Grundfos GI SPC Series User guide

GRUNDFOS INSTRUCTION
GI SPC
Solar Pump Controller
Electrical installation and operating instruction

3
English (GB)
English (GB) Installation and Operating instructions
Original installation and operating instructions.
CONTENTS
Page
1 Safety instructions 4
1.1 Symbols used in this document 4
1.2 Danger 4
1.3 Warnings 4
1.4 Waste disposition 4
1.5 Purchase inspection before installation 4
1.6 Safety instructions for the operator/user 4
2 Introduction 5
3 Product Overview 5
3.1 Features 5
4 Technical data 6
4.1 Product range 6
4.1.1 Dimension 6
4.2 Technical data 7
4.2.1 Low Voltage Range (3 x 220 V) 7
4.2.2 High Voltage Range (3 x 380 V) 7
5 Installation 8
5.1 Installation Example 8
5.2 Cable Specification 8
5.3 Mechanical Installation 8
5.4 Electrical Installation 9
5.4.1 Control circuit wiring 9
5.4.2 Terminal arrangement 9
5.4.3 Terminal arrangement Description of function
terminals 10
5.4.4 Electrical wiring 10
AC input and output connections 10
DC input connections 10
Communication cable connections 11
6 Keypad Operation Procedure 12
6.1 Keypad introduction 12
6.2 Keypad display 13
6.2.1 Stop state parameter display 13
6.2.2 Running state parameter display 13
6.2.3 Fault state display 13
6.2.4 Function code editing state display 13
6.3 Keypad operation 14
6.3.1 Function code modification. 14
6.3.2 Password Setting 14
6.3.3 Monitoring Pump controller state 14
7 Parameters 15
7.1 Special function parameters 22
8 Fault finding 28
8.1 Fault codes and remedies 28
8.2 Fault codes reset 30
8.3 Fault history 30
8.4 LED Indications 30
9 Service and maintenance 31
9.1 Routine inspection 31
9.2 Storage and warranty 31
9.2.1 Storage 31
9.2.2 Warranty 31
10 Disposal 31
Warning
Prior to installation, read these installation
and operating instructions. Installation and
operation must comply with local
regulations and accepted codes of good
practice.

4
English (GB)
1 Safety instructions
These installations and operating instructions contain general
instructions that must be observed during the installation,
operation and maintenance of the inverter.
Before installing, commissioning or using the inverter, please
read the warning information contained in the Installation
Manual.
Please read the followingadditional safety instructions carefully.
Only authorized, trained and qualified personnel are allowed to
install, operate and maintain the drive
1.1 Symbols used in this document
1.2 Danger
These warnings are intended to personnel responsible for
grounding the inverter.
1.3 Warnings
1.4 Waste disposition
1.5 Purchase inspection before installation
If any deviation from the order is found, please contact Grundfos.
Once you get the product, please perform the following
inspections before installation:
Inspection item
Inspection method
Consistency with
ordered product
Inspect the product's nameplate
Damage or scratches
Inspect the product
visually
Completeness of
main inverter and
accessories
Check carefully according to the
product list
Are fastening parts,
such as screws,
tightened properly
Check with screwdriver, if necessary
1.6 Safety instructions for the operator/user
The safety instructions described in these instructions, existing
national regulations on health protection, environmental
protection and for accident prevention and any internal
working, operating and safety regulations of the operator must
be observed.
Warning
If these safety instructions are not observed, it
may result in personal injury.
If these safety instructions are not observed, it
may result in malfunction or damage to the
equipment.
Notes or instructions that make the job easier
and ensure safe operation.
Warning
If these instructions are not observed, it may lead
to electric shock with consequent risk of serious
personal injury or even death.
Warning
Sides of the inverter surface may be hot. Do not
touch
Warning
Damage to the PCBA board may occur if related
requirements are not followed.
Ground the frequency converter to ensure personnel
safety and to reduce electromagnetic interference.
After disconnecting the AC drive from
the mains or from the DC input supply, wait until
the indicators on the cover go out. Wait an
additional 5 minutes before starting any work on
the connections of Inverter. After expiration of this
time, use measuring equipment to absolutely
ensure that no voltage is present. Always ensure
absence of voltage before starting any electrical
work!
Never work on the photovoltaic generator or
inverter and its input/output cables when the
inverter is connected to the mains or to the
photovoltaic generator.
Before performing any measurement on the
inverter, disconnect or isolate the mains supply
voltage or the DC input supply.
Do not touch the components on the inverter or
on the string box cabinet that have high DC
voltage.
The photovoltaic generator cells exposed to light
supply DC voltage even at low light intensity.
Warning
There is heavy metal in the product. Deal with
it as industrial waste.
Warning
When the life cycle ends, the product should
enter the recycling system. Dispose of it
separately at an appropriate collection point
instead of placing it in the normal waste
stream.
Check the condition of the inverter before
installation. Please do not install the inverter if
the equipment appears to be damaged

