Grove GMK 5100 User manual

Operating instructions for lattice extension
2 084 770 en
08.05.2003
Serial number:
51009349

©Copyright reserved by Deutsche GROVE GmbH
The passing on or duplication of this document as well as the utilization and disclosure of its contents are prohibited
unless expressly permitted. Infringement will incur liability to compensation. All rights pertaining to registration of patent
or utility model are reserved.
Important note
Duplications of any kind and excerpts from this
document are not subject to the revision service.
Original documents of Deutsche GROVE GmbH
are marked with the blue serial number of the
truck crane on the cover page.
Duplications and print-outs of data carriers on
which Deutsche GROVE GmbH has delivered this
document are also not subject to the revision
service.
08.05.2003
51009349

The following chapters are contained in these operating
instructions:
1 Important information
2 Transport dimensions and weights
3 Two-stage swing-away lattice extension
4 Boom extension
5 Auxiliary single-sheave boom top
6 Heavy load lattice extension
Alphabetical index
08.05.2003
51009349

08.05.2003
51009349

Table of content
1 Important information . . . . . . . . . . . . . . . . . . . 1 - 1
1.1 About these operating instructions . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
1.2 Basic safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2
1.2.1 Warnings and symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2
1.3 Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3
1.4 Organizational measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5
1.5 Personnel qualifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 7
1.6 Safety instructions for truck crane work . . . . . . . . . . . . . . . . . . . . . 1 - 8
1.7 The units of measurement in US units . . . . . . . . . . . . . . . . . . . . . . 1 - 10
2 Transport dimensions and weights . . . . . . . . . . . . 2 - 1
2.1 In metric units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
2.1.1 Two-stage swing-away lattice extension and boom extension . . . . . . . 2 - 1
2.1.2 Auxiliary single-sheave boom top . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
2.2 In US units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2
2.2.1 Two-stage swing-away lattice extension and boom extension . . . . . . . 2 - 2
2.2.2 Auxiliary single-sheave boom top . . . . . . . . . . . . . . . . . . . . . . . 2 - 2
3 Two-stage swing-away lattice extension
(additional equipment) . . . . . . . . . . . . . . . . . . . 3 - 1
3.1 Identification of the two-stage swing-away lattice extension . . . . . . . . . 3 - 1
3.2 Assembly of lattice extensions . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 3
08.05.2003
Operating instructions for lattice extension 2 084 770 en i - 1
GMK 5100
51009349

3.3 Centre of gravity positions for slinging . . . . . . . . . . . . . . . . . . . . . 3-4
3.4 Check lists for rigging work . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
3.4.1 Overview of the required rigging work . . . . . . . . . . . . . . . . . . . . 3 - 5
3.4.2 CHECKLIST: Installing two-stage swing-away lattice extension . . . . . . . 3 - 6
3.4.3 CHECKLIST: Removing (two-stage) swing-away lattice extension . . . . . . 3 - 7
3.4.4 CHECKLIST: Rigging the 11 m swing-away lattice extension . . . . . . . . 3 - 9
3.4.5 CHECKLIST: Unrigging the 11 m swing-away lattice extension . . . . . . . 3 - 13
3.4.6 CHECKLIST: Rigging the 18 m two-stage swing-away lattice extension . . . 3 - 17
3.4.7 CHECKLIST: Unrigging the 18 m two-stage swing-away lattice extension . 3 - 21
3.5 Description of rigging work . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 27
3.5.1 Preparing the truck crane for rigging . . . . . . . . . . . . . . . . . . . . . 3 - 27
3.5.2 Checking the transport condition . . . . . . . . . . . . . . . . . . . . . . . . 3 - 29
3.5.3 Folding the run-up rail out/in . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 32
3.5.4 Connections with folded lattice extension . . . . . . . . . . . . . . . . . . . 3 - 33
3.5.5 Pin connections on the main boom head . . . . . . . . . . . . . . . . . . . 3 - 39
3.5.6 Pin connections on the lattice extension . . . . . . . . . . . . . . . . . . . . 3 - 42
3.5.7 Swivelling lattice extension onto the main boom head . . . . . . . . . . . 3 - 45
3.5.8 Swivelling the lattice extension when rigging . . . . . . . . . . . . . . . . . 3 - 46
3.5.9 Adjusting angle on the lattice extension . . . . . . . . . . . . . . . . . . . . 3 - 48
3.5.10 Folding deflection sheave on 11 m section out/in . . . . . . . . . . . . . . . 3 - 51
3.5.11 Positioning/removing the hoist cable . . . . . . . . . . . . . . . . . . . . . 3 - 52
3.5.12 Electrical connection on the lattice extension . . . . . . . . . . . . . . . . 3 - 55
3.5.13 Lifting limit switch on the lattice extension . . . . . . . . . . . . . . . . . . 3 - 58
3.5.14 Anemometer on the lattice extension . . . . . . . . . . . . . . . . . . . . . 3 - 60
3.5.15 Transportation on a separate vehicle . . . . . . . . . . . . . . . . . . . . . 3 - 61
3.6 Raising and setting down the main boom with rigged lattice extension . . . 3 - 63
3.7 Telescoping with rigged lattice extension . . . . . . . . . . . . . . . . . . . . 3 - 65
3.8 Operation with the lattice extension . . . . . . . . . . . . . . . . . . . . . . . 3 - 67
3.8.1 SLI shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 67
3.8.2 Procedure if the permissible wind speed is exceeded . . . . . . . . . . . . 3 - 68
3.9 Turning loads with the lattice extension . . . . . . . . . . . . . . . . . . . . . 3 - 69
3.9.1 Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 69
3.9.2 Setting SLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 70
3.10 Driving with rigged crane and lattice extension installed . . . . . . . . . . . 3 - 73
3.10.1 Driving route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 73
3.10.2 Position of the boom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 74
08.05.2003
i - 2 2 084 770 en Operating instructions for lattice extension
GMK 5100
51009349

