Grizzly G3102 User manual

MODEL G3102/G3103

VERTICAL MILL

OWNER'S MANUAL

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

#TS11100 PRINTED IN CHINA

This manual provides critical safety instructions on the proper setup,

operation, maintenance, and service of this machine/tool. Save this

document, refer to it often, and use it to instruct other operators.

Failure to read, understand and follow the instructions in this manual

may result in fire or serious personal injury—including amputation,

electrocution, or death.

The owner of this machine/tool is solely responsible for its safe use.

This responsibility includes but is not limited to proper installation in

a safe environment, personnel training and usage authorization,

proper inspection and maintenance, manual availability and compre-

hension, application of safety devices, cutting/sanding/grinding tool

integrity, and the usage of personal protective equipment.

The manufacturer will not be held liable for injury or property damage

from negligence, improper training, machine modifications or misuse.

Some dust created by power sanding, sawing, grinding, drilling, and

other construction activities contains chemicals known to the State

of California to cause cancer, birth defects or other reproductive

harm. Some examples of these chemicals are:

• Lead from lead-based paints.

• Crystalline silica from bricks, cement and other masonry products.

• Arsenic and chromium from chemically-treated lumber.

Your risk from these exposures varies, depending on how often you

do this type of work. To reduce your exposure to these chemicals:

Work in a well ventilated area, and work with approved safety equip-

ment, such as those dust masks that are specially designed to filter

out microscopic particles.

Table of Contents

SECTION 5: ACCESSORIES ......................... 31

SECTION 6: MAINTENANCE......................... 33

Schedule ...................................................... 33

Cleaning & Protecting .................................. 33

Lubrication ................................................... 34

SECTION 7: SERVICE ................................... 37

Troubleshooting ........................................... 37

Adjusting Gibs .............................................. 39

Adjusting Backlash....................................... 40

SECTION 8: ELECTRICAL ............................ 41

Electrical Safety Instructions ........................ 41

110V Electrical Wiring Diagram ................... 42

220V Conversion Wiring Diagram ............... 44

SECTION 9: PARTS....................................... 45

Head ............................................................ 45

Main ............................................................. 47

Electrical & Accessories .............................. 49

Label Placement .......................................... 50

WARRANTY AND RETURNS ........................ 53

INTRODUCTION............................................... 2

Manual Accuracy ........................................... 2

Contact Info.................................................... 2

Functional Overview ...................................... 2

Identification ................................................... 3

G3102 Machine Data Sheet .......................... 4

G3103 Machine Data Sheet .......................... 7

SECTION 1: SAFETY..................................... 10

Safety Instructions for Machinery ................ 10

Additional Safety Instructions for Mills ......... 12

SECTION 2: CIRCUIT REQUIREMENTS ...... 13

110/220V Operation ..................................... 13

220V Conversion ......................................... 14

SECTION 3: SETUP ....................................... 15

Setup Safety ................................................ 15

Items Needed for Setup ............................... 15

Unpacking .................................................... 15

Inventory ...................................................... 16

Clean Up ...................................................... 17

Site Considerations ...................................... 17

Moving & Placing Mill................................... 18

Mounting to Shop Floor ............................... 19

Assembly ..................................................... 20

Test Run ...................................................... 21

Spindle Break-In .......................................... 22

Recommended Adjustments ........................ 22

SECTION 4: OPERATIONS ........................... 23

Operation Safety .......................................... 23

Table Movement .......................................... 23

Model G3103 Power Feed ........................... 25

Head Rotation .............................................. 26

Turret Rotation ............................................. 26

Setting Spindle Speed ................................. 27

Downfeed Controls ...................................... 29

Loading/Unloading Tooling .......................... 30

-2- G3102/G3103 Vertical Mill

INTRODUCTION

We stand behind our machines. If you have any

service questions, parts requests or general ques-

tions about the machine, please call or write us at

the location listed below.

Grizzly Industrial, Inc.

1203 Lycoming Mall Circle

Muncy, PA 17756

Phone: (570) 546-9663

Fax: (800) 438-5901

E-Mail: [email protected]

If you have any comments regarding this manual,

please write to us at the address below:

Grizzly Industrial, Inc.

C/O Technical Documentation Manager

P.O. Box 2069

Bellingham, WA 98227-2069

Email: [email protected]

Contact Info

Functional OverviewManual Accuracy

We are proud to offer this manual with your new

machine! We've made every effort to be exact

with the instructions, specifications, drawings, and

photographs of the machine we used when writ-

ing this manual. However, sometimes errors do

happen and we apologize for them.