5
English (GB)
2Introduction
This GI SPC User manuals describe the installation and
operation of the solar pump controller, It includes all the
required parameter settings and program features specific to
the solar pump controller.
3Product Overview
The GI SPC is an intelligent IP65 off-Grid solar pump controller is
designed to run with Grundfos pumps.
The GI SPC solar inverter is of high conversion efficiency. The GI
SPC solar inverter enables maximum power output of solar array
and then drive PMSM DC Pump motor.
Fig. 1 GI SPC system with solar package module
Pos.
Description
GC
Solar panels
GI SPC
Solar Pump Controller
SP
Submersible Pumps
The grid power and the Solar Panel (GC) is connected to the Solar
pump controller (GI SPC). Through the selector switch, the
required input power to the solar pump controller can be selected
either AC(grid power) or DC (solar Power) and the Output of the
solar pump controller (GI SPC) is connected to the Submersible
pump.
It is responsibility of the end user to provide the
correct power supply for installation (right
voltage, cable sizing, etc.). Also, the installation of the solar
package module, mechanical solar panels, montage of the solar
panel junction box. The final connection and verification must to
be performed by Grundfos or Authorized Service
Fig. 2 Schematic layout
3.1 Features
•Soft start function
•Lighting and Reverse polarity protection
•Protection against Overvoltage, Undervoltage and
overcurrent
•Advance MPPT that protect against power oscillation due to
rapid cloud movement.
•Sensor less dry run protection.
•LED indication for Run, Alarm and fault.
•RS 485 Modbus communication
•The solar pump can be operate through AC/ DC.
•Selector Switch of ON/OFF.
•Natural convection cooling.
Warning
This manual is for qualified person. The various
tasks described in this manual must be
performed by qualified person only.

6
English (GB)
4Technical data
4.1 Product range
4.1.1 Dimension
Fig. 3 Dimension for GI SPC 03 65 10
Unit : mm
Model
H1
(mm)
W1
(mm)
D
(mm)
H2
(mm)
W2
(mm)
Installation
hole
GI SPC 03 65 10
280
300
137
131
195
8
Fig. 4 Dimension for GI SPC 03 65 10 & GI SPC 7.5 65 10
Unit : mm
Model
H1
(mm)
W1
(mm)
D
(mm)
H2
(mm)
W2
(mm)
Installation
hole
Model
GI SPC 05 65 10
454
360
154.5
184
260
45
8
GI SPC 7.5 65 10
454
360
154.5
184
260
45
8

7
English (GB)
4.2 Technical data
Category
Parameter
3 x 230 V
3 x 380 V
Electrical Data
DC Input
Min. MPPT Voltage
[VDC]
100
220
Max. MPPT Voltage
[VDC]
400
750
Max. Input Voltage
[VDC]
450
800
AC Input
Input Voltage
[AC]
220-240
380-415
Input Frequency
[Hz]
50
50
Output
Output, Phase
3
3
Output, Rated Voltage
[VAC]
220
380
Output Frequency
[Hz]
0-400
0-400
Installation Environment
Min. Ambient Temperature
[°C]
-25
-25
Max. Ambient Temperature
[°C]
60
60
Max. Relative Humidity
[%]
95
95
Communication
RS 485
Enclosure class
IP65
4.2.1 Low Voltage Range (3 x 230 V)
Power
[KW]
Power
[HP]
Product Model
Electrical Data
Weight
[Kg]
Max.P2
[KW]
Rated
Input DC
Current
[A]
Rated
Input AC
Current
[A]
Rated
Output
Current
[A]
2.2
3
GI SPC 03 65 10
2.2
12
24
10
7
4.2.2 High Voltage Range (3 x 380 V)
Power
[KW]
Power
[HP]
Product Model
Electrical Data
Weight
[Kg]
Max.P2
[KW]
Rated
Input DC
Current
[A]
Rated
Input AC
Current
[A]
Rated
Output
Current
[A]
3.7
5
GI SPC 05 65 10
3.7
20
13.5
10
14.1
5.5
7.5
GI SPC 7.5 65 10
5.5
20
19.5
14
14.1
7.5
10
GI SPC 10 65 10
7.5
31
25
18
15

