-4- Model G0638HEP (Mfd. Since 7/20)
Inventory
After all the parts have been removed from the
boxes, you should have the following items:
Inventory (Figures 2–6): Qty
A. Upper Stand Braces ................................... 4
B. Upper Stand Legs ...................................... 4
C. Filter Adapters ............................................ 2
D. Control Box Bracket ................................... 1
E. Lower Stand Legs ...................................... 4
F. Cyclone Mounting Brackets ....................... 4
G. HEPA Filter Support Leg (3 Pieces) .......... 1
H. Handle Hook ............................................... 1
I. Lower Stand Braces ................................... 4
Figure 3. Inventory items J–O.
I
J
KL
M
N
P. Blower Housing with Motor ........................ 1
Q. Control Box ................................................. 1
R. Remote Control .......................................... 1
S. Collection Lid Handle ................................. 1
T. Casters 4" ................................................... 4
U. Drum Lid Connecting Plates ...................... 2
V. Collection Drum Lid .................................... 1
W. Front Drum Panel ....................................... 1
X. Right Drum Panel ....................................... 1
Y. Left Drum Panel ......................................... 1
Z. Rear Drum Panel ....................................... 1
AA. Base Drum Panel ....................................... 1
NOTICE
If you cannot find an item on this list, care-
fully check around/inside the machine and
packaging materials. Often, these items get
lost in packaging materials while unpack-
ing or they are pre-installed at the factory.
The following is a list of items shipped with your
machine. Before beginning setup, lay these items
out and inventory them.
If any non-proprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
J. Outlet Port .................................................. 1
K. Intake Cylinder ........................................... 1
L. Cyclone Funnel (Small) .............................. 1
M. Intake Barrel ............................................... 1
N. Cyclone Funnel Adapter ............................. 1
O. Cyclone Funnel (Large) .............................. 1
Figure 2. Inventory items A–I.
A
B
D
E
F
H
C
G
(Replaces Pages 4–5 in Manual Insert)
Figure 4. Inventory items P-AA.
O
P
Q
R
S
T
U
V
W X
YZ
AA