Also, owing to our policy of continuous improve-

ment, your machine may not exactly match

the manual. If you find this to be the case, and

the difference between the manual and machine

leaves you in doubt, immediately call our techni-

cal support for updates or clarification.

For your convenience, we always keep current

Grizzly manuals and most updates available on

our website at www.grizzly.com. Any updates to

your machine will be reflected in these documents

as soon as they are complete. Visit our site often

to check for the latest updates!

The vertical mill is used to remove material from

metal workpieces to form shapes. Tooling is

inserted into the spindle of the head, which can

be positioned in nearly any configuration above

the table and workpiece.

During most operations, the tooling rotates in the

spindle above the workpiece while the operator

moves the workpiece, which is clamped to the

table, in any combination of three paths of table

movement—longitudinal (X-axis), cross (Y-axis),

and vertical (Z-axis). The range of vertical move-

ment for the table is greater than that of the head

and spindle. However some operations, such as

drilling or tapping, are better accomplished with

vertical spindle movement using the coarse or

fine downfeed controls.

The operator selects available spindle speeds by

configuring the two V-belts across the motor, idler,

and spindle pulleys.

The Model G3103 has a longitudinal power

feed for consistent powered table movement

with adjustable limit stops for a preset range of

motion.

G3102/G3103 Vertical Mill -3-

Identification

Figure 1. Model G3102/G3103 identification.

B C

A. Fine Downfeed Handwheel

B. Coarse Downfeed Lever

C. V-Belt Cover

D. Longitudinal (X-Axis) Handwheel

E. Longitudinal Power Feed (Model G3103)

F. Knee

G. Cabinet Stand & Door

H. Power ON/OFF Switch & Spindle Direction

Switch

I. Cross (Y-Axis) Handwheel

J. Vertical (Z-Axis) Crank

K. Cross Slide

L. Table

M. Spindle Motor

N. Turret

O. Downfeed Selection Knob

P. Halogen Work Light

Q. Longitudinal Handwheel

R. One-Shot Way Oiler

S. Floor Mounting Points

T. Power Connection & Cable

U. Electrical Panel Access Cover

V. Column

W. Power ON/OFF Switch

X. Spindle Direction Switch

-4- G3102/G3103 Vertical Mill

The information contained herein is deemed accurate as of 3/2/2015 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 3Model G3102

MACHINE DATA

SHEET

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

MODEL G3102 VERTICAL MILL

Product Dimensions:

Weight.............................................................................................................................................................. 800 lbs.

Width (side-to-side) x Depth (front-to-back) x Height............................................................... 45-1/2 x 41 x 66-5/8 in.

Footprint (Length x Width)..................................................................................................................... 27-1/2 x 21 in.

Space Required for Full Range of Movement (Width x Depth).................................................................... 60 x 42 in.

Shipping Dimensions:

Type.......................................................................................................................................................... Wood Crate

Content........................................................................................................................................................... Machine

Weight.............................................................................................................................................................. 904 lbs.

Length x Width x Height....................................................................................................................... 37 x 41 x 76 in.

Must Ship Upright................................................................................................................................................... Yes

Electrical:

Power Requirement............................................................................................. 110V or 220V, Single-Phase, 60 Hz

Prewired Voltage.................................................................................................................................................. 110V

Full-Load Current Rating....................................................................................................... 16A at 110V, 8A at 220V

Minimum Circuit Size.......................................................................................................... 20A at 110V, 15A at 220V

Connection Type....................................................................................................................................... Cord & Plug

Power Cord Included.............................................................................................................................................. Yes

Power Cord Length................................................................................................................................................. 6 ft.

Power Cord Gauge......................................................................................................................................... 14 AWG

Plug Included.......................................................................................................................................................... Yes

Included Plug Type................................................................................................................................. 5-15 for 110V

Recommended Plug Type...................................................................................................................... 6-15 for 220V

Switch Type........................................................................................... 220V ON/OFF Push Button Magnetic Switch

Motors:

Main

Type................................................................................................................. TEFC Capacitor-Start Induction

Horsepower............................................................................................................................................. 1.5 HP

Phase............................................................................................................................................ Single-Phase

Amps....................................................................................................................................................... 16A/8A

Speed................................................................................................................................................ 1720 RPM

Power Transfer ............................................................................................................................... V-Belt Drive

Bearings..................................................................................................... Shielded & Permanently Lubricated

G3102 Machine Data Sheet

data sheets

G3102/G3103 Vertical Mill -5-

The information contained herein is deemed accurate as of 3/2/2015 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 2 OF 3Model G3102

Main Specifications:

Operation Info

Spindle Travel.............................................................................................................................................. 3 in.

