions - maintenance.................................................................................62
14.2 Who may carry out maintenance ..................................................................................62
14.3 Maintenance schedule ..................................................................................................63
14.4 Lubricating points..........................................................................................................64
14.5 Tighten allbolts ..............................................................................................................66
14.6 Support wheels tyres pressures....................................................................................66
14.7 Checking the hydraulic system .....................................................................................67
15.0 Repair ..............................................................................................................68
15.1 Safety instructions - Repairs .........................................................................................68
15.2 Who may carry out repairs............................................................................................68
15.4 Replacing shares or tines .............................................................................................69
15.4.1 Preparation .......................................................................................................69
15.4.2 Turning / replacing shares ................................................................................70
15.4.3 Replace tines ....................................................................................................70
15.4.4 Tine spacing, mild harrow tines ........................................................................71
15.4.5 Tine spacing, reinforced dual spring tines, upright vibra-tines..........................72
15.5 Replacing tine trailer tines or bars ................................................................................73
15.5.1 Preparation .......................................................................................................73
15.5.2 Tine trailer - Moving / replacing tines................................................................74
15.5.3 Replacing tine trailer bars .................................................................................74
15.6 Replacing wheel mark eradicator shares......................................................................75
15.6.1 Preparation .......................................................................................................75
15.7 Replacing bulbs in the lighting system..........................................................................76
16.0 Assembly after delivery.................................................................................77
16.1 Safety instructions - Assembly ......................................................................................77
16.2 Parts delivered separately ............................................................................................77
16.3 Installing spike disc harrow / crosskill roller ..................................................................78
16.3.1 Preparation with Tetra 6001..............................................................................78
16.3.2 Installing spike disc harrow on Tetra.................................................................79
16.3.3 Installing crosskill roller on Tetra.......................................................................80
16.4 Installation of the roller binder on spike disc harrow for Tetra 3001 L,
6001 L, 9000 L ..............................................................................................................81
16.5 Installing the roller binder on the crosskill rollers on the Tetra 6001 LS........................82
16.6 Installing the transport lock ...........................................................................................83
17.0 Install lighting (additional equipment) .........................................................84
17.1 Safety instructions - Assembly ......................................................................................84
17.2 Scope of delivery - lighting............................................................................................84
17.3 Installation preparations, from 4.5 m working width......................................................85
17.4 Installing the lighting bracket onto the Tetra with dual spike disc harrow......................85
17.4.1 Installation process ...........................................................................................85
17.4.2 Determine the connection point for the lighting bracket....................................85
17.4.3 Installing lighting bracket on Tetra 3001 L, 6001 L............................................86
Contents

05.2012
8
Tetra
Subject to technical modications
17.4.4 Installing lighting bracket on Tetra 4501 L.........................................................87
17.4.5 Fastening the lighting unit onto the lighting bracket - Tetra ..............................88
17.5 Installing the lighting bracket onto the Tetra with crosskill roller ...................................89
17.5.1 Installation process ...........................................................................................89
17.5.2 Determine the connection point for the lighting bracket....................................89
17.5.3 Installing lighting bracket with adapter on Tetra 6001 LS .................................90
17.5.4 Installing lighting bracket on Tetra 4501 LS ......................................................91
17.5.5 Fastening the lighting unit onto the lighting bracket - Tetra LS .........................92
17.6 Lay lighting cable ..........................................................................................................93
17.6.1 Installing lighting cable on Tetra 3001 L, 6001 L, 6001 LS ...............................93
17.6.2 Installing lighting cable on Tetra 4501 L, 4501 LS ............................................94
18.0 Disposal of the implement.............................................................................95
19.0 Appendix.........................................................................................................96
19.1 Ballast calculation - combination of the tractor and implement.....................................96
19.2 Position of the safety symbols ......................................................................................98
19.2.1 Safety symbols, Tetra 3001 L............................................................................98
19.2.2 Safety symbols, Tetra 4501 L, 4501 LS, 6001 L, 6001 LS,
7500 L, 9000 L..................................................................................................99
19.3 Torques for metric screws - standard threads............................................................100
19.4 Electrical diagram - lighting (additional equipment) ....................................................101
19.5 Hydraulic diagram - Folding hydraulics.......................................................................102
19.6 Hydraulic diagram - Tine trailer (additional equipment) ..............................................103
20.0 Productdelivery/rstusedeclaration......................................................105
21.0 EU Declaration of Conformity .....................................................................107
22.0 Index..............................................................................................................109
Contents