3.10.3 Driving the rigged crane . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 77
3.11 Malfunction when working with lattice extension! . . . . . . . . . . . . . . . 3 - 80
3.12 Maintenance work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 81
3.12.1 Modules requiring protection during cleaning work . . . . . . . . . . . . . 3 - 81
3.12.2 Maintenance work M1, monthly . . . . . . . . . . . . . . . . . . . . . . . . 3 - 82
4 Boom extension (additional equipment) . . . . . . . . . 4 - 1
4.1 Identification and slinging points . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
4.1.1 Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
4.1.2 Slinging points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
4.2 Assembly of boom extensions . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 3
4.3 Check lists for rigging work . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 5
4.3.1 CHECKLIST: Installing the 26 m/34 m boom extension . . . . . . . . . . . . 4 - 5
4.3.2 CHECKLIST: Removing the 26 m/34 m boom extension . . . . . . . . . . . 4 - 8
4.4 Description of rigging work . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 11
4.4.1 Installing/disassembling 8 m sections . . . . . . . . . . . . . . . . . . . . . 4 - 11
4.4.2 Installing/removing two-stage swing-away lattice extension for boom
extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 12
4.4.3 Electrical connection on the boom extension . . . . . . . . . . . . . . . . . 4 - 13
4.4.4 Folding out/in the deflection sheaves on the 8 m sections . . . . . . . . . . 4 - 15
4.4.5 Positioning/removing the hoist cable . . . . . . . . . . . . . . . . . . . . . 4 - 16
4.5 Driving with a rigged crane if boom extension is rigged . . . . . . . . . . . . 4 - 19
4.5.1 Driving route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 19
4.5.2 Position of the boom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 20
4.5.3 Driving the rigged crane . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 22
4.6 Maintenance work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 25
4.6.1 Maintenance work M1, monthly . . . . . . . . . . . . . . . . . . . . . . . . 4 - 25
5 Auxiliary single-sheave boom top (additional equipment) 5 - 1
5.1 Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1
5.2 Installing/removing auxiliary single-sheave boom top . . . . . . . . . . . . 5 - 3
08.05.2003
Operating instructions for lattice extension 2 084 770 en i - 3
GMK 5100
51009349