8
English (GB)
5Installation
Warning
Before starting the installation, ensure the following
points:
•Check the GI SPC carefully first for damage during
transportation, if any problem is found, please contact
Grundfos Pumps India Pvt Ltd or the transportation
company.
•All electrical connections must be in accordance with local
electrical installation criteria.
•Don’t touch other parts in the cabinet except the connecting
terminals in installation.
•Make sure that, the circuit breaker at DC side (PV Panels) is in
open state before carrying out electrical connection.
Make sure that the circuit breaker at DC side (PV Panels) is
open. At least 5 minutes later, use a multimeter to measure
the voltage at DC side before carrying out equipment
maintenance to ensure that the maintenance must be
conducted with no voltage at DC side
Ensure that the packing list consists of the
following.
Model
GI SPC
03 to 5 HP
GI SPC
7.5 to 10 HP
Pump Controller
1
1
Installation bracket
1
1
Operation manual
1
1
Expansion bolts
3 (M6 x 60)
4 (M6 x 60)
DC connector
1
2
Communication
connector
1
1
AC connector
1 (2)
1 (2)
Keypad
1
1
Network cable
1
1
5.1 Installation Example
Fig. 5 Installation example showing the required clearance
for mounting the product.
•The environment temperature is between -25°C and 60°C.
•The installation surface is perpendicular to the horizontal line.
Refer to the Fig 6.
Fig. 6 Installation example showing the required clearance for
mounting the product.
5.2 Cable Specification
Select AC and DC cables based on the following specification
requirements.
Model
DC
Side
AC
Input
Side
AC
Output
Side
Communication
mm²
mm²
mm²
mm²
GI SPC 03 65 10
GI SPC 05 65 10
4mm2
/12
AWG
4mm2
/12
AWG
2.5mm2
/14
AWG
0.52mm2 /
20 AWG
GI SPC 7.5 65 10
GI SPC 10 65 10
4mm2
/12
AWG
6mm2
/10
AWG
4mm2
/12
AWG
0.52mm2 /
20 AWG
Recommended crimp tools and insertion and removal tools
for cables
AC Input
Side
AC Output
Side
Communication
Cable
Tool
Cross screwdriver
Crimp tools: CT-P20/28
Insertion and removal
tools: RT-1.0
5.3 Mechanical Installation
It is recommended to install the solar pump
controller on the firm wall or metal bracket vertically. Take the
typical installation environment as the example given below.
Fig. 7 Installation bracket for GI SPC 03 65 10
Fig. 8 Installation bracket for GI SPC 05 65 10 , GI SPC 7.5 65 10
& GI SPC 10 65 10.

9
English (GB)
Sizes of installation brackets
Model
A (mm)
B (mm)
Installation bracket 1
195
-
Installation bracket 12
260
45
Installation steps of a PV pumping inverter:
•Take the installation bracket from the pump controller by only
removing the M5 screws.
•Then use expansion bolts to fix the installation bracket at the
proper location of a wall.
•Lift the inverter to suspend it on the installation bracket
through the M8 screws.
•Finally, fasten the M5 screws to fix the inverter on the bracket.
Warning
For firm installation, the operators cannot release the device
until the pump controller is installed on the bracket firmly.
Fig. 9 Pump Controller installation.
5.4 Electrical Installation
5.4.1 Control circuit wiring
The COM interfaces are the control circuit interfaces,
including one 485 communication channel and three digital
input channels. Figure 10 shows the wiring. For interface
definitions and specifications.
Fig. 10 Control circuit wiring diagram.
The Run/Stop button on the enclosure corresponds
to the S4 terminal,
5.4.2 Terminal arrangement
Fig. 11 GI SPC terminals
No.
Terminal name
Pin
definition
1
AC input
terminal
GI SPC 03 65 10
Model
1. L
2. N
3. PE
GI SPC 05 65 10
GI SPC 7.5 65 10
GI SPC 10 65 10
Model
1. R
2. Y
3. B
4.PE
2
PV input terminal-
-DC INPUT
3
PV input terminal+
+DC INPUT
4
External keypad terminal
RJ45
5
Function terminal
1. 485+
2. 485-
3. S2Note*
4. S3
5. COM
6. S4 Note*
7. COM
8. PE
6
AC output terminal
1. V
2. W
3. U
4. PE
7
GPRS connection terminal
1. + 24V
2. 485+
3. 485-
4. GND
8
DC switch
/
9
RUN/STOP button
/
Note*: Pin6 does not provide any functions and Pin3 is linked with Pin6
internally