9
05.2012
Tetra
Subject to technical modications
1.1 Explanations about these operating instructions
The individual descriptions are complemented by photographs and diagrams.
We would like to advise you that the implement depicted in the photos may differ from the standard
scope of delivery.
All information pertaining to directions or sides are given as seen when facing the driving direction.
Safety
1.0 For your safety
1.3 Target audience of these operating instructions
These operating instructions are intended for skilled agricultural workers and
individuals, who are employed in other qualied positions in the agricultural
industry and who have received instruction on working with this implement.
1.2 Symbol descriptions
The operating instructions use the following symbols to identify hazards which occur
when using the implement or information on using the implement.
Symbol
in this
docu-
ment
Meaning
Hazard warning
Hazard warnings allude to risks which occur when using the implement.
The hazard warnings are arranged into different levels and are described with
the signal words “Danger, Warning, Caution”.
The signal words specify the severity of the impending hazard.
Danger
Identies hazards with a high degree of risk.
Failure to observe these hazards can result in the most serious injuries or death.
Warning
Identies hazards with a moderate degree of risk.
Failure to observe these hazards can result in serious injuries or death.
Caution
Identies hazards with a low degree of risk.
Failure to observe these hazards can result in moderate injuries.
ATTENTION
Information on using the implement. Failure to observe these instructions can
result in malfunctions to its proper functioning.
NOTE
Instructions which help to simplify use of the implement and the operating in-
structions are indicated by this symbol.
►List of working instructions
1aItem designations in gures
(Not
shown)
This item does not appear in the gure
WAF Width across ats for the tool to be used

10 05.2012
Tetra
Subject to technical modications
1.5 Intended use
The implement is intended exclusively for its normal usage in agricultural work.
Any use surpassing this is regarded as non-intended use. The manufacturer shall not be liable for
any damage resulting from this. It is solely the user who bears this risk.
The intended use also involves compliance with the operating, servicing and repair instructions
specied by the manufacturer.
The implement may only be used by individuals who are familiar with its features. Instructions for
operation, service and the safe use of the implement, as indicated in the operating instructions in the
form of warning notices and on the implement in the form of warning signs, must be observed.
The applicable accident prevention rules as well as any other generally accepted safety
requirements, occupational health and trafc regulations must be observed.
Any unauthorised changes to the implement exclude from the manufacturer's liability for any damage
resulting from this.
Foreseeable incorrect use
In order to prevent use of the implement in a manner not intended by the operating instructions, the
warning notices and warning signs indicate potential incorrect use. The instructions provided must be
observed at all times.
1.6 Who may operate the implement
Qualied persons only.
The implement may only be operated, maintained or repaired by persons whose qualications
authorise them to do so and who are sufciently informed with regard to the dangers involved with
operating the equipment.
In general, these persons have received agricultural education or are comparably trained.
1.4 General safety information
Take note of the safety instructions
• in the interests of your own safety
• in the interests of the safety of your colleagues
• in order to guarantee the safety of the equipment.
A number of hazards may occur as the result of incorrect operation of agricultural implements. You
should therefore work with particular care and never in a hurry.
►Familiarise yourself with the contents of these operating instructions prior to start-up or assembly
of this implement.
►Make sure that the operating instructions have been read and understood by all persons working
with the implement or charged with care or maintenance tasks.
►Make sure that all persons working with the implement or charged with care-related tasks have
access to the operating instructions at all times.
►Regularly inform those working with the implement about the safety instructions and statutory
regulations.
►Conduct training on a regular basis for all persons who work with the implement; at least once a
year.
Untrained or unauthorised personnel may not use the implement.
Safety