5.2.2 Removing the auxiliary single-sheave boom top . . . . . . . . . . . . . . . 5 - 4
5.3 Rigging the auxiliary single-sheave boom top . . . . . . . . . . . . . . . . . 5-5
5.3.1 Rigging in transport position . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 5
5.3.2 Rigging in working position . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 6
5.3.3 Attaching and removing hoist cable . . . . . . . . . . . . . . . . . . . . . . 5 - 7
5.3.4 Possible reeving methods on the auxiliary single-sheave boom top . . . . 5 - 7
5.3.5 Lifting limit switch and anemometer . . . . . . . . . . . . . . . . . . . . . 5 - 8
5.4 Turning loads with the auxiliary single-sheave boom top . . . . . . . . . . . 5-9
6 Heavy load lattice extension . . . . . . . . . . . . . . . 6-1
6.1 Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6.2 Mount / remove heavy load lattice extension . . . . . . . . . . . . . . . . . . 6-3
6.2.1 Installing the heavy load lattice extension . . . . . . . . . . . . . . . . . . 6 - 3
6.2.2 Removing the heavy load lattice extension . . . . . . . . . . . . . . . . . 6 - 4
6.3 Rigging work check lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
6.3.1 CHECK LIST: Changing the heavy load lattice extension . . . . . . . . . . 6 - 5
6.3.2 CHECK LIST: Unrigging heavy load lattice extension . . . . . . . . . . . . 6 - 7
6.4 Rigging / unrigging the heavy load lattice extension . . . . . . . . . . . . . 6-9
6.4.1 Rigging the heavy load lattice extension . . . . . . . . . . . . . . . . . . . 6 - 9
6.4.2 Removing the heavy load lattice extension . . . . . . . . . . . . . . . . . . 6 - 19
6.5 Operation with the heavy load lattice extension . . . . . . . . . . . . . . . . 6 - 21
6.5.1 Telescoping with rigged heavy load lattice extension . . . . . . . . . . . . 6 - 22
6.5.2 Raising and placing the main boom with rigged heavy load lattice
extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 22
6.6 Turning loads with the heavy load lattice extension . . . . . . . . . . . . . . 6 - 23
08.05.2003
i - 4 2 084 770 en Operating instructions for lattice extension
GMK 5100
51009349

1Important information
1.1 About these operating instructions
HAll the lattice extensions described in these operating instructions can be
obtained as additional equipment.
Validity of this
operating manual
This operating manual only applies to lattice extensions which were deli-
vered by Deutsche GROVE GmbH.
In addition, for the operation of the truck crane with a lattice extension
described in these operating instructions, all details in the included Opera-
ting Instructions for the GMK 5100 (for which the lattice extension was deli-
vered from the factory) are applicable.
Prerequisites for
assembly and
operation
The lattice extensions described in these operating instructions may only
be operated together with a GROVE GMK 5100 truck crane whose serial
number is identical with the serial number that is marked on the lattice ex-
tensions.
Safety
instructions
The operation of the GMK 5100 with one of the lattice extensions descri-
bed in these operating instructions is subject to
– all the basic safety instructions to be found in the subsequent section
Basic safety instructions and
– all the safety instructions contained in the supplied operating instructi-
ons for the GMK 5100.
Reference to
other operating
instructions
Cross references to other operating or maintenance instructions are sta-
ted as follows:
➠GMK 5100 Operating Instructions, part 2 Superstructure – Rigging work
You will find the number of the chapter bearing the name Rigging work at
the front, on the second page of the stated operating instructions.
s
08.05.2003
Important information
1.1 About these operating instructions
Operating instructions for lattice extension 2 084 770 en 1 - 1
GMK 5100
51009349

1.2 Basic safety instructions
1.2.1 Warnings and symbols
The following definitions and symbols are used in the operating instructi-
ons to highlight particularly important information:
GThis symbol indicates hazards related to the described operation that
may cause personal injury. The type of danger (e.g. danger of life, perso-
nal injury or risk of crushing) is as a rule specified in the warning sign.
SHere dangers are referred to which could put objects at risk, e.g. damage
to the truck crane, the load or the environment.
BThis symbol alerts you to situations where you are in danger of receiving
an electric shock.
OThis symbol is to remind you that you are working with substances which
pose a risk to the environment. Take particular care. Further information
about handling substances which are harmful to the environment;
➠Maintenance manual, Chapter Safety and environmental protection.
The vertical line to the left of the text indicates: this text regardless of its
length belongs to the warning symbol.
HThe hand with the pointing finger indicates passages that contain additio-
nal instructions and tips with regard to truck crane operation.
sThis symbol indicates that the topic is continued on the next page. So
turn to the next page!
08.05.2003
Important information
1.2 Basic safety instructions
1 - 2 2 084 770 en Operating instructions for lattice extension
GMK 5100
51009349