10
English (GB)
5.4.3 Terminal arrangement Description of
function terminals
Terminal
Name
Description
PE
Grounding terminal
COM
+24V common terminal
S2
Digital input 2
•Internal impedance:
3.3kΩ
•Applicable to 12–30V
voltage input
•Supporting NPN wiring
•Max. input frequency: 1
kHz
•All are programmable
digital input terminal.
Users can set terminal
functions through
function codes.
•S1 is short circuited with
COM in the inverter by
default and it is not
connected externally.
S3
Digital input 3
(Used by the
RMC for
RUN/STOP
through SMS)
S4
Digital input 4
(Used by the
RUN/STOP
button)
485+
485 communication interface
If it is a standard 485 communication
interface, use twisted pairs or shielded cables.
485-
5.4.4 Electrical wiring
Fig. 12 Electrical wiring of the pump controller
Steps of electrical connection:
•If the distance between the solar inverter and the motor is
longer than 50 meters, it is recommended to install the output
choke to avoid the frequent overcurrent protection and the
motor isolation damage. For models of choke, consult
Grundfos.
•Connect the DC output, AC input, AC output and the
communication wire to the males, and then plug them to the
females of the inverter. Tighten up to ensure the proper
connection.
AC input and output connections
Follow the below steps for the connecting AC cable.
•Unscrew the terminal of all components.
Fig. 13 Connector disassembly
•Strip the cable insulation layer by about 10 mm.
•Route the cable through the connector as per fig. 14
Fig. 14 Connector disassembly
•Insert the bared wires ends as per the fig. 15
Fig. 15 Connection details
•Tighten the connection part on the left side of the connector.
Fig. 16 Connector assembly
DC input connections
Warning
Before starting the installation, ensure the following points:
•The circuit breaker between the solar panel combiner box and
solar pump controller (GI SPC) is in OFF position.
•The solar pump controller (GI SPC) is in OFF position.
Make sure that the DC input voltage from the solar
PV array to the solar pump controller does not exceed 750 VDC.
Check the solar PV array's positive and negative
terminal in multimeter, make sure that the polarity is correct as
shown in the fig. 17.
Fig. 17 Multimeter –Polarity checking

11
English (GB)
Follow the below steps for the connecting DC cable
•Unscrew the fastening nuts from the connector.
Fig. 18 Connector disassembly
•Strip off the insulation from the DC cable, the length of
stripped insulation is approximate 7mm.
Fig. 19 DC cable stripping
•Crimp the exposed core part to the connector tube core with
crimping pliers.
Fig. 20 DC cable crimping
Fig. 21 Crimped DC cable
•Plug cable with tube core part through the fastening nut.
Fig. 22 DC cable assembly
•Plug the tube core into the wiring trough until a sound
indicating inserted in place is heard. Tighten the nut in a
opposite direction.
Fig. 23 Connector assembly
Communication cable connections
Follow the below steps for the connecting communication cable.
•Plug the cable into the pin and the stripping length is 5.5 mm.
Fig. 24 Connector disassembly
•Select the corresponding position and note the position of the
jaw and thimble
Fig. 25 Cable crimping
•Crimp the thimble as shown in the fig. 26.
Fig. 26 Crimped cable
•Push the thimble directly in to the connector with the help of
the tools as shown in the fig. 27
Fig. 27 Inserting the crimped cable in the connector
To remove the crimped cable thimbles from the
connector, press the notch with the thumb and pull out.
Fig. 28 Removing the Inserted crimped cable from the
connector.