11
05.2012
Tetra
Subject to technical modications
1.7 Operator's position
The operator's position is on the driver's seat of the tractor. This is where the implement is
operated from.
The implement may only be operated by a single person, from the driver's seat of the tractor.
Safety
1.8 Safety instructions - General usage
WARNING
Risk of accident and injury due to missing or incorrect operator safety equipment.
• Always wear the prescribed work clothing, e.g. closely-tting clothing, safety shoes and
protective gloves, when carrying out all work on or with the implement.
DANGER
Risk of accident due to operating errors.
• Prior to starting work or starting up the implement, familiarise yourself with all equipment
and operating controls and their functions.
WARNING
Risk of accident due to failure to establish operational and road safety.
• Bear in mind the maximum permitted dimensions and axle loads for the tractor/implement
combination.
• Follow the general safety and accident prevention regulations.
• Check the tractor and implement for operational and road safety prior to every start-up.
• Before rst use, re-tighten all bolts to the stipulated tightening torque.
• All safety devices must be fully installed and secured.
• Prescribed setting, maintenance and inspection work must be carried out within the
required timeframe.
DANGER
Risk of accident due to riding on the implement during operations and transport.
• Riding on the implement and standing within areas of danger is prohibited.
Risk of accident due to uncontrolled movements of the tractor/implement
combination.
• The operator must not leave the operator's platform while the vehicle is in motion.
• Before leaving the tractor, always:
- wait until the implement has come to a complete standstill
- lower the implement fully
- apply the tractor's parking brake
- switch off the engine
- remove the ignition key
1.6.1 Definition of personnel qualification
Qualiedpersons
Persons, who have been trained in the tasks assigned to them, who have been briefed on the
potential dangers with improper conduct and who have been instructed with regards to the necessary
protective equipment and measures.
Specialists
Persons with specialist technical training. Due to their qualications and knowledge of the applicable
regulations they are able to evaluate the work assigned to them and identify potential hazards.

12 05.2012
Tetra
Subject to technical modications
Accident and injury hazard due to damaged parts.
• Only use the implement when it is in a technically awless condition.
• Take damaged implements out of service immediately and secure them against being
re-used.
Risk of accident due to components swinging out.
• No persons may be standing in the slewing range during slewing in or out operations.
Risk of injury due to heavy components.
• When handling heavy components, use suitable lifting accessories or seek the assistance
of a second person.
WARNING
Risk of accident when lifting implements or implement combinations with the
tractor's three-point linkage.
• When lifting implements, make sure that the they do not collide with components of the
tractor, e.g. the rear window.
• When lifting implements, make sure that no persons are standing in the danger area.
• When lifting implements, make sure that there is adequate clearance around the
implement.
WARNING
Risk of accident from the folding and unfolding of implement parts.
• When folding and unfolding implement parts, make sure that no persons are standing in
the danger area.
• When folding and unfolding implement parts, make sure that there is adequate clearance
around the implement.
• Close the rear window on the tractor.
DANGER
Electric shock due to overhead power lines.
• When lifting implements and folding/unfolding implement parts, ensure that sufcient
clearance is left for power lines.
Safety
1.9 Safety instructions - Loading
DANGER
Risk of accident due to suspended loads.
• Do to walk under suspended loads.
• Do not stand under or in the vicinity of the implement while it is lifted.
• When lifting the implement, proceed with care and pay attention to balance.
• Only lift the implement with the designated crane points.

13
05.2012
Tetra
Subject to technical modications
1.11 Safety instructions - Hydraulics
WARNING
 Riskofaccidentduetohydraulicuidescapingathighpressure.
The hydraulic system is under high pressure; hydraulic uid may escape when connecting
or disconnecting hydraulic hoses.
• When connecting or disconnecting, make sure that the hydraulic system on the tractor
(oating position) and on the implement have been depressurised!
Risk of accident due to operating errors caused by improperly connected hydraulic
hoses.
Incorrectly connected hydraulic hoses may result in malfunctions and serious injury or
death.
When connecting, ensure that:
• the hydraulic hoses are connected to the prescribed connections.
Riskofinjuryandinfectionduetohydraulicuidpenetratingundertheskin.
Fluids (hydraulic oil) escaping under high pressure may penetrate the skin and cause
severe injury.
• Check hydraulic hoses regularly and replace if damaged or aged!
Only use original spare parts!
• Use suitable tools when looking for leakages!
• Set down implement, depressurise the system, switch off the engine and remove the
ignition key before commencing work on the hydraulic system!
• Consult a doctor immediately in case of injury!
1.10 Safety instructions - Coupling and uncoupling
WARNING
Risk of accident while coupling the implement to and uncoupling it from the tractor.
• During coupling and uncoupling, no person may stand between the tractor and the
implement; also do not step between the tractor and the implement while operating the
external hydraulics control.
• Take note of all crushing and shearing points on all moving parts of the implement.
• Before coupling and uncoupling the hydraulic plug couplings, depressurise the hydraulic system.
Follow the operating instructions and safety instructions.
• Prior to uncoupling:
- wait until the implement has come to a complete standstill
- lower the implement fully
- apply the tractor's parking brake
- switch off the engine
- remove the ignition key
• Secure the implement from rolling away. If necessary, apply the handbrake, apply the
brake on the implement.
• Secure the implement from rolling away by using wheel chocks.
Safety