1.3 Proper use
The truck crane GMK 5100 was constructed in accordance with state of
the art technology and the recognized safety regulations. Nevertheless,
personal injury to the operator or a third party as well as damage to the
crane and other property may occur during use.
The truck crane may only be modified with the consent of the manufacturer.
The GMK 5100 truck crane must be in proper working condition and may
only be used for its intended purpose, while taking into account safe ope-
ration and any possible hazards.
Malfunctions that may affect the safe operation of the unit are to be
corrected immediately.
The GMK 5100 truck crane may only be operated at temperatures of be-
tween –25 and +40 °C if it is not equipped with the relevant special equip-
ment.
The GMK 5100 truck crane is to be used exclusivly for vertical lifting of
loads whose weight and centre of distribution are known. A hook block
must be reeved on the hoist rope and such lifting must be done only in
the permitted rigging modes. Any other use of the crane is considered im-
proper. The manufacturer is not liable for damage resulting from impro-
per or unauthorized use of the GMK 5100 truck crane. The user shall take
on full responsibility for any such use.
Proper use also entails
– observing all crane documentation consisting of the operating instruc-
tions, the lifting capacity table, the outrigger pressure table and the
safety manual,
– following the inspection and maintenance requirements specified in the
Maintenance manual.
s
08.05.2003
Important information
1.3 Proper use
Operating instructions for lattice extension 2 084 770 en 1 - 3
GMK 5100
51009349

Improper use includes:
– transporting loads on the carrier,
– pushing, pulling or lifting loads with the level adjustment system, the
beams or the outrigger cylinders,
– pushing, pulling or lifting loads off the ground using the slewing gear,
the derricking gear or the telescoping gear,
– pulling off fixed objects using the crane,
– two-hook operation with the boom extension and two-hook operation
on the main boom head without additional equipment,
– operation when crane is not on outriggers (free on wheels),
– defining SLI codes that do not correspond to the actual rigging mode,
– working with an overridden SLI or overridden lifting limit switch,
– after SLI deactivation, the radius must be increased by pulling the rai-
sed load at an angle (e.g. with a chain hoist).
– Misuse of the outrigger pressure display as a safety function to prevent
overturning after an SLI shutdown (outrigger pressure greater than 0 t),
– road driving in an unauthorized driving mode (axle load, dimension),
– moving the rigged crane in an unauthorized driving mode,
– the transportation of raised loads by moving the truck crane,
– use of equipment that is not authorized for use with the crane,
– transporting passengers on unauthorized parts of the vehicle,
– transporting passengers without previous written permission from the
manufacturer,
– carrying passengers outside the driver’s cab,
– loading and unloading work, i.e. continuous operation without a corre-
sponding break,
– usage for any kind of sport or recreation event, especially for “Bungee“
jumping.
08.05.2003
Important information
1.3 Proper use
1 - 4 2 084 770 en Operating instructions for lattice extension
GMK 5100
51009349

1.4 Organizational measures
The operating instructions and the lifting capacity table should be kept in
the truck crane for immediate access at all times and must not be remo-
ved from the truck crane. You need to have read and understood the ope-
ration and safety instructions in these operating instructions and to com-
ply with them when working.
In addition to the operating instructions and the lifting capacity table,
observe all general, statutory and otherwise applicable regulations con-
cerning accident prevention and environmental protection. You must
have read and understood these and work accordingly.
This could include:
– the use of hazardous materials,
– wearing personal protective equipment,
– traffic regulations or
– all applicable regulations concerning the operation of a crane.
Ensure that those appointed to work on the truck crane are given the infor-
mation required to carry out the work before starting operations. Give
your employees (e.g. banksmen, slingers, rigging personnel) appropriate
instruction.
Ensure that the maintenance personnel possess the necessary know-how
to safely operate the crane. Ensure that the maintenance personnel have
access to the operating instructions.
Only properly trained or instructed personnel may carry out work on the
truck crane.
Responsibilities related to crane operation, rigging, maintenance and re-
pair work must be clearly defined.
Ensure that only the appointed employees operate the truck crane.
Do not leave long hair down or wear loose clothing or jewellery (including
rings) when working with the crane. These could get caught or pulled into
the unit and result in injury.
Use your personal protective equipment whenever necessary or prescribed.
Observe all safety and warning signs on the truck crane.
Ensure that all safety and warning signs on the truck crane remain legible.
s
08.05.2003
Important information
1.4 Organizational measures
Operating instructions for lattice extension 2 084 770 en 1 - 5
GMK 5100
51009349