12
English (GB)
6Keypad Operation Procedure
6.1 Keypad introduction
The keypad is used to control the solar pump
controller to read data and adjust parameters.
Fig. 29 External Keypad
SI,No
Name
Description
1
Status
indication
RUN/TUNE
Running status indication.
LED OFF - The pump controller is in the stopping state.
LED Blinking - The pump controller is in the parameter autotuning state.
LED ON - The pump controller is in the running state.
FWD/REV
FED/REV indication.
LED OFF –The pump controller is in the forward rotation state.
LED ON - The pump controller is in the reverse rotation state
LOCAL/REMOT
LED for keypad operation, terminals operation and remote communication control.
LED OFF - The pump controller is in the keypad operation state.
LED Blinking - The pump controller is in the terminal’s operation state.
LED ON - The pump controller is in the remote communication control state.
TRIP
Fault indication.
LED ON –The pump controller is in the fault state.
LED OFF –The pump controller is in the normal state.
LED Blinking - The pump controller is in the overload pre-alarm state.
2
Unit
indication
Indicating the unit of the displayed digits
Hz
Unit of frequency
A
Unit of current
V
Unit of voltage
RPM
Unit of rotating speed
%
Percentage
3
Code display
zone
5-digit LED display, displaying various monitoring data and alarm code such as set frequency and output
frequency.
Displayed
character
Corresponding
character
Displayed
character
Corresponding
character
Displayed
character
Corresponding
character
0
1
2
3
4
5
6
7
8
9
A
b
C
d
E
F
H
l
L
N
n
O
P
r
S
t
U
v
.
-

13
English (GB)
4
Analog
potenti
ometer
Corresponds to AI1.
5
Buttons
Programming key
Enter or escape from the first level menu and remove the
parameter quickly
Entry key
Enter the menu step-by-step Confirm parameters
UP key
Increase data or function code progressively
DOWN
key
Decrease data or function code progressively
Right-shift key
Move right to select the displaying parameter circularly in
stopping and running mode.
Select the parameter modifying digit during the parameter
modification
Run key
This key is used to run the inverter in key operation mode
Stop/ Reset key
This key is used to stop the inverter when it is in running state
and it is limited by function code P07.04.
And it is used to reset all control modes in the fault alarm state
Quick key
The function of this key is determined by function code P07.02.
6.2 Keypad display
The display status of GI SPC series solar pump controller
keypads includes stop state parameter display, running state
parameter display, function code parameter display, fault
and alarm state display.
6.2.1 Stop state parameter display
When the pump controller is in the stop state, the keypad
displays stop state parameters. The stop state parameters
displayed by default parameter such as the set frequency,
bus voltage, input and output state. Press >>/SHIFT to shift
the display of the selected parameter from left to right.
6.2.2 Running state parameter display
After receiving a valid running command, the pump
controller enters the running state and the keypad displays
the running state parameters. The RUN/TUNE indicator on
the keypad is on, while the state of FWD/REV is determined
by the current running direction.
In the running state, the parameters displayed by default
include the running frequency, set frequency, bus voltage,
output voltage, output current, and pump rotating speed.
Press >>/SHIFT to shift the display of the selected parameters
form left to right and press QUICK/JOG (P07.02=2) to shift
from right to left.
6.2.3 Fault state display
If the pump controller detects a fault signal, it enters the
fault pre-alarm display state. The keypad displays the fault
code and the TRIP indication on the keypad is on. When a
fault occurs, the pump controller attempts to perform auto
reset for five times by default. If the fault persists, the fault
code remains displayed. The user can reset the pump
controller through the key, control terminal, or
communication command.
6.2.4 Function code editing state display
In the state of stopping, running or fault, press
to enter the editing state (if there is a password, see P07.00).
The editing state is displayed on two levels of menu and the
order is: function code group/function code
number→function code parameter.
Press DATA/ENT to enter the function parameter display
state. In this state, press to save the parameter settings or
press PRG/ESC to exit.
Fig. 30 Display - Stop state

