Grizzly G1030 User manual

DUST COLLECTOR
MODEL G1030
PARTS LIST
COPYRIGHT © 1991 BY GRIZZLY INDUSTRIAL, INC. REG # 3 176 555
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
REVISED FEBRUARY 1999. PRINTED IN USA
PARTS LIST DISCLAIMER
THIS PARTS LIST AND DRAWINGS REPRESENT THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED. THE MACHINE CON-
FIGURATION CAN CHANGE AS PRODUCT IMPROVEMENTS ARE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF THE MACHINE, THIS PARTS
LIST MAY NOT DEPICT YOUR MACHINE EXACTLY. CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS ABOUT PART DIFFERENCES.
PREVIOUS PARTS LIST VERSIONS ARE NOT AVAILABLE ONLINE.

REF PART # DESCRIPTION
1P1028001 CASTER
2PFB01 FLANGE BOLT 5⁄16"-18 x 1⁄2"
3P1030003 BASE PLATE
4PS06 PHLP HD SCREW 10-24 x 3/8"
5P1030005 INLET COVER
6P1028007 CAP SCREW M6-1 x 19 LH
7PB09 HEX BOLT 5⁄16"-18 x 1⁄2"
8P1028009 SPECIAL WASHER
9P1029010 TURBO FAN
10 P1028011 COLLECTOR BODY
11 PW07 FLAT WASHER 5⁄16"
12 DISCONTINUED
13 PFB01 FLANGE BOLT 5⁄16"-18 x 1⁄2"
14 PB03 HEX BOLT 5⁄16"-18 x 1"
15 PSW04 SWITCH
16 P1030016 MOTOR, 3HP
17 PN02 HEX NUT 5⁄16"-18
18 P1030018 OUTLET
19 P1030019 LEFT COLLECTOR
20 G4996 DUST COLL BAG, LOWER
21 P1028023 COLLECTOR SUPPORT
22 P1030022 RIGHT COLLECTOR
23 P1028028 PACKING
24 P1028026 UPPER BAG SUPPORT
25 G1027 DUST COLL BAG, UPPER
26 P1028025 GASKET
27 P1030027 INLET
28 PK28M KEY 7 x 7 x 29
29 PWRCRD220L POWER CORD, 220V, LONG
29A P1029029A INLET CAP
30 PWR1012 WRENCH 10 X 12
31 PAW05M ALLEN®WRENCH 5mm
32 G3707 68" BAND CLAMP
33 PS06 PHLP HD SCREW 10-24 x 3⁄8"
34 PWRCRD220S POWER CORD, 220V, SHORT
-B- G1030 Dust Collector

2
10
23
23
23
26
20
20
22
21
24
25
13
16
15
11
17
29
7
9
86
32
5
33
4
27
29A
3
30
31
1
34
28 2
2
18
2
14
11
2
21
24
13
2
19
25
32