Max Distance Spindle to Column.......................................................................................................... 5-1/2 in.

Max Distance Spindle to Table............................................................................................................ 12-1/2 in.

Longitudinal Table Travel (X-Axis)...................................................................................................... 15-5/8 in.

Cross Table Travel (Y-Axis)......................................................................................................................... 6 in.

Vertical Table Travel (Z-Axis).................................................................................................................... 14 in.

Vertical Head Travel (Z-Axis)................................................................................................................ 2-1/2 in.

Turret or Column Swivel (Left /Right)..................................................................................................... 45 deg.

Head Tilt (Left/Right).............................................................................................................................. 45 deg.

Drilling Capacity for Cast Iron...................................................................................................................... 1 in.

Drilling Capacity for Steel......................................................................................................................... 3/4 in.

End Milling Capacity................................................................................................................................. 3/4 in.

Face Milling Capacity................................................................................................................................... 3 in.

Table Info

Table Length.............................................................................................................................................. 26 in.

Table Width........................................................................................................................................... 6-1/8 in.

Table Thickness.................................................................................................................................... 1-3/4 in.

Number of T-Slots............................................................................................................................................ 3

T-Slot Size.............................................................................................................................................. 0.56 in.

T-Slots Centers.................................................................................................................................... 1-9/16 in.

X/Y-Axis Travel per Handwheel Revolution.......................................................................................... 0.125 in.

Z-Axis Travel per Handwheel Revolution............................................................................................. 0.062 in.

Spindle Info

Spindle Taper............................................................................................................................................... R-8

Number of Vertical Spindle Speeds.................................................................................................................. 9

Range of Vertical Spindle Speeds........................................................................................... 240 – 2760 RPM

Quill Diameter....................................................................................................................................... 2.950 in.

Drawbar Thread Size............................................................................................................................. 7/16-20

Drawbar Length................................................................................................................................... 12-1/4 in.

Spindle Bearings......................................................................................................... Tapered Roller Bearings

Construction

Spindle Housing/Quill........................................................................................................................... Cast Iron

Table.......................................................................................................................... Surface Ground Cast Iron

Head.................................................................................................................................................... Cast Iron

Column/Base....................................................................................................................................... Cast Iron

Base..................................................................................................................................................... Cast Iron

Stand.......................................................................................................................................................... Steel

Paint Type/Finish.................................................................................................................................... Enamel

Other

Recommended Mobile Base................................................................................................................. D2058A

Other Specifications:

Country of Origin ................................................................................................................................................ China

Warranty ........................................................................................................................................................... 1 Year

Approximate Assembly & Setup Time .............................................................................................................. 1 Hour

ISO 9001 Factory .................................................................................................................................................... No

CSA, ETL, or UL Certified/Listed ............................................................................................................................ No

Features:

High Precision Ground Vertical and Cross Ways

Milling Head Micro-Feed

Lower Noise and Convenient Operation

Built-In Work Light

-6- G3102/G3103 Vertical Mill

The information contained herein is deemed accurate as of 3/2/2015 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 3 OF 3Model G3102

Accessories Included:

Arbor

Drawbar

End Mill

Inner Hexagon Spanner

Oil Gun

Tool Box

Two Head Wrench

G3102/G3103 Vertical Mill -7-

G3103 Machine Data Sheet

The information contained herein is deemed accurate as of 3/2/2015 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 3Model G3103

MACHINE DATA

SHEET

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

MODEL G3103 VERTICAL MILL W/ TABLE POWER FEED

Product Dimensions:

Weight.............................................................................................................................................................. 900 lbs.

Width (side-to-side) x Depth (front-to-back) x Height............................................................... 45-1/2 x 41 x 66-5/8 in.

Footprint (Length x Width)..................................................................................................................... 27-1/2 x 21 in.

Space Required for Full Range of Movement (Width x Depth).................................................................... 60 x 42 in.

Shipping Dimensions:

Type.......................................................................................................................................................... Wood Crate

Content........................................................................................................................................................... Machine

Weight.............................................................................................................................................................. 926 lbs.

Length x Width x Height....................................................................................................................... 37 x 41 x 75 in.
