Griots Garage 11923 User manual

DIGITAL
TORQUE
WRENCH
Useful Instructions

Thank you for purchasing this fine product
from
GRIOT'S GARAGE
. The
DIGITAL TORQUE
WRENCH
enables you to accurately set fas-
WRENCH enables you to accurately set fas-WRENCH
tener torque with a convenient LCD display
and audible beep alert. Before operating
the torque wrench, please read this manual
completely, and keep it nearby for future
reference.
MAIN FEATURES
•
Digital torque value
readout +/- 1
~
5% accuracy
•
Peak and track mode selectable
•
Beeper and LED indicator for the
user preset target torque
•
Units of Measure ( ft-lb, in-lb, N-m)
selectable 30 data memory for recall
and joint torque
•
Auditing Auto Sleep after 2 minutes idle
• Auditing Auto Sleep after 2 minutes idle •
•
Power supplied by 2- AA batteries
NAMES & FUNCTIONS OF PARTS
NAMES & FUNCTIONS OF PARTS
1. Reversible Ratchet
Head
2. Direction Lever
3. LCD Readout
4. Buttons
5. Buzzer
6. Battery Compartment
7. Battery Cover
8. Ratchet Drive
9. Handle
10. Torque Value
11. Units (N-m, in-lb, ft-lb)
12. P (peak hold mode)
T (track mode)
13. LED indicator
14. Menu Button
15. Cancel Button
16. Enter (OK) Button
17. Up Button
18. Down Button

SPECIFICATIONS
Accuracy *1
+
/
+
/
+
-
/
-
/
2.5% (CW) and
+
/
+
/
+
-
/
-
/
3.5% (CCW)
Max Range 10-147 ft.-lbs
Operation Mode Peak hold/Track
Unit Selection in.-lb, ft.-lb, N-m
Length 20
7
/
7
/
7
8
/
8
/
"
Square Drive
1
/
1
/
1
2
/
2
/
"
Head Type Lever type ratchet
Gear Teeth 36
Battery AA X 2
Battery Life *2 110 hrs.
(Continuous operation)
1 year
(Standby)
Operating Temperature 14°F
~
140°F
Storage Temperature -4°F
~
158°F
Humidity ≥ 90% non condensing
Drop Test 1 m
Vibration Test *3 10 G
Life Time *4 10,000 cycle
Environmental Test *5 Pass
Electromagnetic
Compatibility Test *6 Pass
*1: The torque accuracy is a typical value. The
calibration point is at the middle line of the
five anti-grip lines on the rubber handle. For
keeping the accuracy, calibrate the wrench
for a constant period time (1 year).
*2: Use two AA battery (Toshiba carbon-zinc
R6UG battery)
*3: Horizontal and vertical test
*4: One cycle means swing the torque wrench
from 0 N-M to maximum range and back to
0 N-M.
*5: Environmental test:
a. Dry heat
b. Cold
c. Damp heat
d. Change of temperature
e. Impact (shock)
f. Vibration g. Drop
*6: Electromagnetic compatibility test:
a. Electrostatic discharge immunity (ESD)
b. Radiated susceptibility
c. Radiated emission
BATTERIES
Before using the Digital Torque Wrench you
must install the batteries. To start remove the bat-
tery cover. Insert two AA batteries matching the
+
/
+
/
+
-
/
-
/
polarities of the battery to the battery compart-
- polarities of the battery to the battery compart- -
ment. Install the battery cover and rotate it tightly
according to the following figures on the last page.

SETUP
Press Cancel button to turn power on.
To start you need to select one of the three
units of measurement; In-Lbs, Ft-Lbs, N-m.
Press the Menu button and scroll to the Unit
window. Using Up and Down arrows, select
your unit preference.
Next, press Menu button again until window
shows "nodE" and then select the operating
mode.
PEAK HOLD MODE - (MAIN OPERATING MODE)
During this mode of operation the LCD will
show the maximum torque value applied to
the fastener. Once displayed you must push
the Cancel button to clear the reading in
preparation for the next fastener.
TRACK MODE
Track mode will display the real time torque
as the wrench is in operation. Track mode
data will only display on the LCD while in
use, and resets to zero when use is discon-
tinued.
The wrench will auto sleep after 2 minutes
idle for power saving. Press Cancel button to
resume use of the torque wrench.
RESETTING TORQUE WRENCH
Press Cancel and Up Arrow buttons at the
same time to reset the torque wrench.
LOW BATTERY
Replace the battery when the low battery
indicator is shown in the upper left corner of
the LCD window.
CARE AND STORAGE
1. Do not store wrench exposed to high heat,
humidity, or direct sunlight.
2. Do not use torque wrench under wet
weather conditions or near standing water.
3. If the wrench gets wet, wipe it dry as soon
as possible.
4. Avoid solvents, such as alcohol or paint
thinner to clean the wrench.

5. Keep the wrench away from magnets.
6. Do not expose the wrench to dust or sand
as this could cause serious damage.
7. Do not shake or shock the wrench.
8. Over torquing can cause breakage.
9. Do not apply pressure to the LCD panel.
BATTERY HANDLING NOTES
1. Remove the batteries for extended storage.
2. Keep spare batteries on hand when going
on a long trip or to a cold area.
3. Do not mix battery types or combine used
batteries with new ones.
4. Wipe battery terminals before loading to
ensure proper connection.
5. Dispose of batteries in a designated dispos-
al area. Do not throw batteries into a fire.
BATTERY ACCESS DIAGRAM

ANSWERS TO YOUR QUESTIONS
ANSWERS TO YOUR QUESTIONS
Should you want to order another
G RIOT ' S
G ARAGE
D IGITAL T ORQUE W RENCH
, or for a
complete selection of quality
G RIOT ' S G ARAGE
products, please write or call us toll-free at
800-345-5789. You can use the Internet at
www.griotsgarage.com.
Reorder item number
11923
.
Have fun in your garage!
®