14
English (GB)
Fig. 31 Display –Running state
Fig. 32 Display –Fault state
6.3 Keypad operation
Operate the pump controller via operation panel. For the
detailed structure description of function codes,
see section 7.
6.3.1 Function code modification.
The PV pumping inverter has three levels of menus, which
are:
• Group number of function code (first-level menu)
• Tab of function code (second-level menu)
• Set value of function code (third-level menu)
Press both the PRG/ESC and the DATA/ENT can return to the
second-level menu from the third-level menu. The difference is that
pressing PRG/ESC will save the parameter settings into the control
panel and then return to the second-level menu and shift to the
next function code automatically, while pressing PRG/ESC will
directly return to the second-level menu without saving the
parameter settings and keep staying at the current function code.
Under the third-level menu, if the parameter is not blinking, it
means the function code cannot be modify. The possible reasons
could be:
• This function code is not modifiable parameter, such as actual
detected parameter, operation records and so on.
• This function code is not modifiable in running state but
modifiable in stop state.
Example: Set function code P00.01 from 0 to 1.
Fig. 33 Parameter modification
Press and to modify the value.
6.3.2 Password Setting
GI SPC series pump controller provide password protection
function to users.
Set P7.00 for the password protection. Press PRG/ESC for the
function code editing state, "0.0.0.0.0" will be displayed. Set the
required password.
Set P7.00 to 0 to cancel password protection function.
Fig. 34 Password Setting.
Press and to modify the value.
6.3.3 Monitoring Pump controller state
GI SPC series pump controller provide group P17 as the
monitoring group. Users can enter into P17 directly to view the
value.
Fig. 35 Parameter Monitoring
Press and to modify the value.

15
English (GB)
7Parameters
The instruction of the function code is listed below in the table.
" ○": The set value of the parameter can be modified on stop and running state.
" ": The set value of the parameter cannot be modified on the running state.
" ●": The value of the parameter is the real value which cannot be modified.
Function
code
Name
Detailed description
Default
Modify
P00 Group: Basic function group
P00.00
Speed control
mode
0: SVC 0
Suitable for the applications which need low frequency, big torque for high
accuracy of rotating speed and torque control.
1: SVC 1
Suitable for the applications which need small power and high performance cases
with the advantage of high accuracy of rotating speed and torque. It does not need
to install pulse encoder.
2: SVPWM control
Suitable for the applications which do not need high control accuracy, such as the
load of fan and pump.
1
P00.01
Run command
channel
The control command of the inverter includes: start, stop, forward/reverse rotating,
jogging and fault reset.
0: "LOCAL/REMOTE"
Carry out the command control by RUN, STOP/RST on the keypad.
Set the multi-function key QUICK/JOG to FWD/REVC shifting function (P07.02=3) to
change the running direction, press RUN and STOP/RST simultaneously in running
state to make the pump controller to stop.
1: “LOCAL/REMOTE"
Carry out the running command control by the forward rotation, reverse rotation
and forward jogging and reverse jogging.
2: “LOCAL/REMOTE"
The running command is controlled by the upper monitor via communication
1
○
P00.03
Max. output
frequency
This parameter is used to set the maximum output frequency of the pump
controller.
Setting range: P00.04–400.00Hz
Note : It is the foundation of the frequency setting and the speed of acceleration and
deceleration.
140.00Hz
P00.04
Upper limit of
the running
frequency
This parameter is used to set the upper limit running frequency of the pump
controller, which is lower than or equal to the maximum frequency.
Setting range: P00.05–P00.03 (Max. output frequency)
140.00Hz
P00.05
Lower limit of
the running
frequency
This parameter is used to set the lower limit running frequency of the pump
controller.The inverter runs at the lower limit frequency if the set frequency is
lower than the lower limit.
Note: Max. output frequency ≥ Upper limit frequency ≥ Lower limit frequency
Setting range: 0.00Hz–P00.04 (Upper limit of the running frequency)
0.00Hz