Note the operational organization on the site. Report your arrival to site
management. Ask for the personnel authorized to issue instructions.
Familiarize yourself with the location and operation of the fire extinguis-
hers on every site.
Note the fire alarm and fire fighting facilities on the site.
Should the operating behaviour of the truck crane change in such a man-
ner that safety is affected or if you doubt the truck craneïs operating safe-
ty, stop the machine immediately and inform the appropriate responsible
persons.
Do not modify any programs in programmable control systems (e.g. the SLI).
Do not modify or mount attachments to the truck crane without the con-
sent of the manufacturer, if such changes could affect the safety of the
unit. This also applies to
– installing safety devices,
– setting safety devices and valves.
Welding work on load-bearing parts may only be conducted by properly
qualified personnel following authorisation by the manufacturer. To avoid
any damage, especially to electronic parts, there are certain steps you
must take before doing any welding work. So always consult GROVE
Product Support before doing any welding work.
Ensure that both the prescribed periods and the periods specified in the
operating and maintenance instructions for regular testing, inspection
and maintenance work are maintained.
Replace the hydraulic hose lines at the prescribed intervals or have them
replaced, even if no safety defects are noticeable.
Replacement parts must fulfill the technical requirements prescribed by
the manufacturer. Genuine spare parts always meet these requirements.
It is imperative that appropriate service equipment be used when carrying
out repair work.
08.05.2003
Important information
1.4 Organizational measures
1 - 6 2 084 770 en Operating instructions for lattice extension
GMK 5100
51009349

1.5 Personnel qualifications
These operating instructions are not a training manual for prospective cra-
ne operators!
All descriptions are written explicitly for crane operators who have been
trained to operate truck cranes.
Employees in training may only operate the truck crane under strict super-
vision.
Only reliable personnel may operate the truck crane.
As a truck crane operator you are obliged to fulfill a number of require-
ments:
– You must possess a driving licence for this type of vehicle that is valid
in the country in which you are working.
– You must have general knowledge of crane operation and any qualifica-
tions that may be required by the country in which you are working.
– You must be familiar with and have understood the operating instruc-
tions.
– You must be familiar with and have understood the accident prevention
regulations.
– You must be in proper physical and psychological condition for opera-
ting the truck crane, e.g. perfect sight and vision or good reactive ability.
Please refer to the section titled You as crane driver and operator in the Safety
Manual.
Only experienced personnel familiar with the applicable accident preventi-
on regulations are authorized to sling loads and train crane operators.
Your responsibilities as a crane operator (including those concerning traf-
fic regulations) must be clearly defined. You must be in a position to refu-
se to carry out any instructions given to you by a third party that violate
safety regulations.
Only trained, experienced personnel with special knowledge in the fields
of hydraulics, pneumatics and electrical equipment may carry out main-
tenance work on the truck crane.
The Deutsche GROVE GmbH gives general and type-related crane opera-
tor and technical courses.
08.05.2003
Important information
1.5 Personnel qualifications
Operating instructions for lattice extension 2 084 770 en 1 - 7
GMK 5100
51009349

1.6 Safety instructions for truck crane work
Carefully select a safe site for the truck crane to stand from where you can
safely work.
Walk around the truck crane before beginning crane work. Check the con-
dition of the truck crane carefully using the check lists in the operating in-
structions. Do not assume that everything is in working order simply
because it was in working order when work was last completed.
Each day, before you start to work with the crane, check that all covers
and safety devices are correctly fitted and that they are all in a proper
working condition.
Check the safety devices each day before beginning work (SLI, lifting limit
switch, dead man’s switch, emergency stop switch for crane control).
Use the appropriate access aids when carrying out overhead rigging or
maintenance work. Do not use parts of the crane as access aids.
Walk only on those machine parts which are equipped with appropriate
steps and railings and therefore guarantee safety. During rigging and
maintenance work on machine sections above body height which have no
apparatus for walking, use the extendable ladder which accompanies the
machine (e. g. when reeving the hoist cable on the boom nose).
Keep all handles, steps, step treads and ladders free of dirt, snow and ice.
Check all operating and control elements in the crane operator’s cab
before starting the crane engine.
Monitor all warning and indicator lamps as well as the control instru-
ments when the engine is started!
Make sure that there are no unauthorised people in the vicinity of or on
the truck crane when rigging or during crane work. Secure the danger
zone using cordons and mark them as such.
When lifting a load, raise the boom to balance out the increase in radius
caused by the boom bending so that the load is lifted up when in a verti-
cal position and does not drag, injure helpers or fall into the hoist cable
diagonally (e.g. from a vehicle or scaffold). Inform banksmen and helpers
about this as well.
08.05.2003
Important information
1.6 Safety instructions for truck crane work
1 - 8 2 084 770 en Operating instructions for lattice extension
GMK 5100
51009349

