Grizzly G0490X Instruction Manual

The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 2Model G0490X
MACHINE DATA
SHEET
Customer Service #: [phone] · To Order Call: [phone] · Fax #: [phone]
MODEL G0490X 8" JOINTER W/ SPIRAL CUTTERHEAD
Product Dimensions:
Weight.............................................................................................................................................................. 508 lbs.
Length/Width/Height...........................................................................................................76-3/8 x 23-1/2 x 32-5/8 in.
Foot Print (Length/Width).................................................................................................................44-1/2 x 16-1/2 in.
Shipping Dimensions:
Carton #1
Type.................................................................................................................................................Wood Crate
Content..................................................................................................................................................Machine
Weight.................................................................................................................................................... 430 lbs.
Length/Width/Height...................................................................................................................81 x 25 x 13 in.
Carton #2
Type...................................................................................................................................................Cardboard
Content......................................................................................................................................................Stand
Weight.................................................................................................................................................... 167 lbs.
Length/Width/Height...................................................................................................................38 x 18 x 28 in.
Electrical:
Switch................................................................. Magnetic with Thermal Overload Protection with Large OFF Button
Switch Voltage......................................................................................................................................................220V
Cord Length............................................................................................................................................................ 6 ft.
Cord Gauge....................................................................................................................................................14 gauge
Minimum Circuit Size........................................................................................................................................ 20 amp
Plug Included............................................................................................................................................................No
Motors:
Main
Type..................................................................................................................TEFC Capacitor Start Induction
Horsepower.................................................................................................................................................3 HP
Voltage........................................................................................................................................................220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................Single
Amps.............................................................................................................................................................15A
Speed.................................................................................................................................................3450 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ...................................................................................................................................Belt Drive
Bearings.............................................................................................................................Sealed Ball Bearings
Main Specifications:
Fence Information
Fence Length............................................................................................................................................. 36 in.
Fence Width...........................................................................................................................................1-1/4 in.
Fence Height................................................................................................................................................5 in.
Fence Stops................................................................................................................................45 and 90 deg.

The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 2 OF 2Model G0490X
Cutting Capacities
Bevel Jointing......................................................................................................................Left & Right 45 deg.
Maximum Width of Cut.................................................................................................................................8 in.
Maximum Depth of Cut..............................................................................................................................1/8 in.
Maximum Rabbeting Depth.......................................................................................................................1/2 in.
Number of Cuts Per Minute.......................................................................................................................21400
Cutterhead Information
Cutterhead Type........................................................................................................................................Sprial
Cutterhead Diameter..............................................................................................................................3-3/8 in.
Number of Cutter Spirals...................................................................................................................................4
Number of Indexable Cutters..........................................................................................................................40
Cutter Insert Type..................................................................................................................Indexable Carbide
Cutter Insert Length................................................................................................................................. 14 mm
Cutter Insert Width...................................................................................................................................14 mm
Cutter Insert Thickness..............................................................................................................................2 mm
Cutterhead Speed..............................................................................................................................5350 RPM
Table Information
Table Length........................................................................................................................................76-3/8 in.
Table Width..................................................................................................................................................8 in.
Table Thickness.....................................................................................................................................1-1/2 in.
Floor to Table Height............................................................................................................................32-5/8 in.
Table Adjustment Type...................................................................................................................Lever Action
Table Movement Type..................................................................................................................Parallelogram
Construction
Body Assembly Construction................................................................................................................Cast Iron
Cabinet Construction.................................................................................................................One Piece Steel
Fence Assembly Construction..............................................................................................................Cast Iron
Guard Construction..................................................................................................................... Die Cast Metal
Table Construction...................................................................................................Precision Ground Cast Iron
Dovetailed Ways on Bed................................................................................................................................No
Parallelogram................................................................................................................................................Yes
Paint...........................................................................................................................................Powder Coated
Other Information
Number of Dust Ports........................................................................................................................................1
Dust Port Size.............................................................................................................................................. 4 in.
Mobile Base.............................................................................................................................................Built-In
Other Specifications:
Country Of Origin ................................................................................................................................................China
Warranty ............................................................................................................................................................1 Year
Serial Number Location ...............................................................................................................................Data Plate
Assembly Time .................................................................................................................................................2 hours
Features:
Parallelogram Bed Adjustment
Sprial Cutterhead with German-Made Indexable Carbide Inserts
Top Mount Switch Controls
Built-In, Easy-to_use Mobile Base
5" Tall Fence
Included 4" Dust Port
Included Push Blocks