16
English (GB)
P00.11
ACC time 1
ACC time - The time needed if the pump controller speeds up from 0Hz to the Max.
output frequency (P00.03).
DEC time - The time needed if the pump controller speeds down from the Max.
Output frequency to 0Hz (P00.03).
GI SPC series pump controller have four groups of ACC/DEC time which can be
selected by P05. The factory default ACC/DEC time of the inverter is the first group.
Setting range of P00.11 and P00.12:0.0–3600.0s
5.0s
○
P00.12
DEC time 1
5.0s
○
P00.13
Running
direction
selection
0: Runs at the default direction, the pump controller runs in the forward direction.
FWD/REV indicator is off.
1: Runs at the opposite direction, the pump controller runs in the reverse direction.
FWD/REV indicator is on.
Note : Modify the function code to shift the rotation direction of the motor. This effect
equals to the shifting the rotation direction by adjusting either two of the motor lines
(U, V and W). The motor rotation direction can be changed by QUICK/JOG on the
keypad. Refer to parameter P07.02.
2: Forbid to run in reverse direction, It can be used in some special cases if the reverse
running is disabled.
0
○
P00.18
Function
restore
parameter
0: No operation
1: Restore the default value
2: Clear fault records
Note :
• The function code will restore to 0 after finishing the operation of the selected
function code.
• Restoring to the default value will cancel the user password, please use this function
with caution.
0
P01 Group: Start Up and Stop Control
P01.08
Stop mode
0: Decelerate to stop
The pump controller decelerates to reduce the output frequency during the set
time. When the frequency decreases to 0Hz, the pump controller stops.
1: Coast to stop:
The pump ceases the output immediately and the load coasts to stop at the
mechanical inertia.
0
○
P01.18
Operation
protection
0: Command is invalid when powering on.
1: Command is valid when powering on.
1
○
P01.21
Restart after
power off
0: Disabled
1: Enabled
1
○
P02 Group: Motor 1
P02.00
Motor type
0: 3PHmotor
1: 1PHmotor
Depend
on
model
P02.01
Rated power
of asynchro-
nous motor
0.1–3000.0kW
Set the parameter of the asynchronous motor.
In order to ensure the controlling performance, set the
P02.01–P02.05 according to the name plate of the
asynchronous motor.
Pump controller provide the function of parameter
autotuning.
Depend
on
model
P02.02
Rated
frequency of
asynchronous
motor
0.01Hz–P00.03
50.00Hz
P02.03
Rated speed
of
asynchronous
motor
1–36000rpm
Depend
on
model

17
English (GB)
P02.04
Rated voltage
of
asynchronous
motor
0–1200V
Note: When resetting the rated power of the motor
(P02.01), initialize the motor parameter of P02.02–P02.10.
Depend
on
model
P02.05
Rated current
of
asynchronous
motor
0.8–6000.0A
Depend
on
model
P04 Group: SVPWM Control
P04.00
V/F Curve
Setting
These function codes define the V/F curve of motor to meet the need of different
loads.
0: Straight line V/F curve, applying to the constant torque load
1: Multi-dots V/F curve
2: 1.3th power torque-stepdown V/F curve
3: 1.7th power torque-stepdown V/F curve
4: 2.0th power torque-stepdown V/F curve
Curves 2–4 apply to the torque loads such as fans and water pumps. Users can
adjust according to the features of the loads to get the best performance.
5: Customized V/F (V/F separation) in this mode, V can be separated from f and f
can be adjusted through the frequency given channel set by P00.06 or the voltage
given channel set by P04.27 to change the feature of the curve.
Note: Vb in the below picture is the motor rated voltage and fb is the motor rated
frequency.
4
P04.01
Torque boost
• Torque boost is for the output voltage for the features of low frequency torque.
P04.01 is for the Max. output voltage Vb.
• P04.02 defines the percentage of closing frequency of manual torque to fb.
• Torque boost should be selected according to the load. The bigger the load is, the
bigger the torque is. Too big torque boost is inappropriate because the motor will
run with over magnetic and the current of the pump controller will increase to add
the temperature of the pump controller and decrease the efficiency.
• When the torque boost is set to 0.0%, the pump controller is automatic torque
boost.
• Torque boost threshold: below this frequency point, the torque boost is valid, but
over this frequency point, the torque boost is invalid.
Setting range of P04.01: 0.0%:(automatic) 0.1%–10.0%
Setting range of P04.02: 0.0%–50.0%
0.0%
○
P04.02
Torque boost
close
20.0%
○