14 05.2012
Tetra
Subject to technical modications
Safety
1.12 Ballast calculation
WARNING
Risk of accident due to inadequate steering and braking power and stability caused
byincorrectlyconguredballastoffset.
Incorrectly congured or absent ballast offset may negatively affect the steering, braking
and stability of the tractor.
• The tractor/implement combination must never be used without the calculated front or
rear ballasting.
See the Appendix for the calculation formulas.
• Never use the tractor/implement combination if the weight or axle load exceeds the
permitted values for the tractor or tyres.
1.13 Safety instructions - Travelling by road / transport
WARNING
Risk of accident while transporting the implement by road.
• Pay attention to national laws and regulations on the use of public highways.
• Ensure that the lights on your implement are in an excellent condition.
An implement with defective lighting is not roadworthy.
• Lock the hydraulic control devices to prevent accidental operation, before each journey by
road.
• Before moving off, check the immediate vicinity. No item or person may be in the
immediate vicinity.
• The operator must not leave the operator's platform while the vehicle is in motion.
Risk of accident due to unsecured attachment components.
• Secure all components of the attachment to prevent uncontrolled movements, using the
retaining system provided (transport lock) or other suitable measures.
• Always use the supplied covers (e.g. tine protection equipment).
Risk of accident due to wide working radius of the implement.
During cornering, the wide working radius of the implement can cause accidents.
• When cornering and making turns, pay attention to obstacles and the trafc situation.
Risk of tipping due to the large centrifugal mass of the implement.
When cornering, the large centrifugal mass can cause the implement to tip over.
• Drive slowing when cornering and in turns.
1.14 Safety instructions - Field use
WARNING
 Riskofaccidentwhileusingtheimplementintheeld.
• Prior to starting work, familiarize yourself with all equipment and operating controls and
their functions.
• Before start-up, check the immediate vicinity. No item or person may be in the immediate
vicinity.
• Only perform adjustment work with the implement lowered.
WARNING
Risk of accident due to objects being ejected.
• Before start-up, check the immediate vicinity. No item or person may be in the immediate
vicinity.

15
05.2012
Tetra
Subject to technical modications
Safety
1.15 Safety instructions - Care, maintenance and repair
WARNING
Risk of accident when performing maintenance work.
• You should always work with particular care and never in a hurry.
• When working on attached implement:
- wait until the implement has come to a complete standstill
- lower the implement fully
- switch off the engine
- remove the ignition key
• Before performing work on the hydraulic system, lower the implement and depressurise
the system.
• When performing care and maintenance tasks, wear work gloves and the prescribed
working clothing.
• All tasks must be performed using suitable tools.
• Always disconnect the power before starting any work on the electrical system (e.g.
lighting)!
• Separate the implement from the tractor before welding work.
• Secure the implement to prevent unauthorised start-up while such work is in progress.
WARNING
Risk of accident due to pinching or crushing while performing adjustment, care,
maintenance and repair work.
• Turn off the engine of the tractor and take the key out of the ignition.
• Only perform work when the implement is in a safe condition and has been secured to
prevent it from dropping and rolling away.
Use all provided supports.
• During all work, wear work gloves, the prescribed working clothing and protective
equipment.
• If the implement is folded, use additional means to secure it against unfolding
unintentionally.
- Close the provided shut-off valves, engage mechanical locks.
Risk of accident due to failure to perform maintenance tasks or not doing so properly.
• Replace self-locking nuts during reassembly with new ones.
• Do not replace self-locking nuts with normal nuts.
• For threaded connections with spring washers, inspect the spring washers during
reassembly, and if necessary replace with new ones.
• Never replace shear bolts with standard bolts.
• Only replace nuts and bolts, where necessary, with those of the same strength class, e.g.
8.8.
• Observe the tightening torques.
• Check the tyre pressure regularly.
• Perform a regular visual inspection of the brake system for damage and leaks.
• Only use original spare parts.
Risk of tipping due to the large centrifugal mass of the implement.
When working on a slope, the large centrifugal mass can cause the implement to tip over.
• Pay attention to the position of the centre of gravity during lifting and turning.