Support the truck crane with the supporting span for the current rigged
counterweight before turning the superstructure.
Ensure that the truck crane is horizontally aligned before carrying out
crane work.
Only use equipment (counterweight sections, lattice extensions) that be-
longs to your truck crane. The serial number of both the truck crane and
the equipment must be identical.
Simultaneously lifting loads with two cranes is particularly dangerous.
Use extreme caution when carrying out this type of work.
When work is interrupted, always put the load down and never leave the
truck crane if a load is raised.
Lock the truck crane when you leave the cab to prevent unauthorised use.
Crane work carried out in the vicinity of electric cables as well as oil, gas
and other supply lines is dangerous and requires that special precau-
tionary measures be taken. Please refer to the section titled Crane operation
under special operating conditions in the Safety Manual and observe the rele-
vant national regulations.
Always check if all other required connections are established, before you
loosen a connection between the lattice extension and main boom or a
connection between the lattice extension sections during rigging or unrig-
ging work. Never loosen all the connections.
08.05.2003
Important information
1.6 Safety instructions for truck crane work
Operating instructions for lattice extension 2 084 770 en 1 - 9
GMK 5100
51009349

1.7 The units of measurement in US units
These operating instructions use mainly metric units of measurement.
Should you be working in a country that uses US units of measurement,
refer to the following table for a comparison of the units.
– the first column shows the units of measurement as used in these in-
structions;
– the second column shows the converted units of measurement, which
are also used in the lifting capacity tables;
– the third column shows the rounded values which are used for better
legibility if both units of measurement are stated (in Chapter 2, Trans-
port dimensions and weights and in the diagrams showing the compo-
sition of the individual lattice extensions.
Stated length in
metric units of measurement
Corresponding length in
US units of measurement
acc. to lifting capacity table
Rounded length in
US units of measurement
in these operating instructions
11 m
Lattice extension
36.1 ft 36 ft
18 m
Two-stage swing-away lattice
extension
59.1 ft 59 ft
26 m
Boom extension
85.3 ft 85 ft
34 m
Boom extension
111.6 ft 112 ft
7msection 23.0 ft 23 ft
8msection 26.2 ft 26 ft
08.05.2003
Important information
1.7 The units of measurement in US units
1 - 10 2 084 770 en Operating instructions for lattice extension
GMK 5100
51009349

2Transport dimensions and weights
2.1 In metric units
This section contains the transport dimensions and weights of the lattice
extensions in metric units.
2.1.1 Two-stage swing-away lattice extension and boom extension
Description Length x width x
height (m)
Weight (kg)
Two-stage swing-away lattice
extension (complete folded)
11.50 x 1.00 x 1.50 1 400
11 m section 11.50 x 1.00 x 1.50 1 000
7 m section 7.20 x 0.60 x 0.70 400
8 m section with deflection
sheave
8.20 x 0.90 x 1.30 700
8 m section without deflection
sheave
8.20 x 0.90 x 1.30 650
2.1.2 Auxiliary single-sheave boom top
Description Length x width x
height (m)
Weight (kg)
Auxiliary single-sheave boom
top with pin
1.00 x 0.40 x 1.00 60
08.05.2003
Transport dimensions and weights
2.1 In metric units
Operating instructions for lattice extension 2 084 770 en 2 - 1
GMK 5100
51009349

2.2 In US units
This section contains the transport dimensions and weights of the lattice
extensions in US units.
2.2.1 Two-stage swing-away lattice extension and boom extension
Description Length x width x
height (ft)
Weight (lbs)
Two-stage swing-away lattice
extension (complete folded)
37.73 x 3.28 x 4.92 3 087
11 m section 37.73 x 3.28 x 4.92 2 205
7 m section 23.62 x 1.97 x 2.30 882
8 m section with deflection
sheave
26.90 x 2.95 x 4.27 1 543
8 m section without deflec-
tion sheave
26.90 x 2.95 x 4.27 1 433
2.2.2 Auxiliary single-sheave boom top
Description Length x width x
height (ft)
Weight (lbs)
Auxiliary single-sheave boom
top with pin
3.28 x 1.31 x 3.28 133
08.05.2003
Transport dimensions and weights
2.2 In US units
2 - 2 2 084 770 en Operating instructions for lattice extension
GMK 5100
51009349