18
English (GB)
P04.03
V/F frequency
point 1
If P04.00 =1, the user can set V//F curve by P04.03–P04.08 V/F is set to the motor
load.
Note: V1＜V2＜V3, f1＜f2＜f3. If the low-frequency voltage is high,
overtemperature and burning may occur and the overcurrent stall and protection
may occur to the solar pump controller.
Setting range of P04.03: 0.00Hz–P04.05
Setting range of P04.04: 0.0%–110.0% (rated voltage of motor1)
Setting range of P04.05: P04.03–P04.07
Setting range of P04.06: 0.0%–110.0% (rated voltage of motor1)
Setting range of P04.07: P04.05–P02.02(rated frequency of motor1) or P04.05–
P02.16(rated frequency of motor1)
Setting range of P04.08: 0.0%–110.0% (rated voltage of motor1)
0.00Hz
○
P04.04
V/F voltage
point 1
00.0%
○
P04.05
V/F
frequency
point 2
00.00Hz
○
P04.06
V/F voltage
point 2
00.0%
○
P04.07
V/F
frequency
point 3
00.00Hz
○
P04.08
V/F voltage
point 3
00.0%
○
P04.09
V/F slip
compensation
gain
This function code is used to compensate the change of the rotation speed caused
by load during compensation SVPWM control to improve the rigidity of the motor.
It can be set to the rated slip frequency of the motor which is counted as below:
△f=fb-n*p/60 Of which, fb is the rated frequency of the motor, its function code is
P02.02; n is the rated rotating speed of the motor and its function code is P02.03; p
is the pole pair of the motor. 100.0% corresponds to the rated slip frequency △f.
Setting range: 0.0–200.0%
0.0%
○
P04.34
2PH control of
1PH motor
Ones: 2PH control mode
0: Disabled
1: Enabled
Tens: Voltage of the secondary winding (V phase) reverse
0: Not reversed
1: Reversed
The setting range: 0–0x11
0x00
P04.35
Voltage ratio
of V and U
0.00–2.00
1.00
○

19
English (GB)
P05 Group: Input terminals
P05.01
S1 terminals
function
selection
0: No function
1: Forward rotation operation
2: Reverse rotation operation
3: 3-wire control operation
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Cancel the frequency change setting
13: Shift between A setting and B setting
14: Shift between combination setting and A setting
15: Shift between combination setting and B setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi- stage speed terminal 4
20: Multi- stage speed pause
21: ACC/DEC time 1
22: ACC/DEC time 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Traverse Pause (stop at the current frequency)
27: Traverse reset (return to the center frequency)
28: Counter reset
29: Torque control prohibition
30: ACC/DEC prohibition
31: Counter trigger
32: Reserve
33: Cancel the frequency change setting temporarily
34: DC brake
35: Reserved
36: Shift the command to the keypad
37: Shift the command to the terminals
38: Shift the command to the communication
39: Pre-magnetized command
40: Clear the power
41: Keep the power
42: PV disabled
43: PV voltage reference
44: Switch between solar input and power frequency input
45: Full-water signal
46: Non-water signal
47–63: Reserved
1
P05.02
S2 terminals
function
selection
0
P05.03
S3 terminals
function
selection
0
P05.04
S4 terminals
function
selection
1
P05.09
HDI terminals
function
selection
0
P05.10
Polarity
selection of
the input
terminals
If the bit is 0, the input terminal is positive.
If the bit is 1, the input terminal is negative.
The setting range: 0x000–0x1FF
0X000

20
English (GB)
P06 Group: Output terminals
P06.03
Relay RO1
output
selection
0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: The inverter fault
6: Frequency degree test FDT1
7: Frequency degree test FDT2
8: Frequency arrival
9: Zero speed running
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-magnetizing
14: Overload pre-warning
15: Underload pre-warning
16: Completion of simple PLC stage
17: Completion of simple PLC cycle
18: Setting count value arrival
19: Defined count value arrival
20: External fault valid
21: Reserved
22: Running time arrival
23: MODBUS communication virtual terminals output
24–26: Reserved
27: Weak light
28: Switching to PV power frequency input (threshold-based)
29: Switching to PV power frequency input (S input-based)
30: Switching to power frequency (threshold- or S input-based)
Note: Function 30 is relay output combining the functions 29 and 28. When one of
the two conditions is met, the relay output frequency is high.
30
○
P06.04
Relay RO2
output
selection
5
○
P06.10
Switch-on
delay of RO1
0.000–50.000s
10.000s
○
P06.11
Switch-off
delay of RO1
0.000–50.000s
10.000s
○
P06.12
Switch-on
delay ofRO2
0.000–50.000s
0.000s
○
P06.13
Switch-off
delay of RO2
0.000–50.000s
0.000s
○
P07 Group: Human Machine Interface
P07.01
Function
parameter
copy
Used to set the parameter copying mode.
0: No operation
1: Upload function parameters from the pump controller to keypad
2: Download function parameters (including the motor parameters) from the
keypad to pump controller
3: Download function parameters (excluding motor parameters of the P02 group)
from the keypad to pump controller
4: Download function parameters (only motor parameters of the P02 group) from
the keypad to pump controller
Note:
After the parameter is set to 1, 2, 3 or 4, and the operation is executed, the parameter
is automatically restored to 0.
0
○