16 05.2012
Tetra
Subject to technical modications
Safety
Risk of injury due to heavy components.
• When handling heavy components, use suitable lifting accessories or seek the assistance
of a second person.
Risk of accident due to defective brake systems
(dependent on equipment).
Improper repairs to the brake systems cause the brakes to fail and result in serious
accidents.
• Adjustment and repair work on brake systems may only be performed by individuals with
the proper technical training or by service centres.
Risk of accident due to improperly carried out work on tyres and wheels.
The removal and installation of wheels requires thorough expertise and approved mounting
tools.
• Repairs to tyres and wheels may only be undertaken by service centres.

17
05.2012
Tetra
Subject to technical modications
Order no. Warning signs Meaning
9998.02.59
9998.02.59
Read the operating instructions before start-up.
Observe the safety instructions.
Observe the transport and assembly instructions.
9998.02.73
9998.02.73
Re-tightenallboltsafterrstuse
Check that all bolts are tightly secured on a regular basis.
Applicable breakaway torques see operating instructions or spare
parts list. Use torque wrench.
9998.02.56
9998.02.56
Riding on the implement while it is operational or being
transported is not permitted.
Only step on the loading ramp or platform while the implement is at a
standstill, fully mounted and securely supported.
9998.02.53
9998.02.53
Fold-out side parts. Keep your distance.
Stay out of the folding area.
Check that there is adequate free space when folding out.
9998.06.29
9998.06.29 Fold-out side parts.
Maintain sufcient distance from high voltage lines.
9998.02.81
9998.02.81
Crushing hazard when staying between tractor and the
implement.
When coupling the implement combination to the tractor, ensure that
no-one is standing between the tractor and the implement!
Do not step between the tractor and the implement when activating
the external control for the three-point linkage.
9998.02.61
9998.02.61
Risk of crushing. Keep your distance.
Do not reach into the crushing hazard zone so long as parts can
move there.
9998.02.84
9998.02.84
Hazard due to projectile foreign bodies.
Keep your distance. Direct persons to leave the hazard area.
9998.06.26
max.200bar
9998.06.26
Operating pressure
The operating pressure of the hydraulic system must not exceed 200
bar.
1.16 Meaning of the safety symbols on the implement
The following labels are afxed to the implement, for your safety.
These labels must not be removed.
Damaged or illegible labels must be replaced.
The position of safety symbols is detailed in the diagrams in the Appendix.

18 05.2012
Tetra
Subject to technical modications
Safety symbols
Order no. Warning signs Meaning
9998.06.27
9998.06.27 Exercise great care with the emergence of high pressure liquid.
Risk of injury and infection due to hydraulic uid penetrating under
the skin.
Observe information in the operating instructions.
9998.06.17
9998.06.17
Read the operating instructions prior to set-up, maintenance
and repair
Observe the safety instructions.
Observe the set-up and assembly instructions.
9998.02.63
9998.02.63
Do not remain in the vicinity of the implement when lifted up.
Attaching lifting accessories here.

19
05.2012
Tetra
Subject to technical modications
2.0 Variants
Variants
Fig. 1; Tetra variants

05.2012
20
dcba
1
2
3
Tetra
Subject to technical modications
3.0 Scope of delivery
Before start-up, check the delivery for
completeness.
Inform your dealer, importer or
manufacturer immediately in writing of any
missing parts or parts damaged during
transport.
NOTE
A few parts must be tted after
delivery.
More information on this can be
found in Chapter “Assembly after
delivery“ - Page 77.
Scope of delivery
3.1 Basic equipment
Included in the delivery:
1) Implement with either:
a) Mild harrow tines, or
b) Upright mild harrow tines, or
c) Dual spring reinforced tines, or
d) Upright vibra-tines
Fig. 2; Scope of delivery
Fig. 3; Scope of delivery - tines
Fig. 4; Scope of delivery - Dual spike disc
harrow
Fig. 5; Scope of delivery - Spike disc, roller
binder
2) L variant - with dual spike disc harrow
3) Roller binder for dual spike disc harrow
